  • Page 1 OPERATIONS & MAINTENANCE M A N U A L B A N D S A W T E C H N O L O G Y...
  • Page 2 With these points clearly in mind we have designed the HYD-MECH M-16 / M-20. Our goal is to change stock cutoff from a "necessary evil" to a money making and time saving part of your operation.
  • Page 3 THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 4 TABLE OF CONTENTS SECTION 1 - INSTALLATION Safety Precaution ....................1.1 Lifting Instruction ....................1.2 Foundation, Levelling and Anchoring ............... 1.3 Wiring Connections ....................1.4 Cutting Fluid and Hydraulic Oil ................1.5 SECTION 2A - Control Console Start-Up ........................2.1 Manual Operation ....................
  • Page 5 Digital Angle Display ................7.6 Variable Vise Pressure ..................7.6 Out of Stock Switch ..................7.6 SECTION 8 - SPECIFICATIONS M-16 Specification List ....................8.1 Layout drawing M-16A ..................M-20 Specification List ....................Layout drawing M-20A ..................SECTION 9 - WARRANTY Warranty ........................
  • Page 6 SECTION 1 INSTALLATION...

  • Page 8: Safety Precaution

    TION TION Upon delivery of your new M-16/20 bandsaw, it is imperative that a thorough inspection be undertaken to check for any damage that could have been sustained during shipping. Special attention should be paid to the electrical and hydraulic systems to check for damaged cords, hoses and fluid leaks. In the event of damage caused during shipping, contact your carrier to file a damage claim.

  • Page 9: Lifting Instruction

    M-16 AND M-20 LIFTING INSTR M-16 AND M-20 LIFTING INSTR M-16 AND M-20 LIFTING INSTRUCTION UCTION UCTION UCTION M-16 AND M-20 LIFTING INSTR M-16 AND M-20 LIFTING INSTR UCTION T T T T T his mac his mac his machine is designed to be lifted in one...
  • Page 10 FOUND FOUNDA A A A A TION FOUND TION TION TION, LEVELLING AND ANCHORING , LEVELLING AND ANCHORING , LEVELLING AND ANCHORING , LEVELLING AND ANCHORING FOUND FOUND TION , LEVELLING AND ANCHORING Machine location should be carefully selected. A flat concrete floor area should be chosen. It should have enough free space surrounding the machine to enable free access for safe operation and maintenance.

  • Page 11: Wiring Connections

    WIRING CONNECTIONS WIRING CONNECTIONS WIRING CONNECTIONS WIRING CONNECTIONS WIRING CONNECTIONS After the machine is levelled and anchored the necessary power hook-up needs to be performed. In order to provide a safe operation as well as to prevent potential damage to the machine, only qualified personnel should be allowed to do the work.
  • Page 12 CUTTING FL CUTTING FL CUTTING FL CUTTING FL CUTTING FLUID The M16/20 uses a pump and reservoir to circulate the necessary cutting fluid to the blade for maximum blade life. Your saw blade supplier will be able to provide information on the cutting fluid products that are available for your needs.
  • Page 13 THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 14 SECTION 2 OPERATING INSTRUCTIONS...
  • Page 16 We can not overstress the importance of familiarizing yourself with the controls of the M-16 or M-20 prior to starting the machine.
  • Page 17 OPERATOR PANEL SWITCHES TOP ROW FRONT VISE - FRONT VISE - FRONT VISE - FRONT VISE - FRONT VISE - This switch has three positions, CLOSE, OPEN, and HOLD. In CLOSE, the vise will close all the way, or until it encounters enough resistance to stop it.
  • Page 18 OPERATOR PANEL SWITCHES CENTER ROW COOL COOL COOLANT - COOL COOL ANT - ANT - ANT - ANT - This switch has three positions, WASH, OFF, and ON. In the WASH position, the coolant system will operate when there is power to the machine, this allows using the wash gun to clean the machine.
  • Page 19 OPERATOR PANEL SWITCHES BOTTOM ROW (continued) HEAD SWING 30 - HEAD SWING 30 - HEAD SWING 30 - HEAD SWING 30 - HEAD SWING 30 - This is a two position push button. By pressing the button in partially, the head will SLOWLY swing towards the 30 degree position until it reaches 30 degrees or the button is released.

  • Page 20: Operation Overview

    MITSUBISHI BASED PLC CONTROL SYSTEM NOTE: This instruction manual is applicable to the M16A, M20A, H18A to H32A machines equipped with a Mitsubishi PLC, c/w feed rate display, manufactured after and including the following serial numbers: Machine Model Serial # M-16A S0298036 M-20A...

