System Installation Guide
Document 101320-026, Revision AA
For use with Software version v15
December, 2016
Copyright © 2009-2016 by Dynon Avionics, Inc.
Permission to print this manual is granted to third parties.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SkyView SE and is the answer not in the manual?

Questions and answers

Related Manuals for Dynon Avionics SkyView SE

Summary of Contents for Dynon Avionics SkyView SE

  • Page 1 SkyView SE SkyView Classic SkyView Touch SkyView HDX System Installation Guide Document 101320-026, Revision AA For use with Software version v15 December, 2016 Copyright © 2009-2016 by Dynon Avionics, Inc. Permission to print this manual is granted to third parties.

  • Page 3: Copyright

    Contact Information Dynon Avionics, Inc. 19825 141 Place NE Woodinville, WA 98072 Phone: 425-402-0433 - 8:00 AM – 5:00 PM (Pacific Time) Monday – Friday Dynon Avionics Technical Support available 7:00 AM–4:00 PM (Pacific Time) Monday – Friday Email: mailto://support@dynonavionics.com Fax: 425-984-1751 Dynon Avionics offers a number of Internet sites for support: http://www.dynonavionics.com...

  • Page 4: Limited Warranty

    Limited Warranty Dynon Avionics warrants this product to be free from defects in materials and workmanship for three years from date of shipment. Dynon Avionics will, at its sole option, repair or replace any components that fail in normal use. Such repairs or replacement will be made at no charge to the customer for parts or labor performed by Dynon Avionics.

  • Page 5: Changes In This Revision

    Section 16 – Added alternate method for adjusting Microphone Gain of SV-COM-C25. 579 pages Table 1 – Changes in this Revision of SkyView Classic / SkyView SE / SkyView HDX System Installation Guide SkyView System Installation Guide - Revision AA...

  • Page 7: Table Of Contents

    Dynon Avionics Product Registration ......................... 1-2 About this Guide ................................. 1-3 Semantics of “Software” vs “Software” ........................1-4 SkyView Classic, SkyView Touch, SkyView SE, and SkyView HDX ................1-4 Special Light Sport Aircraft (S-LSA) Considerations with SkyView ................1-4 Getting Started ................................1-5 2.
  • Page 8 Brightness Setup ............................... 4-38 Top Bar Setup ..............................4-39 Aircraft Information ............................4-39 SkyView Classic, SkyView SE Screen Layout Setup ................... 4-40 SkyView HDX Display Setup / Layout ........................ 4-41 SkyView Classic and SkyView HDX Touch Setup ....................4-42 Glide Ring Setup ............................... 4-42 Weight and Balance Setup ..........................
  • Page 9 Table of Contents Databases ................................... 6-3 Viewing Information about Installed Databases ....................6-3 Terrain Database ..............................6-6 Aviation/Obstacle Databases..........................6-7 US SkyView Pilots – Stadium TFR Database ......................6-8 Charts and Airport Diagrams ..........................6-9 Loading Databases ............................6-10 Removing Databases ............................6-10 7.
  • Page 10 Table of Contents EMS Screen Layout Editor ............................7-85 EMS Sensor Calibration ............................7-87 SkyView HDX ENGINE BOTTOM BAND ........................7-88 8. SV-GPS-250/2020 GPS Receiver Installation and Configuration WAAS Data Reception ..............................8-2 Use of the SV-GPS-2020 outside the US ........................8-3 Considerations for converting an SV-GPS-250 to an SV-GPS-2020 in Special Light Sport Aircraft (S-LSAs) ....
  • Page 11 Table of Contents SV-XPNDR-261/262 Software Update SW02.09 Quick Decision Points............11-35 Deprecated SV-XPNDR-261/262 Software Update Instructions and notes ............ 11-37 SkyView Software v12.2 – v13.0.3 SV-XPNDR-261/262 Software SW02.06 Update ........11-38 SV-XPNDR-261/262 Software Version (SW) v2.02/v2.04/v2.06 Labeling Requirements (US Registered / Operated Aircraft Only) ..........................
  • Page 12 Table of Contents Electrical Connections .............................. 16-6 Antenna Installation ............................... 16-15 SkyView System Settings for SV-COM-C25 ......................16-17 Post Installation Checks ............................16-19 Continued Airworthiness and Maintenance ......................16-20 17. SV-COM-X83 Installation and Configuration 17-1 Certification Considerations ............................. 17-2 Physical Installation: SV-COM-PANEL ........................17-2 Physical Installation: SV-COM-T8 ..........................
  • Page 13 Table of Contents 22. Appendix B: Specifications 22-1 SkyView / Dynon Avionics Minor Equipment Weights ..................... 22-1 SkyView Compatible Engine Sensors (sold by Dynon Avionics) ................22-2 SV-BAT-320 Specifications ............................22-3 SV-XPNDR-261 Specifications ........................... 22-4 SV-XPNDR-262 Specifications ........................... 22-5 SV-XPNDR-261/262 ADS-B Information ........................22-8 SV-COM-C25 Technical Specifications ........................
  • Page 14 Table of Contents 30. Appendix J: Checklists 30-1 Saving Your Checklist with “UTF-8 Character Encoding” ..................30-2 Example Checklist ..............................30-4 Example Checklist Formatting Notes: ........................30-5 Excel Checklist Generation Tool ..........................30-6 Loading a Checklist ..............................30-6 Displaying Your Checklist on your SkyView Display ....................30-9 31.

  • Page 15: Introduction

     SV-ADSB-470 ADS-B Receiver Module*  SV-ARINC-429 ARINC 429 Interface Module*  SV-BAT-320 Backup Battery  SV-COM-C25 and SV-COM-X83 COM Radios  SV-D600 SkyView SE Display  SV-D700 SkyView Classic Display  SV-D900 SkyView SE Display  SV-D1000 SkyView Classic Display ...

  • Page 16: Warning

    / installation manuals available for reference. If you are converting to a SkyView or SkyView SE system from an earlier Dynon Avionics D10/D100 series system, we have written the D10/D100 Series to SkyView Conversion Guide, which details the changes required to convert between the two product families.

  • Page 17: About This Guide

    Introduction About this Guide This guide – the SkyView Classic / SkyView SE / SkyView HDX System Installation Guide (hereafter, “this guide”) contains information for the installation and initial / basic configuration of the SkyView Classic, SkyView SE, and SkyView HDX Systems. Separate guides – the SkyView Pilot’s User Guide, SkyView SE Pilot’s User Guide, and SkyView HDX Pilot’s User Guide explain...

  • Page 18: Semantics Of "Software" Vs "Software

    (most of the time) as an encompassing term for “Software”, “OS”, and “app” functions. SkyView Classic, SkyView Touch, SkyView SE, and SkyView HDX SkyView SE is a streamlined, simplified edition of SkyView. Although the two editions are within the same family of products, the two editions cannot interoperate. For example, you cannot install a SkyView SE display (SV-D600 or SV-D900) into an existing SkyView (non-SE) system and vice versa.

  • Page 19: Getting Started

    Introduction cases, updating SkyView’s Software. If you have an S-LSA, it is recommended that you consult your aircraft’s Pilot Operating Handbook and aircraft’s Maintenance Manual. These will guide you in what modifications, including whether Software updates, are permitted. Please consult your authorized dealer, or your manufacturer, if you have questions.
  • Page 20 11. After you’ve configured SkyView Network, have properly configured any serial devices, exit SETUP MENU. Your SkyView display should now display EMS, PFD, and MAP (SkyView SE does not include MAP as a feature). Map will not display without a GPS fix (the airplane symbol on the Map page will also flash with “?”...
  • Page 21 Introduction b. The layout of which sensor “widgets” are shown on the screen, sizes, styles, etc. is completely configurable: SETUP > EMS SETUP > SCREEN LAYOUT EDITOR 14. Common issues for setting up SV-XPNDR-261/262: a. Ensure that there is a valid tail number set (see above) b.

  • Page 23: System Planning

    SkyView SE displays cannot interoperate in a SkyView system that includes SkyView Classic or SkyView HDX displays. For example, if you plan to use a SkyView SE display, your SkyView system should only use SkyView SV-D600 or SkyView SV-900 displays.

  • Page 24: 9-Pin D9F And D9M Connectors Are Skyview Network (Not Rs-232 Serial)

    System Planning 9-pin D9F and D9M Connectors are SkyView Network (not RS-232 Serial) SkyView displays and SkyView modules use D9M connectors for “SkyView Network” connections between SkyView displays and SkyView modules . This initially causes some confusion because the same type of connector is used for “RS-232 serial”...

  • Page 25: External Switches And Indicators

    A SkyView Classic system can include as many as three SkyView Classic and SkyView Touch displays in any combination of SV-D700s, SV-D1000s, and SV-D1000Ts. A SkyView SE system can include as many as three SkyView SE displays in any combination of SV-D600s and SV-D900s.

  • Page 26: Power Specifications

    System Planning Power Specifications Table 3 contains SkyView displays and devices that are powered by SkyView displays. 5A circuit protection is recommended for SkyView displays in common configurations; 5A is the smallest circuit breaker that is commonly available in certified versions. SkyView Displays: No SV-BAT-320 (see below) Current...
  • Page 27 System Planning Table 4 contains power specifications for SkyView units that are powered from aircraft power (not powered by SkyView Network). The circuit protection recommendations are suitable for most installations and assume that you are using Dynon Avionics harnesses and/or are following the wiring advice in this Installation Guide.

  • Page 28: Major Unit Physical Specifications

    System Planning Major Unit Physical Specifications Table 5 contains physical specifications of major units. Note that dimensions listed in this table are approximate—see the installation sections of each unit for installation drawings with precise dimensions. For physical specifications of minor units such as sensors, see Appendix B: Specifications, Table 99 –...

  • Page 29: Temperature Specifications

    System Planning Unit Dimensions Weight 10.31” W x 7.1” H x 3.1” D SV-HDX1100 3.35 lb. (1.52 kg) (262mm W x 180mm x 79mm D) 3.53” x 1.80” x 1.27” D SV-KNOB-PANEL 0.40 lb. (0.18 kg) (89.7mm x 45.7mm H x 32.4mm D) 4.71”...

  • Page 30: General System Installation Tips

    10V. Installing SkyView in an IFR-Equipped Aircraft SkyView SE does not integrate with any IFR navigation sources, and excludes features and components commonly used in an aircraft equipped for IFR flight.

  • Page 31: Mounting Requirements

    System Planning The entirety of the instrument panel and supporting avionics systems and instrumentation should be designed so that the display of information essential for continued safe flight and landing will remain available to the pilot after any single failure or probable combination of failures.
  • Page 32 System Planning data to the displays. The connection between displays and modules is referred to as SkyView Network. SkyView Network SkyView displays, SkyView modules, and the SV-NET-HUB use Male DSUB 9-pin (henceforth referred to as “D9M”) connectors. SkyView Network cables use Female DSUB 9-pin (henceforth referred to as “D9F”) connectors.
  • Page 33 System Planning SkyView Network Hub (SV-NET-HUB) The SV-NET-HUB SkyView Network hub contains 5 SkyView Network ports. All 5 ports are identical, thus any of the 5 ports can be used to connect to your displays, modules, and/or autopilot servos. Servo power should be broken out, as is normally done.
  • Page 34 System Planning Test SkyView Network Cable SkyView displays are supplied with a test SkyView network cable that is intended for bench top testing only. The test network cable is not built with aircraft-grade Tefzel® wiring and should not be permanently installed in an aircraft. Ethernet Connection SkyView systems that have more than one display should have their Ethernet ports permanently connected together.

  • Page 35: Example Skyview Systems

    System Planning Dynon Avionics P/N Description SV-HARNESS-XPNDR Wiring Harness for SV-XPNDR-261/262 – 15 ft. (4.6 m) SV-NET-1.5CC SkyView Network Cable, both ends with connectors – 1.5 ft. (0.46 m) SV-NET-3CC SkyView Network Cable, both ends with connectors – 3 ft. (0.91 m) SV-NET-6CC SkyView Network Cable, both ends with connectors –...
  • Page 36 System Planning SV-D1000 SV-EMS-220 SV-NET-SPL DB9 Male SV-NET-10CP SV-ADAHRS-200 SV-NET-6CC (with installed D9) DB9 Female SV-HARNESS-D37 SV-GPS-250 Wire Connector Bundle SV-ADAHRS-201 SV-BAT-320 Figure 6 – SkyView System with One Display, One EMS, One GPS, One SV-BAT-320, and Two Redundant ADAHRS Figure 7 –...
  • Page 37 System Planning ADAHRS modules. In most installations, this is the only application of the SV-NET-SPL that is necessary when utilizing the SV-NET-HUB to build a SkyView Network. Figure 8 – SkyView System with Two Redundant Displays, One EMS, Two Backup Batteries (One per Display), Two Redundant GPS, Two Redundant ADAHRS, Two Servos, and one Transponder using splitters (legacy installation method) SkyView System Installation Guide - Revision AA...
  • Page 38 System Planning Note, that in Figure 8, each SV-GPS-250/2020’s power, ground, and output wires are connected to both displays on different serial ports. The primary SV-GPS- 250/2020 should be connected to serial port 5 on each display. The secondary SV- GPS-250/2020 should be connected on another serial port on each display.

  • Page 39: Hsi Requirements

    LPV/VNAV GPS  Approaches SkyView SE does not support SV-ARINC-429. SkyView SE does not support external navigation devices. Requires additional Aviation format serial input into SV-ARINC-429 module. Approach-certified WAAS GPS units only. SkyView System Installation Guide - Revision AA 2-17...
  • Page 40 System Planning SkyView SkyView Generic Generic ARINC-429 ARINC-429 / SkyView SkyView SV-GPS-250 Data NMEA Aviation GPS via SV- Serial (SL30) SV-ADAHRS-200 SV-MAG- SV-GPS- System ARINC-429 SV-ADAHRS-201 2020   Magnetic Heading SkyView Time    Source    ...

  • Page 41: Basic Skyview Display Operation

    SV-D700 or the SV-D1000), the only difference is in the size and resolution of the screen. The SkyView SE SV-D600 and SV-D900 displays are identical in functionality and presentation. The only difference is in the size and resolution of the screen.

  • Page 42: Display Bezel Layout

    Basic SkyView Display Operation Display Bezel Layout The following diagram illustrates the front of an SV-D1000 display and its important parts. Figure 10 – SkyView Display Front Bezel Layout Note the top bar, screen, joystick and button labels, light sensor, two joysticks and eight buttons.

  • Page 43: Joystick And Button Operation

    Operation Basics SkyView Classic and SkyView SE joysticks can be turned and moved. Specific joystick behavior is addressed in subsequent sections of this guide when necessary. Figure 11 – SkyView Classic and SkyView SE Joystick Turn (left) and Movement (right) Directions...
  • Page 44 Because it incorporates an advanced touch screen interface, SkyView HDX knobs (unlike SkyView Classic and SkyView SE) do not move (click) up, down, left, or right – they only rotate clockwise and counter-clockwise. Like SkyView Classic and SkyView SE’s knobs, SkyView HDX knobs incorporate a pushbutton function.

  • Page 45: Skyview Touch - Touch Interface Features Not Used In Setup Menus

    Basic SkyView Display Operation Figure 14 – Adjusting Successive Characters in SkyView Classic and SkyView SE In this example, the first time you turn the joystick, you toggle between the “-“ and “+” symbols. To change the succeeding characters, you must move the cursor joystick to the right.

  • Page 46: Menu Navigation

    Basic SkyView Display Operation When in a list of menu items, to move up and down the menu, simply rotate the knob clockwise to move down the menu, and counter-clockwise to move up the menu. When the desired menu is highlighted, push the knob (pushbutton) to enter the desired menu. Menu Navigation After the display turns on, you will see a screen similar to the one in Figure 10.

  • Page 47: Basic Display Operation Procedures

    Basic SkyView Display Operation Desired Menu Action User Action Save settings and return to Main Press EXIT Menu Table 9 – Menu Navigation Summary Basic Display Operation Procedures This subsection covers basic operation procedures for displays. Detailed instructions for various menus and individual menu items are described later in this guide.
  • Page 48 For example, knob or joystick 1 could be set to adjust the Heading bug and knob or joystick 2 could be set to adjust the Altitude bug. If you have a SkyView Classic or SkyView SE display, move the joystick up, down, left, or right to enter its Function Menu.

  • Page 49: In Flight Setup Menu

    Basic SkyView Display Operation To set the function of a SkyView HDX knob: 1. Push the knob (pushbutton) to enter the knob’s Function Menu. 2. Choose the joystick function by rotating the knob clockwise or counter-clockwise. 3. Confirm the highlighted function by pushing the knob (pushbutton) Wait approximately 7 seconds;...

  • Page 50: Setup Menu

     TRANSPONDER SETUP  TRAFFIC SETUP (Not supported in SkyView SE)  VP-X SETUP (Not supported in SkyView SE or SkyView HDX [as of Software v15.0])  ACM SETUP (Not supported in SkyView SE)  ADS-B STATUS (Not supported in SkyView SE) ...

  • Page 51: System Software Menu

    Basic SkyView Display Operation If no critical system events have occurred on your SkyView display, “SYSTEM EVENT” will not appear as a menu item. If SYSTEM EVENT does appear, it contains instructions on what to do next. SYSTEM SOFTWARE Menu You must have a USB flash drive that is recognizable by the display in one of the USB slots to open this menu.

  • Page 52: System Setup Menu

    Basic SkyView Display Operation  EXPORT DYNON DIAGNOSTIC FILE... – This specialized data log can only be interpreted by Dynon Avionics personnel; there is no data in it that can be interpreted by SkyView pilots. Dynon Avionics Technical Support may request this log in the course of troubleshooting, especially for issues related to AP performance.

  • Page 53: Local Display Setup Menu

    Alternate languages are not supported in SkyView SE – SkyView SE will display only in US English. If you intend to install and use SkyView SE, do not install an alternate language pack.  VIDEO INPUT SETUP – If a SkyView Video Input Adapter (USB) is connected to this display, options such as video input format and orientation can be selected.

  • Page 54: Pfd Setup Menu

    Basic SkyView Display Operation PFD SETUP Menu This menu contains menus and pages related to Primary Flight Display page and data source (ADAHRS module).  ADAHRS SOURCE SELECTION–This page has a list of all configured SkyView ADAHRS modules and their respective status. The ADAHRS module used as the PFD’s source of data can be selected.

  • Page 55: Ems Setup Menu

    (Note: Support for dual SV-EMS-220/221 modules is supported only in SkyView Classic; this feature is not available in SkyView SE or SkyView HDX (as of Software v15.0).  SENSOR DEBUG DATA – Displays diagnostic / troubleshooting data for engine sensors. Also displays the version of the EMS Sensor Definitions file loaded on this SkyView display.

  • Page 56: Autopilot Setup Menu

    Basic SkyView Display Operation  TERRAIN WARNING COLORS – Sets whether Red and Yellow terrain warning are provided on the Map Page  RED AND YELLOW START – When the above setting is set to “YES”, these settings how far above or below the aircraft’s current altitude the red and yellow colors persist.

  • Page 57: Software Updates And File Operations

    Basic SkyView Display Operation Note that if an ADAHRS, EMS, or Servos are not present on the SkyView network, this menu will note the absence by displaying “(EMS NOT DETECTED)”, “(ADAHRS NOT DETECTED)”, or “(SERVOS NOT INSTALLED)” Software Updates and File Operations Dynon Avionics continually provides new functionality and capabilities to your SkyView system via Software updates.

  • Page 58: How To Update Software

    Basic SkyView Display Operation How to Update Software 1. Download the latest SkyView Software file from http://downloads.dynonavionics.com. 2. Copy the Software file onto your USB flash drive. The Software file must be in the root directory of the drive in order to be recognizable by the SkyView display. 3.

  • Page 59: How To Export System Settings

    Basic SkyView Display Operation TAILNUMBER_SNXXXX_SOFTWAREVERSION_SW_UPGRADE.sfg How to Export System Settings This operation creates a set of files on the USB flash drive that contain display settings, equipment settings, and important calibration information. All of the filenames contain the tail number and the Software version. 1.
  • Page 60 Basic SkyView Display Operation from multiple displays onto the same USB flash drive, use the 33-character name field to distinguish the two files, such as naming one “LEFT” and the other one “RIGHT”. If Dynon Avionics Technical Support has requested that you send a Dynon Diagnostic File, go to http://www.dynonavionics.com/docs/upload.html to transmit the file to Dynon Avionics.

  • Page 61: Skyview Display Installation And Configuration

    This section contains information and diagrams that specifically apply to installation of SkyView Classic, SkyView SE, and SkyView HDX displays. After reading this section, you should be able to determine how to prepare a panel for display installation, how to mount a display, how to make all necessary electrical connections, and also how to configure a display.

  • Page 62: Location Requirements For Skyview Displays

    SkyView Display Installation and Configuration Physical Installation Display Panel Cutout Bezel Outline SV-D600 6.97” x 5.35” 7.636” x 5.512” SV-D700 (177.038mm x 135.890mm) (193.954mm x 140.005mm) SV-D900 9.68” x 6.90” 10.320” x 7.064” SV-D1000 (245.872mm x 175.260mm) (262.128mm x 179.426mm) SV-D1000T 6.97”...
  • Page 63 SkyView Classic and SkyView SE displays are shipped with #6-32 hex-drive round head fasteners. Fasteners are 5/8” in length and require a 5/64” hex drive tool. Dynon Avionics recommends fastening the included mounting screws to nut plates installed behind the panel.
  • Page 64 SkyView Display Installation and Configuration Figure 20 – SV-D600 and SV-D700 Panel Cutout and Mounting Hole Dimensions - NOT ACTUAL SIZE SkyView System Installation Guide - Revision AA...
  • Page 65 SkyView Display Installation and Configuration Figure 21 – SV-D600 and SV-D700 Dimensions SkyView System Installation Guide - Revision AA...
  • Page 66 SkyView Display Installation and Configuration Figure 22 – SV-D900, SV-D1000 and SV-D1000T Panel Cutout and Mounting Hole Dimensions – NOT ACTUAL SIZE SkyView System Installation Guide - Revision AA...
  • Page 67 SkyView Display Installation and Configuration Figure 23 – SV-D900, SV-D1000 and SV-D1000T Dimensions  For SV-D1000 units S/N 8082 and earlier, the depth dimension of the enclosure (Dimension A: above) is 1.47 inches as stated above.  For SV-D900 units (all S/Ns) and SV-D1000 units S/N 8083 and later, and the depth dimension of the enclosure (Dimension A: above) is 1.65 inches (same enclosure as the SV-D1000T).
  • Page 68 SkyView Display Installation and Configuration Figure 24 – Panel Cutout and Mounting Hole Dimensions – NOT ACTUAL SIZE SkyView System Installation Guide - Revision AA...
  • Page 69 SkyView Display Installation and Configuration Figure 25 – SV-HDX800 Front Dimensions SkyView System Installation Guide - Revision AA...
  • Page 70 SkyView Display Installation and Configuration Figure 26 – SV-HDX800 Rear Dimensions 4-10 SkyView System Installation Guide - Revision AA...
  • Page 71 SkyView Display Installation and Configuration Figure 27 – SV-HDX800 Side Dimensions SkyView System Installation Guide - Revision AA 4-11...
  • Page 72 SkyView Display Installation and Configuration Figure 28 – SV-HDX1100 Panel Cutout and Mounting Hole Dimensions - NOT ACTUAL SIZE 4-12 SkyView System Installation Guide - Revision AA...
  • Page 73 SkyView Display Installation and Configuration Figure 29 – SV-HDX1100 Front Dimensions SkyView System Installation Guide - Revision AA 4-13...
  • Page 74 SkyView Display Installation and Configuration Figure 30 – SV-HDX1100 Rear Dimensions 4-14 SkyView System Installation Guide - Revision AA...
  • Page 75 SkyView Display Installation and Configuration Figure 31 – SV-HDX1100 Side Dimensions SkyView System Installation Guide - Revision AA 4-15...
  • Page 76 SkyView Display Installation and Configuration Figure 32 – HDX1100 Panel Plate If the SkyView SV-HDX1100 display will be installed into a panel with existing (larger) cutouts and screw holes for a SkyView SV-D900, SkyView SV-D1000, or SkyView SV-D1000 Touch display (initial installation or upgrade), a “filler”...

  • Page 77: Electrical Installation

    SkyView Display Installation and Configuration Electrical Installation Use this section in conjunction with the information contained in Appendix C: Wiring and Electrical Connections (notably Figure 217 on page 23-9). The wires and wire colors in this section refer to the wires on the included SkyView Display Harness (SV-HARNESS-D37). Some wires that are used in SkyView harnesses are identified with secondary color stripes.

  • Page 78: Skyview Network Connectors

    SkyView Display Installation and Configuration by the SkyView display – see System Planning, Power . A fully charged SV-BAT-320 can keep most SkyView systems operating for at least 60 minutes. The SV-BAT-320 does not supply (backup) power to the following SkyView system devices: ...
  • Page 79 When you first power up your SkyView display, it will look similar to the screen below (SkyView HDX and SkyView SE displays will be slightly different). This is normal – you have not yet performed a SkyView Network Configuration for the SkyView display(s) to recognize your ADAHRS, EMS, and other SkyView Network modules.
  • Page 80 SkyView Display Installation and Configuration Figure 34 – Successful SkyView Network Configuration Screen If the SkyView network is successfully configured, but Software versions on equipment are not synchronized, you will see a screen that is similar to Figure 35. Figure 35 – SkyView Network Configuration with Software Update 4-20 SkyView System Installation Guide - Revision AA...

