OPERATIONS &
MAINTENANCE
M A N U A L
I N
B A N D S A W
T E C H N O L O G Y

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H-22A and is the answer not in the manual?

Questions and answers

Related Manuals for Hyd-Mech H-22A

Summary of Contents for Hyd-Mech H-22A

  • Page 1 OPERATIONS & MAINTENANCE M A N U A L B A N D S A W T E C H N O L O G Y...
  • Page 2 H-22A 2 0 0 1 , r e v b , 3 9 3 1 3 0 THANK YOU, On behalf of everyone at HYD . MECH, I would like to thank and congratulate you on your decision to purchase a HYD . MECH band saw.
  • Page 3 THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 4 H-22A Table of Contents SECTION 1, INSTALLATION ........................1 SAFETY PRECAUTIONS ..........................1 H-18 & H-22 LIFTING INSTRUCTIONS ......................2 FOUNDATION, LEVELLING AND ANCHORING ....................3 WIRING CONNECTIONS ..........................4 HYDRAULIC OIL AND CUTTING FLUID ......................4 SECTION 2A, CONTROL CONSOLE ....................1 START-UP ..............................
  • Page 5 PROGRAMMABLE LOGIC CONTROL, MITSUBISHI 100 ................8 PLC 100 PARAMETERS ..........................9 PLC 100 TROUBLESHOOTING ........................10 PLC IS NOT MEASURING LENGTHS ...................... 10 INACCURATE LENGTHS IN AUTO MODE....................11 INCONSISTENT INACCURACY ....................... 11 CONSISTENT INACCURACY ........................12 LINEAR INACCURACY ..........................12 AUTO CYCLE NOT BEING COMPLETED.
  • Page 6 SECTION 7, OPTIONS ..........................1 H-18 & H-22 BUNDLING ASSEMBLY ......................1 SECTION 8, SPECIFICATIONS ......................1 H-22 LAYOUT DRAWING ..........................2 SECTION 9, WARRANTY ........................1 WARRANTY ..............................1 MITSUBISHI PLC PARAMETERS ........................2 H22 2001...
  • Page 7 THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 8: Section 1, Installation

    SECTION 1 INSTALLATION...

  • Page 10: Safety Precautions

    HOLD WORKPIECE FIRMLY AGAINST TABLE. OPERATOR: DO NOT REMOVE JAMMED CUTOFF PIECES UNTIL BLADE HAS STOPPED. NO MODIFICATIONS TO THE MACHINE ARE PERMITTED WITHOUT PRIOR APPROVAL FROM HYD-MECH. ANY APPROVED MODIFICATIONS SHOULD ONLY BE UNDERTAKEN BY TRAINED PERSONNEL. Pg 1.1...

  • Page 11: H-18 & H-22 Lifting Instructions

    H-18 & H-22 LIFTING INSTRUCTIONS Pg 1.2...

  • Page 12: Foundation, Levelling And Anchoring

    FOUNDATION, LEVELLING AND ANCHORING Machine location should be carefully selected. A flat concrete floor area should be chosen. It should have enough free space surrounding the machine to enable free access for safe operation and maintenance. Machine should be levelled in both directions ie. along and across its infeed conveyor specially when machine is to be inserted into a larger conveyor system.

  • Page 13: Wiring Connections

    WIRING CONNECTIONS After the machine is levelled and anchored the necessary power hook-up needs to be performed. In order to provide safe operation as well as to prevent potential damage to the machine, only qualified personnel should make the connections. BEFORE START-UP THE FOLLOWING TWO POINTS SHOULD BE CHECKED: -signs of damage that may have occurred during shipping to the electrical cables and the hydraulic hoses.
  • Page 14 SECTION 2 OPERATING INSTRUCTIONS...

  • Page 16: Manual Operation

    START-UP The H-22A control console has been designed to simplify the operation of the saw, to give the operator the ability to stop any function at any time, and to be able to control all the functions remotely. We can not overstress the importance of familiarizing yourself with the controls of the "H"...

