Dell™ Latitude™ D400 User's Guide
FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\tp.fm
D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY
w w w . d e l l . c o m | s u p p o r t . d e l l . c o m

Advertisement

Table of Contents
loading

Related Manuals for Dell Latitude D400

Summary of Contents for Dell Latitude D400

  • Page 1 Dell™ Latitude™ D400 User’s Guide FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\tp.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...
  • Page 2 Corporation; Microsoft, Windows, Windows NT, and MS-DOS are registered trademarks of Microsoft Corporation; Bluetooth is a trademark owned by Bluetooth SIG, Inc. and is used by Dell Computer Corporation under license; ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency.
  • Page 3 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\tp.fm March 2003 P/N 2X468 Rev. A00 D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...
  • Page 4 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\tp.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...
  • Page 5 ....Dell Support ......
  • Page 6 Internet Connection Firewall ....4 Dell™ QuickSet Features Clicking the QuickSet Icon ....
  • Page 7 Windows 2000 ......7 Using the Dell™ D/Bay About the Dell D/Bay ......
  • Page 8 ....Dell QuickSet Battery Meter ....
  • Page 9 10 Using PC Cards PC Card Types ......PC Card Blanks ......Extended PC Cards .
  • Page 10 Deleting an Asset Tag ..... Assigning an Owner Tag ....Deleting an Owner Tag .
  • Page 11 ....If Your Dell™ Computer Gets Wet ....
  • Page 12 Windows XP ......Windows 2000 ......Using Microsoft®...
  • Page 13 ......Contacting Dell ......
  • Page 14 CE Notice (European Union) ....CE Mark Notice ......New Zealand Telecom Warnings .
  • Page 15 S E C T I O N 1 F i n d i n g I n f o r m a t i o n FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\findinfo.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 16: Safety Instructions

    Readme files, which may be installed on your hard drive or found on CDs such as the Dell™ Drivers and Utilities CD, provide last-minute updates about technical changes to your computer or advanced technical reference material intended for experienced users or technicians.

  • Page 17: Using The Drivers And Utilities Cd

    User’s Guides. Using the Drivers and Utilities CD The Drivers and Utilities CD contains drivers and utilities, the Dell Diagnostics, and user’s guides for your computer and optional devices. Dell ships your computer to you with required drivers and utilities already installed—no further installation or configuration is needed.
  • Page 18 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\findinfo.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY F i n d i n g I n f o r ma t i o n...
  • Page 19 S E C T I O N 2 A b o u t Yo u r C o m p u t e r FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\about.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 20: Front View

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\about.fm Front View display latch touch pad display battery/battery bay device status lights track stick/touch pad buttons keyboard status lights track stick power button microphone speaker volume control buttons keyboard mute button D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY A b ou t Yo u r C omp u t er...
  • Page 21 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\about.fm — Slide the display latch to open the display. D I S P L A Y L A T C H — For more information about your display, see "Using the Display." D I S P L A Y D E V I C E S T A T U S L I G H T S Turns on when you turn on the computerm or blinks steadily when the computer is in standby mode.
  • Page 22 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\about.fm follows: – Solid green: The battery is charging. – Flashing green: The battery is almost fully charged. If the computer is running on a battery, the light operates as follows: – Off: The battery is adequately charged (or the computer is turned off). –...

  • Page 23: Left View

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\about.fm If the computer stops responding, press and hold the power button until the computer turns off completely (which may take several seconds). — To adjust the volume of the integrated speaker, press the volume S P E A K E R control buttons or volume control keyboard shortcuts.
  • Page 24 E L L A Y C O N N E C T O R Connects the Dell™ D/Bay, which is an external media bay that accommodates an optical drive, floppy drive, or second hard drive; also connects standard USB devices IEEE 13 94 —...

  • Page 25: Right View

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\about.fm — Lets you transfer files from your computer to another I N F R A R E D S E N S O R IrDA-compatible device without using cable connections. When you receive your computer, the sensor is disabled. You can use the system setup program to enable the sensor.
  • Page 26 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\about.fm NOTE: The computer CAUTION: Do not block, push objects into, or allow dust to turns on the fan when the accumulate in the air vents. Do not store your computer in a low- airflow environment, such as a closed briefcase, while it is computer gets warm.

  • Page 27: Back View

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\about.fm Back View air intake network connector (RJ-45) USB connector modem connector (RJ-11) (optional) serial connector AC Adapter connector video connector — The computer uses an internal fan to create airflow through the A I R I N T A K E vents, which prevents the computer from overheating.
  • Page 28 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\about.fm V I D E O C O N N E C T O R Connects an external monitor. For more information, see "Using the Display." (RJ-45) N E T W O R K C O N N E C T O R NOTICE: The network connector is slightly larger than the modem connector.
  • Page 29 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\about.fm The AC adapter converts AC power to the DC power required by the computer. You can connect the AC adapter with your computer turned either on or off. CAUTION: The AC adapter works with electrical outlets worldwide. However, power connectors and power strips vary among countries.

  • Page 30: Bottom View

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\about.fm Bottom View Bluetooth module cover air intake battery-bay latch release Service Tag battery memory module/modem cover battery charge gauge docking device slot hard drive — Covers the compartment that contains the L U E T O O T H M O D U L E C O V E R optional Bluetooth module.
  • Page 31 — Identifies your computer when you access Dell Support at E R V I C E computer. support.dell.com or when you call Dell for customer service or technical support. — Covers the compartment that contains M E M O R Y M O D U L E M O D E M C O V E R the memory module and optional modem.
  • Page 32 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\about.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY A b ou t Yo u r C omp u t er...
  • Page 33 S E C T I O N 3 U s i n g M i c r o s o f t ® W i n d o w s ® X P FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\xpfeat.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 34: Help And Support Center

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\xpfeat.fm Help and Support Center NOTE: Windows XP Home Edition and ® The Help and Support Center provides help with the Microsoft Windows XP Professional ® Windows XP operating system and also offers other support and offer different features and appearances.

  • Page 35: Desktop Cleanup Wizard

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\xpfeat.fm Desktop Cleanup Wizard By default, the Desktop Cleanup Wizard moves desktop icons that are not frequently used from your desktop to a designated folder 7 days after you first start your computer and every 60 days after that. The appearance of the Start menu changes as desktop icons are moved.
  • Page 36 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\xpfeat.fm You can transfer the data to the new computer over a network or serial connection, or you can store it on a removable medium, such as a writable CD or floppy disk. To prepare the new computer for the file transfer: Click the Start button, point to All Programs→...

  • Page 37: User Accounts And Fast User Switching

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\xpfeat.fm On the Where are the files and settings? screen, select the method you chose for transferring your settings and files and click Next. The wizard reads the collected files and settings and applies them to your new computer. When all of the settings and files have been applied, the Finished screen appears.

  • Page 38: Setting Up A Home And Office Network

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\xpfeat.fm When you use Fast User Switching, programs that previous users were using remain running in the background, so your computer might run slower. Also, multimedia programs, such as games and DVD software, might not work with Fast User Switching. For more information, see the Windows Help and Support Center.