  • Page 81: Ethernet Connection

    SV-D700 / SV-D1000 / SV-D1000T displays (SkyView) or SV-D600 / SV-D900 displays (SkyView SE), SV-ADAHRS-200/201 modules, SV-EMS-220/221 modules, SV- ARINC-429 modules (not supported in SkyView SE), SV-COM-PANEL for SV-COM-C25 and SV- COM-X83 COM radios, SV-AP-PANEL (not supported in SkyView SE) / SV-KNOB-PANEL control panels, and Dynon Avionics Autopilot Servos.
  • Page 82 SkyView Display Installation and Configuration Dynon Avionics devices that use RS-232 serial ports for communication include the SV-GPS- 250/2020, SV-XPNDR-261 and-262, and SV-ADSB-470. Devices from other manufacturers that are commonly used with SkyView include transponders (with serial port inputs), NAV radios such as Garmin SL30, COM radios such as Garmin SL40, GPS devices such as the Garmin X96 series, Vertical Power VP-X, and Emergency Location Transmitters (ELTs).
  • Page 83 SkyView Display Installation and Configuration 3. Configure the serial port (under SETUP MENU > SYSTEM SETUP > SERIAL PORT SETUP) according to the device’s documentation. 4. When serial port configuration is complete, perform a final check by doing the following: a.
  • Page 84 SkyView Display Installation and Configuration connected to these devices in SERIAL PORT x SETUP, SERIAL IN DEVICE to GARMIN TIS TRAFFIC (which will automatically set the associated parameters). If a device that can provide traffic data is connected to SkyView and configured (usually as a TIS serial traffic device under SETUP MENU >...
  • Page 85 SkyView Display Installation and Configuration Contact Garmin for correctly configuring the GTX 330ES ADS-B Out capability. Also see SV- ADSB-470 Installation and Configuration for additional configuration.  SETUP MENU > SYSTEM SETUP > SERIAL PORT SETUP > SERIAL PORT x SETUP > SERIAL IN DEVICE >...
  • Page 86 SkyView Display Installation and Configuration There must be a SkyView ADAHRS installed for the altitude encoder output to function. SkyView outputs its altitude measurements in two different formats. You can use either format on any of the serial ports. These formats are described in Table 13 and Table 14. SkyView will function properly whether or not this altitude encoder functionality is used.
  • Page 87 SkyView Display Installation and Configuration  Configure the serial port on each display appropriately under SETUP MENU > SYSTEM SETUP > SERIAL PORT SETUP.  Configure the serial port on the transponder appropriately. For a Garmin GTX 327, 330 / ES, the RS-232 output of the appropriate serial port on the transponder should be set to REMOTE+TIS.
  • Page 88 SkyView Display Installation and Configuration Val Avionics NAV 2000  To work with SkyView, the NAV 2000 must have v1.10 Software (minimum). The Software version is displayed during the NAV 2000 startup.  Connect NAV 2000 serial RX Pin 4 (Connector P1) to a SkyView serial TX. If you have more than one SkyView display, make the same connection to all SkyView displays.
  • Page 89 SkyView Display Installation and Configuration  Configure the serial port: SETUP MENU > SYSTEM SETUP > SERIAL PORT SETUP > SERIAL PORT x SETUP > SERIAL IN DEVICE > GARMIN / APOLLO SL40. This will automatically set the SERIAL IN FUNCTION, SERIAL IN/OUT BAUD RATE, and SERIAL OUT DEVICE. ...
  • Page 90 SkyView Display Installation and Configuration BAUD RATE, and SERIAL OUT DEVICE. (Although there is no IC-A210 serial TX to SkyView serial RX connection, SERIAL IN DEVICE must be configured as described.)  SETUP MENU > SYSTEM SETUP > PRIMARY COM > ICOM A210 (PORT x) SETUP MENU >...
  • Page 91 SkyView Display Installation and Configuration On SkyView:  SETUP MENU > SYSTEM SETUP > SERIAL PORT SETUP > SERIAL PORT x SETUP > SERIAL IN DEVICE > GARMIN GNC 255 A/B. This will automatically set the SERIAL IN/OUT BAUD RATE, and SERIAL OUT DEVICE. ...

  • Page 92: Usb Usage And Accessibility

    SkyView Display Installation and Configuration  Configure the SkyView display serial port: SETUP MENU > SYSTEM SETUP > SERIAL PORT SETUP > SERIAL PORT x SETUP SERIAL IN DEVICE: (don’t care, does not affect ELT) SERIAL IN/OUT BAUD RATE: (set to match speed of ELT; typically 4800 or 9600) SERIAL OUT DEVICE: NMEA OUT (BASIC) Dynon Avionics ADAHRS / EMS / SYSTEM / NMEA (GPS) Data Outputs To output real-time data to an external serial device, such as a serial data logger or other device...

  • Page 93: External Dim Control (Dimming) Connections

    SkyView Display Installation and Configuration External Dim Control (Dimming) Connections DIM INPUT (Pin 25) The backlight level on a SkyView display can be increased or decreased using a varying DC voltage of 0 to 36 volts DC, such as provided by the Dynon Avionics SV- KNOB-DIMMER –...
  • Page 94 SkyView Display Installation and Configuration audio panel ground are directly connected together, even though they nominally share a common ground via other aircraft wiring (audio ground is pin 30 on the D37). If there is more than one display on a SkyView network, you MUST connect all displays’ audio outputs to the same audio panel input to ensure that audio is always heard.

  • Page 95: Contact Inputs

    Contact Input #2 – (Optional) External GO AROUND Button. See the Autopilot section for detailed explanation. External GO AROUND Button is not supported in SkyView SE. If you intend to install and use SkyView SE, do not purchase or install an External GO AROUND Button.

  • Page 96: Display Setup

    SkyView Display Installation and Configuration Display Setup You can access important information about a SkyView display as well as configure serial ports, characterize your display backlight behavior and specify other display-specific settings. How to Access Display Hardware Information Enter the Display Hardware Information Page (SETUP MENU > LOCAL DISPLAY SETUP > DISPLAY HARDWARE INFORMATION) to access important display hardware information.
  • Page 97 SkyView Display Installation and Configuration  GPS devices provide GPS position and navigational information. These devices are generally "moving maps" that depict airports, airspaces, etc., and can generate flight plans. They provide source data for the moving map, HSI, autopilot, synthetic vision, and the clock in the Top Bar.

  • Page 98: Brightness Setup

    The backlight level can be adjusted manually by the user (not supported in SkyView SE), automatically by the display based on ambient light conditions, or by an external control signal while on the Brightness Setup Page and in normal flight.

  • Page 99: Top Bar Setup

    SkyView SE display(s) and Dynon Avionics panel units. In a SkyView SE system, if you wish to manually adjust the brightness of your SkyView SE display(s) and Dynon Avionics panel units, you must use a method of External Brightness Management as described below.

  • Page 100: Skyview Classic, Skyview Se Screen Layout Setup

    N-number). If the TRANSPONDER HEX CODE cannot be computed, the TRANSPONDER HEX CODE remains set to 000000. SkyView Classic, SkyView SE Screen Layout Setup You can use Screen Layout Setup page (SETUP MENU > SYSTEM SETUP > SCREEN LAYOUT SETUP) to customize and restrict the ways that the PFD Page, Engine Page, and Map Page are displayed on your SkyView display(s).

  • Page 101: Skyview Hdx Display Setup / Layout

    SkyView Display Installation and Configuration  REQUIRED: The relevant page is always shown on this display. This is always shown on this display. The relevant page button under the SCREEN menu is not available.  ALLOWED (SAVE STATE): This display remembers whether the relevant page was being shown across power cycles.

  • Page 102: Skyview Classic And Skyview Hdx Touch Setup

    SETUP MENU > LOCAL DISPLAY SETUP > TOUCH SETUP. This menu will not appear on SkyView Classic displays SV-D700 and SV-D1000, and SkyView SE displays SV-D600 and SV-D900.  (SV-D1000T Only) TOUCH ENABLED – YES/NO – Enables / disables touch features on a SV- D1000T.

  • Page 103: Maintenance Log Setup

    SkyView Display Installation and Configuration o > EMPTY ARM o > EMPTY MOMENT o > STATIONS  At least one Station is required. Up to nine Stations can be defined.  Typically, Stations would be defined for Fuel, Pilot, Co-pilot, and Baggage ...

  • Page 105: Sv-Adahrs-200/201 Installation And Configuration

    5. SV-ADAHRS-200/201 Installation and Configuration Figure 36 – SV-ADAHRS-201 Figure 37 – SV-ADAHRS-200 Information in this section, and other parts of this manual, that apply equally to either the SV- ADAHRS-200 or the SV-ADAHRS-201, or both units together, the phrase “SV-ADAHRS-200/201” is used.
  • Page 106 SV-ADAHRS-200/201 Installation and Configuration Figure 38 – Suggested SV-ADAHRS-200/201 Installation Procedure Proper installation of the SV-ADAHRS-200/201 module(s) is critical. Correct PFD performance is significantly linked to a proper ADAHRS installation. The installation location must meet all of the mechanical, magnetic, orientation, placement, and environmental requirements detailed below.

  • Page 107: Optional Components For Easier Installation Of Your Sv-Adahrs-200/201

    SV-ADAHRS-200/201 Installation and Configuration Optional Components for Easier Installation of your SV-ADAHRS-200/201 Dynon Avionics offers a number of optional accessories for easier installation of your SV- ADAHRS-200/201. These accessories can be obtained from Dynon Avionics Sales, or your Dynon Avionics dealer. Dynon Avionics offers three different AOA/Pitot probes.

  • Page 108: Physical Installation

    SV-ADAHRS-200/201 Installation and Configuration Dynon Avionics offers the Dual ADAHRS Mounting Kit (P/N 102532-000) – see Figure 45. This kit allows the convenient “stacking” of an SV-ADAHRS-201 onto an SV-ADAHRS-200 for easier installation. This kit allows the dual ADAHRS units to be aligned exactly together in the pitch and roll axis, so there is no possibility that alignment of the two ADAHRS units can be different.
  • Page 109 SV-ADAHRS-200/201 Installation and Configuration Figure 46 – SV-ADAHRS-200/201 with Respect to Center-of-Gravity The instructions below regarding “magnetic suitability” are in reference to the internal magnetometer of the SV-ADAHRS-200/201. If the SV-MAG-236 Remote Magnetometer is installed in your SkyView system, the instructions regarding “magnetic suitability”...
  • Page 110 SV-ADAHRS-200/201 Installation and Configuration surfaces). Thus, you must avoid mounting the module close to sources of dynamic magnetic fields, avoid wires that carry large amounts of current, and use non-magnetic fasteners for installation (see caution below). We recommend that the SV-ADAHRS-200/201 or SV-MAG-236 be a minimum of 2 feet (0.61 meters) from sources of magnetic fields is usually adequate;...
  • Page 111 SV-ADAHRS-200/201 Installation and Configuration Mounting requirements for the SV-ADAHRS-200/201:  Must be mounted within one degree of parallel to all three aircraft axes,  The pneumatic fittings must face toward the front of the aircraft,  The mounting tabs must be towards the bottom of the aircraft, with the label towards the top of the aircraft.
  • Page 112 SV-ADAHRS-200/201 Installation and Configuration Internal Remote Displayed Rate Accel- Pitot Static Magnet- Magnet- Instrument Sensors erometer ometer ometer Ground  Speed (GND) Heading (HDG)      (Internal Magnetometer) Heading (HDG)      (External Magnetometer) Heading (HDG) ...
  • Page 113 SV-ADAHRS-200/201 Installation and Configuration Connecto Figure 48 – SV-ADAHRS-200/201 Mounting Dimensions with Electronic and Pneumatic Connections An SV-ADAHRS-200/201 should be mounted within one degree of parallel to all three aircraft axes, with the pneumatic fittings facing toward the front of the aircraft. To ensure that the Slip/Skid Ball will be displayed as centered during flight, the SV- ADAHRS-200/201 must be installed to 0°...
  • Page 114 SV-ADAHRS-200/201 Installation and Configuration Mounting hardware is not provided with the SV-ADAHRS-200/201. The mounting tabs on each side of the module have holes sized for #10 fasteners, but it is up to the installer to decide how the SV-ADAHRS-200/201 will be secured to the aircraft. We recommend the use of button-head style non-ferrous (brass recommended) fasteners in this location.
  • Page 115 SV-ADAHRS-200/201 Installation and Configuration Figure 49 – Dual ADAHRS Mounting Kit Instructions SkyView System Installation Guide - Revision AA 5-11...

  • Page 116: Skyview Network Connection

    SV-ADAHRS-200/201 Installation and Configuration SkyView Network Connection Connect the SV-ADAHRS-200/201 to the SkyView network using the hardware mentioned in the SkyView System Construction Section or using equivalent hardware. If you have to install a connector on the end of a network cable, insert all pins into the D9 connector.

  • Page 117: Compass Calibration

    SV-ADAHRS-200/201 Installation and Configuration Pitot/Static/AOA Pneumatic Installation Kit To install, simply connect your static and pitot sources to the SV-ADAHRS-200/201. If you are performing a retrofit installation, consider “teeing” off of existing lines using a tee fitting. Reference the sticker on top of the respective module for pneumatic port identification. Use a wrench to secure the mating pressure line fittings to the corresponding locations on the SV-ADAHRS-200/201.

  • Page 118: On-Ground Compass Calibration Procedure

    SV-ADAHRS-200/201 Installation and Configuration Tail wheel equipped aircraft can be calibrated in their normal nose up ground attitude as long as the SkyView attitude display shows the correct corresponding nose up attitude. A working GPS receiver with a view of the sky to acquire GPS data must be connected to the SkyView system in order to perform a compass calibration.

  • Page 119: In-Flight Compass Calibration Procedure

    SV-ADAHRS-200/201 Installation and Configuration In-flight Compass Calibration Procedure: The in-flight compass calibration should be conducted on a clear, VFR day. Before commencing the compass calibration, ensure that you have adequate altitude, clear weather, no traffic, no obstructions in the flight path, great visibility, no airspace conflicts, etc.
  • Page 120 SV-ADAHRS-200/201 Installation and Configuration Figure 50 – In-flight Compass Calibration Menu 5. Push the START button to begin the calibration. 6. Observe the NEW CALIBRATION section of the menu. The goal of the in-flight compass calibration is to achieve a compass calibration “quality” of at least 100. 7.

  • Page 121: Sv-Oat-340 Location And Installation

    SV-ADAHRS-200/201 Installation and Configuration SV-OAT-340 Location and Installation The SV-OAT-340 is designed specifically to work with the SV-ADAHRS-200/201 and SV-MAG-236. For full redundancy, a second ADAHRS module requires its own OAT sensor. Sensor Location The SV-OAT-340 is an outside air temperature sensor. In order for it work properly, it must be able to measure air temperature accurately.
  • Page 122 SV-ADAHRS-200/201 Installation and Configuration On the inside of the fuselage (consider getting assistance for some of the steps below because it may be difficult to be simultaneously on the inside and outside of the fuselage): 1. Feed the nylon washer over the cable. 2.

  • Page 123: Pfd-Related Settings

    SV-ADAHRS-200/201 Installation and Configuration PFD-Related Settings Once the physical ADAHRS installation is complete, it may be necessary to configure PFD- related ADAHRS settings for the SkyView system. All ADAHRS settings are automatically shared between displays in multi-display systems. Aircraft Icon The airplane symbol at the center of the compass rose on the PFD Page, and the center of MAP Page can be changed.
  • Page 124 SV-ADAHRS-200/201 Installation and Configuration To change which ADAHRS is the PRIMARY ADAHRS, highlight an ALTERNATE ADAHRS and press the PRIMARY button to elevate it to PRIMARY status. To disable an ADAHRS until SkyView is next powered up, simply highlight it with the joystick and press the DISABLE button.

  • Page 125: Other Adahrs Calibrations

    SV-ADAHRS-200/201 Installation and Configuration SV-SYNVIS-280 (Synthetic Vision – SynVis) License Display of Synthetic Vision (SynVis) is not supported in SkyView SE. If you intend to install and use SkyView SE, do not purchase or install an SV-SYNVIS-280 (or any other license).

  • Page 126: Performing Pitot/Static Checks

    SV-ADAHRS-200/201 Installation and Configuration AOA CALIBRATION If a Dynon Avionics AOA/Pitot Sensor is installed, familiarize yourself with the AOA calibration procedure before flight by reading through the instructions in the AOA Calibration Wizard: SETUP MENU > HARDWARE CALIBRATION > ADAHRS CALIBRATION > AOA CALIBRATION. Once you are flying straight and level at a safe altitude for stalls, go into the AOA Calibration Wizard (IN FLIGHT SETUP MENU >...
  • Page 127 SV-ADAHRS-200/201 Installation and Configuration  Keep aircraft still (do not move) when pressure is applied. Steps 1. The aircraft itself should be temperature stable. For example, if the aircraft is moved from outside in the sun to a hangar for testing, tests should not be started until the airplane has stabilized at the hangar temperature.

  • Page 129: Sv-Map-270 Navigation Mapping License Purchase And Setup

    SV-MAP-270 to be operated on any display in the system. Checking License Status Display of MAP is not supported in SkyView SE. If you intend to install and use SkyView SE, do not purchase or install an SV-MAP-270 (or any other license).
  • Page 130 All future updates to the SV-MAP-270 Navigation Mapping License. Purchasing and Installing a SV-MAP-270 Navigation Mapping License Display of MAP is not supported in SkyView SE. If you intend to install and use SkyView SE, do not purchase or install an SV-MAP-270 (or any other license).

  • Page 131: Databases

    Databases Display of MAP and Synthetic Vision (SynVis) is not supported in SkyView SE. Thus, Charts, Obstacles data, Terrain data, Basemap data, and Stadium TFR data are not supported in SkyView SE. Aviation data (including a "combo" .DUC file of AVIATION + OBSTACLE) is supported in SkyView SE solely to provide data for the SV-COM- PANEL APT, ATC, ATIS, GND, and TWR buttons.
  • Page 132 Note that in the popup message, only the first database that is past its expiration date is listed.  On a SkyView SE display, a CAUTION message will be displayed in the message area (lower right corner of the display). Like any other CAUTION message, as soon the CAUTION message is acknowledged (viewed), it will no longer appear (for the duration of that power-on cycle).
  • Page 133 SV-MAP-270 Navigation Mapping License Purchase and Setup Figure 52 – SkyView SE Aviation Database Expired Caution Message (Lower Left Corner of Display) Figure 53 – SkyView INSTALLED DATABASES with Expired Database Shown in Yellow SkyView System Installation Guide - Revision AA...

  • Page 134: Terrain Database

    Figure 54 – SkyView SE INSTALLED DATABASES with Expired Database Shown in Yellow Terrain Database Display of MAP and Synthetic Vision (SynVis) is not supported in SkyView SE. Thus, loading of Terrain databases is not necessary in SkyView SE. SkyView uses high resolution terrain databases to display the base topographic map on the MAP page, as well as to display Synthetic Vision on the PFD page.

  • Page 135: Aviation/Obstacle Databases

    Password: (blank) Aviation/Obstacle Databases Display of aviation data and obstacles (on MAP) is not supported in SkyView SE. LOADING of aviation data (including a "combo" .DUC file of AVIATION + OBSTACLE) is supported in SkyView SE to solely to provide data for the SV-COM-PANEL APT, ATC, ATIS, GND, and TWR buttons.

  • Page 136: Us Skyview Pilots - Stadium Tfr Database

    US SkyView Pilots – Stadium TFR Database Display of MAP and Synthetic Vision (SynVis) is not supported in SkyView SE. Thus, loading of Stadium TFR Database is not necessary in SkyView SE. In late 2014, the FAA discontinued transmission of US Stadium TFRs (Temporary Flight Restrictions) through the ADS-B system.

  • Page 137: Charts And Airport Diagrams

    SV-MAP-270 Navigation Mapping License Purchase and Setup Charts and Airport Diagrams Display of MAP and Synthetic Vision (SynVis) is not supported in SkyView SE. Thus, loading of Charts and Airport Diagrams is not necessary in SkyView SE. SkyView’s charting capabilities allow pilots to quickly find and display the procedures they need during flight, all while showing the aircraft’s position and track right on the chart itself.

  • Page 138: Loading Databases

    SkyView. Base Map (Cultural Data) Display of MAP and Synthetic Vision (SynVis) is not supported in SkyView SE. Thus, loading of Base Map (Cultural Data) is not necessary in SkyView SE. Base Map (Cultural Data) is available free-of-charge for all SkyView pilots for SkyView pilots worldwide.
  • Page 139 SV-MAP-270 Navigation Mapping License Purchase and Setup Aviation Data updates are published periodically by Dynon Avionics, PocketFMS, and Jeppesen. It is the user’s responsibility stay current with these updates and keep their equipment up to date. SkyView System Installation Guide - Revision AA 6-11...

  • Page 141: Sv-Ems-220/221 Installation And Configuration

    Figure 55 – SV-EMS-220 (SV-EMS-221 is externally identical) SkyView SE supports only one SV-EMS-220 or SV-EMS-221. If your aircraft has dual engines, or more than 7 cylinders (monitoring CHT and EGT for each), SkyView SE is not recommended. Thus, instructions for installation and configuration of a second SV-EMS-220 or SV-EMS-221 in this section is not applicable to a SkyView SE system.
  • Page 142 SkyView display (typically, the Left Engine is displayed on the left display and the Right Engine is displayed on the right display). Note: Only SkyView Classic provides support for dual SV-EMS-220/221 modules. SkyView SE and SkyView HDX (as of Software v15.0) do not support this feature.

  • Page 143: Physical Installation

    Note: Only SkyView Classic supports the use of dual SV-EMS-220/221 modules; this feature is not supported in SkyView SE and SkyView HDX (as of Software v15.0). The diagram below shows the mounting dimensions of the EMS module with electronic connections.
  • Page 144 SV-EMS-220/221 Installation and Configuration Figure 57 – SV-EMS-220/221 Mounting Dimensions with Electronic Connections Dynon Avionics does not include mounting hardware for use with the SV-EMS-220/221. The mounting tabs on each side of the module have holes sized for #10 fasteners, but it is up to the installer to decide how the EMS will be secured to the aircraft.

  • Page 145: Skyview Network Connection

    SV-EMS-220/221 Installation and Configuration SkyView Network Connection If you have installed two SV-EMS-220s or two SV-EMS- 221s to monitor a 9-cylinder (or more) engine or dual engines, Dynon Avionics offers the SV-NET-SPL “Splitter” Cable – see Figure 60. This cable allows a single (more economical, lower weight) SkyView Network Cable to be run to the location of dual SV-EMS-220/221s and then “split”...
  • Page 146 SV-EMS-220/221 Installation and Configuration compatible with SkyView. Use the tools in this section as well as the worksheet on page 24-1 when planning sensor and transducer installation. SV-EMS-220/221 Engine Sensor Kits Dynon Avionics offers kits of sensors and appropriate harnesses for several common engines. Note that the Fuel Flow Sensor, P/N 100403-003 is optional;...
  • Page 147 SV-EMS-220/221 Installation and Configuration Table 18 – EMSKIT-L4F, P/N 101711-003 – Lycoming / Continental / Superior 4 Cylinder, Fuel Injected Dynon Sensor Type Avionics Description Amps Shunt 100412-000 0-60 Amps, 1mV=1A Pressure – Fuel 101690-000 Kavlico 0 – 15 PSI Liquid Pressure Pressure –...
  • Page 148 SV-EMS-220/221 Installation and Configuration Dynon Sensor Type Avionics Description Amps Shunt 100412-000 0-60 Amps, 1mV=1A Pressure – Fuel 101716-000 Kavlico 0 – 50 PSI Liquid Pressure Pressure – Manifold 100434-000 0” – 60” hg, 1/8” hose Pressure – Oil 101693-000 Kavlico 0 –...
  • Page 149 SV-EMS-220/221 Installation and Configuration Dynon Sensor Type Avionics Description Amps Shunt 100412-000 0-60 Amps, 1mV=1A Fuel Flow Sensor data provided by Rotax 912 iS ECU via CAN BUS Pressure – Fuel 101716-000 Kavlico 0 – 50 PSI Liquid Pressure Pressure – Manifold Sensor data provided by Rotax 912 iS ECU via CAN BUS Pressure –...
  • Page 150 SV-EMS-220/221 Installation and Configuration Dynon Sensor Type Avionics Description Amps Shunt 100412-000 0-60 Amps, 1mV=1A Pressure – Fuel 101716-000 Kavlico 0 – 50 PSI Liquid Pressure Pressure – Oil Included on engine, not supplied by Dynon Avionics Type J (CHT) Thermocouple, Temp –...
  • Page 151 SV-EMS-220/221 Installation and Configuration Dynon Avionics Sensor Type Description Amps Shunt 100412-000 0-60 Amps, 1mV=1A Fuel Flow Pressure – Fuel Included on engine, not supplied by Dynon Avionics Pressure – Manifold 100434-000 0” – 60” hg, 1/8” hose Pressure – Oil Included on engine, not supplied by Dynon Avionics Skykit Airbox Temp Sensor (1/8-27 NPT), Temp –...
  • Page 152 SV-EMS-220/221 Installation and Configuration Dynon Avionics Sensor Type Description Fuel Flow 100403-003 1/4” Female NPT, 0.6 – 70 GPH Pressure – Fuel Included on engine, not supplied by Dynon Avionics Pressure – Fuel 101716-000 Kavlico 0 – 50 PSI Liquid Pressure –...
  • Page 153 SV-EMS-220/221 Installation and Configuration Table 28 – Dynon Avionics EMS Wire Harnesses A typical SV-EMS-220 installation will utilize one EMS 37-pin Main Sensor Harness and one of thermocouple wire harness. A typical SV-EMS-221 installation does not utilize a thermocouple harness. Choose a thermocouple wire harness based on the number of EGTs and/or CHTs that need to be monitored.
  • Page 154 SV-EMS-220/221 Installation and Configuration potentiometers. For example, SV-EMS-220/221 D37 pin 4 can be configured to read a resistive oil temperature sensor. Sensor and transducer compatibility level B denotes that an SV-EMS-220/221 D37 pin labeled as “B” in Table 30 can be configured to support every sensor and transducer listed for “A” while also being compatible with 4 to 20 mA constant current source output sensors that are supported (currently only the Rotax P/N 956413 Honeywell and Rotax P/N 456180 oil pressure sensors).
  • Page 155 SV-EMS-220/221 Installation and Configuration Sensor and Transducer Example sensors and transducers Compatibility Level Carburetor Temperature - Dynon Avionics 2-wire – P/N 100468-000 Contacts CHT – Rotax Fluid Pressure 0-5 PSI (Kavlico) – P/N 101715-000 Fluid Pressure 0-15 PSI (Kavlico) – P/N 101690-000 Fluid pressure 0-50 PSI (Kavlico) –...
  • Page 156 SV-EMS-220/221 Installation and Configuration EMS 37-pin Harness Wire Function Sensor Config Color Voltmeter 1 (0 to 30 volts DC) Yellow or Unwired Voltmeter 2 (0 to 30 volts DC) Black Ground Violet/Blue General Purpose Input 1 Black Ground General Purpose Input 11 White/Yellow (Typically used for Fuel Pressure) General Purpose Input 12...
  • Page 157 SV-EMS-220/221 Installation and Configuration EMS 37-pin Harness Wire Function Sensor Config Color White/Green Standard RPM Input Left White/Blue Standard RPM Input Right Blue Low Voltage RPM Input Left - do not connect to magneto Green Low Voltage RPM Input Right – do not connect to magneto SV-EMS-220: General Purpose TC Input 2+ Thermocouple + Blue or Unwired...
  • Page 158 SV-EMS-220/221 Installation and Configuration Rotax 912 Harness 4-cyl Harness 6-cyl Harness Wire Function Sensor Config (except 912 iS) (100399-001) (100399-002) Color (100399-004) Do not connect  CHT 6 J thermocouple  EGT 6 K thermocouple  CHT 5 J thermocouple ...
  • Page 159 SV-EMS-220/221 Installation and Configuration configure SkyView to support any installations that are not already supported in the preconfigured downloadable resources. Figure 60 is a pin insertion view (rear) of the D25M connector on the Thermocouple Wire Harness. Figure 60 – Thermocouple Wire Harness D25M Pin Insertion View (Rear) Sensors Powered by the SV-EMS-220/221 Some sensors use a 5V (pin 18;...

