Soft Mute

Reduces the level of the audio if the RF level is too low.
• Start Thresh – Property sets the RF Level threshold in dBµV to engage Soft Mute function
to audio output;
• End Thresh – Sets the RF Level threshold in dBµV at which soft mute attenuation will be
set to its maximum value, determined by "Max Atten" setting;
• Attack time – Sets the maximum time in ms it takes to mute the audio;
Release time – Sets the maximum time in ms it takes to unmute the audio;
•
Max Atten – sets the maximum attenuation in dB that will be applied by the soft mute
•
feature to the audio output.
The S.Mute Att bar-graph (placed on top of the page) is directly related to the settings in Soft
Mute section, and indicates the attenuation in dB that is currently applied by the soft mute
feature to the audio output.
The accurate RF bar-graph indicator shows the current value of the RF level.