  • Page 39: Internet Connection Firewall

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\xpfeat.fm Internet Connection Firewall The Internet Connection Firewall provides basic protection from unauthorized access to the computer while the computer is connected to the Internet. The firewall is automatically enabled when you run the Network Setup Wizard. When the firewall is enabled for a network connection, the firewall icon appears with a red background in the Network Connections portion of the Control Panel.
  • Page 40 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\xpfeat.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY Us i ng M icr o s o f t®...
  • Page 41 S E C T I O N 4 D e l l ™ Q u i c k S e t Fe a t u r e s Horizontal Rule FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\quickset.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 42: Clicking The Quickset Icon

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\quickset.fm Dell QuickSet provides you with easy access to configuration settings for power management schemes, battery resources, icon and font size, display brightness, volume, and network activity. If QuickSet is installed on your computer, it runs from the icon located in the taskbar.
  • Page 43 D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY Dell™ QuickSet Features...
  • Page 44 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\quickset.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY D el l™...
  • Page 45 S E C T I O N 5 U s i n g t h e K e y b o a r d a n d To u c h Pa d FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\keyboard.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 46: Numeric Keypad

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\keyboard.fm Numeric Keypad The numeric keypad functions like the numeric keypad on an external keyboard. Each key on the keypad has multiple functions. The keypad numbers and symbols are marked in blue on the right of the keypad keys. To type a number or symbol, hold down and press the desired key.

  • Page 47: Battery

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\keyboard.fm Enables and disables the scroll lock Battery Displays the Dell™ QuickSet Battery Meter QuickSet is installed) CD or DVD Tray Ejects the tray out of the drive (if Dell QuickSet installed) Display Functions Switches the video image to the next display option.

  • Page 48: Speaker Functions

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\keyboard.fm Speaker Functions Increases the volume of the integrated speaker and external speakers, if attached Decreases the volume of the integrated speaker and external speakers, if attached Enables and disables the integrated speaker and external speakers, if attached ®...

  • Page 49: Touch Pad

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\keyboard.fm Touch Pad The touch pad detects the pressure and movement of your finger to allow you to move the cursor on the display. Use the touch pad and touch pad buttons as you would use a mouse. 1 track stick 2 track stick buttons 3 touch pad...

  • Page 50: Customizing The Touch Pad And Track Stick

    You can purchase additional caps by visiting the Dell website at www.dell.com. D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...
  • Page 51 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\keyboard.fm Pull the cap off the track stick. Align the new cap over the square track-stick post and gently press the cap down onto the post. NOTICE: The track stick can damage the display if it is not properly seated on the post.
  • Page 52 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\keyboard.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY Using the Ke yboard and To uch Pa d...
  • Page 53 S E C T I O N 6 U s i n g t h e D i s p l a y FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\display.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 54: Adjusting Brightness

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\display.fm Adjusting Brightness When the Dell™ computer is running on battery power, you can conserve power by setting the brightness to the lowest comfortable setting using the appropriate keyboard shortcuts for the display. Dell QuickSet is installed, the QuickSet Brightness Meter shows the current brightness setting for the display.

  • Page 55: Switching The Video Image

    Before you change any of the default display settings, make a note of the default settings for future reference. If you choose a resolution or color palette that is higher than the display NOTE: Use only the Dell- installed video drivers, supports, the settings adjust automatically to the closest possible setting.
  • Page 56 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\display.fm If the video resolution setting is higher than that supported by the display, NOTE: As the resolution increases, icons and text the computer enters pan mode. In pan mode, the screen cannot be appear smaller on the completely displayed.
  • Page 57 S E C T I O N 7 U s i n g t h e D e l l ™ D / B a y FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\bay.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 58: About The Dell D/Bay

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\bay.fm About the Dell D/Bay You can install Dell Latitude™ D-Family devices such as a floppy drive or an optical drive. Removing and Installing Devices When the Computer is Turned Off NOTICE: To prevent damage to devices, place them in a safe, dry place when they are not installed in the computer.
  • Page 59 Connect the D/Bay cable to the Dell D/Bay connector on the computer.. D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 60: Removing And Installing Devices While The Computer Is Running

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\bay.fm Removing and Installing Devices While the Computer Is Running ® ® Microsoft Windows Double-click the Safely Remove Hardware icon on the taskbar. Click the device you want to eject. NOTICE: To prevent damage to devices, place them in a safe, dry place when they are not installed in the computer.
  • Page 61 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\bay.fm Insert the new device into the bay, push the device until you feel a click, and push the device latch release in so that it is flush with the computer. Windows XP automatically recognizes the new device. If necessary, enter your password to unlock your drive.
  • Page 62 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\bay.fm Pull the device by the latch release to remove the device from the D/Bay. Insert the new device into the bay, push the device until you feel a click, and push the device latch release in so that it is flush with the computer.

  • Page 63: Using The Cd Or Dvd Tray

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\bay.fm Using the CD or DVD Tray NOTICE: Do not press down on the drive tray when opening or closing it. Keep the tray closed when you are not using the drive. NOTICE: Do not move the computer while playing CDs or DVDs. Press the eject button on the front of the drive.

  • Page 64: Adjusting The Volume

    Either right-click the icon in the taskbar or press the volume control buttons to enable or disable the Volume Meter on the screen (if Dell QuickSet is installed). 1 volume icon 2 Volume Meter 3 mute icon D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 65: Adjusting The Picture

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\bay.fm When the meter is enabled, adjust the volume using the volume control NOTE: By default, the Volume Meter appears in buttons or by pressing the following keys: the lower-right corner of the display. You can click • Press to increase volume.
  • Page 66 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\bay.fm Click Apply. Click OK to save the settings and close the window. D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY U s i n g t h e D e l l ™...
  • Page 67 S E C T I O N 8 U s i n g a B a t t e r y FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\battery.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 68: Battery Performance

    Replace the battery only with a compatible battery purchased from Dell. The lithium-ion battery is designed to work with your Dell™ computer. Do not use batteries from other computers with your computer. CAUTION: Do not dispose of batteries with household waste.

  • Page 69: Checking The Battery Charge

    Windows power meter window and icon, the battery charge gauge and health gauge, and the low-battery warning provide information on the battery charge. Dell QuickSet Battery Meter Dell QuickSet is installed, press to display the QuickSet Battery Meter. The Battery Meter screen displays status, charge level, and charge completion time for the battery in your computer.

  • Page 70: Charge Gauge

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\battery.fm If the computer is connected to an electrical outlet, a icon appears. Charge Gauge Press the status button on the battery charge gauge to illuminate the charge-level lights. Each light represents approximately 20 percent of the total battery charge. For example, if the battery has 80 percent of its charge remaining, four of the lights are on.

  • Page 71: Low-Battery Warning

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\battery.fm Low-Battery Warning NOTICE: To avoid losing or corrupting data, save your work immediately after a low-battery warning. Then connect the computer to an electrical outlet, or install a second battery in the module bay. If the battery runs completely out of power, standby mode begins automatically.

  • Page 72: Installing A Battery

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\battery.fm If the computer is connected to a docking device (docked), undock it. See the documentation that came with your docking device for instructions. Slide and hold the battery-bay latch release on the bottom of the computer, and then remove the battery from the bay. Installing a Battery Slide the battery into the bay until the latch release clicks.
  • Page 73 S E C T I O N 9 P o w e r M a n a g e m e n t FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\power.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 74: Power Management Tips

    Power management options may vary, depending on which operating system is installed. If Dell™ QuickSet is installed, click or double-click the icon to open the NOTE: The Power Management Wizard is Power Management Wizard. not available if you have restricted access rights.

  • Page 75: Selecting A Power Scheme

    NOTE: When your computer is running on addition, you can delete power schemes that you create, but you cannot battery power, the delete Dell™ QuickSet predefined power schemes (Maximum Battery, Network Disabled power Maximum Performance, Presentation, and Network Disabled). scheme disables your internal network and wireless activity.

  • Page 76: Setting Battery Alarms And Actions

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\power.fm All QuickSet power schemes are displayed in a drop-down menu near the NOTE: QuickSet automatically adds the center of the screen. The power settings for each scheme in the menu are word (QuickSet) after the listed below the menu. The power settings are listed separately for when the names of power schemes computer is running on battery or connected to an electrical outlet.