  • Page 160: Example Engine Sensor And Transducer Installations

    SV-EMS-220/221 Installation and Configuration this section are designed to not exceed these current limitations. However, more complex and installations that differ significantly from these standard installations should be designed to not exceed the following current limitations: Output Module Current Wire Color Current Draw of Sensors that Use This Output Output Limit...

  • Page 161: Lycoming/Continental 4-Cylinder Carbureted

    SV-EMS-220/221 Installation and Configuration Lycoming/Continental 4-cylinder Carbureted Table 33 and Table 34 below are suggested sensor connections for a Lycoming/Continental 4- cylinder Carbureted engine connected to an SV-EMS-220 EMS module. EMS D37F Harness Sensor Wire Color (with Dynon Avionics P/N if applicable) Battery voltage (voltmeter input) Yellow or Unwired No connection...
  • Page 162 SV-EMS-220/221 Installation and Configuration EMS D25M Thermocouple Sensor Harness Wire Color (with Dynon Avionics P/N if applicable) No Wire No connection No Wire No connection No Wire No connection No Wire No connection No Wire No connection CHT 4 (J-type thermocouple, 100404-000) EGT 4 (K-type thermocouple, 100405-000) CHT 3 (J-type thermocouple, 100404-000) EGT 3 (K-type thermocouple, 100405-000)

  • Page 163: Lycoming/Continental 4-Cylinder Fuel Injected

    SV-EMS-220/221 Installation and Configuration Lycoming/Continental 4-cylinder Fuel Injected Table 35 and Table 36 below are suggested sensor connections for a Lycoming/Continental 4- cylinder Fuel-Injected engine connected to an SV-EMS-220 EMS module. EMS D37F Harness Sensor Wire Color (with Dynon Avionics P/N if applicable) Battery voltage (voltmeter input) Yellow or Unwired No connection...
  • Page 164 SV-EMS-220/221 Installation and Configuration Blue or Unwired No connection Green or Unwired No connection Table 35 – Suggested Lycoming/Continental 4-cylinder Fuel Injected Sensor Connections for EMS D37F Harness EMS D25M Thermocouple Sensor Harness Wire Color (with Dynon Avionics P/N if applicable) No Wire No connection No Wire...

  • Page 165: Lycoming/Continental 6-Cylinder Carbureted

    SV-EMS-220/221 Installation and Configuration Lycoming/Continental 6-cylinder Carbureted Table 37 and Table 38 below are suggested sensor connections for a Lycoming/Continental 6- cylinder Carbureted engine connected to an SV-EMS-220 EMS module. EMS D37F Harness Sensor Wire Color (with Dynon Avionics P/N if applicable) Battery voltage (voltmeter input) Yellow or Unwired No connection...
  • Page 166 SV-EMS-220/221 Installation and Configuration Blue or Unwired No connection Green or Unwired No connection Table 37 – Suggested Lycoming/Continental 6-cylinder Carbureted Sensor Connections for EMS D37F Harness EMS D25M Thermocouple Sensor Harness Wire Color (with Dynon Avionics P/N if applicable) No Wire No connection CHT 6 (J-type thermocouple, 100404-000)

  • Page 167: Lycoming/Continental 6-Cylinder Fuel Injected

    SV-EMS-220/221 Installation and Configuration Lycoming/Continental 6-cylinder Fuel Injected Table 39 and Table 40 below are suggested sensor connections for a Lycoming/Continental 6- cylinder Fuel-Injected engine connected to an SV-EMS-220 EMS module. EMS D37F Harness Sensor Wire Color (with Dynon Avionics P/N if applicable) Battery voltage (voltmeter input) Yellow or Unwired No connection...
  • Page 168 SV-EMS-220/221 Installation and Configuration Blue or Unwired No connection Green or Unwired No connection Table 39 – Suggested Lycoming/Continental 6-cylinder Fuel Injected Sensor Connections for EMS D37F Harness EMS D25M Thermocouple Sensor Harness Wire Color (with Dynon Avionics P/N if applicable) No Wire No connection CHT 6 (J-type thermocouple, 100404-000)

  • Page 169: Jabiru 2200

    SV-EMS-220/221 Installation and Configuration Jabiru 2200 Table 41 and Table 42 below are suggested sensor connections for a Jabiru 2200 engine connected to an SV-EMS-220 EMS module. EMS D37F Harness Sensor Wire Color (with Dynon Avionics P/N if applicable) Battery voltage (voltmeter input) Yellow or Unwired No connection Black...
  • Page 170 SV-EMS-220/221 Installation and Configuration Green or Unwired No connection Table 41 – Suggested Jabiru 2200 Sensor Connections for EMS D37F Harness EMS D25M Thermocouple Sensor Harness Wire Color (with Dynon Avionics P/N if applicable) No Wire No connection No Wire No connection No Wire No connection...

  • Page 171: Jabiru 3300

    SV-EMS-220/221 Installation and Configuration Jabiru 3300 Table 43 and Table 44 below are suggested sensor connections for a Jabiru 3300 engine connected to an SV-EMS-220 EMS module. EMS D37F Harness Sensor Wire Color (with Dynon Avionics P/N if applicable) Battery voltage (voltmeter input) Yellow or Unwired No connection Black...
  • Page 172 SV-EMS-220/221 Installation and Configuration Green or Unwired No connection Table 43 – Suggested Jabiru 3300 Sensor Connections for EMS D37F Harness EMS D25M Thermocouple Sensor Harness Wire Color (with Dynon Avionics P/N if applicable) No Wire No connection CHT 6 (J-type thermocouple, 100404-000) EGT 6 (K-type thermocouple, 100405-000) CHT 5 (J-type thermocouple, 100404-000) EGT 5 (K-type thermocouple, 100405-000)

  • Page 173: Rotax 912 Uls Carbureted

    SV-EMS-220/221 Installation and Configuration Rotax 912 ULS Carbureted Table 45 and Table 46 below are suggested sensor connections for a Rotax 912 ULS Carbureted engine connected to an SV-EMS-220 EMS module. EMS D37F Harness Sensor Wire Color (with Dynon Avionics P/N if applicable) Battery voltage (voltmeter input) Yellow or Unwired No connection...
  • Page 174 SV-EMS-220/221 Installation and Configuration Green or Unwired No connection Table 45 – Suggested Rotax 912 ULS Carbureted Sensor Connections for EMS D37F Harness EMS D25M Thermocouple Sensor Harness Wire Color (with Dynon Avionics P/N if applicable) Open Open Open Open Open EGT 2 (K-type thermocouple, 100405-000*) EGT 1...

  • Page 175: Rotax 912 Is (Electronic Control Unit)

    SV-EMS-220/221 Installation and Configuration Rotax 912 iS (Electronic Control Unit) Table 45 below is the suggested sensor connections for a Rotax 912 iS engine connected to an SV-EMS-221 EMS module. Note that the Rotax 912 iS engine does not utilize thermocouple sensors to monitor CHT and EGT temperatures on the SV-EMS-221 EMS module, thus there is no connection to the D25F connector on the SV-EMS-221.
  • Page 176 SV-EMS-220/221 Installation and Configuration EMS D37F Harness Sensor Wire Color (with Dynon Avionics P/N if applicable) Blue No connection Green No connection Blue or Unwired CAN High from 912 iS ECU Green or Unwired CAN Low from 912 iS ECU Table 47 –...
  • Page 177 SV-EMS-220/221 Installation and Configuration Figure 61 – SV-EMS-221 / Rotax 912 iS Connections Other connections, including fuel pressure, amps, volts, trim/flaps, and fuel quantity sensors are made in the usual way between the individual sensors and the SV-EMS-221 directly. Additional Rotax 912 iS Installation Instructions When installing the SV-EMS-221 and the Rotax 912 iS and configuring the SkyView EMS system, please observe the following: ...
  • Page 178 SV-EMS-220/221 Installation and Configuration  The latest EMS sensor definitions file must be downloaded from the SkyView Downloads page at http://downloads.dynonavionics.com and loaded onto each display. To verify, check SETUP MENU > SYSTEM SETUP > EMS SETUP > SENSOR DEBUG DATA. The date of the sensor definition file currently loaded on the display will be displayed on the top line of the right window.
  • Page 179 SV-EMS-220/221 Installation and Configuration Example 9-cylinder Radial (Using Dual SV-EMS-220s, 100399-000, 100399-001, 100399-002 Harnesses) PRIMARY EMS MODULE with 100399-000 Harness EMS 37-pin Harness Sensor Wire Color (with Dynon Avionics P/N if applicable) Battery Voltage (Voltmeter Input) Yellow or Unwired No connection Black Ground Violet/Blue...
  • Page 180 SV-EMS-220/221 Installation and Configuration PRIMARY EMS MODULE with 100399-002 Harness EMS 25-pin Thermocouple Sensor Harness Wire Color (with Dynon Avionics P/N if applicable) Open CHT 6 (J-type thermocouple, 100404-000*) EGT 6 (K-type thermocouple, 100405-000*) CHT 5 EGT 5 CHT 4 EGT 4 CHT 3 EGT 3...
  • Page 181 SV-EMS-220/221 Installation and Configuration SECONDARY EMS MODULE with 100399-001 Harness EMS 25-pin Thermocouple Sensor Harness Wire Color (with Dynon Avionics P/N if applicable) Open Harness does not have a wire in this pin Harness does not have a wire in this pin Harness does not have a wire in this pin Harness does not have a wire in this pin Not Connected (Harness label CHT 4)

  • Page 182: Dual Engine Support Using Dual Sv-Ems-220/221S And Two Skyview Classic Displays

    Support for dual SV-EMS-220/221 modules is supported only in SkyView Classic; this feature is not supported in SkyView SE or SkyView HDX (as of Software v15.0). SkyView Classic can monitor dual engines by displaying engine data for each engine on separate SkyView Classic displays.

  • Page 183: Engine Sensor And Transducer Installation

    SV-EMS-220/221 Installation and Configuration If, after setting up dual engine support per the above instructions, if DUAL ENGINE SUPPORT is later changed to NO, engine timer values (such as HOBBS) displayed on the individual EMS screens will be reset. One SkyView Classic display’s timers will overwrite timers on all other displays.

  • Page 184: Tools And Equipment Required

    SV-EMS-220/221 Installation and Configuration Engine Monitor readings by having a good ground will also lead to a healthier aircraft electrical system overall. Tools and Equipment Required The following list contains commonly used tools and equipment, however some of the tools or equipment listed below may not apply to your installation.
  • Page 185 SV-EMS-220/221 Installation and Configuration Consult the specific engine’s manual for proper EGT locations. Rotax 912 (except 912 iS) For carbureted Rotax 912 engines, only two of the four cylinders are typically monitored for EGT. Unlike the CHT sensors which are mounted on diagonal cylinders, the EGT sensors should be mounted on the two rear cylinders’...

  • Page 186: Cylinder Head Temperature (Cht) Sensors

    SV-EMS-220/221 Installation and Configuration Cylinder Head Temperature (CHT) Sensors Wire length of CHT/EGT harnesses supplied by Dynon Avionics is not critical. It is acceptable to cut the thermocouple (brown) wire of the CHT/EGT harness to shorten the appropriate length for your installation. It is recommended to not cut the “armored”...

  • Page 187: Tachometer

    SV-EMS-220/221 Installation and Configuration Tachometer Tachometer pulses/revolution are set in the Engine Information Wizard – SETUP MENU > HARDWARE CALIBRATION > EMS CALIBRATION > TACHOMETER CALIBRATION. Dynon Avionics does not sell a tachometer transducer. Depending upon existing equipment and engine type, you have a few options for connecting the tachometer inputs on the SV-EMS-220/221.
  • Page 188 SV-EMS-220/221 Installation and Configuration Connect them as shown in Figure 64. It is important to connect each resistor as close as possible to the spot where you tap into the P-lead. This minimizes the length of cable carrying high voltage spikes. Six-cylinder Lycoming engines sometimes need more inline resistance to prevent false readings by the SV-EMS-220/221.

  • Page 189: Manifold Pressure Sensor

    SV-EMS-220/221 Installation and Configuration 2.0V relative to ground. If the peak voltage exceeds 50 volts, use the included 30 kΩ resistors as described in the P-lead pickoff (Lycoming and Continental) Section above. For signals that have a peak voltage of 12V or lower —such as Light Speed ignition outputs— use the low voltage RPM inputs.

  • Page 190: Oil Pressure Sensor

    SV-EMS-220/221 Installation and Configuration Plug the crimped pins into the included Weatherpack connector. Now, mount the manifold pressure sensor in a secure fashion using the mounting holes on either side of the sensor. The pressure port on the manifold pressure sensor requires 1/4” inner diameter tubing for a secure fit.
  • Page 191 SV-EMS-220/221 Installation and Configuration Legacy Dynon Avionics Oil Pressure Sensor (P/N 100411-002) As of 2012, Dynon Avionics no longer supplies this sensor. For new installations, use the Kavlico oil pressure sensor (above). To retrofit an installation of this sensor with a Kavlico oil pressure sensor, see Retrofit Legacy Oil Pressure Sensor with Kavlico Oil Pressure Sensor, above.
  • Page 192 SV-EMS-220/221 Installation and Configuration Rotax Sensor Rotax Connector SV-EMS-220/221 SV-EMS-220/221 Connector Pin Wire Color Wire Color Pin Number White White / Yellow It is acceptable to It is acceptable to share this pin / wire share this pin / wire with other sensors;...

  • Page 193: Oil Temperature Sensors

    SV-EMS-220/221 Installation and Configuration Note: If you are converting a Dynon Avionics D10/D100 product installation to a SkyView installation, you should remove any resistor that is connected to the existing oil pressure sensor. It is not needed when used with SkyView. Rotax oil pressure sensors, including P/N 456180 and P/N 956413, are compatible only with SV-EMS-220/221 D37 pin 6 (White/Yellow wire).

  • Page 194: Fuel Pressure Sensor

    SV-EMS-220/221 Installation and Configuration Fuel Pressure Sensor Kavlico Fuel Pressure Sensors: 5 PSI (Gravity Feed) – P/N 101715-000 15 PSI (Carbureted) – P/N 101690-000 50 PSI (Fuel Injected) – P/N 101716-000 Mount the fuel pressure sensor securely using an Adel clamp or other method such as using a transducer mounting block on the firewall.
  • Page 195 SV-EMS-220/221 Installation and Configuration Legacy Dynon Avionics Fuel Pressure Sensors (P/N 100411-000 and 100411-001) As of 2012, Dynon Avionics no longer supplies this sensor. For new installations, use the Kavlico fuel pressure sensors (above). If you have a carbureted engine (legacy 30 PSI fuel pressure sensor), select from the Kavlico 0-5 PSI fuel pressure sensor (P/N 101715-000) or the Kavlico 0-15 PSI fuel pressure sensor (P/N 101690- 1/8-27 NPT...
  • Page 196 SV-EMS-220/221 Installation and Configuration For Dynon Avionics P/N 100411-000 and P/N 100411-001 pressure sensors, if Teflon tape or other sealant is used, ensure the sensor casing still maintains a good connection to ground. Rotax 914 Differential Fuel Pressure Sensor The fuel pressure sensors that Dynon Avionics sells are not suitable for use with the Rotax 914 engine, as Rotax specifies that fuel pressure on the 914 engine be measured with respect to the air box pressure.

  • Page 197: Fuel Flow Transducer

    SV-EMS-220/221 Installation and Configuration Configure the pin you chose: (SETUP MENU > EMS SETUP > SENSOR INPUT MAPPING > C37 P8 / P22 / P23 / P31: Rotax 914 Diff Fuel Press Fuel Flow Transducer The approximate pulses/gallon setting for the FloScan 201B (i.e., cast metal case legacy Dynon Avionics fuel flow transducer) is 28,000 to 31,000 (see the tag on the unit).
  • Page 198 SV-EMS-220/221 Installation and Configuration The SV-EMS-220/221 supports differential fuel flow transducer installations in Rotax 912 and 914 installations as illustrated in Figure 73. General Placement Recommendations for Fuel Flow Transducer  Do not install the fuel flow transducer, hoses and fittings near exhaust system or turbocharger.

  • Page 199: Fuel Level Sensor

    SV-EMS-220/221 Installation and Configuration 912 (ULS) Installation Restrictor for 912 (ULS) From Fuel Flow Fuel To Carburetors Transducer Tank Fuel Flow Transducer Fuel Output Signal Tank SV-EMS-220 912 (ULS) or 914 Installation To Carburetors From Fuel Flow Fuel Flow Fuel Fuel Transducer Transducer...
  • Page 200 SV-EMS-220/221 Installation and Configuration  FUEL LEVEL (RESISTIVE) – averages changes in fuel level over 1.5 minutes, with most of the change occurring within the first minute). This is a change from previous versions of this setting, and is the default setting. ...

  • Page 201: Ammeter Shunt

    SV-EMS-220/221 Installation and Configuration If you have a Van’s Aircraft RV and have installed the capacitive plates fuel level sensor option, and are installing the Dynon Avionics Capacitance to Voltage Converter for Van’s Capacitive Plates (P/N 100654-000), instructions for installing this option can be found at Capacitance to Voltage Converter for Van’s Capacitive Plates in Accessory Installation and Configuration.
  • Page 202 SV-EMS-220/221 Installation and Configuration  If you have a VP-X system (SkyView Classic only) in your avionics system, use either position A or position B. Position C is not useful in a VP-X installation because the VP-X measures aircraft loads directly. Position A – Ammeter Figure 74 –...
  • Page 203 SV-EMS-220/221 Installation and Configuration Figure 76 – Amps Shunt Fuse / Wire Connection Diagram Next, crimp the two supplied #8 ring terminals onto the wires using the fusing method chosen above. Connect the other ends of the fuses to the Amps High and Amps Low leads (pins 24 and 25) on the EMS 37-pin Main Sensor Harness.
  • Page 204 SV-EMS-220/221 Installation and Configuration The GRT CS-01 and CS-02 do not connect to Pin 24/25 (Amps Shunt +/- Input). If you are converting from a Dynon Avionics EMS-D10, EMS-D120, or FlightDEK- D180, you must change your wiring per the instructions below. Identify the power cable for which you wish to monitor current flow.

  • Page 205: Carburetor Temperature Sensor

    SV-EMS-220/221 Installation and Configuration o Because each individual CS-01 and CS-02 varies somewhat, configuring the CS-01 and CS-02 typically requires an amps "offset" value to be utilized. SkyView provides 17 different offsets for each sensor via different choices in the SENSOR column. These contain offsets that range from "-8"...

  • Page 206: Trim And Flaps Position Potentiometers

    SV-EMS-220/221 Installation and Configuration Note: If you are converting a Dynon Avionics D10/D100 product installation to a SkyView installation, you should remove any resistor that is connected to the Rotax CHTs. They are not needed when used with SkyView. Trim and Flaps Position Potentiometers Position potentiometers may be connected to any general purpose input pin on the SV-EMS- 220/221’s D37 and must be calibrated according to the instructions found in the EMS Sensor Calibration Section.

  • Page 207: Coolant Pressure Sensor

    SV-EMS-220/221 Installation and Configuration Any of 4, 6, 7, 8, 9, White / Green Varies 10, 11, 12, 20, 21, Signal 22, 23, 31 Figure 77 – Ray Allen Trim Motor Position Sensor Wiring Trim and flaps position potentiometers must be calibrated. Your SkyView display utilizes onscreen wizards that help you do this.
  • Page 208 SV-EMS-220/221 Installation and Configuration Pressure Sensor Wire Color White / Red It is acceptable to share this It is acceptable to share this Power pin / wire with other sensors; pin / wire with other sensors; (5V) see Table 32 above. see Table 32 above.

  • Page 209: Coolant Temperature Sensor

    SV-EMS-220/221 Installation and Configuration Crimp a standard ¼” female Faston onto one of the grounds coming from the SV-EMS- 220/221’s EMS 37-pin Main Sensor Harness. Crimp another ¼” female Faston onto the wire that corresponds to the desired general purpose input. Push the two Fastons onto the two terminals on the fuel pressure sensor.

  • Page 210: Rotax 914 Air Box Temperature

    SV-EMS-220/221 Installation and Configuration Rotax 914 Air Box Temperature Rotax supplies one Skykit Air Box temperature sensor on the 914 for connection to the 914 Turbo Control Unit (TCU). If you wish to monitor Air Box temperature on SkyView, install a second Skykit Air Box temperature sensor and connect it to any of Pins 4, 6, 7, 8, 9, 10, 11, 12, 20, 21, 22, 23, or 31 on the SV-EMS-220/221.

  • Page 211: General Purpose Thermocouple

    SV-EMS-220/221 Installation and Configuration  Install the GEAR contact that when the landing gear is up, the state of the contact is UP and when the landing gear is down, the state of the contact is DOWN.  SETUP MENU > AIRCRAFT INFORMATION: >...

  • Page 212: External Ems Warning Light

    SV-EMS-220/221 Installation and Configuration Dynon Avionics sells both J and K type thermocouple wire which may be used to connect the desired thermocouple to the SkyView. Ensure you order the correct wire type for the thermocouple you intend to use. Crimp a Female DSUB pin on the end of each wire, and plug them into the SV-EMS-220’s EMS 37-pin Main Sensor Harness D37.
  • Page 213 SV-EMS-220/221 Installation and Configuration If you are getting an auto Lean-of-Peak indication that is coming on too early, before the engine actually peaks while leaning, lower this number. It is not meant to be a measure of actual horsepower produced, as engines that are more efficient will act as if they are lower horsepower in the calculation.

  • Page 214: Ems Sensor Definitions, Mapping, And Settings

    SV-EMS-220/221 Installation and Configuration  0-1400 and 5800-6000 RPM in RED  1400-1800 and 5500-5800 RPM in YELLOW  1800-5500 RPM in GREEN At 0 RPM, tachometer alerting is inhibited. When RPM advances above 0, the tachometer alert is inhibited for 10 seconds to avoid nuisance alarms as the engine starts. The alarm type for the tachometer is the “self-clearing”...

  • Page 215: Ems Sensor Input Mapping

    SV-EMS-220/221 Installation and Configuration The SkyView Sensor Definitions file has a .sfg file extension. This file is not automatically shared between displays. It must be loaded onto each display in the system. EMS Sensor Input Mapping In order to save installers time, Dynon Avionics provides preconfigured sensor mapping and settings files which support popular four and six-cylinder engine installations.