  • Page 21: Start-Up

    PLC CONTROL DESCRIPTION ACTIVATING THE PLC Position the head, fixed vise, and shuttle vise switches to the NEUTRAL (center) positions. If any of these switches are not in the NEUTRAL position, the hydraulics will not start. The PLC control will become active when the HYDRAULIC START button is depressed and "held in"...
  • Page 22 FUNCTION B FUNCTION BUTT FUNCTION B UTTON DESCRIPTION ON DESCRIPTION ON DESCRIPTION ON DESCRIPTION FUNCTION B FUNCTION B ON DESCRIPTION If a red indicator light above a function button is illuminated, it means that the function printed in red at the top of the button is enabled.

  • Page 23: Function Button Description

    SINGLE P SINGLE PAR SINGLE P ART CY T CY T CY T CYCLE OPERA CLE OPERA CLE OPERA CLE OPERATION TION TION TION SINGLE P SINGLE P T CY CLE OPERA TION In MAN mode, the PLC allows the operator to initiate a "Single Part Cycle " to cut one piece at a desired length. To accomplish this, follow the procedure below.
  • Page 24 NOTE: Whenever a new job or new material is being loaded for production, the head height should be properly set to clear the material, material positioned for a trim cut and the front vise closed (in "MANUAL MODE"). Before entering AUTO mode, the head should be "HOMED".

  • Page 25: Automatic Operation

    NOTE: The "CT" value is the accumulated total number of parts that have been cut from the JOB number since it was last reset. The machine will only cut the quantity which is the difference between REQUIRED QUANTITY and CUT QUANTITY.

  • Page 26: Kerf Correction

    To fill the QUEUE, follow these two steps. 1) Key in a job number and press ENTER. If that job number has previously been programmed, it's values will be displayed. The cursor will move to the next position in the QUEUE. Up to five jobs may be in the QUEUE at any time.

  • Page 27: Hydraulic Feed Control

    Variable pitch, bi-metal blades (like the 4/6 or 3/4 bi-metal blade supplied with the M-16/20) last much longer, cut faster, and more accurately than conven- tional carbon steel blades. In order to take advantage of the superiority of bi-metal blades, it is critical to properly “break-in”...
  • Page 28 HYDRA HYDRA HYDRAULIC FEED CONTROL ULIC FEED CONTROL ULIC FEED CONTROL ULIC FEED CONTROL HYDRA HYDRA ULIC FEED CONTROL The Hydraulic Feed Control is located adjacent to the drive wheel box. These controls allow independent control of Feed Force and Feed Rate. Feed Force Knob Used to set Feed Force Limit (counterclockwise rotation to increase and clockwise rotation to...

  • Page 29: Step 1 Determine Effective Material Width

    CUTTING P CUTTING P CUTTING PARAMETERS DOOR CHAR ARAMETERS DOOR CHAR ARAMETERS DOOR CHAR ARAMETERS DOOR CHART T T T T CUTTING P CUTTING P ARAMETERS DOOR CHAR A full size DOOR CHART is mounted on the drive door of the saw. The chart contains five steps for the operator to follow in order to achieve optimum performance of the saw.

  • Page 30: Step 2 Set Feed Force Limit

    STEP 2 STEP 2 STEP 2 STEP 2 STEP 2 SET FEED FORCE LIMIT The Feed Force Limit is the maximum amount of force with which the head is allowed to push the blade into the work-piece. FEED FORCE LIMIT should be set with the head in the down mode, according to the label. CUTTING SOLIDS For cutting solids, the wider the section, the less FF should be set, to avoid blade overloading.
  • Page 31 STEP 3 STEP 3 STEP 3 STEP 3 STEP 3 DETERMINE OPTIMUM BLADE PITCH - TEETH PER INCH (T.P.I.) Selecting a blade with proper tooth pitch is important in order to achieve optimal cutting rates and good blade life. For cutting narrow or thin wall structural materials a fine blade with many teeth per inch (T.P.I.) is recommended.

  • Page 32: Step 4 Determine Optimum Blade Speed

    STEP 4 STEP 4 STEP 4 STEP 4 STEP 4 DETERMINE OPTIMUM BLADE SPEED, V V V V V (ft/min) (m/min) The relationship between optimum blade speed and effective material width for various materials is represented on the graph shown. Optimum Blade Speed Curves The graph shows that as effective material width gets wider or as material gets harder, lower blade speeds are recommended.

