Chapter 1: Product Introduction

Hardware Specifications

Camera
▪ Image sensor: 1/3" 3megapixel progressive scan CMOS sensor
▪ Minimum Illumination: B/W 0.05 lux/ color 0.1 lux
▪ Lens: 3.6mm F1.8 fixed lens, 2.8mm F2.0 fixed lens (optional)
▪ Iris type: Fixed iris
▪ Day and night: Yes (true D/N)
▪ WDR: Yes (DWDR)
▪ Image Enhancement
– Brightness, Contrast, Saturation, Sharpness, Backlight compensation,
Mirror, Flip, Day/Night, Anti-flicker
Video
▪ Video compression: H.264/MJPEG
▪ Video streaming: triple streaming
– H.264 Stream 1/ H.264 Stream 2/ MJPEG Stream 3
▪ Video resolution: 2048 x 1536 to 320 x 240
▪ Video quality
– VBR: 5 level adjustable
– CBR: 30Kbps~10Mbps
▪ Frame rate
– 2048 x 1536 @ 20 fps
– 1920 x 1080 @ 30 fps
– 1280 x 720 @ 30 fps
– 720 x 576 @ 30 fps
– 720 x 480 @ 30 fps
– 640 x 480 @ 30 fps
– 320 x 240 @ 30 fps
Copyright © 2013 NEXCOM International Co., Ltd. All Rights Reserved.
Network
▪ Interface: 10/100/1000 Mbps Ethernet, RJ-45
▪ Supported protocols: HTTP, TCP/IP, UDP, RTP, RTSP, FTP, SMTP, DHCP, DNS,
DDNS, NTP, uPnP, ONVIF, IPv4/v6
▪ Security: Multi-level passwords/ HTTP encryption
I/O Connector
▪ D I/O: DIX1, DOX1
▪ Micro SD slot: Yes
▪ RJ45: Yes
Event Management
▪ Event trigger: Motion detection, DI
▪ Notifications: Trigger alarm output, email/ FTP and record video to PC or
SD card
▪ Post-recording: Yes
▪ Pre-recording: Yes
Power
▪ DC: DC 12V terminal block
▪ PoE: Yes/ IEEE 802.3af
General
▪ Power consumption: 6W max.
▪ Weight: 500g
▪ Dimension: 91mm (H), φ131.5mm
▪ Operating Temp.: 0°C~60°C
▪ Humidity: 90% RH (no condensation)
▪ Certification: CE/ FCC
▪ Application: SDK available for application development
