GETTING TO KNOW THE WORKSTATION
Your workstation has a color display (sometimes called a color
monitor) and a text display (sometimes called an alphanumeric
display or alphanumeric monitor). A keyboard is attached to the
text display. You will use the color display to see drawings as
they are created or modified. By typing on the keyboard, you can
give instructions to the workstation and to the computer
associated with the workstation. Your typed instructions will
normally appear on the text display, also messages received from
the computer and the workstation will appear on the text display.
A graphic tablet with a stylus is also attached to the
workstation and various overlays may be purchased for the graphic
tablet. Printed on the overlays are instructions to the
workstation/computer system. By positioning the stylus over an
overlay instruction and pressing on the stylus, you can send the
. selected instruction to the workstation/computer system.
