2.2

Read a transponder

Place the R-PO7470 near the item to be read then press the START button to activate the
reading mode.
During reading mode; move the reader along the item to scan the transponder ID.
To stop the reading mode press the START button again.
The following figure shows the result of a successful reading session:
1. Transponder type
1. The transponder type for Industrial application is PSK and it is a Datamars transponder
2. Identity Code number.
The following figure shows the result of an unsuccessful reading session:
After a while the reading mode times out. The reader stops and shows the message "NO TAG
FOUND".
R-PO7470 Manual – v. 1.1 – August 2008
Reading mode
PSK
Type
D0060BAFF5
Thu 07.02.08 14:48:22
85%
2. ID code
6
