9 Technical supplement – Console commands
9.1

Introduction

This chapter describes how to connect the R-PO7470 to a personal computer (PC). The R-PO7470
can be connected to a PC in two ways: the first is a wired USB connection, while the other is a wire
less Bluetooth connection (optional).
Moreover it describes the console commands implemented in the R-PO7470, in order to remotely
control the features and the functions of the reader.
9.2

How to connect the R-PO7470 to a PC through USB

Before physically connecting the R-PO7470 to the PC through the USB cable, you first have to install
the FTDI's virtual com port (VCP) driver. This driver is included in the R-PO7470 CD, or can be
downloaded from the following link:
http://www.ftdichip.com/Drivers/VCP.htm
An installation guide is also available at the following link:
http://www.ftdichip.com/Documents/InstallGuides.htm
Once the driver is installed and the R-PO7470 is connected to the PC through the USB cable you can
open a new HyperTerminal (for Windows) session.
In the R-PO7470's CD you can find a pre-programmed HyperTerminal session: copy it to the desktop
(or where you prefer) and run it. If you do not have the CD with pre-programmed HyperTerminal
session follow the next description.
To open a new HyperTerminal session, select the Start menu, then Programs, then Accessories, then
Communication and then lunch HyperTerminal. A dialog box appears, input a session name, (i.e. R-
PO7470), then press the ok button. Select the COM port assigned to the VCP driver (usually COM2).
Input the corresponding BAUD rate: check in the R-PO7470 menu, under set-up menu, which BAUD
rate is selected (default is 115200). Select the following options: data bits= 8, parity= none, stop bits=
1, Flow control=none. Press the ok button. At this point the connection starts, but the configuration is
not finished yet: stop the communication by selecting disconnect under the menu Call, then select
Properties under the menu File. A dialog box appears: select the Settings tab and press the ASCII
Setup button. A dialog box appears: select the Echo Typed Characters Locally features. Close the two
dialog box by pressing the ok button.
Now the HyperTerminal session is ready to start: select Call under the menu Call.
9.3

How to connect the R-PO7470 to a PC through BlueTooth

Please refer to the specific installation description.
9.4

Console commands description

All console commands begin by '.' or '?' while ending by clicking the return function ([CR]=13 dec).
The R-PO7470 answers with a bell character ([BEL]=7 dec) followed by line feed characters ([LF]=10
dec) if the command is wrong or not executable, while it answers with just a line feed [LF] when the
command is correct and executed. Some commands give an answer: the answer is formatted in the
following mode:
[CR][LF] "answer string" [CR][LF]
R-PO7470 Manual – v. 1.1 – August 2008 24
