- Page 1 EMS-D10 Installation Guide This product is not approved for installation in type certificated aircraft P/N 100430-000, Revision I For use with firmware version 5.4 August, 2010 Copyright © 2003-2010 by Dynon Avionics, Inc.
-
Page 3: Contact Information
Contact Information Dynon Avionics, Inc. 19825 141 Place NE Woodinville, WA 98072 Phone: (425) 402-0433 - 7:00 AM – 5:00 PM (Pacific Time) Monday - Friday Fax: (425) 984-1751 Dynon Avionics offers online sales, extensive support, and continually-updated information on its products via its Internet sites: ... -
Page 5: Table Of Contents
Panel Location and Mounting............................ 4-8 EMS Configuration Full-Page Setup Menu Overview..........................5-1 Alarm and Color Threshold Configuration........................ 5-2 Global Parameters Setup ............................5-3 Engine Type Configuration ............................5-4 Fuel Level Calibration ............................... 5-5 Trim Calibration ................................ 5-6 Flaps Calibration ............................... 5-7 EMS-D10 Installation Guide... - Page 6 Network Concepts ..............................6-1 Example Networks ..............................6-2 Initial Setup ................................6-4 Network Status ................................6-4 Appendix Appendix A: Capacitance-to-Voltage Converter Installation..................7-1 Appendix B: Troubleshooting ........................... 7-2 Appendix C: Weights ..............................7-3 Appendix D: EMS-D10 Specifications........................7-4 EMS-D10 Installation Guide...
-
Page 7: Introduction
OEM Installations If your EMS-D10 is installed by an OEM distributor, you may find that you are unable to access some menus and settings. Some Dynon distributors customize various areas of the EMS-D10 firmware to maintain a consistent pilot experience and minimize integration issues across a large number of installations. -
Page 8: About This Guide
MORE, then pressing SETUP, and then pressing VRSION to enter the firmware version menu. Note that the MORE button is not shown in the sequence, since pressing MORE reveals more options in the same level of the menu system. EMS-D10 Installation Guide... -
Page 9: Wiring Overview
Please follow these instructions explicitly as improper wiring can result in permanent damage to your instrument and/or the accompanying sensors. All electrical power and data lines interface with the EMS-D10 via the male 37-pin D-Sub connector on the back of the unit. EGT (exhaust gas temperature) and CHT (cylinder head temperature) thermocouple inputs enter the unit via the female 25-pin D-Sub connector. -
Page 10: Grounding
More than one sensor’s ground may be connected to any of these three grounds using a splice. The case of the EMS-D10 is connected to its supply ground. If your panel is connected to aircraft ground, the connection between the instrument’s case and the panel dramatically helps minimize voltage differences between the instrument and sensor grounds. -
Page 11: Excitation
Please contact Dynon Avionics to order extension wire. Harness Mating The following diagram shows the 2 electrical connectors on the back of the EMS-D10. The main EMS harness (for all connections except EGT & CHT thermocouples) should terminate in a 37- pin female D-sub connector. -
Page 12: 37-Pin Female Ems Harness
Wiring Overview 37-Pin Female EMS Harness Below is the wiring diagram of the EMS 37-pin female harness. Refer to the following page for detailed pin out descriptions. EMS-D10 Installation Guide... - Page 13 Fuel pressure Page 3-7 Brown/blue Contact 1 Page 3-18 Brown/yellow Contact 2 Page 3-18 Orange EMS-D10 Transmit / PC Serial Receive Page 4-2 (RS-232) Yellow EMS-D10 Receive / PC Serial Transmit Page 4-2 (RS-232) Black Ground (Fuel Flow) Page 3-9...