  • Page 77: Power Management Modes

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\power.fm Power Management Modes Standby Mode Standby mode conserves power by turning off the display and the hard drive after a predetermined period of inactivity (a time-out). When the computer exits standby mode, it returns to the same operating state it was in before entering standby mode.

  • Page 78: Power Options Properties

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\power.fm Your computer enters hibernate mode if the battery charge level becomes critically low. To manually enter hibernate mode: • In Windows XP, click the Start button, click Turn off computer, press and hold , and then click Hibernate. In Windows 2000, if hibernate support is enabled, click the Start...

  • Page 79: Power Schemes Tab

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\power.fm Power Schemes Tab The Power schemes drop-down menu displays the selected preset power scheme. Keep the default Portable/Laptop power scheme to maximize battery power. Windows XP controls the performance level of the processor depending on the power scheme you select. You do not need to make any further adjustments to set the performance level.

  • Page 80: Hibernate Tab

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\power.fm – Shut down Windows and turn off the computer. Choose no action (None or Do nothing). – To program these functions, click an option from the corresponding drop- down menu and then click OK. Hibernate Tab The Hibernate tab lets you enable hibernate mode by clicking the Enable hibernate support check box.
  • Page 81 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\power.fm Click OK to accept any changes, and then click OK to close the Intel ® SpeedStep technology window. You can also change the Intel SpeedStep settings by right-clicking the flag icon in the notification area. D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY Po wer Management...
  • Page 82 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\power.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY Po wer Management...
  • Page 83 S E C T I O N 1 0 U s i n g P C C a r d s FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\pccards.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 84: Pc Card Types

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\pccards.fm PC Card Types See "Specifications" for information on supported PC Cards. The PC Card slot has one connector that supports a single Type I or Type II NOTE: A PC Card is not a bootable device. card. The PC Card slot supports CardBus technology and extended PC Cards.

  • Page 85: Removing A Pc Card Or Blank

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\pccards.fm Hold the card with its orientation symbol pointing into the slot and the top side of the card facing up. The latch may need to be in the "in" position before you insert the card. Slide the card into the slot until the card is completely seated in its connector.
  • Page 86 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\pccards.fm Press the eject button a second time. Gently remove the card. D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY Using PC Cards...
  • Page 87 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\pccards.fm Save a blank to use when no PC Card is installed in a slot. Blanks protect unused slots from dust and other particles. D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY Using PC Cards...
  • Page 88 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\pccards.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY Using PC Cards...
  • Page 89 S E C T I O N 1 1 U s i n g S m a r t C a r d s FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\smart.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 90: About Smart Cards

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\smart.fm About Smart Cards Smart cards are small portable credit-card shaped devices with internal integrated circuits. Smart cards come in two varieties: memory and microprocessor. Memory smart cards store data but cannot process information. Microprocessor smart cards can add, delete, and manipulate information in the card memory.
  • Page 91 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\smart.fm 1 gold contact pad 2 smart card (top) Slide the smart card into the smart card slot until the card is completely seated in its connector. The smart card will protrude from the slot. The smart card slot is located below the PC Card slot. If you encounter too much resistance, do not force the card.
  • Page 92 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\smart.fm 1 smart card slot 2 smart card D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY U s i n g S m a r t C ar d s...
  • Page 93 S E C T I O N 1 2 Tr a v e l i n g W i t h Yo u r C o m p u t e r FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\travel.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 94: Identifying Your Computer

    Remove any extraneous items, such as paper clips, pens, and paper, from the keyboard and palm rest and close the display. • Use the optional Dell™ carrying case to pack the computer and its accessories together safely. • Avoid packing the computer with items such as shaving cream, colognes, perfumes, or food.

  • Page 95: Travel Tips

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\travel.fm • Protect the computer, the batteries, and the hard drive from hazards such as extreme temperatures and overexposure to sunlight, dirt, dust, or liquids. NOTICE: If the computer has been exposed to extreme temperatures, allow it to acclimate to room temperature for 1 hour before turning it on. •...

  • Page 96: If Your Computer Is Lost Or Stolen

    The representative will attempt to get the phone number and address of the caller. Dell will then contact the law enforcement agency to which you made the report of the missing computer.
  • Page 97 S E C T I O N 1 3 Pa s s w o r d s FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\password.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 98: About Passwords

    If you forget any of your passwords, contact your system administrator or drive passwords. call Dell. For your protection, Dell technical support staff will ask you for proof of your identity to ensure that only an authorized person can use the computer.

  • Page 99: Using An Administrator Password

    Dell. provide access to the hard drive when a hard drive NOTICE: If you disable the administrator password, the primary password is password is assigned.

  • Page 100: Using A Hard Drive Password

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\password.fm Using a Hard Drive Password The hard drive password helps protect the data on your hard drive from unauthorized access. You can also assign a password for an external hard drive (if one is being used) that can be the same as or different from the password for the primary hard drive.

  • Page 101: Assigning An Asset Tag

    Save and close any open files and exit any open programs. Connect the Dell™ D/Bay with a floppy drive to the powered USB connector on the computer, or connect a USB floppy drive to the USB connector on the back of the computer.

  • Page 102: Viewing Existing Asset And Service Tags

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\password.fm When the computer prompts you to verify the asset tag, type NOTE: An asset tag can have up to 10 characters; The computer displays the new or modified asset tag and the Service any combination of Tag. characters excluding spaces is valid.

  • Page 103: Deleting An Owner Tag

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\password.fm Deleting an Owner Tag Boot the computer using the bootable floppy disk you created in NOTE: For security, you "Assigning an Asset Tag." cannot set, change, or delete the owner tag if the Type and press primary or administrator asset /o /d passwords are set.
  • Page 104 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\password.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY Pa sswords...
  • Page 105 S E C T I O N 1 4 S o l v i n g P r o b l e m s FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\problems.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 106: Power Problems

    If the battery status light rapidly flashes orange, the battery may be defective. Contact Dell. — Ensure that the electrical outlet is E S T T H E E L E C T R I C A L O U T L E T working by testing it with another device, such as a lamp.

  • Page 107: Error Messages

    I S K F A I L E D I N I T I A L I Z A T I O N Run the Hard-Disk Drive tests as described in "Using the Dell Diagnostics." — The system configuration information...
  • Page 108 I S K E T T E S U B S Y S T E M R E S E T F A I L E D be faulty. Run the Diskette tests as described in "Using the Dell Diagnostics."...
  • Page 109 CD. Then turn off the computer, reinstall the hard drive, and restart the computer. If the problem persists, try another drive. Run the Hard-Disk Drive tests as described in "Using the Dell Diagnostics." — The hard drive does not respond to...
  • Page 110 E Y B O A R D D A T A L I N E F A I L U R E connection. Run the Keyboard Controller test as described in "Using the Dell Diagnostics." — For external keyboards or keypads, E Y B O A R D S T U C K K E Y F A I L U R E check the cable connection.
  • Page 111 O T I M E R T I C K I N T E R R U P T malfunctioning. Run the System Set tests as described in "Using the Dell Diagnostics." — A floppy disk is in the floppy drive.
  • Page 112 — A chip on the system board may be malfunctioning. H U T D O W N F A I L U R E Run the System Set tests as described in "Using the Dell Diagnostics." — System configuration settings are...

  • Page 113: Video And Display Problems

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\problems.fm — Insert a disk I S N O T A C C E S S I B L E H E D E V I C E I S N O T R E A D Y into the drive and try again.

  • Page 114: If The Display Is Difficult To Read

    I D E O D I A G N O S T I C S T E S T S you still have a display problem, but the display is not completely blank, run the Video device group in the Dell Diagnostics. Then contact Dell.

