Summary of Contents for Gefen EXT-HDMI1.3IR-FO-141
- Page 1 ® 1.3 Over Fiber with IR EXT-HDMI1.3IR-FO-141 User Manual www.gefen.com...
-
Page 2: Asking For Assistance
Chatsworth, CA 91311 www.gefentv.com support@gefen.com Gefen LLC reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. HDMI 1.3 Over Fiber with IR is a trademark of Gefen LLC ©... -
Page 3: Table Of Contents
Introduction Operation Notes Features / Package Includes Sender Panel Descriptions Receiver Panel Descriptions Connecting and Operating the HDMI 1.3 Over Fiber with IR Network Cable Wiring Diagram Specifi cations Warranty... -
Page 4: Introduction
HDMI 1.3 Over Fiber with IR The Gefen HDMI 1.3 Over Fiber with IR system extends Full 1080p HD deep color with multichannel digital audio over a single small strand of fi ber optic cable that can easily be hidden in a wall or above a ceiling. -
Page 5: Operation Notes
Use one SC terminated multi-mode fi ber optic cable and one industry standard CAT-5, CAT-5e or CAT-6 cables to operate the HDMI 1.3 Over Fiber with IR. Gefen recommends CAT-6 cabling for maximum performance. • For 1080p video, maximum extension is 1000 feet (330 meters). -
Page 6: Features / Package Includes
Features • Immune to electro-magnetic interference (EMI) • Transmits HDMI 1.3 audio/video at full bandwidth • 1000-foot (330m) extension distance, maximum • Delivers highest quality signal of any HDMI extension method • Supports video resolutions up to 1080p, 2K, and 1920 x 1200 •... -
Page 7: Front Panel
SENDER PANEL DESCRIPTIONS Front Panel HDMI Input RS-232 IR Blaster Input Output Port Power LED Indicator Back Panel SC Fiber RJ-45 Port 5V DC Power Input Optic Port... -
Page 8: Receiver Panel Descriptions
RECEIVER PANEL DESCRIPTIONS Front Panel HDMI IR Receiver Output RS-232 Power LED Output Indicator Back Panel SC Fiber 5V DC Power Input RJ-45 Port Optic Port... -
Page 9: Connecting And Operating The Hdmi 1.3 Over Fiber With Ir
CONNECTING AND OPERATING THE HDMI 1.3 Over Fiber with IR Connect the HDMI source to the HDMI 1.3 Over Fiber with IR sending unit’s HDMI input port using the supplied HDMI cable. Connect the RS-232 source to the HDMI 1.3 Over Fiber with IR sending unit’s RS-232 input port using the supplied DB-9 serial cable. -
Page 10: Network Cable Wiring Diagram
Gefen has specifi cally engineered their products to work with the TIA/EIA-568-B specifi cation. Please adhere to the table below when fi eld terminating cable for use with Gefen products. Failure to do so may produce unexpected results and reduced performance. -
Page 11: Specifi Cations
SPECIFICATIONS Video Amplifi er Bandwidth ... 340 MHz HDMI Input/Output Connector ... type A, 19 pin Link Connector ... SC Fiber Optic CAT5 Connector ... RJ45 Input Video Signal ... 1.2 Volts p-p Input DDC Signal ... 5 Volts p-p (TTL) Power Supply ... - Page 13 Rev X3 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefentv.com support@gefen.com...