  • Page 216: Ems Sensor Settings

    SV-EMS-220/221 Installation and Configuration Loading a premade sensor mapping file onto SkyView can save installation time. These files define sensors with the four parameters mentioned. Table 63 shows an example oil pressure sensor map on pin 6 of the SV-EMS-220/221 D37 connector.
  • Page 217 SV-EMS-220/221 Installation and Configuration  OFF – no alarm for the sensor.  SELF-CLEAR – When an alert is triggered, it is annunciated both on the engine page and in the messaging system. When the alert condition ceases, all of these annunciations cease, even if the precise alert message was not acknowledged by pressing the rightmost button on the display to bring up the message window.
  • Page 218 SV-EMS-220/221 Installation and Configuration For example, you could set up two ranges for the same gauge, each 0-10, one Red, and one Green, and that range would be Red. To further illustrate this behavior, if another range for that same gauge was configured from 5-15 and set to Yellow, only 10-15 would be Yellow. The two edge ranges are considered to go on "forever,"...
  • Page 219 SV-EMS-220/221 Installation and Configuration the pulses/gallon is adequately set, the fuel seen returning through the second fuel flow sensor is automatically subtracted from the flow that is seen through the primary sensor. If you do not have a second fuel flow sensor, you may ignore this setting entirely. In SETUP MENU >...
  • Page 220 SV-EMS-220/221 Installation and Configuration 2. Set the alarm. Scroll to the ALARM configuration line, move the joystick right to enter the Alarm Adjust Menu, choose the appropriate alarm for the sensor, and then press ACCEPT. Press BACK to return to the sensor configuration menu. 3.
  • Page 221 SV-EMS-220/221 Installation and Configuration  RANGE 4 o ENABLE o COLOR YELLOW o TOP 14.6 VOLTS o BOTTOM 13.6 VOLTS  RANGE 5 o ENABLE o COLOR o TOP 15.0 VOLTS o BOTTOM 14.6 VOLTS Example Contact Sensor Setup Assume this sensor was mapped on the Sensor Input Mapping Wizard as: PIN # FUNCTION SENSOR...
  • Page 222 SV-EMS-220/221 Installation and Configuration o COLOR o TOP 5.0 VOLTS o BOTTOM 2.5 VOLTS  RANGE 2 o ENABLE o NAME CLOSED o COLOR GREEN o TOP 2.5 VOLTS o BOTTOM 0.0 VOLTS  RANGE 3 o ENABLE o NAME o COLOR GREEN o TOP...
  • Page 223 SV-EMS-220/221 Installation and Configuration o COLOR YELLOW o TOP 2250 RPM o BOTTOM 2000 RPM  RANGE 3 o ENABLE o COLOR GREEN o TOP 2700 RPM o BOTTOM 2250 RPM  RANGE 4 o ENABLE o COLOR YELLOW o TOP 2750 RPM o BOTTOM 2700 RPM...
  • Page 224 SV-EMS-220/221 Installation and Configuration Example Oil Temperature Sensor Setup Assume this sensor was mapped on the Sensor Input Mapping Wizard as: PIN # FUNCTION SENSOR NAME C37 P7 TEMPERATURE 5/8”-18 NPT FLUID TEMP P/N 100409-000 Table 67 – Example Sensor Input Mapping for C37 P7 (Oil Temp) Now, we want to configure its alert and graphical properties.

  • Page 225: Ems Screen Layout Editor

    3. Change the size of the widget. Press SIZE until the widget’s size is acceptable. 4. Change the location of the widget on the screen. a. In SkyView Classic and SkyView SE, move the CURSR joystick in up, down, right, and left directions until the location is acceptable. Hold the joystick in those movement positions for accelerated widget movement.
  • Page 226 SV-EMS-220/221 Installation and Configuration Press REMOVE to remove the chosen widget from the screen. Press CANCEL to return to the EMS Setup Menu without saving any changes. Example widget configuration This example configures an oil temperature widget using the instructions mentioned above. This is the same oil temperature sensor that was configured earlier (see Example Oil Temperature Sensor Setup).

  • Page 227: Ems Sensor Calibration

    SV-EMS-220/221 Installation and Configuration Figure 86 – Example Oil Temperature Widget Styles You can also adjust the size of the widget by pressing SIZE. Figure 87 – Example Oil Temperature Widget Sizes Now, locate the widget on the screen by moving the joysticks left, right, up, and down. Once you have decided on a location for this widget, you can add and configure more widgets (press SENSOR to add another widget and follow the procedure on the preceding page) and then save the page layout by pressing SAVE.

  • Page 228: Skyview Hdx Engine Bottom Band

    SV-EMS-220/221 Installation and Configuration SkyView HDX ENGINE BOTTOM BAND Figure 88 – SkyView HDX EMS BOTTOM BAND Layout There are two considerations necessary when laying out the engine sensors on the ENGINE BOTTOM BAND:  Depending on the layout of your SkyView HDX, the layout seen above (dials on the left side, bar graphs on the right side) may be swapped (dials on the right side, bar graphs on the left side).

  • Page 229: Sv-Gps-250/2020 Gps Receiver Installation And Configuration

    8. SV-GPS-250/2020 GPS Receiver Installation and Configuration SkyView SE supports only one unit, either an SV-GPS-250 or an SV-GPS-2020, as a GPS position source. The installation of a secondary GPS position source is not supported in SkyView SE. Thus, instructions for installation and configuration of a secondary GPS position source in this section are not applicable to a SkyView SE system.

  • Page 230: Waas Data Reception

    GPS can be either an SV-GPS-250 (including an existing SV-GPS-250) or a second SV-GPS-2020. There is no restriction on equipping a SkyView system with a second SV-GPS-2020. (A secondary GPS position source is not supported in SkyView SE). Meets FAA 2020 ADS-B...

  • Page 231: Use Of The Sv-Gps-2020 Outside The Us

    SV-GPS-250/2020 GPS Receiver Installation and Configuration Only the SV-GPS-2020 or equivalent “high integrity” GPS unit meets the (GPS portion of the) requirements of the FAA 2020 ADS-B Out mandate. If you are equipping your plane for use in the US, compliant with the FAA 2020 ADS-B Out mandate, we recommend that you install the SV-GPS-2020, not the SV-GPS-250 (except as a secondary GPS).

  • Page 232: Physical Installation

    SV-GPS-250/2020 GPS Receiver Installation and Configuration Figure 91 – Suggested SV-GPS-250/2020 Installation and Configuration Procedure Physical Installation Like all GPS devices, for most reliable performance, the SV-GPS-250/SV-GPS-2020 require a clear, unobstructed “view” of the sky. The SV-GPS-250/SV-GPS-2020 are designed to be mounted on the upper fuselage of the aircraft for an unobstructed (360°...
  • Page 233 SV-GPS-250/2020 GPS Receiver Installation and Configuration Figure 92 – SV-GPS-250/2020 Mounting Dimensions Mounting hardware is not included. The SV-GPS-250/2020 is designed to install with #8 fasteners with 100 degree countersunk heads. The use of nut plates is recommended for convenience, but other hardware can be used if space allows. Specific hardware selection is determined by the installer.

  • Page 234: Considerations For Installing An Sv-Gps-2020 In An Aircraft With An Installed Sv-Gps-250

    Considerations for installing an SV-GPS-2020 in an aircraft with an installed SV-GPS-250 SkyView SE supports only a primary GPS position source. Thus, if you have an SV- GPS-250 currently installed, and plan to install SkyView SE, the SV-GPS-250 must be replaced with an SV-GPS-2020.

  • Page 235: Serial Data Connection

    SV-GPS-250/2020 GPS Receiver Installation and Configuration  At the SkyView display(s), splice the Black wire of the SV-GPS-250 to the Black wire of the SV-GPS-2020.  Connect the SV-GPS-2020’s Gray/Violet (TX) wire to Serial Port 1, 2, 3, or 4 RX wire. ...
  • Page 236 SV-GPS-250/2020 GPS Receiver Installation and Configuration Figure 93 – SV-GPS-250/2020 Connected to Multiple SkyView Displays If there is more than one SV-GPS-250/2020 in your system (including one SV-GPS-250 and one SV-GPS-2020, use the same scheme in Figure 93 on different display serial ports for the other SV-GPS-250/2020 modules, but connect power and ground for the other SV-GPS-250/2020 modules to the same power and ground connections (black and orange wires) that are provided in the serial port 5 wiring bundle on the display harnesses.
  • Page 237 SV-GPS-250/2020 GPS Receiver Installation and Configuration Figure 94 – SV-GPS-2020 and SV-GPS-250 Connected to Multiple Displays (not applicable to SkyView SE) Secondary GPS Serial Serial Port 1 Serial Port 2 Serial Port 3 Serial Port 4 Connection Wire Color / Pin...

  • Page 238: Configuration - Sv-Gps-2020 Only, Serial Port 5

    SV-GPS-250/2020 GPS Receiver Installation and Configuration Configuration – SV-GPS-2020 only, Serial Port 5 Go to the Serial Port Setup Menu (SETUP MENU > SYSTEM SETUP > SERIAL PORT SETUP > SERIAL PORT 5 SETUP) and then configure serial port 5 as follows: SERIAL IN DEVICE: DYNON SV-GPS-2020 SERIAL IN FUNCTION:...

  • Page 239: Testing / Troubleshooting Installation Of The Sv-Gps-250 And/Or Sv-Gps-2020

    SV-GPS-250/2020 GPS Receiver Installation and Configuration Thus, if an SV-GPS-250 is currently installed, for “upgrade protection” do not connect the SV-GPS-250’s serial TX to any device other than the SV-GPS-250. This guidance is reflected in all wiring diagrams for the SV-GPS-250 and SV-GPS-2020. If (as is possible in Software versions through v14.0) a serial device other than an SV-GPS-2020 was connected to the SV-GPS-2020 serial port TX, that other device will no longer function (communicate), and the SV-GPS-2020 may not function...

  • Page 240: Part 2 - Gps Receive Performance

    SV-GPS-250/2020 GPS Receiver Installation and Configuration On this screen, verify the following:  SERIAL IN DEVICE matches the device connected – either SV-GPS-250 or SV-GPS-2020; if the incorrect device is selected, no GPS data will be received.  Verify that SERIAL IN FUNCTION is set to POS 1 for the primary (or only) GPS receiver, or POS 2 for the secondary GPS receiver.
  • Page 241 SV-GPS-250/2020 GPS Receiver Installation and Configuration Figure 96 – GPS FIX STATUS – Very Good, 3D DIFF Figure 97 – No GPS Fix SkyView System Installation Guide - Revision AA 8-13...
  • Page 242 SV-GPS-250/2020 GPS Receiver Installation and Configuration When the SV-GPS-250/2020 is powered up for the first time, or is powered up after several weeks or months of not being used, the SV-GPS-250/2020 may require several minutes to acquire GPS signals. The number of satellites in “view” of the SV-GPS-250/2020 will vary depending on the time of day, location, etc.

  • Page 243: (Us Only) Additional Configuration Required For Sda/Sil=1

    SV-GPS-250/2020 GPS Receiver Installation and Configuration (US only) Additional configuration required for SDA/SIL=1… … required for continued reception of ADS-B Traffic (early 2016) The following is only applicable to US pilots whose aircraft is equipped with an SV-GPS-250 (but not an SV-GPS-2020), SV-XPNDR-261/262 (or other Mode-S / ES transponder), and SV-ADSB-470 (ADS-B In receiver).

  • Page 245: Sv-Bat-320 Backup Battery Installation

    9. SV-BAT-320 Backup Battery Installation Figure 98 – SV-BAT-320 Backup Battery This section contains information that specifically applies to the installation of the SV-BAT-320 Backup Battery. After reading this section, you should be able to determine how to prepare the installation location, mount the module, connect it to a display, monitor its voltage, and ensure it is charged.

  • Page 246: Physical Installation

    SV-BAT-320 Backup Battery Installation Choose a location based on Connect battery to Prepare the Location Install battery the display wiring location Requirements harness Section Confirm battery Perform yearly Charge battery* Pass? charged battery check *Assumes SV-D700 or SV-D1000 is properly installed and working. Figure 99 –...

  • Page 247: Electrical Connection

    SV-BAT-320 Backup Battery Installation  Location should be near the rear of the SkyView display. A 24” cable is included on the SV- HARNESS-D37 for connecting the SV-BAT-320. This cable should not be extended.  Avoid locations that are subject to severe vibration. ...

  • Page 248: Sv-Bat-320 Is Automatically Charged In Flight

    SV-BAT-320 Backup Battery Installation SV-BAT-320 is Automatically Charged in Flight An SV-BAT-320 connected to a SkyView display is automatically charged by the SkyView display when there is adequate power applied to the SkyView display. If the SV-BAT-320 becomes discharged, on the next flight the SkyView display will automatically charge the SV-BAT-320. Charging, when necessary, required a minimum input voltage of 12.25 Volts supplied to the SkyView display.

  • Page 249: Battery Status Icon

    SV-BAT-320 Backup Battery Installation Battery Status Icon Battery status icon is individual to each display in a SkyView system. One of two icons, or no icon will be displayed immediately to the left of the clock in the center of the top bar. No battery icon displayed ...

  • Page 250: Initial Sv-Bat-320 Test

    SV-BAT-320 Backup Battery Installation  DATE OF LAST TEST: UNTESTED / MM-DD-YYYY o If this date is over a year ago, SkyView will annunciate BATTERY TEST NEEDED upon startup. Follow the steps in Initial SV-BAT-320 Test below.  TEST RESULT: o FAIL: VOLTAGE DROP TOO HIGH: Battery likely needs to be replaced.

  • Page 251: In The Event Of Initial Sv-Bat-320 Test Failure

    SV-BAT-320 Backup Battery Installation If your SkyView system has more than one SkyView display with an SV-BAT-320 installed, perform the following test individually on each SkyView display / SV-BAT-320. Test Procedure 1. The SV-BAT-320 must be fully charged prior to commencing this test. Reference the section Charging the SV-BAT-320 above for information on charging the SV-BAT-320.

  • Page 252: Sv-Bat-320 Specifications

    SV-BAT-320 Backup Battery Installation Please have the S/N of the SV-BAT-320 (printed on the SV-BAT-320 product label) available when you call. Note that warranty terms and conditions apply to a new SV-BAT-320. SV-BAT-320 Specifications Specifications for the SV-BAT-320 can be found in Appendix B: Specifications, SV-BAT-320 Specifications.
  • Page 253 SV-BAT-320 Backup Battery Installation Figure 103 – Example Lithium-Ion Battery Shipping Label SkyView System Installation Guide - Revision AA...

  • Page 255: 10. Ap Servo Installation, Configuration, And Calibration

    10. AP Servo Installation, Configuration, and Calibration Figure 104 – SV42 Servo (other servos are similar) This section contains generic mechanical and electrical installation guidelines for the Dynon Avionics servos mentioned in Table 73. Plane-specific kits purchased from Dynon Avionics contain detailed drawings and diagrams which are intended to be used in conjunction with this guide as a complete set of installation instructions.
  • Page 256 AP Servo Installation, Configuration, and Calibration Research Dynon Fabricate Use premade resources for Choose servo mounting mounting autopilot location(s) bracket(s)? bracket(s) application Install mounting Install servo bracket(s) with Install linkage power wiring with Install servo(s) Range of Motion hardware fuse(s) or Limiting Bracket breaker(s) Install...

  • Page 257: Dynon Avionics Autopilot Servo Models

    AP Servo Installation, Configuration, and Calibration Dynon Avionics Autopilot Servo Models Dynon Avionics offers the following servo models: Model Number Torque Attachment SV32 Standard Arm SV32C 36 inch-pounds Capstan SV32L Long Arm SV42 Standard Arm SV42C Capstan Extra Long SV42EL 55 inch-pounds SV42L* Long Arm...

  • Page 258: Servo Mechanical Installation

    AP Servo Installation, Configuration, and Calibration Avionics products. The Forum is especially useful for pilots with uncommon aircraft or unusual installation issues. For SkyView pilots that cannot call Dynon Avionics Technical Support during our normal business hours, the Forum is a convenient way to interact with Dynon Avionics Technical Support.
  • Page 259 AP Servo Installation, Configuration, and Calibration total of +/-60° from neutral position. When the aircraft controls are centered, the arm of the servo should be perpendicular to the attaching push rod. If this is not the case, we recommend adjusting the length of the push rod or consider a different mounting point. For maximum efficiency and the lightest drag on the flight controls, you should choose the smallest servo that provides sufficient torque to move and hold the flight controls with a minimum of slippage.
  • Page 260 AP Servo Installation, Configuration, and Calibration Push-Pull Servo Dimensions Use the following dimensions (in inches) for reference when planning and implementing your installation. Figure 106 – Servo Top Down Dimensions – See Note Below Regarding Arm Length Long-arm variants (not needed in most installations) have linkage mount holes at 1.5”...
  • Page 261 AP Servo Installation, Configuration, and Calibration Linkage Mount Position Force and Travel The two diagrams below illustrate the maximum travel and force available at each linkage mounting point. As can be seen, the closer you mount the linkage to the shaft, the more force the servo can deliver.
  • Page 262 AP Servo Installation, Configuration, and Calibration During installation, the linkage hardware must be connected to the servo arm such that the servo can actuate the connected control surface while approaching, but not exceeding the called out maximum linear travel specification. If too much slippage occurs during servo flight testing, it may be necessary to use a stronger servo.
  • Page 263 AP Servo Installation, Configuration, and Calibration demonstrated below. Use only the screws that are provided or specified in the Range of Motion Limiting Bracket Kit Installation Instructions (include with the Bracket Kit). Figure 112 – Servo Range of Motion Limiting Bracket, Front Figure 113 –...
  • Page 264 AP Servo Installation, Configuration, and Calibration  Immobilize the autopilot servo arm. This can be accomplished by manually restraining the autopilot arm/capstan, or by engaging the autopilot on the ground in servo test mode SETUP MENU > HARDWARE CALIBRATION > AP SERVO CALIBRATION > TEST (you can start this test, proceed to the step where it first activates and immobilizes the servos, and then cancel the test mode once you’ve performed this free play test).
  • Page 265 AP Servo Installation, Configuration, and Calibration Servo Electrical Installation Dynon Avionics’ servos are supplied with 7 unterminated wires, each about 8” in length. We recommended that you use the SV-NET-SERVO (one per servo) network cabling kit when installing servos; however, it is ultimately the responsibility of the installer to decide on connectors and associated wiring.
  • Page 266 AP Servo Installation, Configuration, and Calibration powered on in routine operation. When the servos are receiving power but the autopilot is not engaged, the servos draw negligible power. SkyView Network Connection Connect the servos to the SkyView network according to Figure 114 and Table 74. Dynon Avionics offers the SV-NET-SERVO cabling kit (each kit provides wire and connections for one servo).
  • Page 267 AP Servo Installation, Configuration, and Calibration  Size: 2200 µF (microfarads).  Voltage: For a 12V aircraft: 30V minimum. For a 24V aircraft: 60V minimum. AP Disengage/CWS Button The installation of the AP Disengage/CWS button is required. The AP Disengage/CWS button should be in a very accessible location, usually mounted to the stick or yoke.
  • Page 268 Button should be connected to all SkyView displays in parallel. The following recommendations supersede that earlier guidance. External GO AROUND Button is not supported in SkyView SE. If you intend to install and use SkyView SE, do not purchase or install an External GO AROUND Button.
  • Page 269 AP Servo Installation, Configuration, and Calibration  Connect the External LEVEL Button and/or the External GO AROUND Button to only one display. The External LEVEL Button and/or the External GO AROUND Button will operate for all displays in the SkyView system as long as the display the External LEVEL Button and/or the External GO AROUND Button is wired to is powered on and operating normally.

  • Page 270: Autopilot Servo Calibration And Test Procedures

    AP Servo Installation, Configuration, and Calibration Autopilot Servo Calibration and Test Procedures There are both ground-based setup and in-flight turning procedures that are required to fully configure your autopilot installation. Initial servo setup / calibration / test procedures are covered in this guide. In-flight procedures are covered in the SkyView Autopilot In-Flight Tuning Guide.

  • Page 271: Autopilot Servo Initial Setup

    AP Servo Installation, Configuration, and Calibration successful servo calibration. SkyView will not display AP status on the Top Bar until after this test procedure is successfully completed. To run this procedure on its own (after a successful servo calibration procedure), enter the Servo Test Wizard (SETUP MENU >...
  • Page 272 AP Servo Installation, Configuration, and Calibration the autopilot is not engaged, pitch and roll the aircraft to center both the horizontal and vertical bars with the waterline to fly the airplane like the autopilot would. Figure 119 – Flight Director - Dual Cue (cross bars) Figure 118 –...
  • Page 273 AP Servo Installation, Configuration, and Calibration Now, take the controls and override the servo by moving to either roll left or roll right. Ensure that you are comfortable with the amount of force it takes to override the servo. If you are not, decrease the roll servo torque value by 10% and repeat the test.
  • Page 274 AP Servo Installation, Configuration, and Calibration To adjust the default climb vertical speed: 1. Go to the Pitch Axis Default Climb Vertical Speed Adjust Page (SETUP MENU > AUTOPILOT SETUP > PITCH AXIS > DEFAULT CLIMB VERTICAL SPEED). 2. Adjust the default climb vertical speed. 3.
  • Page 275 AP Servo Installation, Configuration, and Calibration Figure 123 – Top Bar Airspeed High Indication The maximum airspeed parameter cannot be set to a value above 95% of Vne, which should be set to the specifications of your aircraft in the Airspeed Limitations Menu (reference page 5-19 for more information) and is specified in the units set in the Measurement Units Menu (i.e., miles per hour, knots, or kilometers per hour;...
  • Page 276 AP Servo Installation, Configuration, and Calibration To set the minimum airspeed: 1. Go to the Pitch Axis Minimum Airspeed Adjust Page (SETUP MENU > AUTOPILOT SETUP > PITCH AXIS > MINIMUM AIRSPEED). 2. Adjust the minimum airspeed. 3. Press ACCEPT to save the value or press CANCEL to return to the Roll Axis Menu. Disengage Button Options Hold to Engage Hold to Engage may be set to YES or NO.

  • Page 277: Autopilot In-Flight Tuning Procedures

    AP Servo Installation, Configuration, and Calibration 1. Go to the Enable Broken Line Detect Adjust Page (SETUP MENU > AUTOPILOT SETUP > DISENGAGE BUTTON > ENABLE BROKEN LINE DETECT). 2. Set to YES or NO. 3. Press ACCEPT to save or press CANCEL to return to the Disengage Button Menu. Control Wheel Steering Mode Control Wheel Steering may be set to YES or NO.

  • Page 279: 11. Sv-Xpndr-261/262 Installation And Configuration

    11. SV-XPNDR-261/262 Installation and Configuration Figure 126 – SV-XPNDR-261; SV-XPNDR-262 is Physically Identical Dynon Avionics offers two transponders. The SV-XPNDR-262 is a Class 2 Mode-S transponder with Extended Squitter that is limited to use below 15,000 feet and speeds up to 175 knots. The SV-XPNDR-261 is a Class 1 transponder that can be used above those limitations.
  • Page 280 SV-XPNDR-261/262 Installation and Configuration The SV-XPNDR-261/262 is certified to ETSO 2C112b and ETSO C166a, and to FAA TSO C112c and C166b. See Appendix B: Specifications, 11-2 SkyView System Installation Guide - Revision AA...

  • Page 281: Physical Installation

    SV-XPNDR-261/262 Installation and Configuration SV-XPNDR-261 Specifications, and SV-XPNDR-262 Specifications for more information. The SV-XPNDR-261/262 is controlled using SkyView’s on-screen menu system. This allows the SV-XPNDR-261/262 to be mounted separately from the instrument panel and thus requires no panel space. SkyView also provides pressure altitude directly to the SV-XPNDR-261/262, eliminating the need for a separate altitude encoder.
  • Page 282 SV-XPNDR-261/262 Installation and Configuration  Orientation of the SV-XPNDR-261/262 is not critical – it can be mounted horizontally, or vertically.  Secure the mounting tray to the aircraft via the three (3) mounting holes in the tray. The tray should be mounted to a flat surface - it is important that the tray is supported at the dimples as well as the three mounting points.

  • Page 283: Electrical Connections

    SV-XPNDR-261/262 Installation and Configuration Figure 129 – SV-XPNDR-261/262 Dimensions with Mounting Tray (dimensions in millimeters) Additional Items Required Additional items you will require, but which are not in the SV-XPNDR-261/262 package, include:  Antenna and fixing hardware. The SV-XPNDR-261/262 is compatible with transponder antennas commonly available.
  • Page 284 SV-XPNDR-261/262 Installation and Configuration The SV-XPNDR-261/262 package includes a 25-pin connector and pins if you wish to fabricate your own harness. Refer to the sections below for detailed wiring information. Note that your connector kit may contain a 1.21K resistor. This resistor is only used if you intend to connect a certified GPS receiver for ADS-B Out functionality.
  • Page 285 SV-XPNDR-261/262 Installation and Configuration SV-HARNESS- Function Notes XPNDR Color Ident Switch In Green Optional: Not Commonly Connected No Connection No wire installed No Connection No wire installed No Connection No wire installed No Connection No wire installed No Connection No wire installed Table 75 –...
  • Page 286 SV-XPNDR-261/262 Installation and Configuration Serial SV-XPNDR-261/262 SkyView D37 Port Pin 3 (RX) Brown/Violet Pin 7 (TX) Pin 4 (TX) Brown/Orange Pin 5 (RX) Pin 5 (RX) Yellow/Violet Pin 7 (TX) Pin 6 (TX) Yellow/Orange Pin 5 (RX) Pin 7 (RX) Green/Violet Pin 7 (TX) Pin 8 (TX) Green/Orange Pin 5 (RX)
  • Page 287 SV-XPNDR-261/262 Installation and Configuration Figure 133 – All Possible SV-XPNDR-261/262 Connections (Rear Pin Insertion View) Note that Pin 1 and Pin 2 must be connected to each other as depicted above as part of the wiring harness (they are not connected together inside the SV-XPNDR- 261/262).
  • Page 288 SV-XPNDR-261/262 Installation and Configuration Note: The SV-XPNDR-261/262 power input is not protected against reversed power connections. If the power and ground inputs to the SV-XPNDR-261/262 are reversed, and power is applied to the Ground input, and Ground is applied to the Power input, the SV-XPNDR-261/262 will be destroyed and this repair will not be covered under warranty.
  • Page 289 SV-XPNDR-261/262 Installation and Configuration If you are using the Mutual Suppression feature, simply connect all of the Mutual Suppression wires from devices that use them together. Ident Switch Input (Pin 20) (optional) SkyView has an IDENT button in its TRANSPONDER menu that is normally used to ident when requested by ATC.

