PRESETS

Through this menu, the user has full access to the entire set of presets, thus allowing fast switch
up between the FM and Internet radio stations.
When a preset is market with
appears, this means that some changes have been made to the preset and if you would like you
could save it as a new one or overwrite the existing.

HOW TO CREATE A PRESET

You can create up-to 10 presets. The number of FM or Internet radio preset is not limited. For
example, you can set 7 FM presets and 3 Internet radio presets, or 10 FM Radio presets, and etc.
There is no limitation as regards the possible configurations. A new preset could also be created via
the WEB Interface, for further information, please refer to
Please have in mind that if you would like a preset to be assigned to one of the four soft buttons
on the front panel menu, the preset should be set in positions 1 to 4, as these are the positions to be
used for quick access via the soft buttons.
The menu path for creating a new preset is Main menu> Tuner, then:
1. Input Select – Select the input – Internet Radio or FM Radio;
2. If FM Radio is chosen, select FM Radio and press the [OK] button to enter the menu.
Specify Frequency, RF Attenuator, Frequency Step, IF Bandwidth, De-emphasis, RDS
Mode, and if need be, change the default audio processing settings – Stereo Blend, High
Cut, High Blend and Soft Mute.
3. If Internet Radio is chosen, select Internet Radio and press the [OK] button to enter the
menu. Then, set the URL (press the [OK] button and navigate through the letters via the
[UP] and [DOWN] buttons), specify Decoder, Channels, Pre-buffer, Buffering timeout
and Gain adjust.
4. To save the newly added FM or Internet radio, go to Presets and choose one of the available
presets, or an old one and press the soft button labeled [Save]. If you choose to overwrite an
existing preset, the message below will appear. Press [OK] to save the preset.
NOTE:
The name of the preset cannot be user-defined as it is automatically generated by the
device. When FM radio preset is created, the name is composed of the frequency and the PS (if the
device has decoded RDS). For the Internet radio, as a title is used the station name received from
the broadcasted meta information.
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com
in front of it, this means that the preset is in use. If the
"Presets" on page
