P R I N T E R
Possible Values: Auto*, Static
This item controls how the optional Ethernet interface card receives its
network address. When set to Auto, the Ethernet card will receive its
network address from a network DHCP server (typical installation). When
set to Static, the user sets the TCP/IP address, Subnet Mask and TCP/IP
Gateway address as follows:
IP Address
Possible Values: 000.000.000.000 ... 255.255.255.255
To set the TCP/IP address, use the SUBMENU key to select which digit
group you wish to change, and then use the UP/DOWN ARROW keys to
change the value. The value will change rapidly if the key is held down.

Subnet Mask

Possible Values: 000.000.000.000 ... 255.255.255.255
To set the Subnet Mask, use the SUBMENU key to select which digit group
you wish to change, and then use the UP/DOWN ARROW keys to change the
value. The value will change rapidly if the key is held down.
Gateway Address
Possible Values: 000.000.000.000 ... 255.255.255.255
To set the TCP/IP Gateway, use the SUBMENU key to select which digit
group you wish to change, and then use the UP/DOWN ARROW keys to
change the value. The value will change rapidly if the key is held down.
Automatic Carriage Return
58
C O N F I G U R A T I O N
IP Address
192.160.0.27
Subnet Mask
255.255.255.0
IP Gateway
192.168.0.0
Auto CR
On