  • Page 290: Antenna Installation

    SV-XPNDR-261/262 Installation and Configuration This input is typically used if the aircraft is already equipped with a certified GPS unit (typically for qualification for IFR flight). This input is connected to a serial port output of the certified GPS. See SV-XPNDR-261/262 Settings, GPS Data later in this section for information on how to configure SkyView to use this capability.
  • Page 291 SV-XPNDR-261/262 Installation and Configuration Antenna Ground Plane When a conventional aircraft monopole antenna is used it relies on a ground plane for correct behaviour. For ideal performance the ground plane should be very large compared to the wavelength of the transmission, which is 275 mm. In a metal skinned aircraft this is usually easy to accomplish, but is more difficult in a composite or fabric skinned aircraft.
  • Page 292 SV-XPNDR-261/262 Installation and Configuration Electronic Insertion Loss Max Length MIL-C-17 Cable Length dB/meter at in Meters Cables Specialists Electronic in Feet 1090MHz Type M17/128 2.54 8’ 4” 0.59 (RG400) 3.16 10’ 4” 0.47 3C142B M17/112 3.81 12’ 6” 0.39 (RG304) 4.50 14’...
  • Page 293 SV-XPNDR-261/262 Installation and Configuration a TNC Female connector. Therefore, you will need to source a TNC Male connector that is compatible with the antenna cable type that meets your aircraft’s needs. Alternatively, especially if the transponder antenna you have purchased incorporates coaxial cable and a “BNC”...

  • Page 294: Transponder-Related Skyview Display Settings

    SV-XPNDR-261/262 Installation and Configuration Transponder-Related SkyView Display Settings Serial Port Setup Before the TRANSPONDER SETUP menu can be accessed, the SV-XPNDR-261/262 needs to be set up as a serial device in the SkyView system. To accomplish this:  SETUP MENU > SYSTEM SETUP > SERIAL PORT SETUP ...
  • Page 295 SV-XPNDR-261/262 Installation and Configuration XPNDR-261/262 is available from the SkyView display – see SV-XPNDR-261/262 Software Updates later in this section for details on performing Software updates.  USA PART 91.227 COMPLIANT: YES | NO Displays whether the combination of the selected GPS, the SV-XPNDR-261/262 model, and the GPS data being received is compliant with 14 CFR §...
  • Page 296 SV-XPNDR-261/262 Installation and Configuration Figure 136 - SV-XPNDR-261/262 GPS DATA Setup o DYNON SV-GPS-2020:  Select this option if you have an SV-GPS-2020 installed.  The following ADS-B performance parameters will be transmitted:  SDA: 2  SIL: 3  NACp: Dynamic, as reported by GPS.
  • Page 297 SV-XPNDR-261/262 Installation and Configuration  You do not have an SV-GPS-2020 installed  You have an SV-GPS-250 installed as your primary GPS, and  You are instructed that transmitting SIL/SDA=1 is not appropriate for your aircraft.  The following ADS-B performance parameters will be transmitted: ...
  • Page 298 SV-XPNDR-261/262 Installation and Configuration information about updating the SV-XPNDR-261/262 Software. Using this setting causes the SV-XPNDR-261/262 to transmit the following ADS-B performance parameters:  SDA: 2 (Level C integrity)  SIL: 3  NACp: Sent from GPS to transponder. Refer to GPS documentation. ...
  • Page 299 SV-XPNDR-261/262 Installation and Configuration NACp: Sent from GPS to transponder. Refer to GPS documentation. NIC: Sent from GPS to transponder. Refer to GPS documentation. NACv: 1 (10m/s accuracy)  PRESSURE ALTITUDE: Displays status of pressure altitude input for the SV-XPNDR- 261/262 ...
  • Page 300 SV-XPNDR-261/262 Installation and Configuration o In the USA, the VFR squawk code is 1200. o In most parts of Europe, the VFR squawk code should be set to 7000.  AUTO ALT/GND: Allows the SV-XPNDR-261/262 to automatically switch between Airborne and Ground modes. Available options include: o NONE: Automatic switching disabled o SQUAT SWITCH LOW ON GND: Utilizes a physical squat switch connected the SV-XPNDR-261/262 per the above instructions.

  • Page 301: (Us Only) Configuration Required For Sda/Sil=1 For Continued Reception Of Ads-B Traffic (Early 2016)

    SV-XPNDR-261/262 Installation and Configuration 470). Select this option if the ADS-B IN equipment on board is dual-band (receives on both 1090 MHz and 978 MHz).  AIRCRAFT CATEGORY: To assist ATC tracking of aircraft, an aircraft category can be transmitted by Mode S transponders. Set as appropriate for your aircraft. ...

  • Page 302: Skyview Systems With An Sv-Gps-250 As Primary Gps

    SV-XPNDR-261/262 Installation and Configuration SIL/SDA=1. This change is made by default when a SkyView system, with an SV-GPS-250 as its primary GPS, is updated to SkyView Software v14.0 (or later). After your SkyView system is configured to transmit SIL/SDA=1, the ADS-B system will (again) transmit TIS-B (ADS-B traffic) to an aircraft so that an aircraft can display “ADS-B traffic”...

  • Page 303: (Us-Only) Equipping For Compliance With Faa 2020 Ads-B Out Mandate

    SV-XPNDR-261/262 Installation and Configuration Figure 137 –GPS DATA Setting (for SV-GPS-250) Changed as of v14.0 and later Note that: SETUP MENU > TRANSPONDER SETUP > GPS DATA (OK) > SKYVIEW is changed to: SETUP MENU > TRANSPONDER SETUP > GPS DATA (OK) > SV-GPS-250 SIL/SDA=1 If you have a SkyView System with an SV-GPS-250 as your primary GPS, an SV-XPNDR-261/262, do not have a high integrity GPS connected directly to the SV-XPNDR-261/262, and you wish for your aircraft to transmit SIL/SDA=0 (same as Software versions earlier than v14.0) instead of...
  • Page 304 SV-XPNDR-261/262 Installation and Configuration requirement. If your aircraft is equipped with an SV-XPNDR-262, it must be replaced with an SV-XPNDR-261 (or other Class 1 Mode-S transponder) to be compliant with the FAA 2020 ADS-B Out mandate. It is important to note that in the US, the ADS-B Out “mandate” and the associated GPS requirements do not go into effect until January 1, 2020, and the mandate only requires compliance in specific airspaces.

  • Page 305: Installation Of Dynon Avionics Sv-Gps-2020 For Compliance With Faa 2020 Ads-B Out Mandate

    SV-XPNDR-261/262 Installation and Configuration Installation of Dynon Avionics SV-GPS-2020 for compliance with FAA 2020 ADS-B Out mandate The most common GPS position source for compliance for performance requirements for GPS data for FAA 2020 ADS-B Out mandate is the SV-GPS-2020 GPS Antenna/Receiver Module (High Integrity GPS - meets FAA 2020 ADS-B Out requirements).
  • Page 306 SV-XPNDR-261/262 Installation and Configuration Figure 138 - 14 CFR § 91.227 Compliance Status – Not Compliant If your SkyView system is compliant with 14 CFR § 91.227 (all required elements present, with good GPS data), YES will be shown. Figure 139 below illustrates a SkyView system with all the required elements present, online, and good GPS data is being received.
  • Page 307 SV-XPNDR-261/262 Installation and Configuration FAA Report for Compliance with FAA ADS-B OUT 2020 Mandate After you have updated your SkyView system with a SV-GPS-2020 (or other IFR GPS connected directly to the SV-XPNDR-261), and updated your SV-XPNDR-261’s Software to SW02.08 or later, you should fly within an ADS-B coverage area(s) for at least several hours (minimum), or days (optimum), before requesting the report below.

  • Page 308: Sv-Xpndr-261/262 Software Updates

    SV-XPNDR-261/262 Installation and Configuration SV-XPNDR-261/262 Software Updates If your SkyView or SkyView SE system has more than one SkyView display, before you commence with the SV-XPNDR-261/262 Software update, it is recommended to power off all but one SkyView display. Doing so will reduce the power drain on...
  • Page 309 SV-XPNDR-261/262 Installation and Configuration Note the reference to “LOAD WILL BE INITIATED BY MASTER SCREEN”. In a SkyView system, one display is elected “Master” behind the scenes, and the “Master” display will be the one to actually load the new Software onto the SV-XPNDR-261/262… which may not be the display that you began the Software update on (if all displays remained powered on) –...
  • Page 310 SV-XPNDR-261/262 Installation and Configuration After pushing the LOAD button, the screen in Figure 142 appears (below). This is to ensure that you intended to perform a Software update to the SV-XPNDR-261/262. Push the YES button. It is critical not to interrupt the Software update process, thus you should ensure that there is adequate electrical power for the SkyView display(s) and the SV- XPNDR-261/262 to operate uninterrupted for at least 10 minutes.
  • Page 311 SV-XPNDR-261/262 Installation and Configuration Figure 143 below is the screen that appears after the Software update is complete. Once the Software update is complete, the SV-XPNDR-261/262 requires a power cycle to restart with the newer Software. Simply power down the SV-XPNDR-261/262, using the transponder switch, circuit breaker, etc.
  • Page 312 SV-XPNDR-261/262 Installation and Configuration After power-cycling the SV-XPNDR-261/262, the STATUS changes as shown in Figure 144 below. The SV-XPNDR-261/262 is online, with the newer version of Software loaded. Figure 144 – SV-XPNDR-261/262 Online with Updated Software (Normal Operation) 11-34 SkyView System Installation Guide - Revision AA...

  • Page 313: Sv-Xpndr-261/262 Software Update Sw02.09

    SV-XPNDR-261/262 Installation and Configuration SV-XPNDR-261/262 Software Update SW02.09 SV-XPNDR-261/262 Software SW02.09 was included with SkyView Software v14.2.1.3698 on 2016-04-12. SV-XPNDR-261/262s sold after that date may already have Software SW02.09 already installed. This new version of SV-XPNDR-261/262 Software includes:  Fix for a bug that would cause some SkyView pilots to see FAA ADS-B 2020 Compliance Reports fail due to high count of out of range NIC and NACp values.
  • Page 314 SV-XPNDR-261/262 Installation and Configuration available update during SkyView’s normal operation. However, the STATUS menu under SETUP MENU > TRANSPONDER SETUP will be highlighted in YELLOW to indicate that an optional update is available. 11-36 SkyView System Installation Guide - Revision AA...

  • Page 315: Deprecated Sv-Xpndr-261/262 Software Update Instructions And Notes

    SV-XPNDR-261/262 Installation and Configuration Deprecated SV-XPNDR-261/262 Software Update Instructions and notes The instructions for earlier Software updates below are deprecated, retained in this manual for reference only. In 2016 and beyond, it is unlikely that that the situations, or SkyView Software versions, or SV-XPNDR-261/262 Software versions, are present in your aircraft.

  • Page 316: Skyview Software V12.2 - V13.0.3 Sv-Xpndr-261/262 Software Sw02.06 Update

    SV-XPNDR-261/262 Installation and Configuration  If you have a Garmin GNS, GTN or similar IFR GPS that is directly connected to the SV- XPNDR-261/262 to provide a certified position source via Garmin’s ADS-B format data output, you MUST update to version 2.04 or later. ...

  • Page 317: Sv-Xpndr-261/262 Software Version (Sw) V2.02/V2.04/V2.06 Labeling Requirements (Us Registered / Operated Aircraft Only)

    SV-XPNDR-261/262 Installation and Configuration 1. Check SETUP MENU > TRANSPONDER SETUP. The line GPS DATA should read GPS DATA (OK) DIRECT (GARMIN ADS-B/ADS-B+) 2. On the Garmin GNS, GTN or similar IFR GPS, select the serial port connected to the SV- XPNDR-261/262, and change the data format from “ADS-B OUT”...

  • Page 318: Skyview Software V14.0 - V14.1 Sv-Xpndr-261/262 Software Update Sw02.08

    SV-XPNDR-261/262 Installation and Configuration 5. You must apply the new TSO authorization label before the SV-XPNDR-261/262’s next use: a. Cut out the label that is included in the printout from www.dynonavionics.com/transponder (PDF). b. Permanently affix the label to your physical SV-XPNDR-261/262 module. Do not cover any existing labels.

  • Page 319: Sv-Xpndr-261/262 Post Installation Checks

    SV-XPNDR-261/262 Installation and Configuration  If you are a non-US pilot, and you fly only outside the US, none of the FAA or ADS-B requirements or updates apply, thus you are not required to update your SV-XPNDR- 261/262 Software. If a Software update for the SV-XPNDR-261/262 is available, the SV-XPNDR-261/262 will continue to operate with no degradation of performance or annunciation of the available update during SkyView’s normal operation.

  • Page 320: Transponder Warnings (Transponder Self Diagnostics)

    SV-XPNDR-261/262 Installation and Configuration tested and inspected per FAR 91.413. Transponder Warnings (Transponder Self Diagnostics) The SV-XPNDR-261/262 includes limited self-diagnostic capability. If a SV-XPNDR-261/262 fault is detected, a system message will be displayed: XPNDR WARNING MESSAGE. To see the detailed information on the fault, go to SETUP MENU > TRANSPONDER SETUP. The words TRANSPONDER WARNING will be displayed in Yellow;...

  • Page 321: Performing Transponder Checks

    SV-XPNDR-261/262 Installation and Configuration Message Message Explanation Recommendation connector. A visual inspection is often not sufficient to find the fault with the antenna, feedline, or connector. Internal fault, contact Dynon Transmitter power supply Avionics Technical Support TX PSU HIGH (value) output is abnormally high;...

  • Page 322: Dynon Avionics Sv-Gps-250 And Sv-Gps-2020 Compliance Statements

    SV-XPNDR-261/262 Installation and Configuration Dynon Avionics SV-GPS-250 and SV-GPS-2020 Compliance Statements Use of Dynon Avionics SV-GPS-250 as a GPS Position Source for US ADS-B Out at SIL/SDA=1 Prior to early 2016, a SkyView system using an SV-GPS-250 as the GPS position source for ADS-B Out transmitted a SIL and SDA of 0.

  • Page 323: 12. Sv-Arinc-429 Installation And Configuration

    SkyView SE does not integrate with any IFR navigation sources, and excludes features and components commonly used in an aircraft equipped for IFR flight, including the SV-ARINC-429. If you intend to install and use SkyView SE, do not purchase or install an SV-ARINC-429.

  • Page 324: Skyview Network Connection

    SV-ARINC-429 Installation and Configuration Figure 148 – SV-ARINC-429 Mounting Dimensions with Electrical Connections The SV-ARINC-429 does not provide mounting hardware. The mounting tabs on each side of the module have holes sized for #10 fasteners, but it is up to the installer to decide how the SV- ARINC-429 will be secured to the aircraft.
  • Page 325 SV-ARINC-429 Installation and Configuration If you do not own a DSUB machined-pin crimping tool, they can be obtained from many electronics or avionics dealers. You may also find it helpful to own a pin insertion/extraction tool as well. Additional harness construction and wiring information can be found in Appendix C: Wiring and Electrical Connections.
  • Page 326 SV-ARINC-429 Installation and Configuration SV-ARINC-429 Pinout Figure 149 – SV-ARINC-429 D25M Pin Insertion View (Rear) 12-4 SkyView System Installation Guide - Revision AA...
  • Page 327 SV-ARINC-429 Installation and Configuration Function Notes No Connect No Connect Serial RX Aviation Format Only from Connected ARINC-429 GPS No Connect No Connect No Connect No Connect No Connect No Connect ARINC 2 RX B ARINC 1 RX B Pins 12/13 are the same TX signal. Provided for ARINC TX B convenience when connecting to multiple ARINC receivers.
  • Page 328 SV-ARINC-429 Installation and Configuration ARINC Device Connections The SV-ARINC-429 has two ARINC-429 receivers and one transmitter. The single transmitter may be connected to multiple devices that can accept the ARINC-429 information that SkyView transmits. The SV-ARINC-429 also has a serial input that is designed to provide auxiliary information that ARINC-429 GPS outputs do not provide (such as altitude).
  • Page 329 SV-ARINC-429 Installation and Configuration Figure 151 – Garmin 430/530 SV-ARINC-429 Connections Additional Garmin 430/530 Configuration Information The following are the typical Garmin and SkyView configuration settings when this combination of products is used: Garmin Settings "Main ARINC 429 Config" page In 1: High | EFIS / Airdata In 2: Unused by SkyView, configure as needed for other equipment Out: High | GAMA 429...
  • Page 330 SV-ARINC-429 Installation and Configuration SkyView Settings SETUP MENU > SYSTEM SETUP > ARINC-429: (Configure MODULE 1 and MODULE 2 independently) > INPUT SPEED: HIGH > INPUT 1: GPS x > NAVIGATION SOURCE DISP NAME: (user selectable, 7 characters. The name entered here is displayed as the HSI source and the Flight Plan Source (if this device outputs a flight plan).
  • Page 331 SV-ARINC-429 Installation and Configuration Out: High | GAMA Format 2 SDI: Common "VOR/LOC/GS Configuration Page Nav Radio: Enabled ARINC 429 Configuration: TX Speed: High SDI: Common Other Settings: Unused by SkyView “RS-232 Configuration” Page RS232 1 Output: Aviation Output 1 Optional (ADS-B) If a Dynon Avionics SV-XPNDR-261 is being used for ADS-B Out capability: Another GTN serial output should be set to “ADS-B+ OUT”...
  • Page 332 SV-ARINC-429 Installation and Configuration Figure 153 – Garmin 480 SV-ARINC-429 Connections Figure 154 – Garmin 300/150XL/250XL/300XL SV-ARINC-429 Connections 12-10 SkyView System Installation Guide - Revision AA...

  • Page 333: Sv-Arinc-429 Related Settings

    SV-ARINC-429 Installation and Configuration SV-ARINC-429 Related Settings Go to the ARINC-429 SETUP under SETUP MENU > SYSTEM SETUP > ARINC-429. SkyView supports up to two SV-ARINC-429 modules, but since most aircraft will only have one installed, the “MODULE 2” section is normally disabled. If your aircraft does actually have two SV-ARINC-429 modules, note that the serial numbers of each module are provided so you can determine which module is which.

  • Page 335: 13. Vertical Power Vp-X Integration And Configuration

    13. Vertical Power VP-X Integration and Configuration Display of, and control of, VP-X is not supported in SkyView SE or SkyView HDX (as of Software v15.0). If you intend to install and use SkyView SE or SkyView HDX, do not purchase and install a VP-X or an SV-VPX-290 software license.

  • Page 336: Serial Port Connection

    Vertical Power VP-X Integration and Configuration have power supplied by aircraft power, such as the AP servos, SV-ADSB-470, SV- COM-C25/X83, SV-XPNDR-261/262, and Heated AOA/Pitot Probe can have their power monitored by the VP-X by routing the power connections for those components via the VP-X.

  • Page 337: License Information

    Display of, and control of, VP-X is not supported in SkyView SE or SkyView HDX (as of Software v15.0). If you intend to install and use SkyView SE or SkyView HDX, do not purchase and install a VP-X or an SV-VPX-290 software license.

  • Page 338: Vp-X Skyview Classic Display Settings

    Vertical Power VP-X Integration and Configuration the aircraft, choose one to install it onto and provide information for only that display. Once any display is licensed, all connected displays in the Aircraft can use the VP-X features. 2. An SV-VPX-290 VP-X License may be purchased from Dynon Avionics or any authorized Dynon Avionics dealer.

  • Page 339: Post Installation Checks

    Vertical Power VP-X Integration and Configuration  AUX BATTERY WARNINGS: Sets the auxiliary battery voltage levels at which caution and warning indications are provided visually on the VP-X page. If you do not have an auxiliary aircraft battery (note that this is NOT the SkyView Classic SV-BAT-320) installed, this setting can be ignored.
  • Page 340 Vertical Power VP-X Integration and Configuration Figure 155 – VP-X Example (SkyView Classic Only) 13-6 SkyView System Installation Guide - Revision AA...

  • Page 341: 14. Sv-Adsb-470 Installation And Configuration

    Display of MAP is not supported in SkyView SE. Thus, ADS-B weather data and ADS- B traffic data cannot be displayed (on the MAP) in SkyView SE. If you intend to install and use SkyView SE, do not purchase or install an SV-ADSB-470.

  • Page 342: Physical Installation

    SV-ADSB-470 Installation and Configuration Figure 156 – Suggested SV-ADSB-470 Installation and Configuration Procedure Physical Installation The SV-ADSB-470 is designed to be mounted in any convenient location in the cockpit, the cabin, or an avionics bay. The following guidelines should be followed, remembering to allow adequate space for installation of cables and connectors.

  • Page 343: Installation Instructions

    SV-ADSB-470 Installation and Configuration SV-ADSB-470 Dimensions and Connections Figure 157 – SV-ADSB-470 Dimensions (top view) Figure 158 – SV-ADSB-470 Dimensions/Connections (front view) Installation Instructions The SV-ADSB-470 is designed to be mounted in any convenient location in the cockpit, the cabin, or an avionics bay. The following installation procedure should be followed, remembering to allow adequate space for installation of cables and connectors.

  • Page 344: Electrical Installation

    SV-ADSB-470 Installation and Configuration  Select a position in the aircraft that is not too close to any high external heat source. (The SV-ADSB-470 is not a significant heat source itself and does not need to be kept away from other devices for this reason). ...
  • Page 345 SV-ADSB-470 Installation and Configuration SV-HARNESS-ADSB – Pinout (D9F on module / D9M on harness) Color Function Notes 10-30V DC Connect to Aircraft Power Orange Data Input from SkyView Display(s): Serial 1 – Pin 4 (Brown / Orange), or SV-ADSB-470 Serial RX Serial 2 –...
  • Page 346 SV-ADSB-470 Installation and Configuration Serial SkyView D37 SV-ADSB-470 D9 Port Pin 3 (RX) Brown/Violet Pin 3 (TX) Pin 4 (TX) Brown/Orange Pin 2 (RX) Pin 5 (RX) Yellow/Violet Pin 3 (TX) Pin 6 (TX) Yellow/Orange Pin 2 (RX) Pin 7 (RX) Green/Violet Pin 3 (TX) Pin 8 (TX) Green/Orange Pin 2 (RX)

  • Page 347: Antenna Selection And Installation

    SV-ADSB-470 Installation and Configuration  Record the SkyView serial port that you have chosen on each display as you will need to configure it later for use with the SV-ADSB-470. The SV-ADSB-470 communicates with the SkyView system using serial ports, not SkyView Network.
  • Page 348 SV-ADSB-470 Installation and Configuration and avoid sharp bends in the cable to minimize the VSWR (voltage standing wave ratio).  The SV-ADSB-470 antenna should not be installed within 2 feet (24 inches) of a 1090 MHz transponder (including the SV-XPNDR-261/262) antenna. Antenna Ground Plane When a conventional aircraft monopole antenna is used it relies on a ground plane for correct behaviour.

  • Page 349: Sv-Adsb-470-Related Skyview Display Settings

    SV-ADSB-470 Installation and Configuration  Avoid kinking the cable even temporarily during installation.  Secure the cable so that it cannot interfere with other systems. Antenna BNC Female Connector This section describes the technique for attaching the antenna cable to a BNC Male connector. A BNC Male connector is not supplied with the SV-ADSB-470.

  • Page 350: Post Installation Checks

    SV-ADSB-470 Installation and Configuration SETUP MENU > SYSTEM SETUP > SERIAL PORT SETUP > SERIAL PORT x SETUP (the serial port you wired the SV-ADSB-470 to) > SERIAL IN DEVICE > SV-ADSB-470 > ACCEPT (button). SETUP MENU > TRAFFIC SETUP > SHOW TAIL NUMBERS > YES > ACCEPT (button). Post Installation Checks After the SV-ADSB-470 has been configured, confirmation that communication has been established with the module by performing the following procedure:...
  • Page 351 SV-ADSB-470 Installation and Configuration o On: The SV-ADSB-470 is receiving power, but is not operating normally. Cycle power on the SV-ADSB-470 to try to clear this condition. If the indicator remains On (solid, no blinking), after cycling power, contact Dynon Avionics Technical Support (contact information at the beginning of this manual).

  • Page 353: 15. Accessory Installation And Configuration

    15. Accessory Installation and Configuration This section contains information regarding installation and configuration of various Dynon Avionics-supplied accessories for the SkyView system. SkyView System Angle of Attack Pitot Probe The Dynon Avionics AOA/Pitot Probe and the Dynon Avionics Heated AOA/Pitot Probe are used on Dynon Avionics products other than the SkyView system, thus the “generic”...
  • Page 354 Accessory Installation and Configuration RANGE 3, RANGE 4, RANGE 5 ENABLE: NO (other parameters are ignored when ENABLE set to NO) 4. SETUP MENU > EMS SETUP > SCREEN LAYOUT EDITOR SENSOR (button) Select PHEAT (or custom name) CONTACT ACCEPT (button) Adjust size of the icon to your preference.
  • Page 355 Accessory Installation and Configuration Instructions on the right half. Upon exiting the AOA Calibration menu, the SkyView display is returned to its normal configuration. Figure 162 – AOA Calibration Explanation and Wizard If the plane is in flight, after pushing buttons 7+8 you will see the abbreviated IN FLIGHT SETUP MENU, from which you can directly select AOA CALIBRATION.
  • Page 356 Accessory Installation and Configuration Figure 163 – IN FLIGHT SETUP MENU 15-4 SkyView System Installation Guide - Revision AA...

