ID
Name
EXT-HDKVM-ELRR
1
Power
Link
2
Link
3
USB
4
Video
Receiver Unit
HD KVM ELR Extender over one CAT-5 R
®
Description
This LED glows solid blue when the unit is
connected to an AC outlet and the unit is
powered ON.
HDMI Out
Service
This LED glows solid blue when the Sender
unit and Receiver unit are connected and
passing video.
This LED indicator glows solid blue when
a USB device is connected to the Receiver
unit.
This LED indicator flashes blue when a
display is connected to the Receiver unit.
2 E
1
3
Link
Video
Power
USB
2
4
USB
5V DC
