Signode AMPT-12 Operation, Parts And Safe page 11

PARTS LISTS & EXPLODED VIEWS
TOOL HOUSING
KEY DESCRIPTION
1 SHCS, 10-24 x 13/16
1A FHSCS, 10-24 x 3/4
2 SHCS, 10-24 x 1
3 Valve Latch Pin
4 Valve Latch
5 Valve Latch Spring
6 SHSS, 1/4-28 x 7/16
7 Tensioning Lever
8 Sealing Lever
9 Cover
10 Valve Lever Pin
11 Cover Gasket
12 O-Ring
14 Piston
15 O-Ring
16 Tensioner Valve Sleeve
17 O-Ring
18 Tensioner Valve
19 Valve Spring
20 Sealer Valve Sleeve
21 Sealer Valve Sleeve
22 Sealer Valve
23 Sealer Valve Spring
24 Sealer Valve Sleeve
25 Cylinder
27 Hansen Plug
28 Pipe Bushing
29 Elbow
29A Tru-Seal, 1-1/4 NPT
29B 90° Elbow, 1/4 Tube x 1/4-18 NPS
30 SHSS, 1/4-28 x 1/4
31 FHSCS, 10-24 x 1/2
32 Cover Plate
33 Sure-Seal Spring
34 Sure-Seal Pawl
35 O-Ring
36 O-Ring
37 Motor Plunger
38 Plunger Spring
39 Shoulder Bolt
40 Roll Pin, 1/8 x 13/16
41 Motor Latch
42 SHCS, 5/16-18 x 1
43 Sealer Frame
44 SHCS, 1/4-20 x 1/2
45 Roll Pin, 3/16 x 1
46 Roll Pin, 3/16x 1-1/2
QTY. PART NO.
11 180600
1 008757
2 004061
1 020658
1 020653
1 020654
1 004361
1 020656
1 020655
1 020691
1 020671
1 016906
1 020702
1 020648
6 020699
1 020651
5 020701
1 020652
1 020665
1 020660
1 020657
1 020731
1 020725
1 020732
1 020734
1 020704
1 008478
1 020710
1 023087
1 023524
1 003465
2 020729
1 020726
1 020724
1 020727
1 020728
1 020680
1 020668
1 020669
1 024726
2 004658
1 020639
1 009016
1 267632
1 023352
1 006787
1 020707
11
