PARTS LISTS & EXPLODED VIEWS, Continued
TOOL HOUSING
KEY DESCRIPTION
46A Roll Pin, 1/4,x 1-1/2
47 Motor Latch Stop
48 Jaw Support Stop
49 Drive Screw #2-3/16
50 Magazine Spring
51 Seal Pad Assembly
53 Truarc #5133-25
54 Gripper Trigger
55 Trigger Pivot
56 Gripper Spring
57 Flexloc Nut 5/16-18
58 Gripper Lever
59 Ejector Arm Spring
60 Ejector Lever
61 Ejector Spring
62 Ejector
63 Ejector Pin
64 Truarc
65 Strap latch pin
66 Strap Latch (Fixed)
67 Strap Latch (Moveable)
68 SHCS, 5/16-18 x 3/4
69 Dowel Pin 3/16 x 7/8
70 Strap Gripper
71 Cutter Block
72 Ejector Arm Pin
73 Truarc #5100-31
74 Magazine
76 Ram
77 Roll Pin, 3/32 x 1 1/16
78 Ram Release Pin
79 Ram Release Spring
80 Roll Pin, 1/4 x 3/4
82 Roller Pin
83 Cutter Blade
84 Jaw Spacer
85 Outer Jaw
86 Ram Pin
87 Crimper
88 Center Jaw
89 Flat Link
90 Forked Link
91 Toggle Pin
93 Jaw Pin
94 Jaw Support
98 Pickup Spring
QTY. PART NO.
1 070528
1 020638
1 020626
2 004939
1 020640
1 422940
1 023766
1 023756
1 023765
1 020635
3 005211
1 023758
1 423811
1 024719
1 020629
1 024415
1 020621
1 026866
1 020662
1 020601
1 020858
2 003914
1 007150
1 024414
1 024418
1 020622
2 005054
1 024710
1 020647
1 005709
1 020625
1 020646
1 005214
1 423796
1 306915
1 020659
4 422789
1 020649
2 422788
2 422907
2 020608
1 020616
2 020627
2 020615
1 422909
1 020630