  • Page 17: Operator Panel Controls

    OPERATOR PANEL CONTROLS TOP ROW FRONT VISE - This switch has three positions, CLOSE, OPEN, and HOLD. In CLOSE, the vise will close all the way, or until it encounters enough resistance to stop it. With the switch held in the OPEN position the vise will open all the way or until the switch is released. With the switch in the HOLD position, the vise will stay where it is and will not move freely although it will not resist a large force indefinitely without creeping.
  • Page 18 BLADE SPEED - This dial will increase or decrease the speed at any time while the blade is running. BLADE STOP BUTTON - Stops the blade. If the blade is stopped during a cycle, the cycle will continue but will not let the head descend until the blade is started. STOP - This mushroom button stops the blade and hydraulic motors.

  • Page 19: Mitsubishi Based Plc Control System

    MITSUBISHI BASED PLC CONTROL SYSTEM NOTE: This instruction manual is applicable to the M16A, M20A, H14A, H18A, H22A, H28A, H32A equipped with a Mitsubishi PLC, c/w feed rate display, manufactured after and including the following serial numbers: Machine Model Serial # M-16A S0298036 M-20A...

  • Page 20: Activating The Plc

    ACTIVATING THE PLC Position the head, fixed vise, and shuttle vise switches to the NEUTRAL (center) positions. If any of these switches are not in the NEUTRAL position, the hydraulics will not start. The PLC control will become active when the HYDRAULIC START button is depressed and "held in"...

  • Page 21: Function Button Description

    FUNCTION BUTTON DESCRIPTION If a red indicator light above a function button is illuminated, it means that the function printed in red at the top of the button is enabled. No light indicates the the function printed in black at the bottom of the function button is enabled.

  • Page 22: Single Part Cycle Operation

    SINGLE PART CYCLE OPERATION In MAN mode, the PLC allows the operator to initiate a "Single Part Cycle " to cut one piece at a desired length. To accomplish this, follow the procedure below. Before initiating this procedure, the head should be "HOMED". See KERF function button description for 1) A trim cut should be made before initiating the "Single Part Cycle "...

  • Page 23: Automatic Operation

    NOTE: Whenever a new job or new material is being loaded for production, the head height should be properly set to clear the material, material positioned for a trim cut and the front vise (and auxillary vise is used) closed (in "MANUAL MODE").

  • Page 24: Working With A Queue

    NOTE: The "CT" value is the accumulated total number of parts that have been cut from the JOB number since it was last reset. The machine will only cut the quantity which is the difference between REQUIRED QUANTITY and CUT QUANTITY. When REQUIRED QUANTITY equals CUT QUANTITY, the machine AUTO CYCLE will stop and you will be unable to restart the same job until the "CUT QUANTITY"...
  • Page 25 THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 26: Blade Basics

    SECTION 2B, SAW CUTTING CONTROLS This section has been prepared to give the operator the ability to set up the saw for most cutting situations. The saw is equipped with variable blade speed control and hydraulic feed control, as well as an extensive door chart to guide the operator to the correct setting of these controls.

  • Page 27: Hydraulic Feed Control

    HYDRAULIC FEED CONTROL The Hydraulic Feed Control is located to the left of the control panel. These controls allow independent control of Feed Force and Feed Rate. Feed Force Knob Used to set Feed Force Limit (counterclockwise rotation to increase and clockwise rotation to decrease).

  • Page 28: Step 1, Determine Effective Material Width - W ( Inches ) Or (Mm)

    CHART EXAMPLE #1 We will use the parameters chart to set up the saw for cutting 8" (200mm) Diameter #1045 Carbon Steel. STEP 1, DETERMINE EFFECTIVE MATERIAL WIDTH - W ( inches ) or (mm) Effective material width, W (in.) for most common shapes of materials, is the widest solid part of the material to be in contact with blade during cutting.

  • Page 29: Step 3, Determine Optimum Blade Pitch - Teeth Per Inch (T.p.i.)

    STEP 3, DETERMINE OPTIMUM BLADE PITCH - TEETH PER INCH (T.P.I.) Selecting a blade with proper tooth pitch is important in order to achieve optimal cutting rates and good blade life. For cutting narrow or thin wall structural materials a fine blade with many teeth per inch (T.P.I.) is recommended.

