Operation

Although the R-PO7470 has been designed to plug and play, we recommend you read this manual
carefully in order to take advantage of all its features and functions.
2.1

Power on the R-PO7470

Slide your hand between the base unit and the handle. Use your thumb to press the START
button which is located on the upper left corner of the panel.
The display shows the following start-up figure:
Under the Datamars logo you can see the name of the reader and the firmware version.
After a few seconds this main screen shot appears:
6. Bluetooth connection OK
5. Weekday Day
1. Check the battery level, which should read more than 6% vitality to read a transponder.
The battery level shows the discharge level as well as the charge level during charge mode.
2. While the reader is connected to the power net, in charge mode, the reader disables the
reading mode; therefore it is not possible to read a transponder. The other functionalities are
fully active.
3. Clock time is in 24 hour mode.
4. Date format can be selected between EURO/USA.
5. Clock weekday.
6. Bluetooth connection established and ready to use.
R-PO7470 Manual – v. 1.1 – August 2008
R-PO7470 V1.0
2. Connected to power net
4. Date
1. Battery level
3. Clock
