Managing the menu

3.1

Navigating the menu

Power up the reader by pressing the STRAT button (please refer to chapter 2.1).
Press the ENTER button which is the round button in the center of the arrows pad.
The display shows the following figure:
You can scroll through the menu by pressing the UP or DOWN buttons which are the arrows
around the central ENTER button. The arrows located on the right of the display means that this
menu contains a sub menu. In order to enter a sub menu you have to press the RIGHT arrow
button while it is highlighted.
Generally the ENTER round button is used to confirm the changes made through the
parameters of the menu. The START button is used to cancel the changes and go back to a
previous menu level to exit the main menu.
3.2

Browse memory

In the browse menu you will find the ID code stored in the memory of the reader.
The following figure shows the browse memory menu:
You can scroll through the ID codes by pressing the UP or DOWN buttons or skip a page by
pressing the LEFT or RIGHT arrow button. You can scroll quickly through the ID codes by
holding down one of the arrow buttons.
You can select an ID code by pressing the ENTER button while it is highlighted. This function
stores the corresponding ID code in the selected 'hit function' (please refer to chapter 3.3.3 for
more details).
You can exit the current menu by pressing the START button.
R-PO7470 Manual – v. 1.1 – August 2008
BROWSE MEMORY
0006 D005267DB7
0007 D004811B5E
0008 D002C2BE51
0009 D0065BAFF5
0010 D004811B5E
Thu 07.02.08 14:48:22
1. ID code highlighted
2. Time stamp of the
highlighted ID code
