SOFT BUTTONS
Used for navigation through the menus, quick access to the parameters, modes, functions and to
alter their values. The soft buttons indicators are placed on the bottom side of the OLED display.
Depending on the currently selected menu context, the indicators change their function. The soft
buttons will be referred to as (left-to-right) [SB1], [SB2], [SB3] and [SB4]. The purpose of all soft
button corresponds to the selected menu page. Most pages have the same or similar functional
areas. The corresponding functions as Menu page, parameter to be changed, etc., linked with the
soft buttons will appear as labels above them. For example:
[SB1] – Home
[SB2] – About
[SB3] – Status
[SB4] – Back
NOTE:
On some pages, the header and soft button area will disappear in order to expose the
content underneath.
NAVIGATION BUTTONS
[UP], [DOWN], [LEFT], [RIGHT] and [OK] buttons are used to navigate through the menus,
for selecting various functions and parameters of DB3010. The main menu structure has an up-
and-down basis, expanded with left-to-right branches.
65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria
Tel: +359 56 820027, Fax: +359 56 836700
E-mail: office@devabroadcast.com ,Web: www.devabroadcast.com
- 25 -