  • Page 33: Step 5 Determine Feed Rate Setting

    The following table gives examples of the optimum blade speeds for different materials. NO..MATERIAL TERIAL TERIALS S S S S TERIAL OPTIMUM BL OPTIMUM BL OPTIMUM BLADE SPEED ADE SPEED ADE SPEED ADE SPEED TERIAL OPTIMUM BL OPTIMUM BL ADE SPEED...
  • Page 34 Feed Rate, CONTINUED If the saw is fitted with a blade coarser than optimum (e.g.. 1.4/2.5 TPI) we can still use the graph, but we go to the 1.4/2.5 curve. As a result we find that the FEED RATE is decreased to 1.3 in/min (133mm/min) for this blade.
  • Page 35 ADDITION ADDITION ADDITIONAL CUTTING SETUP EXAMPLES ADDITION ADDITION AL CUTTING SETUP EXAMPLES AL CUTTING SETUP EXAMPLES AL CUTTING SETUP EXAMPLES AL CUTTING SETUP EXAMPLES, , , , , CONTINUED CONTINUED CONTINUED CONTINUED CONTINUED EXAMPLE # 3 Material Bundle -Low carbon steel 2" x 2" Tube with 1/4" wall, 12 piece bundle (50mm x 50mm with 6mm wall) Dimensions - 6"...

  • Page 36: Coolant Flow

    SECTION 2C SECTION 2C SECTION 2C, , , , , SECTION 2C SECTION 2C MECHANICAL CONTROL MECHANICAL CONTROLS S S S S MECHANICAL CONTROL MECHANICAL CONTROL MECHANICAL CONTROL COOL COOL ANT FL ANT FLO O O O O W W W W W ANT FL COOL COOLANT FL...
  • Page 37 THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 38 SECTION 3 MAINTENANCE AND TROUBLE SHOOTING...
  • Page 40 SECTION 3, SECTION 3, SECTION 3, SECTION 3, SECTION 3, MAINTEN MAINTEN MAINTENANCE AND TROUBLE SHOO MAINTEN MAINTEN ANCE AND TROUBLE SHOO ANCE AND TROUBLE SHOO ANCE AND TROUBLE SHOO ANCE AND TROUBLE SHOOTING TING TING TING TING L L L L L OCK -OUT OCK -OUT OCK -OUT OCK -OUT...

  • Page 41: Blade Changing

    BLADE CHANGING ADE CHANGING ADE CHANGING ADE CHANGING ADE CHANGING...

  • Page 42: Blade Brush

    BLADE BR ADE BR ADE BR ADE BRUSH ADJUSTMENT USH ADJUSTMENT USH ADJUSTMENT USH ADJUSTMENT ADE BR USH ADJUSTMENT BLADE GUIDES ADJUSTMENT ADE GUIDES ADJUSTMENT ADE GUIDES ADJUSTMENT ADE GUIDES ADJUSTMENT ADE GUIDES ADJUSTMENT...
  • Page 43 L L L L L UBRICA UBRICA UBRICA TION TION UBRICA UBRICATION TION TION...

  • Page 44: Cleanliness

    HYDRA HYDRA ULIC MAINTEN ULIC MAINTEN ANCE ANCE HYDRA HYDRA HYDRAULIC MAINTEN ULIC MAINTEN ULIC MAINTENANCE ANCE ANCE CLEANLINESS CLEANLINESS CLEANLINESS CLEANLINESS CLEANLINESS...