-
Page 14: 25-Pin Male Ems Harness
Inside the outer insulations, each wire in the pair has the color listed on the diagram below. If you are making your own harness, utilize J & K type thermocouple wire as indicated in the diagram. EMS-D10 Installation Guide... -
Page 15: Transducer Installation
Weather Pack crimp tool (common slip joint pliers will also work) o Available from www.whiteproducts.com/tools.shtml #2 Phillips screwdriver Flathead screwdriver ¼” ID tubes, any necessary adapters, and clamps for routing manifold pressure to the sensor. Drill and 1/8” bit EMS-D10 Installation Guide... -
Page 16: Exhaust Gas Temperature (Egt) Probes
Have a knowledgeable mechanic inspect the installation. The probe can come lose during flight, and could potentially come in contact with rotating engine parts or the propeller. We suggest a safety wire to keep the probe in place. EMS-D10 Installation Guide... -
Page 17: Cylinder Head Temperature (Cht) Probes
Rotax 912 engines use 2 resistive CHT probes that are included with the engine. These probes are preinstalled, but you need to route the connections from them to the EMS-D10. See the Rotax CHT Sensors section on page 3-15 for information on making the physical connection to the sensor. -
Page 18: Tachometer
P-leads to the RPM Left and RPM Right inputs on the EMS-D10. Connect them as shown in the diagram. It is important to connect each resistor as close as possible to the spot where you tap into the P-lead. This minimizes the length of cable carrying high voltage spikes. -
Page 19: Manifold Pressure Sensor
RPM Left input on the EMS-D10. DIGITAL IGNITION AND OTHER PICKOFFS The EMS-D10 can read frequency-based RPM signals, provided the peak voltage is at least 10 volts above ground. If the peak voltage exceeds 50 volts, use the included 30kΩ resistors as described in the P-lead Pickoff section above. -
Page 20: Oil Pressure Sensor
Transducer Installation Oil Pressure Sensor The EMS-D10 supports several oil pressure sensor installations. The Dynon-supplied sensor and the Rotax and Jabiru pre-installed sensors are the most common. DYNON-SUPPLIED OIL PRESSURE SENSOR First, mount the oil pressure sensor to a fixed location... -
Page 21: Oil Temperature Sensor
37-pin harness. Crimp another ¼” female Faston onto the brown wire from pin 8. Push the 1/8-27 NPT 1/8-27 NPT two Fastons onto the two terminals on the fuel 0-30 PSI 0-80 PSI pressure sensor. Polarity is not important. If you EMS-D10 Installation Guide... - Page 22 Due to vibration issues, never connect the sensor directly to engine. If you use Teflon tape or other seal, ensure the sensor casing still maintains a good connection to ground. EMS-D10 Installation Guide...
-
Page 23: Fuel Flow Sensor
The inlet port, outlet port, and flow direction are marked on the top of the FT-60. ROTAX PLACEMENT RECOMMENDATIONS If installing on a Rotax 912, review the following page for recommendations specific to these engines. EMS-D10 Installation Guide... - Page 24 Transducer Installation 3-10 EMS-D10 Installation Guide...
-
Page 25: Fuel Level Sensor
RESISTIVE FUEL LEVEL SENSOR You may connect up to four resistive fuel level sensors to the EMS-D10. Simply connect the output of the sensor you would like to be Fuel Level 1 (left tank) to pin 20 and the sensor you would like to be Fuel Level 2 (right tank) to pin 21. -
Page 26: Ammeter Shunt
There are two methods for accomplishing this. You may simply connect two 1 amp fuses in-line between the shunt and the EMS-D10. Or, you may use butt splices to connect 1” to 2” sections of 26 AWG wire between the shunt and each of the Amps leads connecting to the EMS-D10. These fusible links are a simple and cost-effective way to protect against short-circuits. -
Page 27: General Purpose Inputs
B, closest to the alternator. If you find that the current reading on the EMS-D10 is the opposite polarity of what you want, swap the two signal inputs (Amps High and Amps Low) to obtain the desired result. - Page 28 Connect the other black/white wire on the OAT probe to the desired GP input on the EMS-D10 main harness. Again, if using the EFIS 3-wire OAT simply route either the yellow or blue wire (whichever did not get routed to ground) to the desired GP input.