  • Page 30: Step 5, Determine Feed Rate Setting, Fr (In/Min) (Mm/Min)

    The following table gives examples of the optimum blade speeds for different materials. MATERIALS OPTIMUM BLADE SPEED ft/min m/min 5" (125mm)Dia Solid Carbon Steel 12" (300mm) I-Beam 4" x 4" (100 x 100mm) Rec Tube, 1/4" (6mm) Wall 4"(100) 400 Stainless Steel 2"...

  • Page 31: Additional Cutting Setup Examples

    Feed Rate, continued If the saw is fitted with a blade coarser than optimum (e.g.. 1.4/2.5 TPI) we can still use the graph, but we go to the 1.4/2.5 curve. As a result we find that the FEED RATE is decreased to 1.3 in/min (133mm/min) for this blade.

  • Page 32: Coolant Flow

    SECTION 2C, MECHANICAL CONTROLS COOLANT FLOW A generous flow of coolant should be applied in order to increase production and blade life. Machine is provided with two independently controlled coolant spouts. -One from the adjustable guide arm. This one should always flood the blade with coolant.
  • Page 33 OPTIONAL BUNDLING CONTROLS Both the front vise bundling and the shuttle vise bundling can be operated independantly. Both of the bundling actions can be controlled independantly in relation to the close time of the vise jaws or turned off completely. To turn the bundling on, turn the ball valve handle for each of the cylinders (shown in the Shuttle vise...

  • Page 34: Section 3, Maintenance And Trouble Shooting

    SECTION 3 MAINTENANCE AND TROUBLE SHOOTING...

  • Page 36: Lock -Out

    SECTION 3, MAINTENANCE AND TROUBLE SHOOTING LOCK -OUT Purpose: To prevent injury to workers caused by unexpected start-up of machines being worked on. Where the starting of a machine or device may endanger the safety of a worker Control switches or other control mechanisms shall be locked out; Other effective precautions necessary to prevent such starting shall be taken LOCK OUT PROCEDURE Whenever work is to be performed on a machine, the person in charge should follow Lockout procedures as is...

  • Page 37: Blade Changing Procedure

    The brush should be replaced as it becomes worn to approximately 70% of it's original 3" diameter. Replacements can be purchased through your Hyd-Mech Dealer. Blade brush and adjusting nut & screw. Pg 3.2...

  • Page 38: Blade Tracking Adjustment

    BLADE GUIDES ADJUSTMENT Each guide arm is provided with a set of blade guides. Both sets are identical. Each set consists of a top carbide, fixed carbide pad and adjustable carbide pad. To adjust the carbides, loosen the set screws in the handle bases and remove the handles.

  • Page 39: Cam Follower Adjustment

    CAM FOLLOWER ADJUSTMENT There are two cam followers mounted on the head frame. The set of cam followers is shown in the photo. One of them is fixed and the other is adjustable. The cam followers are factory set and usually do not require adjustment. In a properly adjusted system of cam followers only one side should be in contact with the guide.

  • Page 40: Hydraulic Maintenance

    HYDRAULIC MAINTENANCE There are only FIVE items of routine maintenance associated with the hydraulic system. 1. OIL FILTER - Ten micron filtration of the hydraulic oil is provided by a spin on type filter mounted on the tank return line. The element should be changed after the first 50 Hours of operation and then every 500 working hours.

  • Page 41: Trouble Shooting

    Most problems which may occur have relatively simple solutions which appear in this section. If the solution is not found here, contact the Hyd-Mech Distributor from whom you purchased your bandsaw. They have trained field service personnel who will be able to rectify the problem.
  • Page 42 PROBLEM PROBABLE CAUSE SOLUTION 9a. Motor overload has tripped. 9a. Depress each of the over- 9. Saw will not start. load buttons located in the electrical box. Depressing one button at a time and trying to start the saw will indicate which motor was overloaded.
  • Page 43 In manual mode, with front vise switch in 'CLOSE' position press FWD. and REV buttons simultaneously ( not more than 0.5 sec. apart). The PLC will prompt for a password which is obtainable from Hyd-Mech Saws. If the password is correct a screen of parameters will appear. The display will show two lines of parameters at a time.