  • Page 115: If Only Part Of The Display Is Readable

    Turn on the computer and the monitor and adjust the monitor brightness and contrast controls. If the external monitor works, the computer display or video controller may be defective. Contact Dell. Sound and Speaker Problems Fill out the Diagnostics Checklist as you complete these checks.

  • Page 116: If You Have A Problem With External Speakers

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\problems.fm 20 00 I N D O W S O N L Y E N S U R E T H A T D I G I T A L A U D I O F O R T H E —...

  • Page 117: Printer Problems

    U N T H E I S C E V I C E S D I A G N O S T I C T E S T Dell Diagnostics." If the tests complete successfully, the controller is functioning properly.
  • Page 118 Swap the printer cable with a cable that you know is working. Turn on the printer and computer, and try again to print. If you print successfully, contact Dell for assistance in obtaining a new printer cable. — Ensure that the electrical outlet is E S T T H E E L E C T R I C A L O U T L E T working by testing it with another device, such as a lamp.

  • Page 119: Modem And Internet Connection Problems

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\problems.fm Modem and Internet Connection Problems NOTICE: Connect the modem to an analog telephone wall jack only. Connecting the modem to a digital telephone network may damage the modem. NOTICE: Modem and network connectors look similar. Do not plug a telephone line into the network connector.
  • Page 120 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\problems.fm ) — See your telephone U R N O F F C A L L W A I T I N G C A T C H P H O N E directory for instructions on deactivating this feature. Then adjust the dial-up networking connection properties.

  • Page 121: Touch Pad Or Mouse Problems

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\problems.fm — E R I F Y T H A T T H E M O D E M I S C O M M U N I C A T I N G W I T H I N D O W S Windows XP Click the Start button and click Control Panel.

  • Page 122: External Keyboard Problems

    E S T T H E M O U S E C O N T R O L L E R affects pointer movement) and the operation of the touch pad or mouse buttons, run the Mouse test in the Pointing Devices test group in the Dell Diagnostics. — See "Reinstalling Drivers and...
  • Page 123 MS-DOS the keyboard cable and check it for damage, and firmly reconnect the cable. mode or when running the Dell Diagnostics or the If you are using a keyboard extension cable, disconnect it and connect the system setup program.

  • Page 124: Unexpected Characters

    N S U R E T H A T A N E X T E R N A L F L O P P Y D R I V E I S C O N N E C T E D T O T H E — Install the floppy drive in the Dell D/Bay or use the optional C O M P U T E R USB cable to connect the floppy drive to the computer.

  • Page 125: If You Cannot Play A Cd, Cd-Rw, Dvd, Or Dvd+Rw

    • If a drive error message appears, see "Error Messages" for an explanation. • Run the Diskette tests as described in "Using the Dell Diagnostics." If you cannot play a CD, CD-RW, DVD, or DVD+RW High-speed CD drive vibration is normal and may cause noise. The noise...

  • Page 126: If You Hear An Unfamiliar Scraping Or Grinding Sound

    If a drive error message appears, see "Error Messages" for an explanation. Run the IDE Drives tests as described in the Dell Diagnostics. If you cannot eject the CD, CD-RW, DVD, or DVD+RW drive tray Ensure that the computer is shut down.

  • Page 127: If You Have Problems With A Hard Drive

    Properties. Click the Tools tab. Under Error-checking, click Check Now. Click Start. • Run the IDE Drives tests as described in the Dell Diagnostics. PC Card Problems P C C — Ensure that the PC Card is properly inserted into...

  • Page 128: Smart Card Problems

    Contact Dell. F Y O U H A V E P R O B L E M S W I T H A S M A R T C A R D N O T P R O V I D E D B Y —...

  • Page 129: General Program Problems

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\problems.fm General Program Problems Fill out the Diagnostics Checklist as you complete these checks. A program crashes NOTE: Software usually includes installation — Many software manufacturers E E T H E S O F T W A R E D O C U M E N T A T I O N instructions in its maintain websites with information that may help you solve the problem.

  • Page 130: Error Messages Appear

    CAUTION: Perform this procedure only after you are certain that it is safe to do so. If the computer is connected to an electrical outlet, Dell recommends that you turn off AC power at the circuit breaker before attempting to remove the power cables from the electrical outlet.

  • Page 131: If You Drop Or Damage Your Computer

    If the computer does not start, or if you cannot identify the damaged NOTE: See your System Information Guide components, contact Dell information on your warranty coverage. If You Drop or Damage Your Computer Save and close any open files, exit any open programs, and shut down the computer.

  • Page 132: Resolving Other Technical Problems

    U P P O R T W E B S I T E with general usage, installation, and troubleshooting questions. See "Getting Help" for a description of the hardware and software support provided by Dell. — Go to support.dell.com and then click E-Mail Dell in the M A I L E L L Communicate list.
  • Page 133 S E C T I O N 1 5 U s i n g t h e D e l l D i a g n o s t i c s FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\diag.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 134: When To Use The Dell Diagnostics

    Dell's service and support personnel. NOTICE: Use the Dell Diagnostics to test only your Dell computer. Using this program with other computers may cause incorrect computer responses or result in error messages.

  • Page 135: Starting The Dell Diagnostics

    • Error messages that appear if any problems are detected Starting the Dell Diagnostics The Dell Diagnostics is located on a hidden Diagnostic utility partition on your hard drive. Shut down the computer. NOTE: If your computer cannot display a screen If the computer is connected to a docking device (docked), undock it.
  • Page 136 Booting Dell Diagnostic Utility Partition. Press any key to continue Press any key to start the Dell Diagnostics from the Diagnostics utility partition on your hard drive. After the Dell Diagnostics loads and the Main Menu screen appears, click the button for the option you want.
  • Page 137 When you have finished running a test, close the screen to return to the Main Menu screen. To exit the Dell Diagnostics and reboot the computer, close the Main Menu screen. D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...
  • Page 138 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\diag.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY U s i n g t h e D e l l D i a g n os ti c s...
  • Page 139 S E C T I O N 1 6 C l e a n i n g Yo u r C o m p u t e r FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\cleaning.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 140: Computer, Keyboard, And Display

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\cleaning.fm Shut down the computer through the Start menu. Ensure that your computer and attached devices are turned off. If your computer and attached devices did not automatically turn off when you shut down your computer, turn them off now. Remove the battery.

  • Page 141: Optical Media

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\cleaning.fm Optical Media NOTICE: Always use compressed air to clean the lens in the drive, and follow the instructions that are included with the compressed air. Never touch the lens in the drive. If you notice problems, such as skipping, with the playback quality of your CDs or DVDs, try cleaning the discs.
  • Page 142 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\cleaning.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY Cleaning Yo ur Computer...
  • Page 143 S E C T I O N 1 7 R e i n s t a l l i n g S o f t w a r e FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\drivers.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 144: Reinstalling Drivers And Utilities

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\drivers.fm Reinstalling Drivers and Utilities Dell ships your computer to you with required drivers and utilities already installed—no further installation or configuration is needed. Drivers and Utilities NOTICE: The CD may contain drivers for operating systems that are not on your computer. Ensure that you are installing software appropriate for your operating system.

  • Page 145: Manually Reinstalling Drivers For Windows Xp

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\drivers.fm Click the Install button (if present) to begin installing the driver or utility. At the welcome screen, follow the screen prompts to complete the installation. If no Install button is present, automatic installation is not an option. For installation instructions, either see the appropriate instructions in the following subsections, or click Extract, follow the extracting instructions, and read the readme file.