  • Page 45: Trouble Shooting

    TROUBLE SHOO TROUBLE SHOOTING TROUBLE SHOO TING TING TING TROUBLE SHOO TROUBLE SHOO TING...
  • Page 47 In Manual Mode In Manual Mode In Manual Mode In Manual Mode In Manual Mode nents. In Automatic Mode In Automatic Mode In Automatic Mode In Automatic Mode In Automatic Mode...
  • Page 48 PROGRAMMABLE L PROGRAMMABLE LOGIC CONTROL, PROGRAMMABLE L OGIC CONTROL, OGIC CONTROL, OGIC CONTROL, PROGRAMMABLE L PROGRAMMABLE L OGIC CONTROL, MITSUBISHI 100 MITSUBISHI 100 MITSUBISHI 100 MITSUBISHI 100 MITSUBISHI 100 NOTE:...
  • Page 49 PLC 100 P C 100 P C 100 P C 100 P C 100 PARAMETERS ARAMETERS ARAMETERS ARAMETERS ARAMETERS TE: P TE: P ar ar ar arameter ameter ameter s with * ar s with * ar e not r e not r equir equir...
  • Page 50 C 100 TROUBLESHOO C 100 TROUBLESHOO TING TING PLC 100 TROUBLESHOO C 100 TROUBLESHOO C 100 TROUBLESHOOTING TING TING , f , f , f , f , for automa or automa or automa or automa or automatic models with a shuttle tic models with a shuttle tic models with a shuttle tic models with a shuttle.
  • Page 51 , f , f , f , f , for automa or automa or automa tic models with a shuttle tic models with a shuttle tic models with a shuttle..or automa or automatic models with a shuttle tic models with a shuttle...
  • Page 53 , for P models or P models or P models or P models, disr , disr , disre e e e e g g g g g ar , disr ar ar ar ard all r d all r d all r d all ref ef ef ef efer er er er erences to a shuttle...
  • Page 56 MITSUBISHI 100 INPUTS & OUTPUTS MITSUBISHI 100 INPUTS & OUTPUTS MITSUBISHI 100 INPUTS & OUTPUTS MITSUBISHI 100 INPUTS & OUTPUTS MITSUBISHI 100 INPUTS & OUTPUTS MITSUBISHI 2 3 4 5 Power 10 11 12 13 14 15 16 Batt V Prog E -32MR 10 11...
  • Page 57 Input / Output T Input / Output T erminal Inf erminal Inf orma orma tion : tion : Input / Output T Input / Output T Input / Output Terminal Inf erminal Inf erminal Informa orma ormation : tion : tion : Inputs - X0 - Pop Down (H saw only)
  • Page 58 CALIBRA CALIBRA CALIBRATION PROCEDURE FOR MITSUBISHI CALIBRA CALIBRA TION PROCEDURE FOR MITSUBISHI TION PROCEDURE FOR MITSUBISHI TION PROCEDURE FOR MITSUBISHI TION PROCEDURE FOR MITSUBISHI C 100LE C 100LE PLC 100LE C 100LE C 100LE NOT APPLICABLE T T APPLICABLE T T APPLICABLE T T APPLICABLE T T APPLICABLE TO "P"...
  • Page 59 HEAD HEIGHT CALIBRA HEAD HEIGHT CALIBRA HEAD HEIGHT CALIBRA HEAD HEIGHT CALIBRA HEAD HEIGHT CALIBRATION TION TION TION TION...
  • Page 60 SERVICE RECORD & NO VICE RECORD & NO VICE RECORD & NO VICE RECORD & NOTES VICE RECORD & NO DATE SERVICED BY COMMENTS...
  • Page 61 THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 62 SECTION 4 ELECTRICAL SYSTEM...

  • Page 64: General Information

    The battery will need to be replaced every 3 to 5 years, depending on usage. A visual warning will be displayed on the interface when the battery drains to a certain level. Battaries can be purchased through your Hyd-Mech Distibutor. 2) 2) 2) 2) 2) If the machine is equiped with an inverter, do not turn disconnect on for 3 three minutes after disconnect has been shut off.
  • Page 65 ELECTRICAL COMPONENTS ELECTRICAL COMPONENTS ELECTRICAL COMPONENTS ELECTRICAL COMPONENTS ELECTRICAL COMPONENTS Head encoder Head encoder Head encoder Coolant pump. Coolant pump. Coolant pump. Out of Stock Limit Out of Stock Limit Out of Stock Limit Out of Stock Limit Out of Stock Limit Head encoder Head encoder Coolant pump.

