OLED DISPLAY

DB3010 has an easy to read, high-resolution OLED graphical display that visualizes all
measurements of the received signal and settings. Upon switching it on, the Company Logo and
model of the device will be displayed. After a few seconds the start-up screen will disappear,
replaced by the main screen. This is the starting point of the navigation process.
DB3010's OLED display has three function areas: header, soft buttons and main screen working
area.

HOW TO CHANGE DEVICE PARAMETERS

Set-up menu title

Shows the path to the currently selected menu. Note that the parameter should be included in
the settings menu title. For example: Setup> Communication> HTTP> Port is different from
Setup> Communication> FTP> Data Port.

Navigation area

Selection of branches / parameters is made in this area. The selected item is highlighted. All
parameters are listed on the left side of the navigational area. All parameter values are displayed
on the right side against the parameter name. As the branches have no values associated, tree dots
are shown instead. This indicates that a transition to a sub-menu is available.
Front panel buttons usage:
[OK] – Depending on the selected menu element can perform different actions:
• Menu branch – transition to selected sub-menu will be made;
• Menu parameter – when a name of a parameter is highlighted pressing [OK] will highlight
the value and switch to edit mode;
Menu complex parameter (such as Alarm) – the parameter editor screen will be shown.
•
[UP] / [DOWN] – If edit mode is active, the value of the selected parameter will be changed.
Otherwise, are used for navigation through the menu;
[LEFT] / [RIGHT] – Change the selection when the parameter value is in edit mode;
[SB4] – Return one level up or cancel edit mode.
