Horizontal Tabs - Printek FormsPro 4300 Owner's Manual

ANSI X3.64 Emulation

Horizontal Tabs

Horizontal tab stops are associated with columns, not absolute physical positions.
Changing character spacing will change the physical position of the tab stops.
Default tab stops are set at every eighth column, i.e. column 9, 17, 25, 33, 41, etc. If
different tab stops are to be set, the default tab stops should first be cleared.
Horizontal Tab
Advances to the next horizontal tab stop. If no tab stop exists between the active
column and the right margin, the HT will be ignored. Default tab stops are set at
every eighth column, i.e. column 9, 17, 25, 33, 41, etc. Different tab stops may be set
with ESC H, ESC 1, or ESC [ n1 ; n2 ; ... nx u.
Control code:
Hexadecimal:
Set Horizontal Tab Stop
(or)
Sets a horizontal tab stop at the current print position. The tab stop is associated with
the active column, not an absolute physical position. Changing character spacing will
change the physical position of the tab stop.
Default tab stops are set at every eighth column, i.e. column 9, 17, 25, 33, 41, etc.
The tab stop set by this escape sequence will be added to previously set tab stops,
including the default tab stops. If this is not desired, the old tab stops should first be
cleared.
Control code:
Hexadecimal:
Escape Sequence:
Hexadecimal:
Clear Horizontal Tab Stop
(or)
Clears the horizontal tab stop at the current print position. The tab stop to be cleared
is associated with the active column (based upon the current character spacing), not
an absolute physical position.
Escape Sequence:
Hexadecimal:
Page 2-10
HT
09
HTS
88
ESC H
1B 48
ESC [ g
1B 5B 67
HT
HTS
ESC H
ESC [ g
ESC [ 0 g