  • Page 357: Encoder Serial-To-Gray Code Converter

    Accessory Installation and Configuration Encoder Serial-to-Gray Code Converter This section guides you through the installation of a Dynon Avionics Encoder Converter (P/N 100362-000). The Encoder Converter is an electronic device that receives the serial encoder data from a SkyView display and outputs standard Mode-C Parallel Gray code into your Mode-C SV-XPNDR-261/262.
  • Page 358 Accessory Installation and Configuration the wires listed in the table leave one end of the Encoder Converter in a single bundle. If your transponder has a switched power output, connect this to the power inputs on the Encoder Converter. If your transponder does not include this switched power output, the Encoder Converter power connections should be made directly to your switched avionics power.
  • Page 359 Accessory Installation and Configuration Transponder Yellow Green White/Blue Blue Orange White/Red SkyView Display Encoder Converter White/Green DB37 Connector Module White White/Black SkyView Display Serial Transmit Unconnected Green Wire Unconnected Strobe Shared Ground Black Wire The Encoder Converter Module is compatible with all SkyView display serial ports.

  • Page 360: Capacitance To Voltage Converter For Van's Capacitive Plates

    Accessory Installation and Configuration Capacitance to Voltage Converter for Van’s Capacitive Plates Dynon Avionics Capacitance to Voltage Converter for Van’s Capacitive Plates (P/N 100654-000) is designed to interface the capacitive plates fuel level sensor option for Van’s Aircraft RV aircraft to Dynon Avionics EMS units, including the SkyView SV-EMS-220/221. The capacitance signal is via a BNC Male connector (the connector for the Van’s capacitive plates is a BNC Female) and the output is a 0-5 volts DC.

  • Page 361: Skyview Video Input Adapter

    SkyView Video Input Adapter Display of video from the SkyView Video Input Adapter is not supported in SkyView SE. If you intend to install and use SkyView SE, do not purchase or install a SkyView Video Input Adapter. The SkyView Video Input Adapter (P/N 102211-000) allows display of a video source (nominally, a camera), displayed either 100% (SkyView Classic only), or 50% of the SkyView Classic or SkyView HDX display to which it is connected.
  • Page 362 Accessory Installation and Configuration Video quality of analog video devices such as cameras that output composite or S- Video is extremely sensitive to the quality of cable used. It is recommended to use high quality video cable for the connection between the video source (especially a camera) and the Video Input Adapter.
  • Page 363 Accessory Installation and Configuration  PAL S-VIDEO – Your video source is connected to the S-Video (Mini-DIN) connector and it complies with PAL (non-US analog video standard) FLIP HORIZONTAL: YES | NO - Select as appropriate for the image from your video input device to display correctly on the SkyView display.
  • Page 364 Accessory Installation and Configuration Depending on the layout of your SkyView HDX display, the VIDEO window will appear on the left, or right 50% window, overlaying the non-primary 50% window, or converting a 100% window into 50% / 50% windows. If the Video Input Adapter is connected and working, but no video signal is being received by the Video Input Adapter, a blank blue field will be displayed for video on the SkyView display.

  • Page 365: Skyview Wi-Fi Adapter

    Accessory Installation and Configuration SkyView Wi-Fi Adapter Use of Wi-Fi is not supported in SkyView SE. If you intend to install and use SkyView SE, do not purchase or install a SkyView Wi-Fi Adapter. The SkyView Wi-Fi Adapter allows communication with selected Wi-Fi devices and selected applications (apps) on those devices.
  • Page 366 Accessory Installation and Configuration  OFFLINE: NO ADAPTER OTHER SCREEN – A SkyView Wi-Fi Adapter connected to another SkyView display(s) is not connected or not functioning.  OFFLINE: NO ADAPTER THIS SCREEN – A SkyView Wi-Fi Adapter connected to this SkyView display is not connected or not functioning.
  • Page 367 Accessory Installation and Configuration  NO – Choose NO if you have an Apple iPhone or Apple iPad with cellular capability AND you wish to use the cellular Internet connection at the same time as being connected to the SkyView Wi-Fi system. Wi-Fi Operations Instructions for using the SkyView Wi-Fi System with specific devices and applications is included in the SkyView Pilot’s User Guide, which is updated when additional devices and...

  • Page 368: Advanced Flight Systems (Afs) Advanced Control Module (Acm)

    SkyView SE does not integrate with any IFR navigation sources, and excludes features and components commonly used in an aircraft equipped for IFR flight. If you intend to use SkyView SE incorporated into an ADVANCED Quick Panel System, confirm (with Advanced Flight Systems) that your choice of (optional) navigation units is compatible with SkyView SE.

  • Page 369: Sv-Button-Level

    Accessory Installation and Configuration SV-BUTTON-LEVEL Note that on SkyView SE, installation of the SV-BUTTON-LEVEL is the only method that can be used to engage the AP LEVEL mode. To provide a prominent LEVEL button on the panel, Dynon Avionics offers the SV-BUTTON-LEVEL; P/N 102553-000 – see Figure 170 for the SV-BUTTON-LEVEL kit, AND Figure 169 for the SV-BUTTON-LEVEL button.
  • Page 370 Accessory Installation and Configuration Installation: Figure 169 – SV-BUTTON-LEVEL Installation Dimensions 15-18 SkyView System Installation Guide - Revision AA...
  • Page 371 Accessory Installation and Configuration Wire Color Connection Points / Notes Aircraft Power; connect to same point as SkyView display Power (Red) wires, Pins 1 and 20 SkyView Pin 26 – White wire 24V electrical systems require a 1.1KΩ resistor (included in the kit) in series with the SV-BUTTON-LEVEL’s white wire White and the SkyView display’s Pin 26 white wire.
  • Page 372 Accessory Installation and Configuration application. An example diode is the very common 1N914, available from Radio Shack (P/N 276-1122). With a diode installed for each display, the SV-BUTTON-LEVEL will work correctly with any combination of displays powered on and powered off. Configuration: There is no configuration necessary for installation of the SV-BUTTON-LEVEL.

  • Page 373: Pitot/Static/Aoa Pneumatic Installation Kit

    Accessory Installation and Configuration Pitot/Static/AOA Pneumatic Installation Kit Figure 171 – Dynon Avionics Pitot/Static/AOA Pneumatic Installation Kit, P/N 102628-000 The instructions in this section is adapted from “AOA, Pitot, Static Installation Guide – Plumbing Kit, Document 102708-000, Rev A that is included with this kit. That documentation is more generic, intended for use with all Dynon Avionics products that require AOA, Pitot, Static pneumatic connections.
  • Page 374 Accessory Installation and Configuration For quick reference: Blue tubing is intended for use with the ANGLE OF ATTACK (AOA) port. Green tubing is intended for use with the PITOT port. White tubing is intended for use with the STATIC port Kit Contents Dynon Avionics Part Description...
  • Page 375 Accessory Installation and Configuration Polyethylene Tube 102632-000 25 ft. Blue (-000) 102632-001 25 ft. Green (-001) 102632-002 35 ft. White (-002) Pitot Static 102642-000 Snap Bushing 102641-000 Tubing Cutter 102630-000 102642-000 Flared Coupling See Below 102643-000 Assembly 102644-000 Note: Parts may look slightly different than pictured. Please read this installation information in its entirety before beginning your installation of your AOA/Pitot/Static pneumatic system.

  • Page 376: Recommended Tools & Installation Accessories

    Accessory Installation and Configuration retainers are properly retracted by pressing the outer release ring. This allows for connection, disconnection, and reconnection of tubing easily with only one hand. A fresh cut of the tubing with the supplied tubing cutter is recommended before re-inserting the tubing. With the use of these Quick-Disconnect fittings, maintenance and instrument removal are made significantly easier from the standpoint of a builder such as yourself.
  • Page 377 Accessory Installation and Configuration with the alignment and drilling of 2 to 4 evenly spaced rivets. Another option is to use a compound, such as Pro-Seal, to mount the static port and seal out moisture. Structural Penetration and Pass-Thru 30 snap bushings have been provided in this kit to make plumbing within the fuselage and passing through internal structures easier and reduce possible chafing of the tubing.
  • Page 378 Accessory Installation and Configuration 15-26 SkyView System Installation Guide - Revision AA...

  • Page 379: Panel Module Faceplate Blank

    Accessory Installation and Configuration Panel Module Faceplate Blank Dynon Avionics offers the Panel Module Faceplate Blank (SV- BLANK-PANEL; P/N 102542-000) – see Figure 174. The Panel Module Faceplate Blank is the same dimensions and screw positions as other Dynon Avionics panel units such as SV-AP- PANEL, SV-COM-PANEL, SV-KNOB-PANEL, and SV-INTERCOM-2S.

  • Page 380: Sv-Knob-Dimmer

    Avionics panel units such as SV-AP-PANEL, SV-COM-PANEL, SV-KNOB-PANEL, and SV-INTERCOM-2S. Figure 173 SV-KNOB-DIMMER Note that on SkyView SE, installation of the SV-KNOB-DIMMER is the only method to manually control brightness of display and panel modules. Installation: Figure 174 – SV-KNOB-DIMMER Installation Dimensions...
  • Page 381 Accessory Installation and Configuration Wire Color Connection Points / Notes Connect to same point as SkyView display Ground (Black) Black wires, Pins 21 and 22 Connect to same point as SkyView display Power (Red wires), Red (electrical system) Pins 1 and 20 Connect to Violet wire (Pin 25) of SkyView display.

  • Page 383: 16. Sv-Com-C25 Installation And Configuration

    16. SV-COM-C25 Installation and Configuration Note: SV-COM-C25 is the complete radio system, consisting of the SV-COM-PANEL control panel installed on the panel, and the SV-COM-425 transceiver installed elsewhere. Installation instructions for the SV-INTERCOM-2S (referenced in these instructions) has its own, separate manual with much more technical detail than is included in this guide, available for download at http://docs.dynonavionics.com.

  • Page 384: Physical Installation: Sv-Com-Panel

    SV-COM-C25 Installation and Configuration Physical Installation: SV-COM-PANEL SV-COM-PANEL Dimensions Figure 176 – SV-COM-PANEL Dimensions 16-2 SkyView System Installation Guide - Revision AA...
  • Page 385 SV-COM-C25 Installation and Configuration Physical Installation SV-COM-PANEL – VERTICAL Installation Dimension Quick Overview  Panel Cutout: (irregular – see drawing)  Bezel Outline: 1.80” W x 3.532” T (45.72 mm W x 89.71 mm T)  Note that the SV-COM-PANEL/V is sized such that two units can be stacked to the same height as the height of an SV-D1000 display.
  • Page 386 SV-COM-C25 Installation and Configuration  COM Antenna, coaxial cable, terminated to BNC Male connector (or cable and connector is included with your COM antenna). The SV-COM-C25 is compatible with aircraft COM antennas commonly available. Mounting Dimensions The following diagrams are NOT to scale. However, paper templates are included with your SV-COM-C25 and may also be downloaded from http://docs.dynonavionics.com.
  • Page 387 SV-COM-C25 Installation and Configuration Figure 178 – SV-COM-425 Dimensions – NOT ACTUAL SIZE Figure 179 – SV-COM-425 Mounting Hole Pattern – NOT ACTUAL SIZE SkyView System Installation Guide - Revision AA 16-5...

  • Page 388: Electrical Installation

    SV-COM-C25 Installation and Configuration Electrical Installation Use this section in conjunction with the information contained in Appendix C: Wiring and Electrical Connections (notably Figure 217 on page 23-9). Power Input The SV-COM-C25 is compatible with 12 volt and 24 volt systems (10 to 30 volts DC). Power input is connected to the SV-COM-425, which then supplies power to the SV-COM-PANEL via the 5-wire cable between the two units.
  • Page 389 SV-COM-C25 Installation and Configuration Additional harness construction and wiring information can be found in Appendix C: Wiring and Electrical Connections. The SV-COM-PANEL has two (electrically identical) D9M connectors for connection to SkyView Network and one D15M connector for connection with the SV-COM-425 and an optional Frequency Flip/Flop pushbutton input.
  • Page 390 SV-COM-C25 Installation and Configuration SV-COM-425 – D15M Pinout Function Notes MICROPHONE IN SV-INTERCOM-2S Pin 25 MICROPHONE / PTT See diagram below. GROUND SV-COM-PANEL To SV-COM-PANEL Pin 6 ENABLE GROUND OUT Do not connect SV-INTERCOM-2S Pin 12 PTT IN Push Button Normally Open (PBNO) to Ground (Pins 4, 11, or 15) DATA TX to SV-COM- To SV-COM-PANEL Pin 4...
  • Page 391 SV-COM-C25 Installation and Configuration Note that SkyView Network connection(s) on SV-COM-PANEL are not shown, nor are additional connections between the SV-INTERCOM-2S and other devices that it connects to. Figure 180 – Single SV-COM-C25 to SV-INTERCOM-2S Single SV-COM-C25 to SV-INTERCOM-2S Harness Construction Notes Shielded cable between SV-COM-425 Pins 9 and 10, and SV-INTERCOM-2S Pins 1 and 14: ...
  • Page 392 SV-COM-C25 Installation and Configuration Shielded cable between SV-COM-425 Pins 1 and 2, and SV-INTERCOM-2S Pins 1 and 25:  This cable consists of two wires plus shield.  Use one of the wires to connect SV-COM-425 Pin 1 to SV-INTERCOM-2S Pin 25. ...
  • Page 393 SV-COM-C25 Installation and Configuration The following figure depicts how a dual SV-COM-C25 is connected to an SV-INTERCOM- 2S. Note that the additional connections between the SV-INTERCOM-2S and other devices that it connects to are not shown. Note that the associated SV-COM-PANELs are also not shown;...
  • Page 394 SV-COM-C25 Installation and Configuration Shielded cable between SV-COM-425 #1 Pins 1 and 2, and SV-INTERCOM-2S Pins 1 and 25:  This cable consists of two wires plus shield.  Use one of the wires to connect SV-COM-425 #1 Pin 1 to SV-INTERCOM-2S Pin 25. ...
  • Page 395 SV-COM-C25 Installation and Configuration o Shield of the cable from SV-COM-425 #1 Pins 1 and 2 o SV-COM-425 #2 Pin 9 o Shield of the cable from SV-COM-425 #2 Pins 9 and 10 o SV-COM-425 #2 Pin 2 o Shield of the cable from SV-COM-425 #2 Pins 1 and 2 Rather than trying to terminate these eight connections directly to SV-INTERCOM-2S Pin 1, we suggest connecting a wire to Pin 1, then bond all nine connections together.
  • Page 396 SV-COM-C25 Installation and Configuration Figure 183 – Headset Jack Schematic Interpretation Power/Ground Input The SV-COM-C25 requires 10-30V DC. For wire runs from power distribution to the SV-COM- 425 up to 6’, 22 AWG wire is sufficient for power and ground wires. For wire runs from power distribution to the SV-COM-425 longer than 6’, 20 AWG wire is recommended for power and ground wires.

  • Page 397: Antenna Installation

    SV-COM-C25 Installation and Configuration Optional Flip / Flop Button Pin 7 of the SV-COM-PANEL can be connected to a Push Button Normally Open (PBNO) and GROUND. Pushing this button “flip flops” the ACTIVE and STANDBY frequency selection - the same function as pressing in the TUNE knob on the SV-COM-PANEL. Typically, this signal is used with a button on the stick.
  • Page 398 SV-COM-C25 Installation and Configuration  Separation of COM antenna(s) from transponder(s) and GPS receivers / antennas: 1 foot (12 inches).  Separation of COM antenna(s) from Automatic Direction Finder (ADF) or 121.5 MHz Emergency Locator Transmitter (ELT): 4 feet (48 inches) ...

  • Page 399: Skyview System Settings For Sv-Com-C25

    SV-COM-C25 Installation and Configuration  Avoid kinking the cable even temporarily during installation.  Secure the cable so that it cannot interfere with other systems. SkyView System Settings for SV-COM-C25 Network Setup As with all other SkyView Network devices, the SV-COM-C25 must be configured into the SkyView Network: ...
  • Page 400 SV-COM-C25 Installation and Configuration > MIC GAIN – The default setting of 50 should work for most installations. To assist in setting SV-COM-425’s microphone gain, the COM RADIO SETUP > MIC GAIN (SV-COM-425 ONLY) menu includes a diagnostic feature (MIC LEVEL: LOW / GOOD / HIGH), as shown on screen: To adjust, speak “test”...

  • Page 401: Post Installation Checks

    SV-COM-C25 Installation and Configuration Displayed COM (Top Bar) The status of one COM radio can be displayed on the top bar. The radio that is selected here is also the radio that you can send airports and frequencies to via SkyView’s Map Menu APT>COM and TUNE COM buttons.

  • Page 402: Continued Airworthiness And Maintenance

    SV-COM-C25 Installation and Configuration  Is received audio clear at most volume levels on the SV-COM-C25? (Distortion at high volume levels is normal.)  Are transmissions from the SV-COM-C25 heard by others at reasonable ranges? (Keep in mind that the power output of the SV-COM-C25 is 6 watts.) ...

  • Page 403: 17. Sv-Com-X83 Installation And Configuration

    17. SV-COM-X83 Installation and Configuration Note: SV-COM-X83 is the complete radio system, consisting of the SV-COM-PANEL control panel installed on the panel, and the SV-COM-T8 transceiver installed elsewhere. Installation instructions for the SV-INTERCOM-2S (referenced in these instructions) has its own, separate manual with much more technical detail than is included in this guide, available for download at http://docs.dynonavionics.com.

  • Page 404: Certification Considerations

    SV-COM-X83 Installation and Configuration Certification Considerations The SV-COM-T8 VHF COM Transceiver Module is supplied to Dynon Avionics by Trig Avionics Limited and is derived from the Trig TY91 VHF radio system. The TY91 VHF radio unit supplied by Trig communicates only with the TC90 Front Panel Controller. The Dynon Avionics SV-COM- T8 communicates only with the Dynon Avionics SV-COM-PANEL.
  • Page 405 SV-COM-X83 Installation and Configuration Physical Installation SV-COM-PANEL – VERTICAL Installation Dimension Quick Overview  Panel Cutout: (irregular – see drawing)  Bezel Outline: 1.80” W x 3.532” T (45.72 mm W x 89.71 mm T)  Note that the SV-COM-PANEL/V is sized such that two units can be stacked to the same height as the height of an SV-D1000 display.

  • Page 406: Physical Installation: Sv-Com-T8

    SV-COM-X83 Installation and Configuration Mounting Dimensions The following diagrams are NOT to scale. However, paper templates are included with your SV-COM-C25 and may also be downloaded from http://docs.dynonavionics.com. Figure 186 – SV-COM-PANEL - VERTICAL Panel Cutout and Mounting Hole Dimensions - NOT ACTUAL SIZE Physical Installation: SV-COM-T8 The figures on the following pages show mechanical dimensions for the SV-COM-T8.
  • Page 407 SV-COM-X83 Installation and Configuration  If you are installing two SV-COM-X83s, it is acceptable to co-locate the two SV-COM-T8 transceiver modules.  Select a position in the aircraft for the SV-COM-T8 that is not too close to any high external heat source and where reasonable airflow is available.
  • Page 408 SV-COM-X83 Installation and Configuration Figure 187 – SV-COM-T8 Dimensions – NOT ACTUAL SIZE 17-6 SkyView System Installation Guide - Revision AA...

  • Page 409: Electrical Installation

    SV-COM-X83 Installation and Configuration Electrical Installation Use this section in conjunction with the information contained in Appendix C: Wiring and Electrical Connections (notably Figure 217 on page 23-9). Power Input When the voltage supplied to the SV-COM-X83 is below 11V, the transmit power will be reduced below the nominal output of 6 watts.

  • Page 410: Electrical Connections

    SV-COM-X83 Installation and Configuration Electrical Connections Harness Construction Because the SV-COM-X83 (SV-COM-PANEL connected to SV-COM-T8) can be mounted in a variety of locations, the harness length requirements will vary from airplane to airplane. Thus, Dynon Avionics does not supply pre-manufactured harnesses for the SV-COM-X83. Instead, your SV-COM-X83 includes connectors and pins to generate a wide variety of harness configurations.
  • Page 411 SV-COM-X83 Installation and Configuration SV-COM-T8 – D25M Pinout Function Notes Connect to SV-INTERCOM-2S Pin 1 PHONES GROUND (Inside shielded cable) Connect to SV-INTERCOM-2S Pin 14 PHONES OUT (Inside shielded cable) No connection Do not connect No connection Do not connect DATA RX from SV- Connect to SV-COM-PANEL Pin 5 COM-PANEL...
  • Page 412 SV-COM-X83 Installation and Configuration The following figure depicts how a single SV-COM-T8 is connected to an SV-INTERCOM-2S. Note that SkyView Network connection(s) on SV-COM-PANEL are not shown, nor are additional connections between the SV-INTERCOM-2S and other devices that it connects to. Figure 188 –...
  • Page 413 SV-COM-X83 Installation and Configuration  Use the other wire to connect SV-COM-T8 Pin 9 to SV-INTERCOM-2S Pin 1 (see instructions below - Terminating Shielded Cables to Pin 1 of SV-INTERCOM-2S).  On the SV-COM-T8 end, continue the shield as far into the connector as possible until you're forced to pare it back to access the two inner wires.
  • Page 414 SV-COM-X83 Installation and Configuration Figure 189 – Dual SV-COM-T8s to SV-INTERCOM-2S Transmit Interlock When two SV-COM-X83 radios are installed, the TRAMIT INTERLOCK pin can be connected to reduce “break-through” (noise being heard as the squelch opens) in one COM radio when the other COM radio is transmitting.
  • Page 415 SV-COM-X83 Installation and Configuration Shielded cable between SV-COM-T8 #1 Pins 23 and 9, and SV-INTERCOM-2S Pins 1 and 25:  This cable consists of two wires plus shield.  Use one of the wires to connect SV-COM-T8 #1 Pin 23 to SV-INTERCOM-2S Pin 25. ...
  • Page 416 SV-COM-X83 Installation and Configuration o Shield of the cable from SV-COM-T8 #1 Pins 1 and 2 o SV-COM-T8 #1 Pin 9 o Shield of the cable from SV-COM-T8 #1 Pins 23 and 9 o SV-COM-T8 #2 Pin 1 o Shield of the cable from SV-COM-T8 #2 Pins 1 and 2 o SV-COM-T8 #2 Pin 9 o Shield of the cable from SV-COM-T8 #2 Pins 23 and 9 Rather than trying to terminate these eight connections directly to SV-INTERCOM-2S Pin 1, we...
  • Page 417 SV-COM-X83 Installation and Configuration Figure 191 – Headset Jack Schematic Interpretation Power/Ground Input The SV-COM-T8 and SV-COM-PANEL require 10-30V DC. 20 AWG wire is recommended for power and ground wires for the SV-COM-T8. For all other connections, 22 AWG wire is recommended.

  • Page 418: Antenna Installation

    SV-COM-X83 Installation and Configuration Phones / Headset Connections for SV-INTERCOM-2S SV-COM-T8 SV-INTERCOM-2S Notes PHONES OUT Audio signal from radio to headset phones PHONES GROUND Shield connection for PHONES OUT PUSH TO TALK IN When connected to GROUND, SV-COM-X83 switches from Receive to Transmit MICROPHONE IN Audio signal from headset...
  • Page 419 SV-COM-X83 Installation and Configuration  Separation of COM antenna(s) from Automatic Direction Finder (ADF) or 121.5 MHz Emergency Locator Transmitter (ELT): 4 feet (48 inches)  Separation of COM antenna from another COM or NAV antenna: Recommended separation between COM antenna(s), NAV antenna(s), and ELT antennas is 6 feet (72 inches). Minimum required separation between antennas is 4 feet (48 inches).
  • Page 420 SV-COM-X83 Installation and Configuration  Avoid kinking the cable even temporarily during installation.  Secure the cable so that it cannot interfere with other systems. Antenna TNC Connector BNC connectors are more common for COM radio installations than TNC connectors. TNC Male to BNC Female adapters such as Amphenol P/N 242149 are readily available and inexpensive and will allow an antenna system terminated in a BNC Male connector to be used with the SV-COM-T8.

  • Page 421: Skyview System Settings For Sv-Com-X83

    SV-COM-X83 Installation and Configuration TNC to BNC Adapter If you have purchased a COM antenna that has coaxial cable and a BNC connector already installed, you can use a “TNC Male to BNC Female” adapter to adapt the SV-XPNDR-261/262’s TNC connector to a BNC connector.

  • Page 422: Post Installation Checks

    SV-COM-X83 Installation and Configuration SETUP MENU > ENABLE 8.33 KHZ (SV-COM-X83) > NO. This setting can be changed back to 8.33 kHz at any time. Post Installation Checks  On Ground  Do all SV-COM-PANEL buttons and knobs function normally? ...
  • Page 423 SV-COM-X83 Installation and Configuration  Periodic function checks as required by your aviation authority. SkyView System Installation Guide - Revision AA 17-21...

  • Page 425: 18. Sv-Ap-Panel Installation And Configuration

    18. SV-AP-PANEL Installation and Configuration If you intend to install and use SkyView SE, be advised that the buttons on the SV- AP-PANEL will not function. The SV-AP-PANEL’s Trim Control Subsystem, used for Electric Trim Control, and SkyView AP Auto-trim, can be used with SkyView SE.
  • Page 426 SV-AP-PANEL Installation Figure 193 is an overview of suggested steps for SV-AP-PANEL installation. Figure 193 – Overview of SV-AP-PANEL Installation 18-2 SkyView System Installation Guide - Revision AA...

  • Page 427: Physical Installation

    SV-AP-PANEL Installation Physical Installation The following diagrams as printed are NOT to scale, NOT actual size. 1:1 template drawings and CAD models (same as SV-COM-PANEL) are available for download at http://docs.dynonavionics.com. Figure 194 – SV-AP-PANEL Panel Cutout and Mounting Hole Dimensions - NOT ACTUAL SIZE SkyView System Installation Guide - Revision AA 18-3...

