DTP T FB 332 and DTP T FB 232 • Setup Guide (Continued)
Step 3 — Make side panel connections under the adapter plates and set the
TP function switch
Power (see
A
figure 1
transmitter or receiver, as shown at right. Use the included tie-wrap to strap the cord to the
captive screw connector.
Connect an IEC power cord between the power supply and a 100-240 VAC, 50-60 Hz source.
NOTE: switch (
If the TP
If the switch is in HDBT, each unit requires its own power supply.
Remote RS-232 port — For serial RS-232 control, connect a host device or control system to
B
the 3.5 mm, 3-pole captive screw connector. The wiring and protocol are shown at right.
TP function switch —
C
If the receiving device is in the Extron DTP series, set this switch to DTP. The TP output
consists of HDMI with embedded audio, analog audio, RS-232 and IR, and remote power. The
transmitter and receiver can be powered by one 12 VDC power supply connected to either unit.
For an HDBaseT-enabled receiver type, set this switch to HDBT position. The TP output consists of HDMI with embedded audio plus
RS-232 and IR. The transmitter and receiver each requires its own 12 VDC power supply.
ATTENTION:
• Position this switch BEFORE connecting the appropriate device to the TP connector. Failure to comply can damage the
endpoint.
• Positionnez le sélecteur AVANT de connecter l'appareil approprié au connecteur TP. Ne pas respecter cette procédure
pourrait endommager le point de connexion.
Out port— Connect the Out (RJ-45) port to the DTP In port on the receiver. Extron recommends that you terminate both cable ends in
D
accordance with the following, at a minimum: TIA/EIA T 568B and 24 AWG, solid conductor, shielded cable with 400 MHz bandwidth.
ATTENTION:
• Do not connect this connector to a computer data or telecommunications network.
• Ne connectez pas ces port à des données informatiques ou à un réseau de télécommunications.
Signal LED indicator — Lights when the device is transmitting a video signal or a test pattern.
Link LED indicator — Lights when a valid link between a DTP or HDBT input and output is established.
Step 4 — Mount the unit in the floor box
Place the DTP T FB unit in the desired position in the floor box so that the side panel connectors face
a.
towards the opening of the floor box.
ATTENTION:
• Ensure there is enough space between the top panel connectors and the lid of the floor box so the lid fully closes.
• Assurez vous qu'il y ait assez d'espace entre les connecteurs du panneau supérieur et le couvercle du boîtier de sol afin
que celui-ci puisse se fermer entièrement.
Using the provided self-threading screws, secure the DTP T FB unit to the adapter plates (see figures 2 through 5).
b.
Ackermann GB3 (OBO Betterman) floor box
995242
DTP T FB Unit in an Ackermann GB3 (OBO Betterman) Floor Box
Figure 2.
2
on page 1) — Connect the included 12 VDC power supply to either unit,
) is in DTP, one power supply can power both units.
C
PO
12 V W ER
A M
AX R EM
R S- O TE
23
2
- +
G
R x
Tx
995241
Smooth
Ridges
SECTION A–A
A
Power Supply
Output Cord
3"
Tx Rx Gnd 16 (5 mm) MAX
RS-232 Device • 9600 Baud
• No parity
Pins:
12345678
Pin
1
2
3
4
5
6
7
8
TP Wires
NOTE:
For position 2, install
adapter plate 995242 to
one of the other adapter
plates.
Captive
Screw
Connector
3"
16 (5 mm) MAX
A
• 8 data bits
• 1 stop bit
TIA/EIA T
568B
Wire color
White-orange
Orange
White-green
Blue
White-blue
Green
White-brown
Brown
