Signode AMPT-12 Operation, Parts And Safe page 4

TABLE OF CONTENTS
General Safety Instructions
Specifications
Pneumatic Information
Strap Tension
Loading Seals
Cutter Adjustment
Operating Instructions
Joint Inspection
Tool:
Parts List & Views
Disassembly/Assembly
Gear Housing
Parts List & View
Disassembly/Assembly
Air Motor I8R36:
Parts List & View
Disassembly/Assembly
Troubleshooting
Maintenance
Declaration of Conformity
MODEL
AMPT-12
Page
2
4
5
8
8
8
9
10
11
17
20
20
22
24
25
33
35
SPECIFICATIONS
STRAP
TYPE WIDTH
Tenax
1822,1818,1816
Contrax
818,816,814
(12mm)
Dymax
508,506,504,502
Part No. 422910
DO NOT USE AMPT-12
WITH STEEL STRAPPING
Using strap not recommended for this
tool can result in strap breakage,
improper joint formation and tool
damage.
THICKNESS
1/2" .015" to .030"
(0.4 - 0.8mm)
4
AMPT-12
SEAL
50ASD
