Summary of Contents for Phonak CROSLink

  • Page 1 CROSLink ™ User Guide...
  • Page 2: Welcome

    It is easy to handle, very discreet, and fits to a vast range of behind-the-ear hearing instruments on the market. For maximum benefit, it is recommended that CROSLink is used in combination with Phonak hearing instruments. Please read this user guide carefully.
  • Page 3: Table Of Contents

    Welcome Instrument description How to wear Insert / Change batteries Switch on and go For experienced users (BiCROS) Readjust the CROSLink To adjust the volume of the CROSLink Important points Warning Declaration of conformity Service and warranty Phonak distributors worldwide...
  • Page 4: Instrument Description

    / audio shoe Switch = Off position: The signal from the ° CROSLink transmitter on the unaidable ear cannot be received. • Please consult your hearingcare • professional about the correct switch • position when using CROSLink with your hearing instrument.
  • Page 5: How To Wear

    How to wear The CROSLink transmitter (pictured) is worn on the unaidable ear. The tiny CROSLink receiver can be plugged into the hearing instrument worn on the better hearing ear by means of a 3-pin assembly. The receiver receives the speech signal coming from the CROSLink transmitter.
  • Page 6: Insert/Change Batteries

    Insert/Change batteries The CROSLink transmitter requires size 13 batteries. Operating time of a new battery: between 100 and 150 hours 1) Switch off the CROSLink instrument 2) Open the battery door 3) Remove the old battery...
  • Page 7 (flat side of the battery) is on the same side as the battery door 5) Gently shut the battery cover until you feel it “click” into place and switch on the instrument click The CROSLink receiver uses the battery from the hearing instrument.
  • Page 8: Switch On And Go

    Switch on and go 1) Switch the CROSLink transmitter on and wear it on the unaidable ear 2) Switch on the hearing instrument and set the CROSLink receiver to the setting recommended by the hearingcare professional: one dot position two dot position...
  • Page 9 3) Attach receiver to audioshoe 4) Attach audioshoe to hearing instrument 5) Attach the CROSLink receiver to the hearing instrument and wear it on the better ear. Ready!
  • Page 10: For Experienced Users (Bicros)

    For experienced users (BiCROS) Readjust the CROSLink To achieve a balanced sound quality from all directions proceed as follows: Step 1: Adjust the volume on the hearing instrument Wear the CROSLink system and switch on only the hearing instrument.
  • Page 11 1) Set the volume of the hearing instrument on the better ear as recommended by your hearingcare professional. 2) Use a radio as a sound source. 3) Sit on a chair at approximately 1 meter (3 feet) in front of the radio speaker. 4) Turn yourself slightly so that the sound is directed toward your better hearing ear.
  • Page 12 Readjust the CROSLink Step 2: Adjust the level of the CROSLink transmitter on the unaidable (poorer) ear Switch on the CROSLink transmitter and receiver and set the receiver to the setting recommended by the hearingcare professional.
  • Page 13 1) Turn yourself 180° to direct the radio loudspeaker sound toward the poorer ear. 2) Turn the volume control of the CROSLink transmitter to a comfortable level, trying to match the volume you experienced in Step 1. 3) Recheck the transmitter volume by turning yourself again 180°...
  • Page 14: To Adjust The Volume Of The Croslink

    For BiCROS use: • Adjust (balance) the loudness of the signal on your poorer side by increasing or decreasing the volume on your CROSLink transmitter. • Adjust the overall loudness by increasing or decreasing the volume on your hearing instrument.
  • Page 15: Important Points

    Important points • Do not use water or other fluids for cleaning. • Use only original Phonak accessories. • The CROSLink may only be repaired by an authorized service center. Warning Changes or modifications made to this equipment not expressly approved by Phonak may void the FCC...
  • Page 16: Declaration Of Conformity

    Declaration of conformity Phonak AG, Laubisrütistrasse 28, CH-8712 Stäfa, Switzerland confirms that the CROSLink conforms to EN 301-489-9, CFR47 part 15 subpart C and EN 300 330-1. FCC ID: KWCCTX Phonak AG Stäfa, Switzerland Date: June 22, 2004 This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada.
  • Page 17 radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver.
  • Page 18: Service And Warranty

    Please ask at the point of sale for full details of this warranty. The salesperson will note the serial number of your CROSLink below. It will be needed in the event of a warranty repair. Serial number CROSLink transmitter:...
  • Page 19: Phonak Distributors Worldwide

    Phonak France SA, 69500 Bron Germany Phonak GmbH, 70736 Fellbach-Oeffingen Italy Phonak Italia S.r.l., 20159 Milano Japan Phonak Japan Co., Ltd., Tokyo 101-0044 Jordan Phonak Middle East, 11181 Amman Netherlands Phonak B.V., 3439 ME Nieuwegein New Zealand Phonak New Zealand Ltd., Takapuna...
  • Page 20 This unit sold by: www.phonak.com...
