User Manual

Color video door phone CDV-43Q
• Thank you for purchasing COMMAX products.
• Thank you for purchasing COMMAX products.
• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
instructions to use a product exactly.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDV-43Q and is the answer not in the manual?

Questions and answers

Related Manuals for Commax CDV-43Q

Summary of Contents for Commax CDV-43Q

  • Page 1: User Manual

    User Manual Color video door phone CDV-43Q • Thank you for purchasing COMMAX products. • Thank you for purchasing COMMAX products. • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly.

  • Page 2: Table Of Contents

    Table of Contents 1. Warnings and Cautions................2 Part Names ...................3 Contents ....................3 Wiring and Connection Instructions............4 Installation ....................Operation ......................5 Specifications...................7 1. Warnings and caution Please follow the things described below in order to prevent any danger or property damage.

  • Page 3: Part Names

    Menu Button Select Button Up Button Down Volume Power Switch Wall bracket User Manual (1EA) Video Phone for monitor (1EA) (CDV-43Q) Talk Button & Power LED Door Release Button Monitor fixing Wall bracket mounting 4P Connector (2EA) screw (1EA) screw (4EA)

  • Page 4: Wiring And Connection Instructions

    4. Wiring and Connection Instructions ▷ Polarity of interphone connector ▷ Polarity of the camera connector 1. Red: Talk (Audio) 1. Red: Talk (Audio) 3. Yellow: Power (+12V) 3. Yellow: Power (+14V) 2. Blue: GND 2. Blue: GND 4. White: Video 4.

  • Page 5: Operation

    6. Operation 1. Visitor calls from entrance ① When a visitor presses CALL button at entrance, the chime melody rings and visitor image is shown on the screen. ② Press TALK button to talk with the visitor and you can open the door by pressing DOOR RELEASE button.
  • Page 6 •Products settings need the following 4 buttons on the right of product. * Start Menu / Exit : MENU button * Select and in-put : SELECT button * Move up / Move right : △(UP button) * Move down / Move left : ▽(DOWN button) 4-1.

  • Page 7: Specifications

    (2) SCREEN MODE : to set for screen ratio ① ZOOM: Zoon in(expansion) image maintaining actual ratio(4:3) is shown. (full of the screen) ② 4:3: Image of 4:3 ratio without expansion is shown.(This is actual ratio for camera) ③ WIDE: Full of the screen. Not actual ratio (4:3). Image is expanded according to LCD (WIDE LCD) ratio.
  • Page 8 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Busine ss Dept. Tel. : +82-31-7393-540~550 Fax. : +82-31-745 -2133 Web site : www.commax.com PM0743Q00011 Printed In Korea / 2016.07.104...