  • Page 428: Electrical Installation

    SV-AP-PANEL Installation Figure 195 – SV-AP-PANEL Dimensions Electrical Installation SkyView Network The SV-AP-PANEL has two SkyView Network connections (D9M connectors). Both connectors are electrically identical and are internally connected. Thus, the SV-AP-PANEL can be installed in the SkyView Network as a “pass-through” device, or “daisy chained” from one SkyView Network device, through the SV-AP-PANEL, to the next SkyView Network device.
  • Page 429 SV-AP-PANEL Installation Trim and Flaps Position Potentiometers in the SV-EMS-220/221 Installation and Configuration section. Trim Motor Control Safety Features  Pilot trim controls override Copilot trim controls.  If SkyView Network connection or SkyView power is lost, the trim motor functions will continue to function as long as avionics power is available at Pin 9.
  • Page 430 SV-AP-PANEL Installation D15M Pin Function Notes Pin 3 or Pin 5 grounded: Pin 7 polarity is +, Pin 8 polarity is - MOTOR 1 WIRE #1 (Motor rotates in one direction) Pin 4 or Pin 6 grounded: Pin 7 polarity is -, Pin 8 polarity is + MOTOR 1 WIRE #2 (Motor rotates in the other direction) If trim motor(s) control is not used, do not connect.
  • Page 431 SV-AP-PANEL Installation Figure 196 – SV-AP-PANEL Trim control wiring diagram Network Setup As with all other SkyView Network devices, the SV-AP-PANEL must be configured into the SkyView Network:  Go to SETUP MENU > SYSTEM SETUP > SKYVIEW NETWORK SETUP > CONFIGURE > (right click) >...
  • Page 432 SV-AP-PANEL Installation > MOTOR 1: > AUTO-TRIM FUNCTION: NONE (right click to enter the menu) Follow the on-screen instructions to define which trim surface the Autopilot auto-trim feature will move. This process also determines the correct auto-trim motor directions. Pushing the RESET button will restart the calibration process. After the calibration is complete, the AUTO-TRIM FUNCTION: (label) will reflect the trim surface that will be automatically trimmed by the autopilot when that autopilot axis is engaged.

  • Page 433: Autopilot Auto-Trim

    SV-AP-PANEL Installation Autopilot Auto-trim SkyView can provide automatic trim control (AP Auto-trim) if your plane’s electric trim motor(s) are operated through the SV-AP-PANEL’s trim controller (trim control pushbuttons on the stick, and the electric trim motors, are connected to the SV-AP-PANEL). The SV-AP-PANEL can provide AP Auto-trim whether the SkyView AP is configured to EXPERT AP mode, or SIMPLIFIED AP mode.

  • Page 435: 19. Sv-Knob-Panel Installation

    19. SV-KNOB-PANEL Installation This section contains pre-installation considerations and installation instructions and details to install the SV-KNOB-PANEL/H (Horizontal orientation) and SV-KNOB-PANEL/V (Vertical orientation). Physically, electronically, and operationally, the two versions are identical, and hereafter referred to SV-KNOB-PANEL. SV-KNOB-PANEL is an optional control panel for a SkyView system that provides dedicated function knobs for: ...

  • Page 436: Physical Installation

    SV-KNOB-PANEL Installation Physical Installation The following diagrams as printed are NOT to scale, NOT actual size. 1:1 template drawings and CAD models are available for download at – http://docs.dynonavionics.com (use SV-COM-PANEL drawings, which have the same dimensions as SV-AP-PANEL). Figure 198 – SV-KNOB-PANEL Panel Cutout and Mounting Hole Dimensions - NOT ACTUAL SIZE 19-2 SkyView System Installation Guide - Revision AA...

  • Page 437: Electrical Installation

    SV-KNOB-PANEL Installation Figure 199 – SV-KNOB-PANEL Dimensions Electrical Installation SkyView Network The SV-KNOB-PANEL has two SkyView Network connections (D9 connectors). Both connectors are electrically identical and are internally connected. Thus, the SV-KNOB-PANEL can be installed in the SkyView Network as a “pass-through” device, or “daisy chained” from one SkyView Network device, through the SV-KNOB-PANEL, to the next SkyView Network device.

  • Page 439: 20. Sv-Mag-236 Installation And Configuration

    20. SV-MAG-236 Installation and Configuration Figure 200 – SV-MAG-236 (Photo) The SV-MAG-236 Remote Magnetometer was developed for situations where the SV-ADAHRS- 200/201’s integrated magnetometer cannot be located in an area free of magnetic disturbances while satisfying the other installation constraints (such as proximity to center of gravity) of the SV-ADAHRS-200/201.

  • Page 440: Physical Installation

    SkyView Display Installation and Configuration Figure 202 is a high-level overview of a suggested installation and configuration procedure for the SV-MAG-236: Figure 202 – Suggested Installation Sequence for the SV-MAG-236 Physical Installation The most critical factor in the SV-MAG-236 being able to accurately sense magnetic heading is for it to be installed in an area of the plane that is magnetically benign.
  • Page 441 SkyView Display Installation and Configuration If you use a magnet to test whether possible interfering materials are non- magnetic, do not actually touch the magnet to the material you are testing, as this contact can cause the material you are testing to become magnetized. Move a handheld compass throughout the space surrounding your intended location to get a rough idea of the suitability of the area.

  • Page 442: Optional Sv-Oat-340 Connected To Sv-Mag-236

    SkyView Display Installation and Configuration  The label on the SV-MAG-236’s must be oriented towards the top of the aircraft.  The side of the SV-MAG-236 where the cable exists must be oriented towards the nose of the aircraft (as noted on the label of the unit – CABLE END FORWARD). ...
  • Page 443 SkyView Display Installation and Configuration Because the SV-OAT-340 is optional for the SV-MAG-236, installation instructions are not included in this section – see SV-OAT-340 Location and Installation in the Beginning in Software v15.0, SkyView Classic, and SkyView HDX can provide up to ten maintenance reminders based on Date, elapsed Tach Time, or elapsed Hobbs Time.

  • Page 445: Skyview Network Connection

    SV-ADAHRS-200/201 Installation and Configuration section earlier in this manual. SkyView Network Connection Connect the SV-MAG-236 to the SkyView network using a SkyView Network Cable. To minimize any potential magnetic interference from the connector, it is recommended to not locate the connector near the SV-MAG-236.

  • Page 446: On-Ground Compass Calibration Procedure

    SV-MAG-236 Installation and Configuration Tail wheel equipped aircraft can be calibrated in their normal nose up ground attitude as long as the SkyView attitude display shows the correct corresponding nose up attitude. A working GPS receiver with a view of the sky to acquire GPS data must be connected to the SkyView system in order to perform a compass calibration.

  • Page 447: In-Flight Compass Calibration Procedure

    SV-MAG-236 Installation and Configuration Figure 204 – On-ground COMPASS CALIBRATION Menu 5. Orient the aircraft to North, South, East, or West. 6. When the aircraft is stable at the chosen orientation, push the button indicating the direction the aircraft is oriented in. Example – when the aircraft is pointed North, push the NORTH button.
  • Page 448 SV-MAG-236 Installation and Configuration Confine the flying for the in-flight compass calibration to a specific area to minimize variations in the earth’s magnetic field during the calibration process (IE, don’t combine the in-flight compass calibration with a cross-country flight). While the in-flight compass calibration is optional, it will likely improve the dynamic performance of the heading indications in many aircraft.

  • Page 449: Restoring Use Of The Sv-Adahrs-200/201 Internal Magnetometer

    SV-MAG-236 Installation and Configuration 7. The minimum maneuvers for in-flight compass calibration is one 360° turn clockwise, and one 360° turn counterclockwise. Flying additional maneuvers incorporating pitch and roll changes will likely improve the in-flight compass calibration. 8. When the quality is as high as you can obtain (above 70, the minimum), push the FINISH button to complete the in-flight compass calibration.

  • Page 451: 21. Appendix A: Maintenance And Troubleshooting

    21. Appendix A: Maintenance and Troubleshooting This appendix provides builders, installers and technicians basic information regarding SkyView maintenance and troubleshooting. Dynon Avionics’ Internet sites may provide more up-to-date information on maintenance and troubleshooting than this document. The following sites should be used a reference: ...

  • Page 452: Saving A Screenshot Of A Specific Screen

    Appendix A: Maintenance and Troubleshooting Saving a Screenshot of a Specific Screen It is sometimes helpful to have a screenshot of a behavior to share with Dynon Avionics Technical Support. Screenshots recorded with this method are far superior to photos because they are always “in focus”...

  • Page 453: Skyview Displays Error: Sys Event 5: See Setup

    Appendix A: Maintenance and Troubleshooting SkyView Displays Error: SYS EVENT 5: SEE SETUP The System Event diagnostic was added in SkyView Software v13.0. System Event 5 indicates that the SkyView display's internal Solid State Disk (SSD) is experiencing an abnormal number of errors, and thus should be replaced.
  • Page 454 Appendix A: Maintenance and Troubleshooting SkyView Display Scenario 1: When the documentation furnished with the repaired display indicates that is being returned to you with the exact same settings/configuration as it was sent to Dynon Avionics with 1. In this case, the display contains EXACTLY the same configuration as it did when you sent it in.
  • Page 455 Appendix A: Maintenance and Troubleshooting 4. If you do not have an EXPORT SETTINGS file, use the SkyView Installation Guide to perform ALL setup and configuration steps as if the entire system is being installed for the first time. SkyView Display Scenario 3: When other display is part of a multi-display system in the aircraft, and the documentation furnished with the repaired unit indicates that the display was shipped “like new”...

  • Page 456: In A Multi-Display Skyview System, Continuing To Fly With A Missing Display

    Appendix A: Maintenance and Troubleshooting c. Confirm all SkyView Network components are found, including ALL displays that are in the aircraft. d. Exit Setup mode. 8. On the recently repaired display, confirm that the tail number under SYSTEM SETUP > AICRAFT INFORMATION is now set to the actual aircraft tail number, not DYNON.

  • Page 457: Operational Status

    Appendix A: Maintenance and Troubleshooting performance of compass and AOA calibration. If these do not seem to work as well as they previously did, redo those calibrations. If the ADAHRS is not the same serial number as the one you returned for repair, all setup and calibration steps should be performed because this ADAHRS is being installed for the first time.
  • Page 458 Appendix A: Maintenance and Troubleshooting  Serial port status and current baud rate  Button and joystick states  Operational hours Display Serial Number The serial number of the display is noted here as SERIAL NUMBER: XXXXXX. Display Software Version The Software version of the display is noted here as SOFTWARE VERSION: X.X.XX.XXX.

  • Page 459: Instructions For Continued Airworthiness

    Appendix A: Maintenance and Troubleshooting External Light Control Signal Output SkyView displays are compatible with external light control signals. The state of the external light control signal is shown here. Brightness Level Output SkyView displays can output a brightness level signal to control the brightness of compatible external equipment screens.

  • Page 460: Annual Sv-Bat-320 Test

    Appendix A: Maintenance and Troubleshooting  Autopilot servos – see Autopilot Servo Installation, Configuration, and Calibration section for details.  Any other issues should be addressed on an as-needed basis. Annual SV-BAT-320 Test This procedure assumes that an Initial SV-BAT-320 Test has been performed – see SV-BAT-320 Backup Battery Installation, Initial SV-BAT-320 Test.
  • Page 461 Appendix A: Maintenance and Troubleshooting 4. On the SkyView display that is being tested, during the 30 second power off countdown, press the TEST BAT button above button 8 (far right button) – see Figure 210 below. Figure 210 – TEST BAT Button Appears After Removing Power to SkyView Display 5.

  • Page 462: Troubleshooting

    Appendix A: Maintenance and Troubleshooting the USA, call 1-800-8-BATTERY or see the Call 2 Recycle website at http://www.rbrc.org. Troubleshooting The Display Hardware Information Page (SETUP MENU > LOCAL DISPLAY SETUP > DISPLAY HARDWARE INFORMATION) can be a valuable resource when troubleshooting SkyView and is described in the previous section.
  • Page 463 Appendix A: Maintenance and Troubleshooting SkyView Reports STANDBY NETWORK ERROR Figure 211 – Troubleshooting STANDBY NETWORK ERROR message SkyView has detected a problem with the SkyView Network wiring between one or more modules. Go to SETUP MENU > SYSTEM SETUP > SKYVIEW NETWORK SETUP > NETWORK STATUS for a description of the problem.
  • Page 464 Appendix A: Maintenance and Troubleshooting  Ensure the SkyView network status includes the ADAHRS you’re trying to calibrate. Use the Network Status Wizard and confirm that the ADAHRS is present in the system.  Ensure the ADAHRS location is compatible with the requirements outlined in the General System Installation Tips Section of this guide, especially the discussion of external magnetic interference.
  • Page 465 Appendix A: Maintenance and Troubleshooting Engine Sensor Does Not Show Up Onscreen Make sure the sensor is installed, defined, mapped, and configured according to the instructions found in SV-EMS-220/221 Installation and Configuration. MAP Button Is No Longer Available SkyView displays are shipped with a 30 Flight Hour trial of the SkyView Map. After 30 Flight Hours have elapsed (the trial has expired), the next time SkyView is powered up, the MAP button will not appear.

  • Page 467: 22. Appendix B: Specifications

    22. Appendix B: Specifications SkyView / Dynon Avionics Minor Equipment Weights For Major Equipment Weights, see System Planning, Major Unit Physical Specifications. SkyView / Dynon Avionics Equipment Description Approx. Weight Ammeter Shunt P/N 100412-000 0.32 lb. (0.14 kg) AOA/Pitot Probe, unheated (100141-000) 0.36 lb.

  • Page 468: Skyview Compatible Engine Sensors (Sold By Dynon Avionics)

    Appendix B: Specifications *Single sensor / accessory. Multiply by the number for total weight of sensors / accessories. SkyView Compatible Engine Sensors (sold by Dynon Avionics) Dynon Avionics Description Range/Type Fittings 0-60 A Amps Shunt or 2 each 1/4” Ring (can be configured to 100412-000 Ammeter Shunt...

  • Page 469: Sv-Bat-320 Specifications

    Appendix B: Specifications Dynon Avionics Description Range/Type Fittings Oil Pressure (Legacy – no longer 0-150 PSI 1/8-27 NPT 100411-002 sold by Dynon Avionics) Oil Pressure – Kavlico 0-150 PSI 1/8-27 NPT 101693-000 Oil Temperature (for Lycoming/ -10° F to 300° F 5/8-18 UNF 100409-001 Continental/Superior)

  • Page 470: Sv-Xpndr-261 Specifications

    Appendix B: Specifications SV-XPNDR-261 Specifications Specification Characteristics ETSO 2C112b Class 1 Level 2els (see below), ETSO C166a Class B0, TSO C112c Class 1 Level 2els (see below), TSO C166b Class B1S Level 2 (Comm B) Level 1 + receive and transmit 112 Bit Messages Level 2A Same as Level 2 without the support air-initiated Comm B messages...

  • Page 471: Sv-Xpndr-262 Specifications

    Appendix B: Specifications Operating -20°C to +70°C Temperature Transmitter Frequency 1090MHz ± 1MHz 250 Watts nominal; 125 Watts minimum at Transmitter Power antenna after allowing for 0.5dB connector losses and 1.5dB cable losses. Transmitter 6M75 V1D Modulation Receiver Frequency 1030 MHz Receiver Sensitivity -74Dbm ±...
  • Page 472 Appendix B: Specifications s – Surveillance Identifier (SI) code. Used by Mode S transponders and Mode S equipped SSR to limit interrogations to specific transponders. FCC Identification VZI00675 EUROCAE ED-73C, EUROCAE ED-14F (RTCA DO- Applicable documents 160F), RTCA DO-181D, RTCA DO-260B Software ED-12B (RTCA DO-178B) Level B Hardware...
  • Page 473 Appendix B: Specifications Loss of Cooling 4.5.5 Cooling air not required (+70°C operating without cooling air) Altitude 4.6.1 35,000 feet Decompression 4.6.2 8,000 to 35,000 feet in 15 seconds Overpressure 4.6.3 -15,000 feet Temperature Variation Equipment tested to Category C Humidity Equipment tested to Category A Operational Shocks...

  • Page 474: Sv-Xpndr-261/262 Ads-B Information

    Appendix B: Specifications Audio frequency conducted 18.0 Equipment tested to Category B susceptibility Induced signal susceptibility 19.0 Equipment tested to Category AC Radio frequency susceptibility 20.0 Equipment tested to Category TT Radio frequency emission 21.0 Equipment tested to Category B Equipment identified as Category XXXX –...
  • Page 475 Appendix B: Specifications Surface Length/Width Surface Antenna Offset Table 105 – SV-XPNDR-261/262 ADS-B Parameters Supported In all cases, uncompensated latency due to the transponder is less than 10 milliseconds. Analysis of the system latency should add this to the latency of the GPS system and the transmission time of the position data from the GPS to the transponder to determine the overall latency.

  • Page 476: Sv-Com-C25 Technical Specifications

    Appendix B: Specifications SV-COM-C25 Technical Specifications Specification Characteristics Current Requirement RX: 200 mA / TX: 3.0A FCC Identification WU6-310001-000 Voltage Input 10 V to 30 V DC Temperature Range -20° C to +60° C (-4° F to +140° F) Audio 150 Ohms nominal input impedance Microphone...

  • Page 477: Sv-Com-X83 (Ty91L Vhf Radio Unit) Technical Specifications

    Appendix B: Specifications SV-COM-X83 (TY91L VHF Radio Unit) Technical Specifications Specification Characteristics ETSO 2C169a Class C, E, H1, H2, 4, 6 Compliance ETSO 2C128 TSO C169a Class C, E, 4, 6, TSO C128a FCC Identification VZI00882 EUROCAE ED-23C EUROCAE ED-67 Applicable documents EUROCAE ED-14F (RTCA DO-160F) RTCA DO-186B...

  • Page 478: Sv-Gps-250 Specifications

    Appendix B: Specifications SV-COM-T8 Environmental Qualification Form Nomenclature: TY91L VHF radio Part Number: 00882-00-01 ETSO: 2C169a Manufacturer: Trig Avionics Limited Address: Heriot Watt Research Park, Riccarton, Edinburgh, Scotland, EH14 4AP Conditions DO-160F Description of Conducted Tests Section Temperature and Altitude Equipment tested to Categories A2, C1 Low temperature ground survival 4.5.1...

  • Page 479: Sv-Gps-2020 Specifications

    Appendix B: Specifications Specification Parameters Update Rate 5 Hz Receives WAAS Correction Signals (where available) Uses all available positioning satellites? Time to Acquire Fix (cold start) 60 seconds TX – Grey/Violet RS-232C @ 38,400 baud Data Interface RX – Grey/Orange RS-232C (not currently implemented) NMEA data sentences GGA, GSA, GSV, RMC, VTG...
  • Page 480 Appendix B: Specifications Specification Parameters Uses all available positioning satellites? No (L1 only) Time to Acquire Fix (cold start) 60 Seconds TX – Grey/Violet RS-232C @ 115,200 baud Data Interface RX – Grey/Orange RS-232C (not currently implemented) GPGGA, GPGLL, GPGSA, GPGSV, GPRMC, NMEA data sentences GPVTG, GPZDA (additional proprietary data)

  • Page 481: 23. Appendix C: Wiring And Electrical Connections

    23. Appendix C: Wiring and Electrical Connections SkyView utilizes standardized network connectors and wire harnesses for equipment-to-equipment connections as well as other connections. Installers should rarely have to build custom wire harnesses. This appendix is included as a reference for those rare times when custom wiring is required. Improper wiring can result in permanent damage to your instrument and/or the accompanying sensors.

  • Page 482: Dsub Crimp Contacts And Tools

    Appendix C: Wiring and Electrical Connections DSUB Crimp Contacts and Tools DSUB crimp contacts can be obtained from a variety of sources. Dynon Avionics recommends the use of the following Mil Spec types in avionics applications. Gender Mil Spec # Wire AWG Female/Socket M39029/63-368...
  • Page 483 Appendix C: Wiring and Electrical Connections Pair #3: 9-Pin Connector Wire Color Signal Name Pin # (SkyView Convention) Black Ground 1 Power 1 Pair #4: 9-Pin Connector Wire Color Signal Name Pin # (SkyView Convention) White/Black Ground 2 White/Red Power 2 Individual wire, not twisted with any other wire: 9-Pin Connector Wire Color...

  • Page 484: Skyview Equipment Electrical Connections

    Wire: 22 AWG Tefzel SkyView Equipment Electrical Connections SkyView and SkyView SE displays have six connectors on the back of the unit as illustrated in Figure 212:  One D37M for connection to the SkyView Display Harness (SV-HARNESS-D37)  Two D9M SkyView network connectors (SV-NET-xxxx) ...
  • Page 485 Appendix C: Wiring and Electrical Connections Figure 212 – SkyView Display Connectors A SkyView ADAHRS module (SV-ADAHRS-200/201) has two connectors as illustrated in Figure 213:  One D9M SkyView network connector  One 2-pin OAT sensor connector (only compatible with the SV-OAT-340) Figure 213 –...

  • Page 486: Skyview Equipment Electrical Connector Pinout Tables

    Appendix C: Wiring and Electrical Connections Figure 214 – SV-EMS-220/221 Connectors The SV-GPS-2020 and SV-GPS-250 GPS receivers include four unterminated wires. These wires may be trimmed or spliced and extended as needed to suit the installation location. Match the colors of these wires with the corresponding colors on the display harness as mentioned in the Serial Data Connection Section of SV-GPS-250/2020 GPS Receiver Installation and Configuration.

  • Page 487: Skyview Display D37 Pinout (Sv-Harness-D37)

    SkyView Display D37 Pinout (SV-HARNESS-D37) Figure 216 – SkyView Display D37F Connector Pin Numbering Dynon Avionics SkyView and SkyView SE displays use a D37M connector for the majority of its connections. Figure 216 – SkyView Display D37F Connector Pin Numbering above shows the pin numbering for the mating D37F connector, installed on the cable that plugs into this connector, from the rear (pin insertion) view.

  • Page 488: Skyview D37M Block Diagram

    Appendix C: Wiring and Electrical Connections SkyView Display SV-HARNESS-D37 Wire Color Description D37M Pin Orange with Yellow stripe Contact Input 3 Orange with Green stripe Contact Input 4 USB Power Black USB Ground White USB- Green USB+ Power Input Black Ground Black Ground...
  • Page 489 Appendix C: Wiring and Electrical Connections Figure 217 – SkyView Display’s D37M Connector Electrical Connections SkyView System Installation Guide - Revision AA 23-9...
  • Page 490 Appendix C: Wiring and Electrical Connections SkyView Network Pinout (SV-NET-XXXX) SkyView Network SkyView Network Description D9M Pin Cable Wire Color Green SkyView Network Data 1 A Black SkyView Network Ground 1 White with Black SkyView Network Ground 2 Stripe White with Blue SkyView Network Data 2 B Stripe Orange...

  • Page 491: Sv-Ems-220/221 Pinouts (Ems Harnesses)

    Appendix C: Wiring and Electrical Connections SV-EMS-220/221 Pinouts (EMS Harnesses) Figure 219 – SV-EMS-220/221 D37F Connector Pin Numbering The SV-EMS-220/221 uses a D37M connector for connecting most engine sensors. Figure 219 above shows the pin numbering for the mating D37F connector, installed on the cable that plugs into this connector, from the rear (pin insertion) view.
  • Page 492 Appendix C: Wiring and Electrical Connections SV-EMS-220 EMS 37-pin Harness Wire Description D37M Pin Color White/Green Standard RPM Left Input White/Blue Standard RPM Right Input Blue Low Voltage RPM Left Input Green Low Voltage RPM Right Input Blue General Purpose TC Input 2+ Green General Purpose TC Input 2- Table 116 –...
  • Page 493 Appendix C: Wiring and Electrical Connections SV-EMS-221 D37 EMS 37-pin Harness Wire Sensor (with Dynon Avionics part Color number if applicable) Black Signal Ground White/Orange Enhanced General Purpose Input 13 White/Green Standard RPM Left Input White/Blue Standard RPM Right Input Blue Low Voltage RPM Left Input Green...

  • Page 494: Sv-Arinc-429 Pinout

    Appendix C: Wiring and Electrical Connections EMS 25-pin SV-EMS-220/221 D25F Thermocouple Description Thermocouple Connector Pin Harness Wire Color* White CHT3 WHITE Yellow EGT3 YELLOW White CHT2 WHITE Yellow EGT2 YELLOW White CHT1 WHITE Yellow EGT1 YELLOW Table 118 – SV-EMS-220/221 D25F Thermocouple Connector *Note –...
  • Page 495 Appendix C: Wiring and Electrical Connections Pins 12/13 are the same TX signal. Provided for (determined by ARINC TX B convenience when connecting multiple ARINC installer) receivers. Pins 12/13 are the same TX signal. Provided for (determined by ARINC TX B convenience when connecting multiple ARINC installer) receivers.

  • Page 496: Sv-Xpndr-261/262 Pinout (Sv-Harness-Xpndr)

    Appendix C: Wiring and Electrical Connections Note – this connector is NOT a SkyView Network Connector. SV-ADS-B 470 Function Notes Wire Color 10-30V DC Connect to Aircraft Power Orange SV-ADSB-470 Serial RX Data Input from SkyView Violet SV-ADSB-470 Serial TX Data Output to SkyView Black Ground...
  • Page 497 Appendix C: Wiring and Electrical Connections SV-XPNDR- SV-HARNESS- 261/262 D25 XPNDR Function Description Wire Color White Loopback 1 Connect to Pin 2 White Loopback 1 Connect to Pin 1 White GPS Serial Input Aviation Format Only No Connect SV-XPNDR- Connect to Pin 4, 6, 8, or 10 on Orange 261/262 Serial RX SkyView Display D37 connector...