  • Page 66: Electrical Components

    ELECTRICAL COMPONENTS ELECTRICAL COMPONENTS, , , , , ELECTRICAL COMPONENTS ELECTRICAL COMPONENTS ELECTRICAL COMPONENTS Contin Contin Continued Contin Contin Shuttle Encoder (located on the Shuttle Encoder (located on the Shuttle Encoder (located on the Shuttle Encoder (located on the Shuttle Encoder (located on the Proximity sensor (located Proximity sensor (located Proximity sensor (located...
  • Page 67 /,67 2) 0B0 (/(&75,&$/ &20321(176 ,WHP &RGH DV RQ &RPSRQHQW 'HVFULSWLRQ 3DUW 1XPEHU 0 6FKHPDWLF 0DQXIDFWXUHU 3% 5HG PXVKURRP KHDG VSULQJ UHWXUQ SXVK EXWWRQ =% %& 7HOHPHFDQLTXH (PHUJHQF\ 6WRS 3XVK %XWWRQ 0RXQWLQJ EDVH ZLWK  1& FRQWDFW EORFN =% %= 7HOHPHFDQLTXH 3%+\GUDXOLF 6WDUW *UHHQ LOOXPLQDWHG IOXVK KHDG SXVK EXWWRQ...
  • Page 68 ,WHP &RGH DV &RPSRQHQW 'HVFULSWLRQ 3DUW 1XPEHU 00 0DQXIDFWXUHU 6FKHPDWLF );105 0LWVXELVKL 3/& );105 0LWVXELVKL 07$  0LWVXELVKL ,QWHUIDFH 07$  0LWVXELVKL ,QWHUIDFH FRPPXQLFDWLRQ FDEOH 66/' 6HOHFWULF %ODGH PRWRU UHOD\ *56 2PURQ &5 SOXV PRXQWLQJ EDVH 35)( +HDG DGYDQFH UHOD\ *56 2PURQ &5...
  • Page 69 0 32:(5 &20321(176 IRU 63(&,),& 92/7$*(6 H 68CDI@ÃWPGU6B@ 9r†p…vƒ‡v‚ÃÃÉÃD‡r€Ã 8‚€ƒ‚r‡ÃÃÃà 8‚qrÃh†Ã‚Ã†pur€h‡vp Hhˆshp‡ˆ…r… "ƒuÃ!'Wà "ƒuÃ!#Wà "ƒuÃ"'W "ƒuÃ# $W "ƒuÃ#'W "ƒuÃ%W "CQÃC`9S6VGD8ÃQVH QÃH PUPSà H ÃA…h€rÃTv“rà '!U8à 'ÃSQH  Fy‚pxr…à 8PIU68UPSà H T@à ÃQFaP T@à ÃQFaP T@à ÃQFaP T@à ÃQFaP T@à ÃQFaP T@Ã...
  • Page 70 0 32:(5 &20321(176 IRU 63(&,),& 92/7$*(6 H68CDI@ÃWPGU6B@ 9r†p…vƒ‡v‚ÃÃÉÃD‡r€Ã 8‚€ƒ‚r‡ÃÃÃà 8‚qrÃh†Ã‚Ã†pur€h‡vp Hhˆshp‡ˆ…r… "ƒuÃ!'Wà "ƒuÃ!#Wà "ƒuÃ"'W "ƒuÃ# $W "ƒuÃ#'W "ƒuÃ%W "CQÃC`9S6VGD8ÃQVH QÃH PUPSà H ÃA…h€rÃTv“rà '!U8à 'ÃSQH  Fy‚pxr…à 8PIU68UPSà H T@à ÃQFaP T@à ÃQFaP T@à ÃQFaP T@à ÃQFaP T@à ÃQFaP T@à ÃQFaP H‚ryyr…ÃÃ...
  • Page 71 Pg 4.8 M1620...
  • Page 72 Pg 4.9 M1620...
  • Page 73 Pg 4.10 M1620...
  • Page 74 SECTION 5 HYDRAULIC SYSTEM...
  • Page 76 ULIC SY STEM , , , , , The M-16, M-20 hydraulic system does not require any special work on a new machine before its start up. The hydraulic tank is filled with Texaco Rando HD46 hydraulic oil and all machine functions have been tested at the factory to ensure proper operation upon initial start-up.
  • Page 77 M-20 HYDRA M-20 HYDRA M-20 HYDRAULIC COMPONENTS LIST ULIC COMPONENTS LIST ULIC COMPONENTS LIST ULIC COMPONENTS LIST M-20 HYDRA M-20 HYDRA ULIC COMPONENTS LIST Hydraulic Manifold, Pump/Motor Assembly. ,7(0 47< 3$57 180%(5 '(6&5,37,21 0&% +HDG &\OLQGHU 0&$ 6KXWWOH &\OLQGHU 6& %ODGH 7HQVLRQ &\OLQGHU 0& )URQW 9LVH &\OLQGHU...