  • Page 146: Using The Windows Xp Device Driver Rollback

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\drivers.fm Using the Windows XP Device Driver Rollback If you install a new device driver that causes system instability, you can use the Windows XP Device Driver Rollback to replace the new device driver with the previously installed version of the device driver. If you cannot reinstall your previous driver by using the Device Driver Rollback process, then use System Restore...

  • Page 147: Resolving Software And Hardware Incompatibilities

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\drivers.fm Click Browse to browse to the location to which you previously extracted the driver files. When the name of the appropriate driver appears, click Next. Click Finish and restart your computer. Resolving Software and Hardware Incompatibilities ® ®...

  • Page 148: Windows 2000

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\drivers.fm You can also use the Windows XP Hardware Troubleshooter. To use the troubleshooter, click the Start button and click Help and Support. Type in the Search field, and then click the arrow hardware troubleshooter to start the search. Click Hardware Troubleshooter in the Search Results list.
  • Page 149 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\drivers.fm ® ® Using Microsoft Windows System Restore The Microsoft Windows XP operating system provides a System Restore feature that allows you to return your computer to an earlier operating state if changes to the computer’s hardware, software (including new hardware or program installations), or system settings have left the computer in an undesirable operating state.

  • Page 150: Creating A Restore Point

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\drivers.fm Creating a Restore Point You can either use the System Restore Wizard or manually create a restore point. Using the System Restore Wizard To use the System Restore Wizard, click the Start button, click Help and Support, click System Restore, and then follow the instructions in the System Restore Wizard window.

  • Page 151: Undoing The Last System Restore

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\drivers.fm Click a calendar date to which you want to restore your computer. The Select a Restore Point screen provides a calendar that allows you to see and select restore points. All calendar dates with available restore points appear in bold. Select a restore point and click Next.

  • Page 152: Before You Reinstall

    XP . The options can overwrite files and possibly affect programs installed on your hard drive. Therefore, do not reinstall Windows XP unless instructed to do so by a Dell technical support representative. NOTICE: To prevent conflicts with Windows XP , disable any virus protection software installed on your computer before you reinstall Windows XP .
  • Page 153 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\drivers.fm When the message appears, Press any key to boot from CD press any key. Windows XP Setup When the Windows XP Setup screen appears, press select To set up Windows now. Read the information on the Microsoft Windows Licensing Agreement screen, and press to accept the license agreement.

  • Page 154: Reinstalling Drivers And Software

    CD provides options for reinstalling the Windows 2000 operating system. The options can potentially overwrite files installed by Dell and possibly affect programs installed on your hard drive. Therefore, do not reinstall your operating system unless instructed to do so by a Dell technical support representative.
  • Page 155 Shut down the computer through the Start menu and restart the computer. Press immediately after the DELL™ logo appears. If the operating system logo appears, wait until you see the Windows desktop, and then shut down the computer and try again.

  • Page 156: Enabling Hibernate Mode

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\drivers.fm When the Computer Name and Administrator Password window appears, enter a name for your computer and a password, if desired. Then click Next. Enter the date and time in the Date and Time Settings window and click Next. Windows 2000 installs components and configures the computer.
  • Page 157 S E C T I O N 1 8 A d d i n g a n d R e p l a c i n g Pa r t s FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\r_r.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 158: Adding Memory

    NOTE: Memory modules CAUTION: Before working inside your computer, read the safety System Information Guide purchased from Dell are instructions in your covered under your Ensure that the work surface is flat and clean to prevent scratching the computer warranty.
  • Page 159 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\r_r.fm NOTICE: To prevent damage to the memory module connector, do not use tools to spread the memory-module securing clips. If you are replacing a memory module, remove the existing module: Use your fingertips to carefully spread apart the securing clips on each end of the memory module connector until the module pops Remove the module from the connector.
  • Page 160 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\r_r.fm 1 memory module 2 securing clips (2) Ground yourself and install the new memory module: Align the notch in the module edge connector with the tab in the connector slot. Slide the module firmly into the slot at a 45-degree angle, and rotate the module down until it clicks into place.

  • Page 161: Installing A Memory Module Under The Keyboard

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\r_r.fm NOTE: If the memory module is not installed properly, the computer may not boot properly. No error message indicates this failure. Replace the cover. NOTICE: If the cover is difficult to close, remove the module and reinstall it. Forcing the cover to close may damage your computer.
  • Page 162 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\r_r.fm 1 captive screws (2) 2 DIMM1 cover 3 memory module 4 securing clips (2) 5 securing tabs (3) NOTICE: To prevent damage to the memory module connector, do not use tools to spread the memory-module securing clips. If you are replacing a memory module, remove the existing module: Use your fingertips to carefully spread apart the securing clips on each end of the memory module connector until the module pops...

  • Page 163: Adding A Modem

    General tab. Adding a Modem If you ordered the optional modem at the same time that you ordered your computer, Dell installed the modem for you. CAUTION: Before working inside your computer, read the safety System Information Guide...
  • Page 164 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\r_r.fm If the computer is connected to a docking device (docked), undock it. See the documentation that came with your docking device for instructions. Disconnect the computer from the electrical outlet. Wait 10 to 20 seconds, and then disconnect any attached devices. Remove any installed PC Cards and the battery.

  • Page 165: Replacing The Keyboard

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\r_r.fm Connect the modem cable to the modem. NOTICE: The cable connectors are keyed for correct insertion; do not force the connections. Align the modem with the screw hole, and press the modem into the connector on the system board. Install the screw to secure the modem to the system board.
  • Page 166 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\r_r.fm 1 keyboard 2 keyboard pull tab 3 screws (2) 4 securing tabs (5) 5 keyboard-connector pull 6 interface connector (system board) Rest the keyboard face down on the palm rest. Pull straight up on the pull tab that is attached to the keyboard connector to disconnect the connector from the interface connector on the system board.

  • Page 167: Adding A Mini Pci Card

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\r_r.fm Connect the keyboard connector to the interface connector on the system board. Insert the five securing tabs on the keyboard into their respective slots in the palm rest. Replace the two screws at the top of the keyboard. Replace the center control cover and snap it down so that it is flush with the palm rest.
  • Page 168 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\r_r.fm 1 antenna cables (2) 2 Mini PCI card Release the Mini PCI card by spreading the metal securing tabs until the card pops up slightly. Lift the Mini PCI card out of its connector. D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY Adding and Replacing Pa rts...
  • Page 169 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\r_r.fm 1 securing tabs(2) 2 Mini PCI card connector NOTICE: To avoid damaging the Mini PCI card, never place cables on top of or under the card. NOTICE: The connectors are keyed to ensure correct insertion. If you feel resistance, check the connectors and realign the card.

  • Page 170: Replacing The Hard Drive

    NOTICE: Hard drives are extremely fragile; even a slight bump can damage the drive. To replace the hard drive in the hard drive bay: NOTE: Dell does not guarantee compatibility Ensure that the work surface is flat and clean to prevent scratching the or provide support for computer cover.

  • Page 171: Adding A Bluetooth™ Module

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\r_r.fm Slide the hard drive out of the computer. Remove the new drive from its packaging. Save the original packaging for storing or shipping the hard drive. NOTICE: Use firm and even pressure to slide the drive into place. If you use excessive force, you may damage the connector.
  • Page 172 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\r_r.fm Save and close any open files, exit any open programs, and then shut down the computer. If the computer is connected to a docking device (docked), undock it. See the documentation that came with your docking device for instructions.
  • Page 173 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\r_r.fm 1 Bluetooth module cover 2 captive screw 3 battery bay If a Bluetooth module is not already installed, go to step 9. If you are replacing the Bluetooth module, remove the existing module: Pull the Bluetooth module out of the slot. Disconnect the cable from the module.
  • Page 174 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\r_r.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY Adding and Replacing Pa rts...
  • Page 175 S E C T I O N 1 9 U s i n g t h e S y s t e m S e t u p P r o g r a m FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\setup.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 176: Overview

    System security and hard-drive password settings NOTICE: Unless you are an expert computer user or are directed to do so by Dell technical support, do not change the settings for the system setup program. Certain changes might make your computer work incorrectly.