  • Page 498: Sv-Ap-Panel Pinout (D15M Connector)

    Appendix C: Wiring and Electrical Connections SV-AP-PANEL Pinout (D15M connector) Figure 224 – SV-AP-PANEL D15F Connector Pin Numbering The SV-AP-PANEL Trim Control Subsystem uses a D15M connector for connecting to trim control buttons, the trim servo(s), and power for the trim servos(s). Figure 224 above shows the pin numbering for the mating D15F connector, installed on the cable that plugs into this connector, from the rear (pin insertion) view.

  • Page 499: Sv-Com-Panel Pinout (D15M)

    Appendix C: Wiring and Electrical Connections Motor 2: Pin 14 polarity is + COPILOT TRIM RIGHT (determined by installer) Pin 15 polarity is - Motor 2: Pin 14 polarity is - COPILOT TRIM LEFT (determined by installer) Pin 15 polarity is + Pin 10 or Pin 12 grounded Pin 14 polarity is +, Pin 15 polarity is - (Motor rotates in MOTOR 2 WIRE #1...

  • Page 500: Sv-Com-425 Pinout

    Appendix C: Wiring and Electrical Connections Wire Color Function Notes From SV-COM-425 Pin 7 or Power In (determined by installer) 10-30V DC @ 5A (SV-COM-T8) From SV-COM-425 Pin 7 or Ground In (determined by installer) Ground (SV-COM-T8) Optional – for Grounding Pin 7 (Flip/Flop Ground Out (determined by installer) Switch).
  • Page 501 Appendix C: Wiring and Electrical Connections The SV-COM-425-uses a D15M connector for connecting to the SV-COM-PANEL. Figure 226 above shows the pin numbering for the mating D15F connector, installed on the cable that plugs into this connector, from the rear (pin insertion) view. Wire Color Function Notes...

  • Page 502: Sv-Com-T8 Pinout

    Appendix C: Wiring and Electrical Connections SV-COM-T8 Pinout Figure 227 – SV-COM-T8 D25F Connector Pin Numbering The SV-COM-T8 uses a D25M connector for connecting to the SV-COM-PANEL. Figure 227 above shows the pin numbering for the mating D25F connector, installed on the cable that plugs into this connector, from the rear (pin insertion) view.
  • Page 503 Appendix C: Wiring and Electrical Connections TRANSMIT (Use only when there are two SV-COM-X83s (determined by installer) INTERLOCK installed.) Connect to other radio’s PTT. GROUND IN GROUND (determined by installer) No Connection No Connection GROUND IN GROUND (determined by installer) Connect to SV-INTERCOM-2S Pin 25 MICROPHONE IN (determined by installer)

  • Page 505: 24. Appendix D: Sv-Ems-220/221 Sensor Input Mapping Worksheet

    24. Appendix D: SV-EMS-220/221 Sensor Input Mapping Worksheet Use this worksheet to record SV-EMS-220/221 sensor input mapping. IMPORTANT INSTALLATION INFORMATION SV-EMS-220/221 S/N Installer Installation Completion Date Function Sensor Name C37 P1 C37 P2 C37 P4 C37 P6 C37 P7 C37 P8 C37 P9 C37 P10 C37 P11...
  • Page 506 Appendix D: SV-EMS-220/221 Sensor Input Mapping Worksheet Function Sensor Name C37 P33/35 C37 P36/37 C25 P2/14 C25 P3/15 C25 P4/16 C25 P5/17 C25 P6/18 C25 P7/19 C25 P8/20 C25 P9/21 C25 P10/22 C25 P11/23 C25 P12/24 C25 P13/25 24-2 SkyView System Installation Guide - Revision AA...

  • Page 507: 25. Appendix E: Serial Data Output

    25. Appendix E: Serial Data Output Any of SkyView’s five RS232 serial ports can be configured to output various types of serial data via SETUP MENU > SYSTEM SETUP > SERIAL PORT SETUP. Technical information on the installation and connection to the serial ports can be found in the Serial Devices section of the SkyView Installation Guide.

  • Page 508: Dynon Adahrs Serial Data Format

    Appendix E: Serial Data Output DYNON ADAHRS Serial Data Format The following section details the format of DYNON ADAHRS serial output data: Position Width Name Description Start Character/Data Type 1 = ADAHRS data. Other Dynon Avionics Data Type formats look similar, and may be interleaved. This bit tells you what kind of data will follow.
  • Page 509 Appendix E: Serial Data Output Position Width Name Description +/- then 000 to 999, rate of yaw change in degrees/second * 10, positive meaning the Turn Rate (deg/s) aircraft is turning right. XXXX when not available. +/- then 00 to 99, lateral g’s in units of g * 100 (99 = 0.99 g’s), positive meaning the aircraft is Lateral Accel (g) experiencing leftward lateral acceleration (slip...

  • Page 510: Dynon System Serial Data Format

    Appendix E: Serial Data Output !1121144703-014+00003310811+01736+003-03+1013-033+110831245+01650023176C DYNON SYSTEM Serial Data Format The following section details the format of DYNON SYSTEM serial output data: Position Width Name Description Start Character ‘!’ 2 = System Info. Other Dynon Avionics formats Data Type look similar, and may be interleaved, this bit indicates what kind of data will follow.
  • Page 511 Appendix E: Serial Data Output Position Width Name Description +/- then 00 to 99 percent of deflection, + Glideslope (%) meaning deflected upward, ‘XXX’ w/o valid GS. 0-7. 0=Off, 1= roll only, 2=pitch only, 3= roll+pitch, 4=yaw, 5=roll+yaw, 6=pitch+yaw, AP Engaged 7=pitch+roll+yaw (yaw doesn’t currently exist, but format supports it).
  • Page 512 Appendix E: Serial Data Output Position Width Name Description 0 or 1. 0 = No slipping on this servo. 1 = At least one slip on this servo in the last 3 AP Pitch Slip (bool) seconds. Always reads zero when AP pitch not engaged.

  • Page 513: Dynon Ems Serial Data Format

    Appendix E: Serial Data Output DYNON EMS Serial Data Format The following section details the format of EMS data output to the serial port: Position Width Name Description Start ‘!’ Character 3 = EMS Data. Other Dynon Avionics formats look similar, and may be Data Type interleaved, this bit indicates what kind of data will follow.
  • Page 514 Appendix E: Serial Data Output Position Width Name Description 000 to 999 or XXX. Fuel pressure in 1/10 Fuel PSI. 274 = 27.4 PSI. Pressure Varies There must be a pressure sensor named (PSI) “FUEL” for this to work. See note 2. 000 to 999 or XXX.
  • Page 515 Appendix E: Serial Data Output Position Width Name Description Thermocou +/- then 000 to 999. In degrees C. See C25 P8/20 ple 7 (deg C) note 2. Thermocou +/- then 000 to 999. In degrees C. See C25 P9/21 ple 8 (deg C) note 2.
  • Page 516 Appendix E: Serial Data Output Position Width Name Description +/- then 0000 to 9999, then units. +YYYYZ. GP Input 11 C37 P6 See note 3. +/- then 0000 to 9999, then units. +YYYYZ. GP Input 12 C37 P7 See note 3. +/- then 0000 to 9999, then units.

  • Page 517: Dynon Adahrs / System / Ems Serial Data Output Combinations

    Appendix E: Serial Data Output  ZZZZ if the input is not configured  P if the signal is in pressure, and the units are 1/10 PSI  YYYY is 1/10th PSI, so 0123 = 12.3 PSI  XXXX if the signal is out of range (red X on ems page) ...

  • Page 518: Nmea Out Serial Data Formats

    Appendix E: Serial Data Output DYNON ADAHRS + EMS Serial Data Format DYNON ADAHRS+EMS output data alternates between DYNON ADAHRS data and DYNON EMS data. For example, the following is one cycle of DYNON ADAHRS+EMS output data where the first line is ADAHRS output and that is followed by EMS output: !1121144703-014+00003310811+01736+003-03+1013-033+110831245+01650023176C !3221144705060+09323632363272057057164263263000280280+1200001300020+197+592+1 97+592+197+592+197+592+197+592+197+592+197+197-...
  • Page 519 Appendix E: Serial Data Output $GPGGA,214921,3121.6199,N,00000.0000,E,1,04,1.90,3000.0,M,33.9,M,,0000 $GPGSA,A,3,01,02,03,04,00,00,00,00,00,00,00,00,1.00,1.90,1.90*07 $GPGSV,1,1,04,01,20,100,10,02,30,200,56,03,45,300,32,04,62,045,05*7A $GPRMC,214921,A,3121.6199,N,00000.0000,E,82.07,1.00,300811,0.51,W,A*01 $GPVTG,1.00,T,0.51,M,82.07,N,151.99,K,A*1E NMEA OUT (FULL) NMEA OUT (FULL) data consists of all of the NMEA OUT (BASIC) sentences followed by RMB, GLL, BWC, XTE, BOD, and APB sentences nominally output at a rate of 1 Hz. The rate is reduced if necessary to transmit the entire set of data at the selected baud rate.

  • Page 521: 26. Appendix F: User Data Logs

    26. Appendix F: User Data Logs SkyView continuously stores four retrievable data logs that can be exported for user analysis. These data logs are stored on SkyView’s internal flash memory and are exported to a USB flash drive. The base file name is the same on all four logs. Each element is separated by a dash (-) character: ...

  • Page 522: Recent Flight Data Log

    Appendix F: User Data Logs The User Data Log records at the selected Record Rate (see below) any time the SkyView system is powered on. A sample of what a few columns and rows of data would look like when viewed in a spreadsheet program is shown below.

  • Page 523: History Data Log

    Appendix F: User Data Logs example, oil pressure going into the red zone for a few seconds, then back into green, and automatically clearing. When exported, the data log is a standard CSV (comma separated value) file and can be viewed in spreadsheet programs such as Microsoft Excel once exported from the system.
  • Page 524 Appendix F: User Data Logs configured to monitor the left engine, the data log exported from the left display contains the data log for the left engine (only). It is recommended to use a separate USB flash drive per engine to prevent the possibility of overwriting data logs.

  • Page 525: 27. Appendix G: Kavlico Pressure Sensor Part Numbers

    27. Appendix G: Kavlico Pressure Sensor Part Numbers Dynon Avionics Technical Advisory 120214 – Kavlico Pressure Sensors Prior to installing Kavlico sensors, reference Dynon Avionics Technical Advisory 120214 – Kavlico Pressure Sensors – http://dynonavionics.com/docs/support_bulletins.html important information. Kavlico pressure sensors sold by Dynon Avionics for fuel and oil pressure monitoring are externally physically identical and can be distinguished only by the Kavlico P/N stamped on the side.

  • Page 527: 28. Appendix H: Sensor Debug Data

    28. Appendix H: Sensor Debug Data If you have installed one, or dual SV-EMS-220/221s, SkyView can display the “raw data” from all connected and configured engine sensors to assist in troubleshooting engine sensor issues: SETUP MENU > EMS SETUP > SENSOR DEBUG DATA. Figure 229 –...
  • Page 528 Appendix H: Sensor Debug Data o C25 (Connector, 25-pin) – the 25-pin connector on the SV-EMS-220/221. o Px refers to an individual pin on the 37-pin or the 25-pin connector. o Px/x refers to a pair of pins used for thermocouples (CHT/EGTs) on the 37-pin or the 25-pin connector.
  • Page 529 Appendix H: Sensor Debug Data Similarly, as Pin 14, in Figure 229 above, the displayed RAW value is shown as “5AD” (not 00000000). This value is displayed as a hexadecimal number (Base 16), and increments by 1 for each pulse. Succeeding pulses would change this value to 5AE, then 5AF, then 5B0, etc. If the engine is on (fuel is flowing from the engine back to the tank), the RAW value should be incrementing.
  • Page 530 Appendix H: Sensor Debug Data 0diff: VALUE should be near 0.4. This only affects thermocouples. ColdJ: Cold junction, which is the temp of the EMS box. VALUE should be the temp of the EMS box in degrees F. This only affects thermocouples. 28-4 SkyView System Installation Guide - Revision AA...

  • Page 531: 29. Appendix I: Skyview System Installation Guide Revision History

    29. Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description  Initial release of this document  Document number 101320-000 December, 2009  SkyView Software v1.0  118 pages  Document number changed to 101320-001.  Software changes in SkyView Software v1.5: Added: A basic moving map displaying aviation data within the United States.
  • Page 532 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description  SV-EMS-220 Installation and Configuration Section Updates: Clarified the theory behind and the use of EMS sensor definition and configuration files in SkyView. Added a section regarding SV-EMS-220 wire harnesses. Added example engine sensor and transducer installations.
  • Page 533 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description Improved: More robust failure handling on SkyView network. Should module(s) or screen(s) fails, the remaining available devices will continue working normally with no action or setup steps required. This also means that unlike in the D10/D100 series, SkyView systems have no specific “master”...
  • Page 534 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description  Software changes in SkyView Software v2.6 (continued – see Rev E)  Clarified that cable-side transponder TNC connector is not provided by Dynon Avionics.  Added SV-BAT-320 connection information for customers making their own harnesses. ...
  • Page 535 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description Added: EMS serial output stream capability. Added: Option to disable flight path marker. Added: Option to disable extreme pitch warning indication chevrons. Added: Software version now listed in LOCAL SCREEN SETUP > SCREEN HARDWARE INFORMATION.
  • Page 536 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description Hardware Support Change Only: Maintenance release to support internal hardware change. There are no bug fixes, feature additions, or documentation changes for this release from 3.2.0.  Added angle of attack menu item. ...
  • Page 537 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description  Software changes in SkyView Software v3.3.2 released April 12, 2012 (no documentation changes): Fixed: Critical bug that could result in a frozen display when Skyview-based navigation (either direct-to or flight plan based) is being used. Fixed: Erroneous TIS traffic dropout annunciation.
  • Page 538 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description No feature changes: Support for minor change in SkyView hardware in displays shipped in 9/2012. Customers that have 4.0 do not need to install 4.0.1 unless advised by Dynon Avionics Technical Support. ...
  • Page 539 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description Improved: Fuel quantity gauges can now use arc, bar, and contact widget styles Improved: Engine gauge widgets can now be set to the lower of zero or the lowest possible value defined via the sensor definition file (.sfg).
  • Page 540 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description New: Simplified Autopilot Controls - great for VFR pilots that are looking to reduce the complexity of the Autopilot and cruise in comfort without a steep learning curve. With these controls, there are fundamentally two autopilot modes, each activated by a single button.
  • Page 541 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description Improved: Boot reliability on displays that sometimes booted to a "...contact Dynon Avionics..." or other similar message on the Dynon Avionics logo boot/splash screen. Changed: Default MIC GAIN setting for COM radio is now 50%. Fixed: Flight Director now commands the correct pitch when FLIGHT ANGLE PITCH ADJUST setting is non-zero Fixed: Displays reliably turn on using button 1 after it had been previously...
  • Page 542 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description Improved: Center-click of joystick knobs now supported in the PFD function menu as well as the MAP. Center click can now be used to pull up, set, and sync (by holding) the PFD joystick functions menus (bugs, baro, CRS, etc.).
  • Page 543 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description New: SkyView can switch its HSI Source when an external IFR NAV+GPS navigator such as the Garmin GNS (430 and similar) or GTN series direct it to. Configure under SYSTEM SETUP > ARINC-429 > ALLOW AUTO SWITCH. Note that when this is enabled, the external navigator’s CDI/source select feature must be used to switch between the GPS/NAV sides of the device, even manually.
  • Page 544 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description Added: Pre-upgrade settings files are now saved to a subdirectory on the USB memory stick to aid technical support troubleshooting. Added: Tail numbers for ADS-B equipped traffic will be shown below traffic targets when available.
  • Page 545 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description Fixed: Displays without backup batteries would not always automatically restart if their input voltage dropped below 10V (for example, during engine crank.)  First revision of the SkyView System Installation Guide that is electronic-only, included on USB flash drives packages with SkyView displays, and posted to Dynon Avionics website.
  • Page 546 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description New: Support for Video Input Adapter. Allows display of video via NTSC and PAL S-video and composite connections. Note: Only compatible with SkyView Touch and newer SkyView SV-D1000 (s/n >= 6000) and SV-D700 (s/n >= 4000) displays.
  • Page 547 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description Improved: Alert that annunciates if there is no high-res terrain available for the current aircraft location (usually because a different world region is loaded). Improved: Distance and speed units settings are now separately set. Improved: Fuel efficiency can now be displayed in L/100km.
  • Page 548 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description Fixed: If dual ADAHRS installed, during magnetic calibration and one ADAHRS fails, a message appears denoting which unit failed the calibration.  Software changes in SkyView Software v11.1 released October, 2014 (no documentation changes): Fixed: Some TFRs received via ADS-B were not being displayed.
  • Page 549 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description Added explanation that SkyView can be powered on during engine start (Page 2-5) Recommendation to install Panel Mount USB cable with each SkyView display (Page 2-6) Serial port connection and configuration information for Emergency Location Transmitter (ELT) (Page 4-20) External Dim Control Connections (Page 4-20) SV-ADAHRS-200/201 must be installed level or the Slip/Skid Ball will not be...
  • Page 550 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description New: In-air magnetic calibration routine: Pilots can now perform an optional in-flight magnetic heading calibration routine in addition to the existing ground-based calibration. This is likely to improve magnetic heading performance during flight maneuvers.
  • Page 551 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description Improved: When a GTN or GNS series ARINC navigator is in GPS OBS mode, the selected inbound course to the waypoint being navigated to is depicted on SkyView's map when that navigator's flight plan is the displayed map. Improved: Display auto-dimming improved to improve behavior during light changes such as when a flashlight is used at night.
  • Page 552 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description Corrected Pin 18 of SV-EMS-220/221 in Table 74, page 22-10) and Table 75 (Page 22-11), incorrectly stated 500 mA output; corrected to 300 mA output. Updated User datalog filename explanation, page 25-3 Updated Kavlico Pressure Sensor P/Ns reference, page 26-1 Updated mentions of SV-EMS-220/221 Pin 18 fuse;...
  • Page 553 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description Updated Table 73 – SV-COM-C25 Specifications, page 22-6 Updated format of V if the signal is in volts (contact input), page 25-11 Updated Appendix B: Specifications Changed references to “backup settings file” to “EXPORT SETTINGS file” ...
  • Page 554 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description servos but does not activate control wheel steering mode. Pressing/holding the disengage switch when the AP servos are active still activates control wheel steering mode. Improved: Com frequency order for PocketFMS digital aviation data improved to preserve the native order as provided by PocketFMS.
  • Page 555 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description Rotax 912 iS Throttle Position widget, including cold start assistance – page 7-29 Rotax 912 iS Power/ECO mode widget – page 7-29 GRT CS-02 Hall Effect Current Sensor is now supported – page 7-54 and page 7-55 Responsiveness of fuel level display can now be selected –...
  • Page 556 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description TRANSPONDER SETUP > FAA FAR 91.227 COMPLIANCE STATUS page updated for SV-GPS-2020 usage. Hex codes for US registered aircraft with “N”-prefixed registrations are now computed automatically. When all position sources are lost, map page is still viewable. The displayed state of map layers such as enroute charts (sectionals, IFR Lo/Hi) and terrain now remembered across power cycles and USB stick removal/reinsertion.
  • Page 557 Appendix I: SkyView System Installation Guide Revision History Revision Revision Date Description Improved: Automatic detection and restart for issues that would previously cause SkyView displays to become unresponsive. This will also generate a SYSTEM EVENT that will ask the user to export a Dynon Diagnostic Log. Added: New SYSTEM EVENT alerts that let SkyView detect additional software anomalies.
  • Page 558 496 pages  Document number changed to 101320-023, Revision X  Document name changed to SkyView and SkyView SE System Installation Guide  Software changes in SkyView Software v14.1, released 2016-03-29. Added: SYSTEM EVENT alerts that enabled SkyView detect additional software anomalies.
  • Page 559 Added caution to only have one SkyView display powered on during transponder Software update (Page 11-28) Added Cleaning a SkyView / SkyView SE Display (Page 21-1) Added Table 79 – SV-BAT-320 Specifications (Page 22-4) Added Table 87 – SV-GPS-250 Specifications (Page 22-14) Added Table 88 –...

  • Page 561: 30. Appendix J: Checklists

    30. Appendix J: Checklists Checklists are not supported in SkyView SE. Although a checklist file can be loaded into a SkyView SE system, SkyView SE cannot display a Checklist. Personalized Checklists can be displayed in SkyView as of Software v14.0: TOOLS > CHECKLIST.

  • Page 562: Saving Your Checklist With "Utf-8 Character Encoding

    Appendix J: Checklists files to be grouped together and all Checklists easily seen on your USB flash drive when you are loading the Checklist into your SkyView display. Although you can use mixed case in the Checklist filename, when selecting and loading your Checklist file onto SkyView, the Checklist filename will be displayed in UPPERCASE.
  • Page 563 Appendix J: Checklists Then, follow steps 13-18 as illustrated in Figure 234 at right (step 12 and step 19 not shown): 12. On the TextEdit menu bar, click File, then Save. 13. Fill in Save As: with your checklist filename. 14.

  • Page 564: Example Checklist

    Appendix J: Checklists such as a one Checklist file for the Pilot’s SkyView display and another Checklist file for the Co- Pilot’s SkyView displays. If you desire to do so, create Checklist items for Pilot and Co-Pilot in a single Checklist and then work from different sections of that Checklist. After you load a Checklist, it is stored in your SkyView display(s) non-volatile memory.

  • Page 565: Example Checklist Formatting Notes

    Appendix J: Checklists CHKLST4.TITLE, RUN-UP & PRE-TAKEOFF CHKLST4.LINE1, CHKLST4.LINE2, BUILD YOUR CHECKLIST HERE # … CHKLST21.TITLE, MISC: TRANSPONDER CODES CHKLST21.LINE1, CHKLST21.LINE2, VFR - 1200 (USA) CHKLST21.LINE3, VFR - 7000 (Europe) CHKLST21.LINE4, Hijack – 7500 CHKLST21.LINE5, Radio Fail – 7600 CHKLST21.LINE6, Emergency - 7700 Example Checklist Formatting Notes: Comment lines (not displayed as a Checklist item) begin with #.

  • Page 566: Excel Checklist Generation Tool

    Appendix J: Checklists # LINES ARE 40 CHARACTERS LONG ON A SKYVIEW 50 PERCENT PAGE # LINES WITH MORE CHARACTERS THAN ABOVE ARE NOT WRAPPED AND WILL NOT SHOW CHKLST0.TITLE, 1234567890123456789012345678901234567890 CHKLST0.LINE1, 1234567890123456789012345678901234567890 If you wish to keep track of the version of Checklist that you develop, this is easily done by making the title of your last Checklist a version number (with no Checklist items), such as: CHKLST23.TITLE, CHECKLIST INFO CHKLST23.LINE1,...
  • Page 567 Appendix J: Checklists Figure 234 – Checklist File Loaded Successfully If your Checklist file had a formatting or other error, you will see the following screen: Figure 235 – Checklist File Has an Error, Line Number Displayed, Could Not Be Loaded In SkyView Software v14.1, if a checklist file being loaded has an error, the line number(s) of the checklist file with the error is listed.
  • Page 568 Appendix J: Checklists Once loaded onto one SkyView display, a Checklist is synchronized to all other SkyView displays and the Checklist can be displayed on any, or all, of the SkyView displays. Troubleshooting Your Checklist File Ensure that your SkyView system has been updated to Software v14.0 (or later); support for Checklists was added in Software v14.0.

  • Page 569: Displaying Your Checklist On Your Skyview Display

    Appendix J: Checklists home, so this is best done using a laptop computer in the aircraft, so you can edit, export, and test rapidly on your SkyView display. Once a Checklist is loaded, there is no way to delete the current Checklist. The closest thing to a “delete Checklists”...
  • Page 570 Appendix J: Checklists Figure 236 – List of Checklists Available Figure 237 – Example PRE-FLIGHT Checklist The Checklist will continue to be displayed until the CHECKLIST button is pressed again (the CHECKLIST button “toggles” the display of your Checklist On and Off). 30-10 SkyView System Installation Guide - Revision AA...

  • Page 571: 31. Appendix K: Switches, Etc. External To Skyview Units

    31. Appendix K: Switches, etc. External to SkyView Units Some SkyView units provide inputs or outputs for switches, other controls, indicators, etc. that are installed external to the SkyView unit. Some of these are required (such as Servo Disconnect / CWS), while others provide optional, additional functionality. Table 130 below provides a comprehensive listing of all external switches, etc.
  • Page 572 Open (PBNO) connect to EXTERNAL Ground. SV-D600 GO AROUND Orange/Red External GO AROUND button SV-D700 Button is not supported in SV-D900 SkyView SE. SV-D1000 SV-BUTTON- Push Button Normally SV-D1000T LEVEL (LEVEL Orange/Black Open (PBNO) connect to Button) Ground. For easy access to USB...
  • Page 573 Appendix K: Switches, etc. External to SkyView Units SkyView Unit Function Wire Color Notes Number mount USB extension cable(s) SV-EMS-220 EMS Warning Yellow/Green Indicator SV-EMS-221 Indicator Copilot Push To Push Button Normally Talk (PTT) Open (PBNO) Wiring Copilot Diagram Headset jacks (pair) Headset jacks Stereo 3.5mm jack or Music In Jack...

This manual is also suitable for:

Skyview hdxSkyview classicSkyview touch

Table of Contents

Save PDF
