3.3.3

Selected hit

The 'selected hit' function checks and displays the current ID code read is present in the
memory. This function is useful to identify a specific item in a large group of items. When this
function is OFF, the reader does not show anything. While it is ON, it shows the message "TAG
ID FOUND" when the tag read match the selected ID, or the selected tag ID to be found when
the tag ID does not match.
The following figure shows the selected hit function enabled:
In this case; the message "NO TAG SELECTED" appears. This means that you have to select
an ID code thanks to the 'browse memory' function (refer to chapter 3.2 for details). Therefore,
press the ENTER round button to enter the main menu, then press the RIGHT button to enter
the browse menu. Scroll through the ID codes list until you find the needed ID code. When
highlighted, press the ENTER button so that it is selected for the 'selected hit' function.
BROWSE MEMORY
0006
0007
0008
0009
0010
Thu 07.02.08 14:48:22
At this point you are ready to search the selected ID code in a large group of items. When you
read an ID code, which matches the selected one, the reader displays the message "TAG ID
FOUND!" and beeps three times.
R-PO7470 Manual – v. 1.1 – August 2008
PSK
Type
D004811B5E
NO TAG SELECTED
Thu 07.02.08 14:48:22
D005267DB7
D004811B5E
D002C2BE51
D0065BAFF5
D004811B5E
PSK
Type
D005267DB7
TAG ID FOUND!
Thu 07.02.08 14:48:22
85%
No ID code is selected
from the memory
PSK
Type
D004A11F42
D005267DB7
Thu 07.02.08 14:48:22
85%
85%
9