  • Page 78 Pg 5.3...
  • Page 79 Pg 5.4...
  • Page 80 Pg 5.5...
  • Page 81 THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 82 SECTION 6 MECHANICAL ASSEMBLIES...
  • Page 84 SECTION 6, SECTION 6, SECTION 6, SECTION 6, SECTION 6, MECHANICAL ASSEMBLES MECHANICAL ASSEMBLES MECHANICAL ASSEMBLES MECHANICAL ASSEMBLES MECHANICAL ASSEMBLES ADE BR ADE BR USH ASSEMBL USH ASSEMBL USH ASSEMBLY Y Y Y Y BLADE BR ADE BR ADE BRUSH ASSEMBL USH ASSEMBL ,7(0 47<...
  • Page 85 GUIDE ARM & CARBIDE GUIDE ASSEMBLIES GUIDE ARM & CARBIDE GUIDE ASSEMBLIES GUIDE ARM & CARBIDE GUIDE ASSEMBLIES GUIDE ARM & CARBIDE GUIDE ASSEMBLIES F F F F F or M-16 only or M-16 only or M-16 only or M-16 only..
  • Page 86 GUIDE ARM & CARBIDE GUIDE ASSEMBLIES GUIDE ARM & CARBIDE GUIDE ASSEMBLIES, , , , , GUIDE ARM & CARBIDE GUIDE ASSEMBLIES GUIDE ARM & CARBIDE GUIDE ASSEMBLIES GUIDE ARM & CARBIDE GUIDE ASSEMBLIES P P P P P AR ARTS LISTS TS LISTS TS LISTS...
  • Page 87 ,7(0 47< 0 3$57 180%(5 0 '(6&5,37,21 0 ,'/(5 :+((/ 6+$)7 0  1) +(; +($' &$3 6&5(: %; +(; +($' &$3 6&5(: /2& /2&. :$6+(5 6;) 62&.(7 6(7 6&5(: )/$7 32,17 0 0 %/$'( 7(16,21 $50 0$ %/$'( 7(16,21 6+$)7 $66(0%/<  35(66 ,1 *5($6( ),77,1* 0...
  • Page 88 PIVO O O O O T LINK ASSEMBL T LINK ASSEMBL T LINK ASSEMBL T LINK ASSEMBLY Y Y Y Y T LINK ASSEMBL 47< 0 3$57 180%(5 '(6&5,37,21 ,7(0 0% 3,927 /,1. :(/'0(17 0 +'3 3/$67,& ',6& 0 ',6& 0 3,927 6+$)7 0%...
  • Page 89 ,7(0 47< 0  3$57 180%(5 '(6&5,37,21 0 32:(5 3$&. :(/'0(17 6$ 2,/ 7$1. /,' %[ +(; +($' &$3 6&5(: 6(66 ),//(5 &$3 %5($7+(5 PLFURQ 7[ 75866 +($' 0$&+,1( 6&5(: 7)63 68&7,21 675$,1(5 +3 3,3( 3/8* GUDLQ 61$% /(9(/ 7(03(5$785( *$8*( 03 ( GHJ (/%2: 0137)137 6$)...
  • Page 90 ,7(0 47< 0  3$57 180%(5 '(6&5,37,21 7&  +3 530 63(&,)< 92/7$*( / [   -$: 7<3( &283/,1* )/$1*( 1 -$: 7<3( ,16(57 / [  -$: 7<3( &283/,1* )/$1*(  +3 %(// +286,1* /2& /2&. :$6+(5 %[ +(;...
  • Page 91 FRONT VISE & CONVEY FRONT VISE & CONVEY OR ASSEMBL OR ASSEMBLY Y Y Y Y OR ASSEMBL FRONT VISE & CONVEY FRONT VISE & CONVEY FRONT VISE & CONVEYOR ASSEMBL OR ASSEMBL Pg 6. 8...
  • Page 92 FRONT VISE & CONVEY FRONT VISE & CONVEYOR, FRONT VISE & CONVEY FRONT VISE & CONVEY FRONT VISE & CONVEY P P P P PAR ARTS LIST TS LIST TS LIST TS LIST TS LIST ,7(0 47< 0  3$57 180%(5 '(6&5,37,21 0% 9,6(  &219(<25 :(/'0(17...

