FAULT CODE TABLE

FAULT
MODULE DESCRIPTION
CODE
Left keypad fault
(switch kept activated
B2210 Cluster
more than 60
seconds)
Suspension UP/
DOWN switches
B2211 Cluster
shorted to ground
fault
Suspension UP/
B2212 Cluster DOWN switches
disconnected fault
VTS UP/DOWN
B2213 Cluster switches shorted
to ground fault
VTS UP/DOWN
B2214 Cluster switches
disconnected fault
Right keypad fault
(switch kept activated
B2220
Cluster
more than 60
seconds)
MODE/SET switches
B2221
Cluster shorted to ground
fault
MODE/SET switches
B2222
Cluster
disconnected fault
UP/DOWN switches
B2223
Cluster shorted to ground
fault
UP/DOWN switches
B2224 Cluster
disconnected fault
Brake Lever Sensor
(BRLS) signals A
C0042 iBR
open/shorted to
ground
smr2009-029
Section 03 ELECTRONIC MANAGEMENT SYSTEMS
Subsection 04 (MONITORING SYSTEM AND FAULT CODES)
POSSIBLE CAUSE
Problem with left keypad
Problem with left keypad
Problem with left keypad
Problem with left keypad
Problem with left keypad
Problem with right
keypad
Problem with right
keypad
Problem with right
keypad
Problem with right
keypad
Problem with right
keypad
Damaged sensor,
damaged circuit wires,
damaged connector
or damaged iBR pins.
Fault detected when
the engine is running or
stopped
SERVICE ACTION
The switch may be defective, verify the
functionality of the switch or the wires.
Refer to the Shop Manual for switch
diagnosis/testing procedure.
Look for pin B if shorted to ground or
pin C.
Look for pin B if disconnected
to pin 14 on the cluster.
Look for pin C if disconnected to
pin 15 on the cluster.
Look for pin A if shorted to ground or
pin C.
Look for pin A if disconnected
to pin 13 on the cluster.
Look for pin C if disconnected to
pin 15 on the cluster.
The switch may be defective, verify the
functionality of the switch or the wires.
Refer to the Shop Manual for switch
diagnosis/testing procedure.
Look for pin B if shorted to ground or
pin C.
Look for pin B if disconnected
to pin 17 on the cluster.
Look for pin C if disconnected to
pin 18 on the cluster.
Look for pin A if shorted to ground or
pin C.
Look for pin B if disconnected
to pin 16 on the cluster.
Look for pin C if disconnected to
pin 18 on the cluster
Check system circuits C03-6pos and
C01-12pos.
Check for 0.5 to 3 V on pin F
and 0.25 to 1.5 on pin C.
