Chapter 1: Product Introduction

Hardware Specifications

Camera
▪ Image sensor: 1/1.8" 6MP True WDR progressive scan CMOS sensor
▪ Minimum Illumination: B/W 0 lux/Color 0.1 lux
▪ Lens: Motorized lens
– 3.6-10mm, F1.5 for NCr-661-VHA
– 12-40mm, F2.1 for NCr-662-VHA
▪ Field of View (NCr-661-VHA):
– Horizontal: 11°~33°
– Vertical: 8°~25°
– Diagonal: 14°~43°
▪ Field of View (NCr-662-VHA):
– Horizontal: 40°~96°
– Vertical: 30°~75°
– Diagonal: 52°~119°
▪ Iris type: P-iris
▪ Day and night: Yes (True D/N)
▪ IR distance:
– up to 30m (20ft ~ 33ft) for NCr-661-VHA
– up to 50m (33ft ~ 66ft) for NCr-662-VHA
▪ Capture distance:
– 6m ~ 10m (20ft ~ 33ft) for NCr-661-VHA
– 10m ~ 20m (33ft ~ 66ft) for NCr-662-VHA
▪ IR wavelength: 850nm
▪ ICR: Yes
▪ WDR: Yes (True WDR)
▪ Image Enhancement
– Brightness, Contrast, Saturation, Sharpness, Hue, Rotation, Flip,
Day/Night, Anti-flicker, AWB, BLC, Corridor
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Video
▪ Frame rate:
– 2048 x 1536 @ 30fps
– 1920 x 1080 @ 30fps
– 1280 x 720 @ 30fps
– 640 x 480 @ 30fps
– 640 x 360 @ 30fps
– 320 x 240 @ 30fps
▪ Video compression: H.264++/M-JPEG
▪ Video streaming: Triple streaming
▪ Video quality: VBR/CBR
Audio
▪ Audio streaming: Two-way
▪ Audio compression: G.711 8KHz/ 16-bit
▪ Audio input: Line-in
▪ Audio output: Line-out
Network
▪ Interface: 10/100/1000 Mbps Ethernet, RJ-45
▪ Supported protocols: HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS,
DDNS, NTP, uPnP, ONVIF, IPv4/v6, SNMP, HTTPS
▪ Browser: Internet Explorer, Chrome, Firefox, Safari
▪ Security: Multi-level passwords/ HTTP encryption
I/O Connector
▪ Audio in/ out port: 3.5mm phone jack x1
▪ D I/O: DI x1, DO x1
▪ RS485: N/A
▪ Micro SD slot: Yes, SD card slot x1
▪ RJ45: Yes
