Battery installation:
Open the battery cover on the back side of the transmitter and put 4 alkaline
batteries (AA, not included) into the box in accordance with electrode instructions,
as picture 1,2 shown.
Picture 1
Notice:
Phone Installation Instruction:
1. Pull up the phone holder( Picture 3), firstly open the lower clamp, then pull the
upper holder until can hold the phone(Picture 4).
2. Put the phone into the holder, then release the clamp, the clamp will hold the
phone tightly( Picture 5/6).
Picture 3
4*1.5V
Alkaline Batteries
Battery Cover
1. Make sure the electrodes are correct.
2. Do not mix new and old batteries.
3. Do not mix different kinds of batteries.
4. Do not charge the non rechargeable battery.
Picture 4
9
www.udirc.com
Picture 2
Picture 5
Picture 6
