Spare Parts Installation Instruction - UDI R/C U31W Navigator Operation Manual

To take photo and record video
1. Insert the TF card into the slot in accordance with Picture 18. Ensure that the
metal side of the card faces up as shown in picture 18.
Picture 18
2. The aerial photo will be saved on both your mobile phone and the TF card, while the
video will only be saved onto the TF card. Additionally, you can only download the
video to the mobile phone when the mobile phone is connected to the drone WiFi and
the TF card .
Tip: Click on the video icon to save a video when ending recording, or the video cannot be
saved.
3. Power off the drone at first when finished with the aerial photography. Take out the TF
card and insert it into a card reader. Connect the card reader with computer USB
port. After a while, view the aerial photography data from "my computer"-
"mobile disk".
Tip: Please try playing a video or photo after coping all aerial photography data to the computer to
ensure that the media software can support the AVI format.
Basic parameter for aerial camera: Video DPI 1280*720P;

Spare Parts Installation Instruction

Propeller Installation Diagram
1. To disassemble for a new propeller installation, insert the lever between propeller and
motor( picture 19) and press down on it. Once the propeller is dislodged, pull it up in the
vertical direction ( Picture 20/21).
Picture 19
Image Size 1280*720P.
Picture 20
22
Picture 21
