1.3.2

The Back Panel

The router's back panel shows the connection ports, buttons and antennas. Refer to the following for detailed
instructions.
Item
Power
Power On/Off
USB 2.0
USB 3.0
Internet
Ethernet (1, 2, 3, 4)
Reset
Antennas

Requirements for Operation

1.4
To connect and use the router for Internet sharing, you must have the following:
• Broadband Internet Access Service (DSL/Cable/Ethernet).
One DSL/Cable Modem that has an RJ45 connector (which is not necessary if the router is connected directly to the
•
Ethernet).
• Computers with an active Ethernet Adapter and an Ethernet cable with RJ45 connectors.
• TCP/IP protocol on each computer.
Chapter 1 Get to Know About Your Router
For connecting the router to power socket via the provided power adapter.
The switch for the power. Press it to power on or off the router.
For connecting to a USB 2.0 storage device or a USB 2.0 printer.
It's on the right front corner of the router.
For connecting to a 3.0 USB storage device or a 3.0 USB printer. It is also compatible with
USB 2.0 devices.
In router mode, it's used for connecting to the DSL/cable Modem or Internet.
In repeater mode, it's used for connecting to Ethernet-enabled device, working the same as
the Ethernet port.
In access point mode, it's used for connecting to front router or Internet.
These ports (1, 2, 3, 4) connect the router to the local computer(s).
With the router powered on, use a pin to press and hold the Reset button until the Touch
P5 logo displays.
Used for wireless operation and data transmit. Upright them for the best Wi-Fi performance.
Description
7