  • Page 44: Plc 100 Parameters

    PLC 100 PARAMETERS Parameter Definition HGT CLB "ENTER" This is to be used only if calibration is required. Call Hyd-Mech Service department for instruction. ACT HT - Actual Height Value. Value that must be entered after performing Head Height Calibration procedure (see Pg.

  • Page 45: Plc 100 Troubleshooting

    PLC 100 TROUBLESHOOTING PROBLEM #1, for automatic models with a shuttle. PLC is not measuring lengths. POSSIBLE CAUSES; i) Encoder - pinion gear loose on encoder shaft - bad encoder ii) Encoder Cable - bad connection at encoder or PLC - open or shorted wire ii) PLC unit - damaged hardware...

  • Page 46: Inaccurate Lengths In Auto Mode

    PROBLEM # 2, for automatic models with a shuttle. Inaccurate lengths in AUTO mode. POSSIBLE CAUSES; i) Encoder - pinion not engaging rack all the way from front to back; mechanical interference, pinion loose on encoder shaft ii) Encoder Cable - bad connection at encoder or at PLC - intermittent open in one or more signal wires iii) Improper programmed information...

  • Page 47: Consistent Inaccuracy

    CONSISTENT INACCURACY (make sure blade kerf value is correct) - change "Actual Pos." parameter to 1. This will make the PLC show actual shuttle travel in AUTO With no material in the machine: - program JOB 1 for 2 pieces of 5" length, JOB 2 for 2 pieces of 10" length, and JOB 3 for 2 pieces of a length as one shuttle will allow.

  • Page 48: Auto Cycle Not Being Completed

    PROBLEM # 3, for P models, disregard all references to a shuttle. AUTO cycle not being completed. In the AUTO mode, the PLC controls saw functions through output relays. For a certain function to be actuated, the PLC must first see specific input(s). Like the output relays, the input relays are located on the PLC unit.

  • Page 49: No Display

    If the fuse is good and no output voltage condition still exists, with the output light on, then the relay is defective. If this is the case the PLC will have to be returned to the manufacturer for repair. (Contact HYD-MECH SAWS).

  • Page 50: Mitsubishi 100 Inputs & Outputs

    MITSUBISHI 100 INPUTS & OUTPUTS MITSUBISHI 0 1 2 3 4 5 6 7 Power 10 11 12 13 14 15 16 17 Batt V Prog E -32MR 0 1 2 3 4 5 6 7 10 11 12 13 14 15 16 17 COM4 COM3 COM1...

  • Page 51: Input / Output Terminal Information

    Input / Output Terminal Information : Inputs - X0 - Length Encoder, Channel A X10 - Shuttle Vise Close Switch X1 - Length Encoder, Channel B X11 - Shuttle Vise Open Switch X2 - Blade Speed X12 - Front Vise Close Switch X3 - Head Encoder, Channel A X13 - Front Vise Open Switch X4 - Head Encoder, Channel B...

  • Page 52: Calibration Procedure For Mitsubishi Plc

    In manual mode position a piece of material which is longer than the shuttle full stroke length (i.e.. M-16A = 32.500") and close the front VISE. Simultaneously depress "FWD" & "REV" buttons on the PLC to access parameters. A password is required at this point which can be obtained from Hyd-Mech Service Department. SCREEN WILL DISPLAY: LTH.CLB.

  • Page 53: Head Height Calibration

    HEAD HEIGHT CALIBRATION 1) Enter the PLC parameter screen as per Length Calibration Procedure on Pg. 3.19. 2) Using the arrow cursor keys scroll down until the screen displays : HT CLB "ENTER" ACT HT 00.000 3) With the cursor on the , press the ENTER key.

  • Page 54: Service Record & Notes

    SERVICE RECORD & NOTES DATE SERVICED BY COMMENTS Pg 3.19...
  • Page 55 THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 56: Section 4, Electrical System

    SECTION 4 ELECTRICAL SYSTEM...

  • Page 58: General Information

    1)The PLC is equipped with a lithium battery to keep the program stored while the power is shut down. The battery will need to be replaced every 3 to 5 years, depending on usage. A visual warning will be displayed on the interface when the battery drains to a certain level. Battaries can be purchased through your Hyd-Mech Distibutor.

