Chapter 1: Product Introduction

Hardware Specifications

Camera
▪ Image sensor: 1/3" 3megapixel true WDR progressive scan CMOS sensor
▪ Minimum Illumination: B/W 0.01 lux/ color 0.1 lux
▪ Lens: Motorized (3-10mm, F1.4) lens
▪ Iris type: P-iris
▪ Day and night: Yes (true D/N)
▪ WDR: Yes
▪ Image Enhancement
– Brightness, Contrast, Saturation, Sharpness, Backlight compensation,
Mirror, Flip, Day/Night, Anti-flicker
Video
▪ Video compression: H.264/MJPEG
▪ Video streaming: triple streaming
– H.264 Stream 1/ H.264 Stream 2/ MJPEG Stream 3
▪ Video resolution: 2048 x 1536 to 320 x 240
▪ Video quality
– VBR/ CBR
▪ Frame rate
– 2048 x 1536 @ 30 fps
– 1920 x 1080 @ 60 fps
– 1280 x 720 @ 30 fps
– 720 x 576 @ 30 fps
– 720 x 480 @ 30 fps
– 640 x 480 @ 30 fps
– 320 x 240 @ 30 fps
Audio
▪ Audio Streaming: Two-way
▪ Audio Compression: G.711 8KHz/ 16bit
▪ Audio Input: Line in
▪ Audio Output: Line out
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
Network
▪ Interface: 10/100/1000 Mbps Ethernet, RJ-45
▪ Supported protocols: HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS,
DDNS, NTP, uPnP, ONVIF, IPv4/v6
▪ Security: Multi-level passwords/ HTTP encryption
I/O Connector
▪ Audio in/ out Port: 1x 3.5mm phone jack
▪ D I/O: 1x DI, 1x DO
▪ Micro SD slot: Yes
▪ RJ45: Yes
Event Management
▪ Event trigger: Motion detection, DI
▪ Notifications: Trigger alarm output, email/ FTP and record video to PC or
SD card
▪ Post-recording: Yes
▪ Pre-recording: Yes
Power
▪ DC: DC 12V/AC 24V terminal block
▪ PoE: Yes/ IEEE 802.3at (PoE+)
General
▪ Power consumption: 10W max.
▪ Weight: 650g
▪ Dimension: 145mm (D) X 73.27mm (W) X 64mm (H)
▪ Operating Temp.: 0°C~60°C / 0°F~140°F
▪ Humidity: 90% RH (no condensation)
▪ Certification: CE/ FCC
▪ Weatherproof: With housing
▪ Application: SDK available for application development