- Page 29 CHT sensor to pin 4. Repeat this with the right CHT sensor. Be sure to configure the EMS-D10 to recognize the Rotax CHT sensors on the 2 general-purpose inputs as described in the General Purpose Inputs section on page 5-16.
- Page 30 Connect the ground input on the sensor to a ground common to the EMS-D10. Connect the output of the sensor to the desired GP input. You may connect up to three trim/flap sensors. For physical installation, refer to the instructions that came with your position sensor.
- Page 31 (Dynon P/N 100446-000) included Color Function with the EMS-D10. You will be using one of these Desired See chart resistors for proper installation of your coolant temperature on page 3- sensor.
-
Page 32: Contacts
(connection to ground). You may connect up to two contacts you would like to be monitored by the EMS-D10. You must ensure that when closed, the contact connects to a ground common to the EMS-D10. The voltage on the contact inputs must not exceed 15V. -
Page 33: Instrument Installation
Dynon employees and customers at wiki.dynonavionics.com. The EMS-D10 has one RS-232 serial port that can be used for several purposes. This serial port can only be configured for one purpose at a time. This serial port is used for: ... -
Page 34: Sl30 And/Or Gps Connection
If you do not have a serial port on your PC, you may use a USB-to-Serial adapter to connect the EMS-D10 to your PC’s USB port. You may purchase an adapter from us, Radio Shack, or many computer stores. If you are using Windows 2000 or XP, ensure that the adapter driver CD is inserted in your PC before plugging the adapter into the USB port for the first time. - Page 35 (Apollo) GNS Dynon product firmware, UNITS/MAGVAR option, set the MAGVAR to but untested. Requires AUTO. The EMS-D10 auto-detects most GPSs, manual configuration. See but may require a manual setting for some. This note at left. Fully is true for communication with at least the...
- Page 36 You will need a way to disconnect both lines when you plug your EFIS into a PC for firmware updates and checklists. IF YOU OWN ONLY AN EMS-D10 OR EMS-D120 We recommend that you only connect a GPS to an EMS-only system; without the magnetic heading from an EFIS, the HSI page will not be functional.
-
Page 37: External Ems Warning Light
Connect one of the lamp’s leads to your plane’s power. Connect the other lead to pin 29 on the EMS-D10 37-pin wiring harness. During an alarm condition, this pin is connected to ground, causing current to flow through the lamp. - Page 38 Outside terminal To ground To set the volume of the engine alarms, you will need your EMS-D10 powered on and the alarm output wired as described above. Enter the EMS menu by pressing any button beneath an EMS main page. Press MORE > SETUP > GLOBAL. Press DOWN▼ to select ALARM CONFIG and press SEL.
-
Page 39: Dynon Smart Avionics Bus (Dsab) Wiring
Wherever possible, ensure that the two DSAB wires (DSAB A and B) are run as a twisted pair. This minimizes the system’s susceptibility to electrical noise. Refer to the DSAB Configuration chapter on page 6-1 for detailed instructions on configuring your DSAB network. EMS-D10 Installation Guide... -
Page 40: Panel Location And Mounting
Installation of the EMS-D10 main unit should on ly be completed once all other physical and electrical installations have been performed. This will ensure that last-minute adjustments will not have to be made with the EMS-D10 mounted in the panel. EMS-D10 Installation Guide... - Page 41 EMS-D10 into place in the panel, putting the washers in between the EMS-D10 and the panel. Place one of the 4 supplied mounting nuts on the end of each of the 4 studs protruding from the back of the panel. Secure the nuts tightly against the panel to complete the installation.
