UG-981 EVAL-AD5340DBZ User Guide
Power-Down Control
Click the blue progressive disclosure button on the POWER-
DOWN LOGIC block to access the selection box, which allows
the device to operate in normal mode or power-down mode. A
window opens that allows the user to click the Powerdown
option for the DAC, as shown in Figure 7. Click OK to write the
appropriate values to the AD5340.
Figure 7. Powerdown Config Window
Rev. 0 | Page 6 of 13