  • Page 177: System Setup Screens

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\setup.fm System Setup Screens On each screen, the system setup options are listed at the left. To the right of each option is the setting or value for that option. You can change settings that appear as white type on the screen. Options or values that you cannot change (because they are determined by the computer) appear as blue text.

  • Page 178: Changing Com Ports

    Performing a One-Time Boot You can set a one-time-only boot sequence without entering the system setup program. (You can also use this procedure to boot the Dell Diagnostics on the diagnostics utility partition on your hard drive.) Turn off the computer.

  • Page 179: Enabling The Infrared Sensor

    Enabling the Infrared Sensor Enter the system setup program: Turn on your computer. Press when the DELL™ logo appears. Press until you locate Infrared Data Port under Basic Device Configuration. Press the down-arrow key to select the Infrared Data Port setting, and NOTE: Ensure that the press the right-arrow key to change the setting to a COM port.
  • Page 180 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\setup.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY U s i n g t h e S y s te m S e t u p Pro g r a m...
  • Page 181 S E C T I O N 2 0 A l e r t S t a n d a r d Fo r m a t ( A S F ) FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\asf.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...
  • Page 182 Periodic heartbeats have been transmitted to verify Entity Presence system presence. For more information about Dell's ASF implementation, see ASF for Dell Portable Computers and the ASF Administrator's Guide for Dell Portable Computers, which are available on the Dell Support website at support.dell.com.
  • Page 183 S E C T I O N 2 1 G e t t i n g H e l p FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\gethelp.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 184: Technical Assistance

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\gethelp.fm Technical Assistance If you need help with a technical problem, Dell is ready to assist you. CAUTION: If you need to remove the computer covers, first disconnect the computer power and modem cables from all electrical outlets.

  • Page 185: Autotech Service

    AutoTech Service Dell's automated technical support service—AutoTech—provides recorded answers to the questions most frequently asked by Dell customers about their portable and desktop computers. When you call AutoTech, use your touch-tone telephone to select the subjects that correspond to your questions.

  • Page 186: Automated Order-Status Service

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\gethelp.fm Automated Order-Status Service To check on the status of any Dell products that you have ordered, you can go to support.dell.com, or you can call the automated order-status service. A recording prompts you for the information needed to locate and report on your order.

  • Page 187: Before You Call

    Dell’s receiving dock and returned to you. Before You Call NOTE: Have your Express Service Code ready when you call. The code helps Dell’s automated-support telephone system direct your call more efficiently. Remember to fill out the Diagnostics Checklist. If possible, turn on your computer before you call Dell for technical assistance and call from a telephone at or near the computer.
  • Page 188 Address: Phone number: Service Tag (bar code on the back of the computer): Express Service Code: Return Material Authorization Number (if provided by Dell support technician): Operating system and version: Devices: Expansion cards: Are you connected to a network? Yes No...

