Chapter 1: Product Introduction

Hardware Specifications

Camera
▪ Image sensor: 1/3" 3megapixel progressive scan CMOS sensor
▪ Lens: varifocal (3-10mm, F1.3) board type
▪ Field of View: diagonal 127.2°~36°/ horizontal 95.6°~28.8°/
vertical 68.8°~21.6°
▪ Iris type: DC-iris
▪ Day and night: True D/N (NCi-311-R), Digital D/N (NCi-311)
▪ IR Distance: Effective up to 15 meter (NCi-311-R only)
▪ IR wavelength: 850nm (15 pcs φ 5.0 IR-LED, NCi-311-R only)
▪ IR control: Smart IR (NCi-311-R only)
▪ ICR: NCi-311-R only
▪ WDR: YES (DWDR)
▪ Image Enhancement
– Brightness, Contrast, Saturation, Sharpness, Backlight compensation,
Mirror, Flip, Day/Night, Anti-flicker
Video
▪ Video compression: H.264/MJPEG
▪ Video streaming: triple streaming
– H.264 Stream 1/ H.264 Stream 2/ MJPEG Stream 3
▪ Video resolution: 2048x1536 to 320x240
▪ Video quality: VBR/CBR
▪ Frame rate
– 2048x1536 @ 20 fps
– 1920x1080 @ 30 fps
– 1280X720 @ 30 fps
– 720x576 @ 30 fps
– 720x480 @ 30 fps
– 640x480 @ 30 fps
– 320x240 @ 30 fps
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
Network
▪ Interface: 10/100/1000 Mbps Ethernet, RJ-45
▪ Supported protocols: HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS,
DDNS, NTP, uPnP, ONVIF and IPv4/v6
▪ Security: multi-level passwords/ HTTP encryption
I/O Connector
▪ 1x Micro SD slot
▪ 1x RJ45 port
▪ 1x Digital Input, 1x Digital Output
Event Management
▪ Event trigger: motion detection, DI
▪ Notifications: Trigger alarm output, email/ FTP and record video to PC or
SD card
▪ Support post-recording and pre-recording
Power Input
▪ DC/AC: DC 12V terminal block
▪ PoE: IEEE 802.3af
General
▪ Power consumption: 7W max. (NCi-311-R), 6W max. (NCi-311)
▪ Weight: 744g
▪ Dimensions: 74 mm (H), φ113mm
▪ Operating temperatures: 0°C to 60°C
▪ Humidity: 90% RH, non-condensing
▪ Certification: CE/FCC
▪ Application: SDK available for application development