-
Page 43: Ems Configuration
INC+ and DEC- buttons will appear. Press INC+ to increase the value and DEC- to decrease it. The EMS-D10 comes with most displays defaulted to ON. If you have not installed a given sensor or have reason to not display it, set the DISPLAY parameter to OFF. -
Page 44: Alarm And Color Threshold Configuration
HI RED/YEL parameter beyond 6.8 until you increased the TOP RED parameter. Likewise, you would not be able decrement the HI RED/YEL value below 6.2 until you decrease the HI YEL/GRN parameter. EMS-D10 Installation Guide... -
Page 45: Global Parameters Setup
SEL► until the number shown reflects the number of fuel tanks included on the aircraft. If you need to adjust the Hobbs time on the EMS-D10 to match that of your engine, press DOWN▼ to select the item, SET HOBBS Split display TIME. -
Page 46: Engine Type Configuration
EMS Configuration If you need to adjust the tachometer time on the EMS-D10 to match that of your engine, press DOWN▼ to select the item, SET TACH TIME. Press SEL► to enter the tachometer time setting submenu. Press SEL► to select the desired digit and then DOWN▼ or UP▲ to change the value. -
Page 47: Fuel Level Calibration
266-280ºF in RED ENGINE TYPE: OTHER For all other engine types, select OTHER. Currently, the EMS-D10 calculates percent power only for normally-aspirated Lycoming or Continental engines. Dynon Avionics will consider adding more engine types to our percent power calculations. If your engine is not currently supported and you would like to see it considered for possible inclusion, please send your engine’s power chart to: betatest@dynonavionics.com. -
Page 48: Trim Calibration
START. Follow the on-screen instructions until the completion of your fuel calibration. At the completion of your fuel level calibration, the EMS-D10 will present you with a table of values in the format “[pour #]: [mV] [gallons]”. Ensure that the mV values (just after the colon) change throughout the range of pours. -
Page 49: Flaps Calibration
If the number does not change, the flaps sensor may be incorrectly wired to the EMS-D10, or incorrectly configured in the GP input selection under the SENSOR menu. At any point in the process, you may press CANCEL to end the calibration without overwriting the previous calibration results. -
Page 50: Tachometer
EMS-D10 will automatically ignore this unused input. Next, enter your normal cruise RPM. This is used when computing Tach Time on the TIMES page. See the EMS-D10 Pilot’s User Guide for more information. Manifold Pressure If the manifold pressure transducer has been installed, set... -
Page 51: Oil Pressure
Dynon P/N 100409-000 the DISPLAY parameter to ON, otherwise, GRT FT-LC-01 set it to OFF. Change the SENSOR TYPE to Rotax pre-installed the correct number using the sensor type table. Jabiru pre-installed Chevrolet LS7 pre-installed EMS-D10 Installation Guide... -
Page 52: Exhaust Gas Temperature (Egt)
SPN alert. If you have configured the ALARM setting to either SELF-CLEAR or LATCHING, the SPN alarm will be red and will be accompanied by an alarm bar. If you have configured ALARM to be OFF, the SPN alarm will be yellow. 5-10 EMS-D10 Installation Guide... -
Page 53: Cylinder Head Temperature (Cht)
SPN alert. If you have configured the ALARM setting to either SELF-CLEAR or LATCHING, the SPN alarm will be red and will be accompanied by an alarm bar. If you have configured ALARM to be OFF, the SPN alarm will be yellow. EMS-D10 Installation Guide 5-11... - Page 54 SHK alert. If you have configured the ALARM setting to either SELF-CLEAR or LATCHING, the SHK alarm will be red and will be accompanied by an alarm bar. If you have configured ALARM to be OFF, the SHK alarm will be yellow. 5-12 EMS-D10 Installation Guide...
