Epson FX Emulation
m DPI Graphics
Selects eight wire graphics of density m as listed in the following table for n1 + (n2 x
256) columns of data.
m
0
1
2
3
4
5
6
7
Example: The following escape sequence will print four bytes of graphics data at 72
x 72 dpi. The resulting figure will resemble a square, since the horizontal and vertical
density are the same. If some other density is chosen, the figure will resemble a
rectangle.
Escape Sequence:
Hexadecimal:
Page 3-26
Density
60 dpi (same as ESC K)
120 dpi (same as ESC L)
120 dpi high speed (same as ESC Y)
240 dpi high speed (same as ESC Z)
80 dpi
72 dpi
90 dpi
144 dpi
ESC
*
5
1B
2A
05
ESC * m n1 n2 data
_______
4
0
<
<
04
00
3C
3C
<
<
3C
3C