  • Page 59: Electrical Components

    ELECTRICAL COMPONENTS, PHOTOS Mitsubishi PLC. Fuses & overloads. Control fuses. Transformer. Electrical control box layout. Hirschman connectors and directional control valve solenoids. 3 HP electric motor. Hydraulic control components. Pg 4.2...

  • Page 60: Electrical Components Lists

    ELECTRICAL COMPONENTS LISTS LIST OF H18A SV_H22A ELECTRICAL COMPONENTS Item Code as on Component Description Part Number H22A Schematic Manufacturer 1PB- Red mushroom head, latching push button. ZB2 BT4 Telemecanique Emergency Stop Push Button Mounting base with 1 N/C contact block. ZB2 BZ102 Telemecanique 2PB-Hydraulic Start...
  • Page 61 LIST OF H18 SV_H22A ELECTRICAL COMPONENTS Item Code as on Component Description Part Number H22A Schematic Manufacturer FX2N-48MR Mitsubishi PLC. FX2N-48MR Mitsubishi E200 Mitsubishi Interface E200 Mitsubishi Interface communication cable H22-FX2N32-009 Ferrite core 444164951 Ferrite Hyd. Valve Hirschmann connector H/927811311 Hirschmann Connector Coolant pump relay...
  • Page 62 H22A POWER COMPONENTS for SPECIFIC VOLTAGES MACHINE VOLTAGE Description & (Item Code) Component as on schematic Manufacturer 3ph 208V 3ph 240V 3ph 380 3ph 415V 3ph 480V 3ph 600V 3HP HYDRAULIC PUMP MOTOR (1M) Frame Size 182TC, 1800 R.P.M. CONTACTOR (1M) Telemecanique LC1D1210G6 LC1D1210G6...

  • Page 63: Electrical Schematic And Wiring Drawings (240 Volts)

    ELECTRICAL SCHEMATIC and WIRING DRAWINGS (240 volts) Pg 4.6 H28-32...
  • Page 64 œ +<' 0(&+ *5283 /,0,7(' UC@ÃI@X œ H@8Cà UurÃS‚pxÃT‚yvqÃT‚yˆ‡v‚ Pg 4.7 H28-32...
  • Page 65 Pg 4.8 H28-32...
  • Page 66 œ +<' 0(&+ *5283 /,0,7(' UC@ÃI@X œ H@8Cà UurÃS‚pxÃT‚yvqÃT‚yˆ‡v‚ Pg 4.9 H28-32...
  • Page 67 Pg 4.10 H28-32...
  • Page 68 œ +<' 0(&+ *5283 /,0,7(' UC@ÃI@X œ H@8Cà UurÃS‚pxÃT‚yvqÃT‚yˆ‡v‚ Pg 4.11 H28-32...
  • Page 69 Pg 4.12 H28-32...
  • Page 70 œ +<' 0(&+ *5283 /,0,7(' UC@ÃI@X œ H@8Cà UurÃS‚pxÃT‚yvqÃT‚yˆ‡v‚ Pg 4.13 H28-32...
  • Page 71 Pg 4.14 H28-32...
  • Page 72 œ +<' 0(&+ *5283 /,0,7(' UC@ÃI@X œ H@8Cà UurÃS‚pxÃT‚yvqÃT‚yˆ‡v‚ Pg 4.15 H28-32...
  • Page 73 Pg 4.16 H28-32...
  • Page 74 œ +<' 0(&+ *5283 /,0,7(' UC@ÃI@X œ H@8Cà UurÃS‚pxÃT‚yvqÃT‚yˆ‡v‚ Pg 4.17 H28-32...
  • Page 75 ELECTRICAL SCHEMATIC and WIRING DRAWINGS (480 / 575 volts) Pg 4.18 H28-32...
  • Page 76 œ +<' 0(&+ *5283 /,0,7(' UC@ÃI@X œ H@8Cà UurÃS‚pxÃT‚yvqÃT‚yˆ‡v‚ Pg 4.19 H28-32...
  • Page 77 Pg 4.20 H28-32...
  • Page 78 œ +<' 0(&+ *5283 /,0,7(' UC@ÃI@X œ H@8Cà UurÃS‚pxÃT‚yvqÃT‚yˆ‡v‚ Pg 4.21 H28-32...
  • Page 79 Pg 4.22 H28-32...
  • Page 80 œ +<' 0(&+ *5283 /,0,7(' UC@ÃI@X œ H@8Cà UurÃS‚pxÃT‚yvqÃT‚yˆ‡v‚ Pg 4.23 H28-32...
  • Page 81 Pg 4.24 H28-32...
  • Page 82 œ +<' 0(&+ *5283 /,0,7(' UC@ÃI@X œ H@8Cà UurÃS‚pxÃT‚yvqÃT‚yˆ‡v‚ Pg 4.25 H28-32...
  • Page 83 Pg 4.26 H28-32...
  • Page 84 œ +<' 0(&+ *5283 /,0,7(' UC@ÃI@X œ H@8Cà UurÃS‚pxÃT‚yvqÃT‚yˆ‡v‚ Pg 4.27 H28-32...
  • Page 85 Pg 4.28 H28-32...
  • Page 86 œ +<' 0(&+ *5283 /,0,7(' UC@ÃI@X œ H@8Cà UurÃS‚pxÃT‚yvqÃT‚yˆ‡v‚ Pg 4.29 H28-32...
  • Page 87 THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 88 SECTION 5 HYDRAULIC SYSTEM...
  • Page 90 SECTION 5, HYDRAULIC SYSTEM The H-22 hydraulic system does not require any special work on a new machine before its start-up. The hydraulic tank is filled with Duro AW46 hydraulic oil and all machine functions have been tested at the factory to ensure proper operation upon initial start-up.

