- Page 3 Dear customer! This electric integrated gas cooker is manufactured for household use. Our appliances are packed in the environmentally friendly materials which may be recycled, deposited or destroyed without any hazard to the environment. Such packaging materials are also labeled accordingly. Once the life cycle your appliance is over, make sure not to pollute the environment, and deliver it to the authorized collectors of old household appliances.
- Page 4 TECHNICAL INSTRUCTIONS AND INSTALLATION IMPORTANT • Installation of the appliance (installation class:3) into a kitchen worktop and its connection to the power mains and the gas supply may only be performed by an adequately qualified WARNINGS technician. • When the appliance is in use, additional heat and moisture are emitted into the room. When the appliance is used for a prolonged period of time at a high performance level, intensive ventilation or use of kitchen hood may is required in the room where the appliance is installed.
- Page 5 INSTALLATION Important warnings • Installation of the appliance into a kitchen worktop and its connection to the power mains may only be performed by an adequately qualified technician. • Veneer or other fi nish of the piece of kitchen furniture into which the hob is to be built in should be treated with heat resistant glue (100°C);...
- Page 6 sharp objects. Installation procedure • Worktop must be placed absolutely horizontal. • Suitably protect the edges of the cut aperture. (with springs) • Connect the cooking hob to the mains power supply (see instructions for the connection of the cooking hob to mains power supply). •...
- Page 7 Connection: • Incorrect connection may destroy parts of the appliance, making the warranty void. • Before connecting the appliance, make sure the voltage indicated on the rating plate is consistent with the voltage in your home network. Connection voltage should be checked by a qualified technician using a corresponding measuring device! •...
- Page 8 After connecting the gas hob, check the joints for any leaks. Gas supply connection plug A ISO7-1 R1/2 connection plug B Non-metal gasket with thickness of 2 mm C Pipe adapter for liquid gas (depending on the model) Only use pipes and seals in accordance with the Standards. These pipes must be installed so that, when fully extended, their length does not exceed 2000 mm.
- Page 9 TECHNICAL INFORMATION 499602 499604 499606 A= Auxiliary SR= Semirapid R= Rapid MW= Mini-Wok TC= Triple Crown i 8 ! " % B ' " 7 8 " # 3 3 ! " % ' # 3 C C D E C G D H X Y ` D a b D A c Regulated for gas G20=20mbar G20=20mbar...
- Page 10 • Use pans which are the right size for each burner. Do not use small pans on large burners. The flame should not touch the sides of the pan. • For combustion, the gas also needs air. If a pan is too large, air supply to the burner is insufficient;...
- Page 11 INSTRUCTIONS FOR USE AND MAINTENANCE OPERATION Hob control elements Gas valve closed Ignition Maximum power Minimum power User’s instructions Ignition and operation This appliance must be used for the purpose it was designed for, i.e. domestic cooking. Any of the burners other use is considered to be improper and therefore dangerous.
- Page 12 CLEANING AND MAINTENANCE Do not use a steam cleaning appliance to clean this appliance. The steam could reach the electrical components and cause a short circuit. The appliance should be cleaned regularly, preferably after each use, after cooling down. To avoid water marks and limescale deposits, use a soft cloth to dry surfaces that have been cleaned with water.
- Page 13 ceramic surface does not affect its operation or the stability of the surface. Such discolorations are mostly a result of burnt food residues or use of cookware made of materials such as aluminum or copper; these stains are difficult to remove. Warning: All damage described above predominantly relates to the aesthetics, i.e.
- Page 14 ADJUSTMENT TO A DIFFERENT TYPE OF GAS PRESTAVBA NA JINÝ DRUH PLYNU DOSTOSOWANIE DO INNEGO RODZAJU GAZU A KÉSZÜLÉK ÁTÁLLÍTÁSA MÁS TÍPUSÚ GÁZRA PREINAKA NA DRUGU VRSTU PLINA PRISPÔSOBENIE NA INÝ DRUH PLYNU PRIREDITEV NA DRUGO VRSTO PLINA Art.no. Country of destination Category Gas and supply pressures Artiklu...
