Chapter 1: Product Introduction
Event Management
▪ Event trigger: Alarm, Motion detection, DI, Sabotage
▪ Notifications: Trigger alarm output, email/ FTP and record Snapshot/video
to Network storage or SD card
▪ Post-recording: Yes
▪ Pre-recording: Yes
Power
▪ DC: DC 12V/AC 24V terminal block
▪ PoE: Yes/IEEE 802.3at (PoE+)
General
▪ Power consumption: 18W max.
▪ Weight: 3kg
▪ Dimension: 406.2mm (D) x 161mm (W) x 263.3mm (H)
▪ Operating Temp.: -40°C~60°C / -40°F~140°F
▪ Humidity: 90% RH (no condensation)
▪ Certification: CE/FCC
▪ Vandal resistant: IK10
▪ Outdoor capable: IP66/IP67
▪ Application: SDK available for application development
Packaging Information
▪ NWT: 3kg
▪ GWT: 3.1kg
▪ Dimension: 311mm (D) x 286mm (W) x 178mm (H)