  • Page 91: Gland Assemblies

    CYLINDER ASSEMBLIES Gland assemblies Piston assemblies Pg 5.2...
  • Page 92 THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 93 Pg 5.4 H28-32...
  • Page 94 Pg 5.5 H28-32...
  • Page 95 Pg 5.6 H28-32...
  • Page 96 Pg 5.7 H28-32...
  • Page 97 Pg 5.8 H28-32...
  • Page 98 Pg 5.9 H28-32...
  • Page 99 THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 100: Section 6, Mechanical Assemblies

    SECTION 6 MECHANICAL ASSEMBLIES...

  • Page 102: H-22 Blade Brush Assembly

    SECTION 6, MECHANICAL ASSEMBLIES H-22 BLADE BRUSH ASSEMBLY ITEM H-22 PART NUMBER DESCRIPTION 129-0017 HYDRAULIC MOTOR H22-48-01 MOTOR MOUNTING BRACKET S20-926-02A EXTENSION .5FLT FLAT WASHER 12280 3" BLADE BRUSH .5HXNUT HEX NUT B2-.25x.75 HEX HEAD CAP SCREW, NF .375FLT FLAT WASHER TC 13 COMPRESSION SPRING A1-.375x3.75...

  • Page 103: H-22 Guide Arm Assembly

    H-22 GUIDE ARM ASSEMBLY ITEM H-22 PART NUMBER DESCRIPTION H22-47-02 GUIDE AM BAR A1-.5x1 SOCKET HEAD CAP SCREW H22-47-00 IDLER GUIDE ARM H22-46-00 DRIVE GUIDE ARM H18-47-04 GUIDE ARM SPRING CARRIER 30 K2000-037 DISK SPRING H18-47-03 GUIDE ARM PISTON CRBL-01A CARBIDE SUPPORT CRBL-02 CARBIDE LOADER BOLT...

