Panel Indicators, Switches and Connectors

DB3010 has easy to read, high-resolution OLED graphical display that visualizes all

measurements of the received signal and DB3010's settings.

The full-time LED meters allow quick and easy monitoring of the metering, making the setup,

adjustment and programming easy.

Used for navigation through the menus, quick access to the parameters, modes, functions and to

alter their values. The soft buttons indicators are placed on the bottom side of the OLED display.

Depending on the currently selected menu context the indicators change their function. The soft

buttons will be referred as (left-to-right) [SB1], [SB2], [SB3] and [SB4].

[UP], [DOWN], [LEFT], [RIGHT] and [OK] buttons, are used to navigate through the menus

selecting various functions and parameters of DB3010.
