Camera
The X-Star and X-Star Premium are both equipped with a 4k UHD camera. The
camera supports various shooting modes including single shot, burst shooting,
AEB and time lapse. Videos can be recorded in MOV or MP4 formats, and photos
can be saved in JPG or DNG formats. An HD live view from the camera can be
displayed on your mobile device through the mobile app Starlink.
Remote Controller
The remote controller enables wireless communication with the aircraft through
a 5.8GHz radio frequency band. The maximum working range of the remote
controller in an open area is about 400m when set as CE standard, or about
1000m (X-Star)/2000m (X-Star Premium) when set as FCC standard. 900MHz HD
video streaming module of the X-Star Premium remote controller allow video
downlink from the aircraft for real-time light and video data displayed on the app,
enabling convenient control of aerial photography and remote piloting.
IMPO RT A NT
The X-Star network is only established when the aircraft, the remote
controller and the mobile device are properly connected through the WiFi
network (X-Star) or HD video streaming (X-Star Premium).
Functionality Description
10
• The left antenna transmits 5.8GHz RF signal to
the aircraft for sending commands and receiving
light information.
①
•
Antennas
900MHz HD video signals ( X-Star Premium
from the aircraft and transfer the fight
camera data to the connected mobile app.
② Holds the mobile device with a 180° adjustable
Mobile Device Holder
viewing angle for optimum visibility.
Displays the light status, warning messages and
③
Flight Information Panel
real-time instructions. (
Set by default:
④
Left Command Stick
Upward / Downward and Turn Left / Turn Right
Set by default:
⑤
Right Command Stick
Forward / Backward and Move Left / Move Right
⑥
Attached to a neck strap for easy portability.
Strap Hole
⑦
Starts the motors.
Motor Starter
⑧
Take-off/Landing Button Commands the aircraft to take off or land.
Press and hold for 2 seconds to turn on/off the
remote controller. You will hear a buzz sound. The
⑨
Power Button
power button shows a solid green light when you
turn on the remote controller.
⑩
Commands the aircraft to return to the home point.
Go Home Button
Commands the aircraft to stop moving temperarily
⑪
Pause Button
and hover in position when necessary.
Connected to the X-Star/X-Star Premium charger
⑫
Power Port
to charge the built-in battery of the remote controller.
)
data and
13)