  • Page 93: Shuttle Vise Assembly

    SHUTTLE VISE ASSEMBL SHUTTLE VISE ASSEMBL SHUTTLE VISE ASSEMBLY Y Y Y Y SHUTTLE VISE ASSEMBL SHUTTLE VISE ASSEMBL ,7(0 47< 0  3$57 180%(5 '(6&5,37,21 0$ 6+877/( 9,6( )5$0( 0 9,6( -$: 6+$)7 +  6+$)7 :,3(5 [[ :($5 5,1*  675,3 0& 9,6( &</,1'(5 0$...
  • Page 94 SHUTTLE D SHUTTLE DA A A A A TUM J SHUTTLE D TUM J TUM J TUM JAW ASSEMBL AW ASSEMBL AW ASSEMBL AW ASSEMBLY Y Y Y Y SHUTTLE D SHUTTLE D TUM J AW ASSEMBL ,7(0 47< 0  3$57 180%(5 '(6&5,37,21 0...

  • Page 95: Length Control Assembly

    LENGTH CONTROL ASSEMBL LENGTH CONTROL ASSEMBL LENGTH CONTROL ASSEMBLY Y Y Y Y LENGTH CONTROL ASSEMBL LENGTH CONTROL ASSEMBL ,7(0 47< 0  3$57 180%(5 '(6&5,37,21 0$ /(1*7+ &21752/ 5$&. $[  62&.(7 +($' &$3 6&5(: +* 6385 *($5 0 (1&2'(5 +,1*  /8&$6 (1&2'(5...
  • Page 96 CHIP A CHIP AUGER ASSEMBL CHIP A UGER ASSEMBL UGER ASSEMBL UGER ASSEMBLY Y Y Y Y CHIP A CHIP A UGER ASSEMBL CHIP AUGER INSTALLED CHIP AUGER INSTALLED CHIP AUGER INSTALLED CHIP AUGER INSTALLED CHIP AUGER INSTALLED ,7(0 47< 0  3$57 180%(5 '(6&5,37,21...

  • Page 97: Coolant Group

    COOL COOL COOL COOL COOLANT GROUP ANT GROUP ANT GROUP ANT GROUP ANT GROUP T T T T T O IDLER GUIDE ARM O IDLER GUIDE ARM O IDLER GUIDE ARM O IDLER GUIDE ARM O IDLER GUIDE ARM 3103-B 2101-4-4 ELBOW 1/4"...

  • Page 98: Doors And Covers

    DOORS and CO DOORS and COVERS DOORS and CO VERS VERS VERS DOORS and CO DOORS and CO VERS Driv Drive Door Driv e Door e Door e Door Blade Co Blade Co Blade Cov v v v v er er er er er Idler Door...

  • Page 99: Drive Assembly

    DRIVE ASSEMBL DRIVE ASSEMBL DRIVE ASSEMBLY Y Y Y Y , , , , , DRIVE ASSEMBL DRIVE ASSEMBL PARTS LISTS ON FOLLOWING 2 PAGES. PARTS LISTS ON FOLLOWING 2 PAGES. PARTS LISTS ON FOLLOWING 2 PAGES. PARTS LISTS ON FOLLOWING 2 PAGES. PARTS LISTS ON FOLLOWING 2 PAGES.
  • Page 100 M16 DRIVE ASSEMBL M16 DRIVE ASSEMBLY Y Y Y Y , , , , , M16 DRIVE ASSEMBL M16 DRIVE ASSEMBL M16 DRIVE ASSEMBL P P P P P AR TS LISTS TS LISTS TS LISTS..ARTS LISTS TS LISTS ,7(0...
  • Page 101 M20 DRIVE ASSEMBL M20 DRIVE ASSEMBL M20 DRIVE ASSEMBLY Y Y Y Y , , , , , M20 DRIVE ASSEMBL M20 DRIVE ASSEMBL P P P P P AR ARTS LISTS TS LISTS TS LISTS TS LISTS..TS LISTS ,7(0 47<...
  • Page 102 Pg 6.19...
  • Page 103 Pg 6.20...
  • Page 104 SECTION 7 OPTIONAL ASSEMBLIES...

