Bluetooth - Milkotester Master Pro Operating Instructions Manual

Milkotester Ltd
Ultrasonic milk analyzers
USB usage is the most popular way for PC connection for now. All
milk analyzers from the Master series have embedded USB port. It
operates at the same way as RS connector, but the difference is that the
USB has to be installed from the CD (supplied with each analyzer) and it
forms own COM PORT. For example, if your computer has not got RS
port, the USB will form COM 1. If there is RS on your computer, the USB
will form COM 2, if your computer has 10 communication ports, then the
USB connector will create COM 11 and etc.
●
Serial port bluetooth module (Slave)
● Bluetooth protocol: Bluetooth Specification v2.0+EDR
● Frequency: 2.4GHz ISM band
● Modulation: GFSK(Gaussian Frequency Shift Keying)
● Emission power: ≤4dBm, Class 2
● Sensitivity: ≤-84dBm at 0.1% BER
● Speed: Asynchronous: 2.1Mbps(Max) / 160 kbps, Synchronous:
1Mbps/1Mbps
● Security: Authentication and encryption
● Profiles: Bluetooth serial port
57
Operating Instructions Master Pro