-
Page 55: Fuel Level
(carbureted) Alarm and Color Threshold Configuration on Dynon P/N 100411-001 page 5-2. Change the SENSOR TYPE to the (injected) correct number using the sensor type table. GRT LPS-02 (remove the external pull-up resistor) EMS-D10 Installation Guide 5-13... -
Page 56: Fuel Flow
FUEL PRESSURE menu. Fuel flow can also be displayed as an info bar, as described in the EMS-D10 Pilot’s User Guide > Global Configuration Settings > Info Item Configuration section. Select the alarm mode and the analog bar thresholds as described in Alarm and Color Threshold Configuration on page 5-2. -
Page 57: Voltage
EMS Configuration Voltage The voltmeter info item reports the voltage that the EMS-D10 reads on its Master Power input (pin 1 on the EMS 37-pin connector). Because of this, there is no sensor to install or configure. Simply, select the alarm mode and the analog bar thresholds as described in Alarm and Color Threshold Configuration on page 5-2. -
Page 58: General Purpose Inputs
Configure the info item (bar, text, or flaps/trim) for each GP input to display in the desired location(s)s, as described in the EMS-D10 Pilot’s User Guide > Global Configuration Settings > Info Item Configuration section. - Page 59 Under the desired GP input number, set FUNCT to TRIM RUDR. There are no alarm thresholds or any other setting required for rudder trim. FLAP POSITION Under the desired GP input number, set FUNCT to FLAP POS. There are no alarm thresholds or any other setting required for flap position. EMS-D10 Installation Guide 5-17...
- Page 60 If desired, repeat this for LABEL 2. If you leave LABEL 2 with its default “----” value, the temperature units are displayed beneath the temperature bar’s label; otherwise, the value of LABEL 2 is displayed. 5-18 EMS-D10 Installation Guide...
-
Page 61: Contacts
INFO ITEM. Configure the contacts info item to display in the desired location(s), as described in the EMS-D10 Pilot’s User Guide > Global Configuration Settings > Info Item Configuration section. Press DOWN▼ to select the NAME field that you want to appear for CONTACT (1 or 2). -
Page 62: General Purpose Thermocouple
Color Threshold Configuration section on page 5-2. Type Configure the GP thermocouple info bar to display in the J Type Thermocouple desired location(s), as described in the EMS-D10 Pilot’s K Type Thermocouple User Guide > Global Configuration Settings > Info Item Configuration section. -
Page 63: Dsab Configuration
Master is not present, the Autopilot will not function. If the Bus Master is turned off or fails, all data sharing ceases, causing units to display internally-derived data only. When you first perform DSAB network configuration on an EFIS-based instrument, that device is automatically assigned EMS-D10 Installation Guide... -
Page 64: Example Networks
The second diagram depicts a system with an HS34 connected, demonstrating that all NAV and GPS devices must be connected to the HS34. Both diagrams discuss what devices can be assigned various roles and what happens when DSAB fails. EMS-D10 Installation Guide... - Page 65 DSAB Configuration EMS-D10 Installation Guide...
-
Page 66: Initial Setup
DSAB IDENT shown. If the instrument you wish to identify is the one which you are currently interacting with, the line changes to read THIS UNIT. Press DOWN▼ or UP▲ to scroll through each of the other instruments configured in your network. EMS-D10 Installation Guide... -
Page 67: Appendix
EMS pin out information when connecting this product to your EMS-D10. You must configure the fuel level sensor type on your EMS-D10 to capacitive sender before calibrating this product. Refer to the Fuel Level configuration section on page 5-11 for fuel level sender type configuration and page 5-5 for fuel level sender calibration. -
Page 68: Appendix B: Troubleshooting
Dynon representative, the issue cannot be resolved, we will provide you with an RMA number to use when shipping the EMS-D10 to us. If your unit is still under warranty, the repairs will be performed and the EMS-D10 will be returned promptly. If your warranty has expired, the Dynon representative will make arrangements with you and make you fully aware of the costs before proceeding with the repair. -
Page 69: Appendix C: Weights
The following are the weights of the EMS-D10 and associated Dynon-supplied sensors EMS-D10 ......................1 lb 4 oz (0.567 kg) Manifold pressure Sender ...................3 oz (0.09 kg) Oil pressure sender......................4 oz (0.11 kg) Fuel pressure sender....................4 oz (0.11 kg) -
Page 70: Appendix D: Ems-D10 Specifications
Appendix Appendix D: EMS-D10 Specifications Fits into standard 3 1/8” panel hole Mechanical Optional flush mount bracket available Operating -22° to 122° F (-30° to 50° C) Temperature Voltage: 10 - 30 Vdc Power Power: 8 watts typical; 10 watts maximum Wiring: DB25 female &...