  • Page 189: Contacting Dell

    NOTE: Toll-free numbers are for use within the country for which they are listed. When you need to contact Dell, use the electronic addresses, telephone numbers, and codes provided in the following table. If you need assistance in determining which codes to use, contact a local or an international operator.
  • Page 190 Local Numbers, and Country Code Toll-Free Numbers City Code Australia (Sydney) E-mail (Australia): au_tech_support@dell.com International Access Code: 0011 E-mail (New Zealand): nz_tech_support@dell.com Country Code: 61 Home and Small Business 1-300-65-55-33 City Code: 2 Government and Business toll-free: 1-800-633-559 Preferred Accounts Division (PAD)
  • Page 191 City Code Bermuda General Support 1-800-342-0671 Bolivia General Support toll-free: 800-10-0238 Brazil Website: www.dell.com/br International Access Code: 00 Customer Support, Technical Support 0800 90 3355 Country Code: 55 Tech Support Fax 51 481 5470 City Code: 51 Customer Care Fax...
  • Page 192 Website and E-Mail Address Local Numbers, and Country Code Toll-Free Numbers City Code China (Xiamen) Tech Support website: support.ap.dell.com/china Country Code: 86 Tech Support E-mail: cn_support@dell.com City Code: 592 Tech Support Fax 818 1350 Home and Small Business Technical Support...
  • Page 193 International Access Code Website and E-Mail Address Local Numbers, and Country Code Toll-Free Numbers City Code Denmark (Copenhagen) Website: support.euro.dell.com International Access Code: 00 E-mail Support (portable computers): den_nbk_support@dell.com Country Code: 45 E-mail Support (desktop computers): den_support@dell.com E-mail Support (servers): Nordic_server_support@dell.com...
  • Page 194 International Access Code Website and E-Mail Address Local Numbers, and Country Code Toll-Free Numbers City Code France (Paris) (Montpellier) Website: support.euro.dell.com International Access Code: 00 E-mail: support.euro.dell.com/fr/fr/emaildell/ Country Code: 33 Home and Small Business City Codes: (1) (4) Technical Support...
  • Page 195 Hong Kong Technical Support (Dimension™ and Inspiron™) 296 93188 International Access Code: 001 Technical Support (OptiPlex™, Latitude™, and 296 93191 Dell Precision™) Country Code: 852 Customer Service (non-technical, post-sales issues) 800 93 8291 Transaction Sales toll-free: 800 96 4109 Large Corporate Accounts HK...
  • Page 196 International Access Code Website and E-Mail Address Local Numbers, and Country Code Toll-Free Numbers City Code Italy (Milan) Website: support.euro.dell.com International Access Code: 00 E-mail: support.euro.dell.com/it/it/emaildell/ Country Code: 39 Home and Small Business City Code: 02 Technical Support 02 577 826 90...
  • Page 197 0120-198-226 Technical Support outside of Japan (Dimension and 81-44-520-1435 Inspiron) Technical Support (Dell Precision™, OptiPlex™, toll-free:0120-198-433 and Latitude™) Technical Support outside of Japan (Dell Precision, 81-44-556-3894 OptiPlex, and Latitude) 24-Hour Automated Order Service 044-556-3801 Customer Care 044-556-4240 Business Sales Division (up to 400 employees)
  • Page 198 Sales (Austin, Texas, U.S.A.) 512 728-4397 SalesFax (Austin, Texas, U.S.A.) 512 728-4600 or 512 728-3772 Luxembourg Website: support.euro.dell.com International Access Code: 00 E-mail: tech_be@dell.com Country Code: 352 Technical Support (Brussels, Belgium) 02 481 92 88 Home/Small Business Sales (Brussels, Belgium)
  • Page 199 Country Code: 31 (Enterprise): nl_server_support@dell.com City Code: 20 (Latitude): nl_latitude_support@dell.com (Inspiron): nl_inspiron_support@dell.com (Dimension): nl_dimension_support@dell.com (OptiPlex): nl_optiplex_support@dell.com (Dell Precision): nl_workstation_support@dell.com Technical Support 020 674 45 00 Technical Support Fax 020 674 47 66 Home/Small Business Customer Care 020 674 42 00...
  • Page 200 International Access Code Website and E-Mail Address Local Numbers, and Country Code Toll-Free Numbers City Code New Zealand E-mail (New Zealand): nz_tech_support@dell.com International Access Code: 00 E-mail (Australia): au_tech_support@dell.com Country Code: 64 Home and Small Business 0800 446 255 Government and Business...
  • Page 201 International Access Code Website and E-Mail Address Local Numbers, and Country Code Toll-Free Numbers City Code Portugal E-mail: support.euro.dell.com/es/es/emaildell/ International Access Code: 00 Technical Support 800 834 077 Country Code: 35 Customer Care 800 300 415 or 800 834 075...
  • Page 202 International Access Code: 00 E-mail: swe_support@dell.com Country Code: 46 E-mail Support for Latitude and Inspiron: Swe-nbk_kats@dell.com City Code: 8 E-mail Support for OptiPlex: Swe_kats@dell.com E-mail Support for Servers: Nordic_server_support@dell.com Technical Support 08 590 05 199 Relational Customer Care 08 590 05 642...
  • Page 203 International Access Code Website and E-Mail Address Local Numbers, and Country Code Toll-Free Numbers City Code Switzerland (Geneva) Website: support.euro.dell.com International Access Code: 00 E-mail: swisstech@dell.com Country Code: 41 E-mail for French-speaking HSB and Corporate Customers: support.euro.dell.com/ch/fr/emaildell/ City Code: 22...
  • Page 204 Area Codes, International Access Code Website and E-Mail Address Local Numbers, and Country Code Toll-Free Numbers City Code U.K. (Bracknell) Website: support.euro.dell.com International Access Code: 00 Customer Care website: dell.co.uk/lca/customerservices Country Code: 44 E-mail: dell_direct_support@dell.com City Code: 1344 Technical Support (Corporate/Preferred...
  • Page 205 1-888-798-7561 Software and Peripherals Sales toll-free: 1-800-671-3355 Spare Parts Sales toll-free: 1-800-357-3355 Extended Service and Warranty Sales toll-free: 1-800-247-4618 toll-free: 1-800-727-8320 Dell Services for the Deaf, Hard-of-Hearing, or toll-free: 1-877-DELLTTY Speech-Impaired (1-877-335-5889) U.S. Virgin Islands General Support 1-877-673-3355 Venezuela...
  • Page 206 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\gethelp.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY Getting Help...
  • Page 207 S E C T I O N 2 2 S p e c i f i c a t i o n s Microprocessor System Information PC Card Smart Card Memory Ports and Connectors Communications Video Audio Display Keyboard Touch Pad Track Stick Battery AC Adapter...
  • Page 208 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\specs.fm Microprocessor ® Microprocessor type Intel Centrino™ Mobile Technology or ® Intel Pentium L1 cache 32 KB instruction and 32 KB write-back data cache L2 cache 1 MB External bus frequency 400 MHz, source synchronous processor system bus System Information System chip set Intel 855GM...
  • Page 209 Video 15-hole connector Audio microphone connector, stereo headphone/speakers connector two 4-pin USB 2.0-compliant connectors (including the Dell™ D/Bay connector) Dell™ D/Bay connector 4-pin power supply and 4-pin USB 2.0- compliant connector Infrared sensor compatible with IrDA Standard 1.1 (Fast IR) and IrDA Standard 1.0 (Slow IR)
  • Page 210 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\specs.fm (continued) Communications Type v.92 56K MDC Controller softmodem Interface internal AC’97 bus Network adapter 10/100/1000 Ethernet LAN on system board Wireless Internal Mini PCI Wi-Fi and Bluetooth™ wireless support (optional) Video Video type Intel UMA integrated Video controller 855GM chip set Video memory 1 MB with Intel DVMT up to 32 MB (with...
  • Page 211 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\specs.fm (continued) Display Height 214.3 mm (8.4 inches) Width 285.7 mm (11.3 inches) Diagonal 357.1 mm (14.1 inches) Maximum resolutions 1024 x 768 at 256 K (or 262,144) colors Response time (typical) 20-ms rise (maximum), 30-ms fall (maximum) Refresh rate 60 Hz Operating angle...
  • Page 212 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\specs.fm Track Stick X/Y position resolution (graphics table mode) 250 count/sec @ 100 gf Size protrudes higher than surrounding keycaps Battery Type 6-cell "smart" lithium ion (42 WHr) 4-cell "smart" lithium ion (27 WHr) Dimensions: Depth 88.5 mm (3.48 inches) Height 21.5 mm (0.83 inch) Width...
  • Page 213 Width 290 mm (11.42 inches) Depth 242.5 mm (9.55 inches) Weight: Computer with 4-cell battery 1.7 kg (3.7 lb) Dell D/Bay (alone) 256 g (0.56 lb) CD drive (alone) 215 g (0.47 lb) Environmental Temperature range: Operating 0° to 35°C (32° to 95°F) Storage –40°...
  • Page 214 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\specs.fm (continued) Environmental Operating 10% to 90% (noncondensing) Storage 5% to 95% (noncondensing) Maximum vibration (using a random-vibration spectrum that simulates user environment): Operating 0.9 GRMS Storage 1.3 GRMS Maximum shock (measured with hard drive in head-parked position and a 2-ms half-sine pulse): Operating 122 G...
  • Page 215 S E C T I O N 2 3 A p p e n d i x FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\appendix.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...

  • Page 216: Ergonomic Computing Habits

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\appendix.fm Ergonomic Computing Habits CAUTION: Improper or prolonged keyboard use may result in injury. CAUTION: Viewing the display or external monitor screen for extended periods of time may result in eye strain. For comfort and efficiency, observe the following ergonomic guidelines when setting up and using your computer workstation: •...

  • Page 217: Regulatory Notices

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\appendix.fm References: 1. American National Standards Institute. ANSI/HFES 100: American National Standards for Human Factors Engineering of Visual Display Terminal Workstations. Santa Monica, CA: Human Factors Society, Inc., 1988. 2. Human Factors and Ergonomics Society. BSR/HFES 100 Draft standard for trial use: Human Factors Engineering of Computer Workstations.
  • Page 218 EMC classification for the intended environment. For parallel printers, a cable is available from Dell. If you prefer, you can order a cable from Dell on the World Wide Web at accessories.us.dell.com/sna/category.asp?category_id=4117. Most Dell computers are classified for Class B environments. However, the inclusion of certain options can change the rating of some configurations to Class A.

  • Page 219: Fcc Notices (U.s. Only)

    Once you have determined your computer’s FCC classification, read the appropriate FCC notice. Note that FCC regulations provide that changes or modifications not expressly approved by Dell could void your authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: •...
  • Page 220 FCC regulations: • Model number: PPT • Company name: Dell Computer Corporation One Dell Way Round Rock, Texas 78682 USA 512-338-4400 Modem Regulatory Information This equipment complies with Part 68 of the FCC Rules. On the bottom of...
  • Page 221 If you experience trouble with this telephone equipment, see "Contacting Dell" to find the appropriate telephone number for obtaining customer assistance. If the equipment is causing harm to the telephone network, the telephone company may request that you disconnect the equipment until the problem is resolved.

  • Page 222: Ic Notice (Canada Only)

    Industry Canada (IC) Interference-Causing Equipment Standard #3 (ICES-003) as Class B digital devices. To determine which classification (Class A or B) applies to your computer (or other Dell digital apparatus), examine all registration labels located on the bottom, side, or the back panel of your computer (or other digital apparatus).
  • Page 223 The REN for the internal modem as stated on the IC regulatory label located on the bottom of the computer is 0.6 B. The following information is provided in compliance with IC regulations: Dell Computer Corporation One Dell Way Round Rock, TX 78682 USA 512-338-4400 D E L L C O N F I D E N T I A L –...