  • Page 104: Antivibration Roller Assembly

    ANTIVIBRATION ROLLER ASSEMBLY ITEM H18-22 PART NUMBER DESCRIPTION AVR-471-01A BLOCK, IDLER SIDE AVR-461A-01 BLOCK, DRIVE SIDE A1-.375x2 SOCKET HEAD CAP SCREW 6200 2RS BALL BEARING AVR-461-03 BACK ROLLER RACE AVR-461-02A FRONT ROLLER RACE B3-10x30S METRIC SOCKET HEAD SHOULDER SCREW O-RING (.625x1/16) AVR-471-02A BUSHING 6000 2RS...
  • Page 105 H-22 IDLER WHEEL ASSEMBLY ITEM H-22 PART NUMBER DESCRIPTION H22-43-01A BACK PLATE H22-431-00 SLIDER WELDMENT S1-.5X1C SOCKET SET SCREW, CUP POINT H22-6-01 TENSION CYLINDER MOUNTING PIN H22-C5-00 TENSION CYLINDER MOUNTING PIN H22-43-02 TENSION TRACK A1-.875X3.25 SOCKET HEAD CAP SCREW A1-.875X2.5 SOCKET HEAD CAP SCREW S1-.875X1.5 SOCKET SET SCREW, FLAT POINT...

  • Page 106: Hydraulic Pump Assembly

    HYDRAULIC PUMP ASSEMBLY ITEM H-18 PART NUMBER DESCRIPTION 182TC 3 HP, 1800RPM, SPECIFY VOLTAGE 5J - 1 1/8 SUREFLEX COUPLING FLANGE 5JEM SLEEVE 5J 3/4 SUREFLEX COUPLING FLANGE 1960 3 & 5HP BELL HOUSING .5LOC LOCK WASHER B1-.5x1.5 HEX HEAD CAP SCREW PVQ-13-A2R-SE-15-10-CM7 HYDRAULIC PUMP .375LOC...

  • Page 107: Hydraulic Tank Assembly

    HYDRAULIC TANK ASSEMBLY ITEM H-18 PART NUMBER DESCRIPTION H16-611-00 POWER PACK WELDMENT H16-61-01 OIL TANK LID S1-.19x.5 SOCKET HEAD CAP SCREW SES-3-40-S-80 FILLER CAP & BREATHER, 50micron T1-.19x.5 TRUSS HEAD MACHINE SCREW 2103-4-4 90 deg ELBOW, MNPT/MJIC TFS-100-0-P SUCTION STRAINER MP-100-FE 90 deg ELBOW, FNPT/FNPT 30182B-12-8...

  • Page 108: Front Vise Assembly

    FRONT VISE ASSEMBLY ITEM H-18 PART NUMBER (H22) DESCRIPTION H22-511-00 FRONT VISE FRAME H22-5-01 VISE FRAME COVER H22-5-03 MOVABLE JAW SHAFT H3000 3" SHAFT WIPER 9.375x1x.125 WEAR RING (702 STRIP) H22-C31-00 VISE CYLINDER H22-5-05 CYLINDER MOUNTING PLATE F1-.5X1 FLAT SOCKET HEAD CAP SCREW SH-0287-PA 2 7/8 EXTERNAL RETAINING RING H18-5-04 (H22-5-04)

  • Page 109: Front Vise Datum Line Jaw Assembly

    FRONT VISE DATUM LINE JAW ASSEMBLY ITEM H-18 PART NUMBER DESCRIPTION H18-512-00 DATUM LINE JAW H18-5-02 WEAR STRIP F1-.312x.5 FLAT SOCKET HEAD CAP SCREW H14-5-10 SMALL JAW MOUNTING PIN H14-5-12 SMALL DATUM JAW LINK H14-5-11 LARGE DATUM JAW LINK H14-5-15 LARGE JAW MOUNTING PIN SH-0125-PA 1 1/8 EXTERNAL RETAINING RING...

  • Page 110: Shuttle Vise Assembly

    SHUTTLE VISE ASSEMBLY ITEM H-18 PART NUMBER (H22) DESCRIPTION H22-521-00 FRONT VISE FRAME H22-5-01 VISE FRAME COVER H22-5-03 MOVABLE JAW SHAFT H3000 3" SHAFT WIPER 9.375x1x.125 WEAR RING (702 STRIP) H22-C31-00 VISE CYLINDER H22-5-05 CYLINDER MOUNTING PLATE F1-.5x1 FLAT SOCKET HEAD CAP SCREW SH-0287-PA 2 7/8 EXTERNAL RETAINING RING H18-5-04 (H22-5-04)

  • Page 111: Shuttle Vise Datum Line Jaw Assembly

    SHUTTLE VISE DATUM LINE JAW ASSEMBLY ITEM H-18 PART NUMBER DESCRIPTION H18-522-00A DATUM LINE JAW H18-5-02 WEAR STRIP F1-.312x.75 FLAT SOCKET HEAD CAP SCREW H14-5A-10 SMALL JAW MOUNTING PIN H14-5A-12 SMALL DATUM JAW LINK H14-5A-11 LARGE DATUM JAW LINK H14-5-15 LARGE JAW MOUNTING PIN SH-0125-PA 1 1/8 EXTERNAL RETAINING RING...

