Chapter 1: Product Introduction
Hardware Specifications
Camera
▪ Image sensor: 1/3" 3megapixel true WDR progressive scan CMOS sensor
▪ Lens: 3.6mm F1.8 fixed lens, 2.8mm F2.0 fixed lens (optional)
▪ Iris type: Fixed iris
▪ Image Enhancement
– Brightness, Contrast, Saturation, Sharpness, Backlight compensation,
Mirror, Flip, Day/Night, Anti-flicker
Video
▪ Video compression: H.264/MJPEG
▪ Video streaming: triple streaming
– H.264 Stream 1/ H.264 Stream 2/ MJPEG Stream 3
▪ Video resolution: 2048x1536 to 320x240
▪ Video quality
– VBR: 5 level adjustable
– CBR: 30Kbps~20Mbps
▪ Frame rate
– 2048x1536 @ 20 fps
– 1920x1080 @ 30 fps
– 1280X720 @ 30 fps
– 720x576 @ 60 fps
– 720x480 @ 60 fps
– 640x480 @ 60 fps
– 320x240 @ 60 fps
Network
▪ Interface: 10/100/1000 Mbps Ethernet, RJ-45
▪ Supported protocols: HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP client,
DNS, DDNS, NTP, uPnP, IPv4/v6
▪ Security: multi-level passwords/ HTTPS encryption
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
I/O Connector
▪ 1x Micro SD slot
▪ 1x RJ45 port
Event Management
▪ Event trigger: motion detection
▪ Notifications: email/ FTP and record video to server or SD card
▪ Support post-recording and pre-recording
Power Input
▪ PoE: IEEE 802.3af
Dimensions
▪ 111mm (H) , φ51.3mm
Weight
▪ 392g
Environment
▪ Operating temperatures: -40°C to 60°C
▪ Relative humidity: 90%, non-condensing
▪ Vandal Resistant: IK10
Certifications
▪ CE approval
▪ FCC
▪ EN-50155
2
NCm-301-V/NCm-301-VM/NCm-301-2V/NCm-301-2VM User Manual