  • Page 224: Ce Notice (European Union)

    Class A is for typical commercial areas. • Class B is for typical domestic areas. This Dell device is classified for use in a typical Class B domestic environment. A "Declaration of Conformity" in accordance with the preceding directives and standards has been made and is on file at Dell Computer Corporation Products Europe BV, Limerick, Ireland.

  • Page 225: New Zealand Telecom Warnings

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\appendix.fm New Zealand Telecom Warnings General "The grant of a Telepermit for any item of terminal equipment indicates only that Telecom has accepted that the item complies with minimum conditions for connection to its network. It indicates no endorsement of the product by Telecom, nor does it provide any sort of warranty.
  • Page 226 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\appendix.fm "This equipment shall not be set up to make automatic calls to the Telecom ‘111’ Emergence Service." "If a charge for local calls is unacceptable, the ‘Dial’ button should NOT be used for local calls. Only the 7-digits of the local number should be dialed from your telephone.

  • Page 227: Energy Star ® Compliance

    ® comply with EPA ENERGY STAR requirements as configured when shipped by Dell. Any changes you make to this configuration (such as installing additional expansion cards or drives) may increase the computer’s power consumption beyond ® the limits set by the EPA's ENERGY STAR Computers program.

  • Page 228: En 55022 Compliance (Czech Republic Only)

    VCCI Notice (Japan Only) Most Dell computers are classified by the Voluntary Control Council for Interference (VCCI) as Class B information technology equipment (ITE). However, the inclusion of certain options can change the rating of some configurations to Class A.
  • Page 229 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\appendix.fm Class A ITE This is a Class A product based on the standard of the Voluntary Control Council for Interference (VCCI) for information technology equipment. If this equipment is used in a domestic environment, radio disturbance may arise.

  • Page 230: Mic Notice (Republic Of Korea Only)

    (or other Dell digital device), examine the Republic of Korean Ministry of Information and Communications (MIC) registration labels located on your computer (or other Dell digital device). The MIC label may be located separately from the other regulatory marking applied to your product. Line two of the label identifies the emissions class for the product—"(A)"...
  • Page 231 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\appendix.fm MIC Class A Regulatory Label If the regulatory label includes the following marking, your computer is a Class A product: Class B Device Please note that this device has been approved for nonbusiness purposes and may be used in any environment, including residential areas. MIC Class B Regulatory Label If the regulatory label includes the following marking, your computer is a Class B product.

  • Page 232: Polish Center For Testing And Certification Notice

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\appendix.fm Polish Center for Testing and Certification Notice The equipment should draw power from a socket with an attached protection circuit (a 3-prong socket). All equipment that works together (computer, monitor, printer, and so on) should have the same power supply source.

  • Page 233: Bsmi Notice (Taiwan Only)

    FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\appendix.fm BSMI Notice (Taiwan Only) If you find a mark on the regulatory label on the bottom, side, or back panel of your computer, the following section is applicable: D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY Appendix...
  • Page 234 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\appendix.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY Appendix...

  • Page 235: Nom Information (Mexico Only)

    (NOM): Exporter: Dell Computer Corporation One Dell Way Round Rock, TX 78682 Importer: Dell Computer de México, S.A. de C.V. Paseo de la Reforma 2620 - 11° Piso Col. Lomas Altas 11950 México, D.F. Ship to: Dell Computer de México, S.A.

  • Page 236: Warranty And Return Policy

    Dell Computer Corporation (“Dell”) manufactures its hardware products from parts and components that are new or equivalent to new in accordance with industry-standard practices. For information about the Dell warranty for your computer, see the System Information Guide. D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...
  • Page 237 S E C T I O N 2 4 G l o s s a r y FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\glossary.fm D E L L C O N F I D E N T I A L – P R E L I M I N A R Y 1 / 2 9 / 0 3 – F O R P R O O F O N LY...
  • Page 238 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\glossary.fm Terms in this Glossary are provided for informational purposes only and may or may not describe features included with your particular computer. A C — alternating current — The form of electricity that powers your computer when you plug the AC adapter power cable into an electrical outlet. A CP I —...
  • Page 239 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\glossary.fm ™ — A wireless technology standard for short-range (9 m [29 feet]) L U E T O O T H networking devices that allows for enabled devices to automatically recognize each other. — Specifies the order of the devices from which the computer B O O T S E Q U E N C E attempts to boot.
  • Page 240 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\glossary.fm only once onto a CD-R. Once recorded, the data cannot be erased or written over. C D - R W — CD rewritable — A rewritable version of a CD. Data can be written to a CD-RW disc, and then erased and written over (rewritten). CD -RW —...
  • Page 241 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\glossary.fm DMA — direct memory access — A channel that allows certain types of data transfer between RAM and a device to bypass the microprocessor. — See APR. D O C K I N G D E V I C E DMTF —...
  • Page 242 E R V I C E O D E Dell™ computer. Use the Express Service Code when contacting Dell for assistance. Express Service Code service may not be available in some countries. — A display setting that allows you to use a second E X T E N D E D D I S P L A Y M O D E monitor as an extension of your display.
  • Page 243 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\glossary.fm or disk is formatted, the existing information on it is lost. FSB — front side bus — The data path and physical interface between the microprocessor and RAM. F TP — file transfer protocol — A standard Internet protocol used to exchange files between computers connected to the Internet.
  • Page 244 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\glossary.fm — hertz — A unit of frequency measurement that equals 1 cycle per second. Computers and electronic devices are often measured in kilohertz (kHz), megahertz (MHz), gigahertz (GHz), or terahertz (THz). IC — Industry Canada — The Canadian regulatory body responsible for regulating emissions from electronic equipment, much as the FCC does in the United States.
  • Page 245 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\glossary.fm KB — kilobyte — A unit of data that equals 1024 bytes but is often referred to as 1000 bytes. — A command requiring you to press multiple keys at the K E Y B O A R D S H O R T C U T same time.
  • Page 246 — A bay that supports devices such as optical drives, a second M O D U L E B A Y battery, or a Dell TravelLite™ module. — The high-resolution TV-like device that displays computer output. M O N I T O R —...
  • Page 247 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\glossary.fm — A drive that uses optical technology to read or write data P T I C A L R I V E from CDs, DVDs, or DVD+RWs. Example of optical drives include CD drives, DVD drives, CD-RW drives, and CD-RW/DVD combo drives. —...
  • Page 248 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\glossary.fm PX E — pre-boot execution environment — A WfM (Wired for Management) standard that allows networked computers that do not have an operating system to be configured and started remotely. R AI D — redundant array of independent disks — A system of two or more drives working together for performance and fault tolerance.
  • Page 249 — A bar code label on your computer that identifies your E R V I C E computer when you access Dell Support at support.dell.com or when you call Dell for customer service or technical support. — A program that is used to install and configure hardware and S E T U P P R O G R A M software.
  • Page 250 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\glossary.fm — Prevent voltage spikes, such as those that may occur S U R G E P R O T E C T O R S during an electrical storm, from entering the computer through the electrical outlet. Surge protectors do not protect against lightning strikes or against brownouts, which occur when the voltage drops more than 20 percent below the normal AC-line voltage level.
  • Page 251 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\glossary.fm UPS — uninterruptible power supply — A backup power source used when the electrical power fails or drops to an unacceptable voltage level. A UPS keeps a computer running for a limited amount of time when there is no electrical power. UPS systems typically provide surge suppression and may also provide voltage regulation.
  • Page 252 FILE LOCATION: S:\SYSTEMS\Pebble\UG\A00\English\glossary.fm A common type of virus is a boot virus, which is stored in the boot sectors of a floppy disk. If the floppy disk is left in the drive when the computer is shut down and then turned on, the computer is infected when it reads the boot sectors of the floppy disk expecting to find the operating system.

Table of Contents