  • Page 112: Chip Auger Assembly

    CHIP AUGER ASSEMBLY ITEM H-18 PART NUMBER DESCRIPTION MG.12.09.10 HYDRAULIC MOTOR 2503-6-4 O RING ADAPTOR, M STRT/FNPT 2103-4-4 90 deg ELBOW, MNPT/MJIC S1-.312x.25C SOCKET SET SCREW, CUP POINT F1-.375x1 FLAT SOCKET HEAD CAP SCREW H18-12-00 AUGER WELDMENT Pg 6.11...

  • Page 113: H-22 Drive Assembly

    H-22 DRIVE ASSEMBLY ITEM H-22 PART NUMBER DESCRIPTION PM70 GEAR BOX, 45.15:1 256TC 10HP, 1200RPM, SPECIFY VOLTAGE H22-41-02 UPPER MOUNTING PLATE H22-41-01 LOWER MOUNTING PLATE B1-.875x2 HEX HEAD CAP SCREW H20-44-01 DRIVE WHEEL H22-44-02 RETAINING CAP A1-.625x1.75 SOCKET HEAD CAP SCREW S1-.875x1.5 SOCKET SET SCREW, CUP POINT 24mmLOC...
  • Page 114 THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 115 Pg 6.14 H28-32...
  • Page 116 Pg 6.15 H28-32...
  • Page 117 THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 118: Section 7, Options

    SECTION 7 OPTIONAL ASSEMBLIES...

  • Page 120: H-18 & H-22 Bundling Assembly

    SECTION 7, OPTIONS H-18 & H-22 BUNDLING ASSEMBLY ITEM H-22 PART NUMBER DESCRIPTION H22-531A-00 BUNDLING BRACKET WELDMENT H22-532-02 BUNDLING SHAFT 7.26x1x.125 WEAR RING (702 STRIP) H2250 2 1/4 SHAFT WIPER H22-C23-00 BUNDLING CYLINDER SH-0237-PA 2 3/8 EXTERNAL RETAINING RING H22-532A-01 BUNDLING CLAMP H22-532A-03 WEAR STRIP...
  • Page 121 H-18 & H-22 OUTBOARD BUNDLING ASSEMBLY Pg 7.2 H1822 20011...

  • Page 122: Section 8, Specifications

    SECTION 8 SPECIFICATIONS...

  • Page 124: Specifications

    SECTION 8, SPECIFICATIONS MODEL H-22 DIMENSIONS Capacity Round: 22" Diameter Square: 22" x 22" (Bundling to full capacity optional) Blade Length: 22" Width: 2" (Optional) Thickness: .063" Blade Speed 50-350 SFM Blade Tension Hydraulic Blade Guides Carbide Blade Wheel Diameter 27"...

  • Page 125: H-22 Layout Drawing

    H-22 LAYOUT DRAWING Pg 8.2 H22 2001...

  • Page 126: Section 9, Warranty

    SECTION 9 WARRANTY...
  • Page 128 Hyd . Mech's sole obligation under this warranty is limited to the repair or replacement without charge, at Hyd . Mech's factory, warehouse, or approved repair shop,of any part or parts which Hyd-Mech's inspection shall disclose to be defective. Return freight must be prepaid by the user.

  • Page 129: Mitsubishi Plc Parameters

    MITSUBISHI PLC PARAMETERS (refer to "Calibration Procedures" in Sec 3, for proper usage of paramters) PLC 100 ACT HT FST APR DIST HGT CLB "ENTER" FST APR OFST (OPTION) (OPTION) DOWN DWL LTH CLB "ENTER" ACT LTH STROKE SLW DIST ACC DIST DEC DIST TRG WD...