  • Page 106: Bundling Assembly

    SECTION 7, SECTION 7, SECTION 7, SECTION 7, SECTION 7, OPTIONS OPTIONS OPTIONS OPTIONS OPTIONS B B B B B UNDLING ASSEMBL UNDLING ASSEMBL UNDLING ASSEMBL UNDLING ASSEMBL UNDLING ASSEMBLY Y Y Y Y For customers who cut bundles, a bundling vise is available. For "P" model machines, only one bundling assembly is required for the single vise, an "A"...
  • Page 107 B B B B B UNDLING ASSEMBL UNDLING ASSEMBL UNDLING ASSEMBL UNDLING ASSEMBLY Y Y Y Y UNDLING ASSEMBL SHUTTLE VISE ONLY. MOUNTED INSIDE TOP OF SHUTTLE FRAME. FRONT VISE ONLY SHUTTLE VISE ONLY. DU@H H %ÃÉÃ!ÃQ6SUÃIVH7@S 9@T8SDQUDPI H !!" 6 7V I 9GDI B ÃTC 6AU ÃAS P I U ÃWDT@ 6 $‘...
  • Page 108 TICAL ROLLER ASSEMBL TICAL ROLLER ASSEMBL TICAL ROLLER ASSEMBLY Y Y Y Y VERTICAL ROLLER ASSEMBL TICAL ROLLER ASSEMBL ,7(0 47< 0  3$57 180%(5 '(6&5,37,21 0 02817,1* %5$&.(7 :(/'0(17 0 6+$)7 :(/'0(17 [ 52// 3,1 0 9(57,&$/ 78%( 6+3$   (;7(51$/ 5(7$,1,1* 5,1* 0 02817,1* %5$&.(7...
  • Page 109 M-16A DIRECT DRIVE ASSEMBL M-16A DIRECT DRIVE ASSEMBL M-16A DIRECT DRIVE ASSEMBLY Y Y Y Y M-16A DIRECT DRIVE ASSEMBL M-16A DIRECT DRIVE ASSEMBL ,7(0 47< 0 3$57 180%(5 '(6&5,37,21 7& VKDIW FXW WR  +3 530 63(&,)< 92/7$*( /[  /29( -2<...
  • Page 110 M-20A DIRECT DRIVE ASSEMBL M-20A DIRECT DRIVE ASSEMBLY Y Y Y Y M-20A DIRECT DRIVE ASSEMBL M-20A DIRECT DRIVE ASSEMBL M-20A DIRECT DRIVE ASSEMBL ,7(0 47< 0 3$57 180%(5 '(6&5,37,21 7& VKDIW FXW WR  +3 530 63(&,)< 92/7$*( -[  &283/,1* )/$1*( PRWRU &283/,1* 6/((9(...
  • Page 111 MITSUBISHI PL MITSUBISHI PL MITSUBISHI PLC 500 CONTROLER C 500 CONTROLER C 500 CONTROLER C 500 CONTROLER MITSUBISHI PL MITSUBISHI PL C 500 CONTROLER This option allows for automatic operation of the head angle, not available for "P" model machines. The PLC 500 operator interface.
  • Page 112 SECTION 8 SPECIFICATIONS...

  • Page 114: M-16 Specification List

    SECTION 8 SPECIFICA SPECIFICA TIONS TIONS SPECIFICA SPECIFICA SPECIFICATIONS TIONS TIONS , , , , , M-16 SPECIFICA M-16 SPECIFICA M-16 SPECIFICATION LIST M-16 SPECIFICA M-16 SPECIFICA TION LIST TION LIST TION LIST TION LIST DIMENSIONS DIMENSIONS DIMENSIONS DIMENSIONS DIMENSIONS IMPERIAL...
  • Page 115 Pg 8. 2...
  • Page 116 SPECIFICA SPECIFICATION M-20 SPECIFICA TION M-20 TION M-20 TION M-20 DIMENSIONS DIMENSIONS DIMENSIONS SPECIFICA SPECIFICA TION M-20 DIMENSIONS DIMENSIONS IMPERIAL METRIC Capacity round 20" dia 500mm dia rectangular 20" x 30" 500 x 750mm at 45 deg 20" round, 18x20" rec. 400mm round, 350x400mm rec.
  • Page 117 Pg 8. 4...
  • Page 118 Pg 8.5...
  • Page 119 Pg 8. 6...

  • Page 120: Warranty

    SECTION 9 WARRANTY...
  • Page 122 Hyd-Mech's sole obligation under this warranty is limited to the repair or replacement without charge, at Hyd-Mech's factory, warehouse, or approved repair shop,of any part or parts which Hyd-Mech's inspection shall disclose to be defective.
  • Page 123 MITSUBISHI PL MITSUBISHI PL MITSUBISHI PL MITSUBISHI PL MITSUBISHI PLC P C PARAMETERS ARAMETERS ARAMETERS ARAMETERS ARAMETERS (refer to "Calibration Procedures" in Sec 3, for proper usage of paramters) PLC 100 A A A A A CT HT CT HT CT HT CT HT CT HT...
  • Page 124 OPERATIONS & MAINTENANCE MANUAL OPERATIONS & MAINTENANCE MANUAL OPERATIONS & MAINTENANCE MANUAL OPERATIONS & MAINTENANCE MANUAL OPERATIONS & MAINTENANCE MANUAL OPERATIONS & MAINTENANCE MANUAL OPERATIONS & MAINTENANCE MANUAL OPERATIONS & MAINTENANCE MANUAL OPERATIONS & MAINTENANCE MANUAL OPERATIONS & MAINTENANCE MANUAL OPERATIONS &...
