HYDRIM
®
C51w
• Operator's Manual
HYDRIM C51w Operator's Manual 95-109074 Rev 2.0.
www.scican.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HYDRIM C51w and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SciCan HYDRIM C51w

Summary of Contents for SciCan HYDRIM C51w

  • Page 1 HYDRIM ® C51w • Operator’s Manual HYDRIM C51w Operator’s Manual 95-109074 Rev 2.0. www.scican.com...

  • Page 2: Table Of Contents

    7. Warranty ......16 8. Hydrim C51w Specifications ..17...

  • Page 3: Introduction

    Contents of this manual are subject to change without notice to reflect changes and improvements to the Hydrim product. The Hydrim C51w should only be installed and serviced by a qualified contractor as it is an Installation Category 2 device. Before connecting the unit, the installer should check that the voltage and frequency of the electrical supply correspond with the details in the installation instructions.

  • Page 4: Important Information

    (button flush) potential hazard Hot Surface to the operator. The following symbols appear in this book. Caution, a potential Important information A situation which may lead hazard to the operator. to a mechanical failure. HYDRIM C51w Operator’s Manual Page 3...

  • Page 5: Disclaimers

    3. Disclaimers Do not permit any person other than authorized personnel to supply parts for, service or maintain your Hydrim C51w. SciCan shall not be liable for incidental, special or consequential damages caused by any maintenance or services performed on the...

  • Page 6: Instructions For Use

    NOTE: SciCan recommends that all hinged instruments be placed in open baskets in the Heavy Duty cycle. NOTE: If using the cannula post adapter, always use the Heavy Duty Cycle. When processing small or light objects in the Hydrim use the basket with lid (SciCan part number 01-108294). HYDRIM C51w Operator’s Manual...

  • Page 7: Cycle Description Chart

    Instruments with concave surfaces or cavities should be placed so that water can drain freely. The Hydrim C51w wash trolley can be configured in a number of different ways to accommodate a wide range of instruments. On the trolley you can insert open baskets, SysTM™...
  • Page 8 4. Instructions for Use cont’d. 1. Baskets Only A variety of baskets can be used in the Hydrim C51w. ® The Statim 2000 or Statim 5000 baskets and the basket with hinged lid require the support trolley center. The large basket requires the support rack (not shown).

  • Page 9: The Cannula Post

    (fig. 2c). There will be slight resistance. When it is secured in place, Figure 2b you will detect a slight click. Attaching the 5. To remove the cannula post, reverse the Cannula Post above procedure. Figure 2c HYDRIM C51w Operator’s Manual Page 8...

  • Page 10: Activating The Washer

    3. Press the door open button to open the door. 4. Remove the instruments from the washer. 5. Inspect the instruments for debris prior to packaging / sterilizing. Instruments may be HOT when cleaning cycles are complete. HYDRIM C51w Operator’s Manual Page 9...

  • Page 11: Maintenance

    5. Maintenance 5.1 Loading the Hydrim C51w Cleaning Solution The Hydrim C51w uses a 1.9 L / 0.5 U.S. gallon container of Hydrim C51w Cleaning Solution. Use only the recommended cleaning agent and be sure to read the caution instructions on each bottle before inserting into the unit.

  • Page 12: Scican

    (If streaks or water spots appear, turn the water hardness dial to a higher number.) Note: After refilling the salt container, always run a complete wash cycle with no instruments. ppm or mg / l 0-110 120-360 370 - 510 520 - 890 water hardness dial Figure 4 HYDRIM C51w Operator’s Manual Page 11...

  • Page 13: Using Rinse Aid

    5.3 Using Rinse Aid SciCan recommends using STAT-DRI™ Plus. STAT-DRI Plus can be purchased in a 230 ml / 8 U.S. fl. oz. refill or a 1 L / 34 U.S. fl. oz. refill. STAT-DRI Plus is available from your dealer or you can contact SciCan directly for order information.

  • Page 14: Cleaning The Hydrim C51W

    5. Maintenance cont’d. 5.4 Cleaning the Hydrim C51w To clean all outside surfaces, use a soft cloth moistened with soap and water only. Do not use harsh cleaning chemicals or disinfectants. 5.5 Filter and Wash Arm Maintenance Filter Maintenance: Inspect the coarse and fine filters daily for debris and clean if necessary.

  • Page 15: Troubleshooting

    • Instruments are not properly arranged in the unit. Wash cycles are taking too long to • The water is not hot. Contact your local SciCan complete. dealer. The Cleaning Solution level is not • Check for kink in tubing.

  • Page 16: Scican

    Error light flashes once. • The water is not heating to the wash cycle specifications. • Contact your SciCan Dealer if problem persists. Error light flashes twice. • The unit has failed to fill with water. • Contact your SciCan Dealer if problem persists.

  • Page 17: Warranty

    7. Warranty Limited Warranty For a period of one year, SciCan guarantees that the Hydrim C51w, when manufactured in new and unused condition, will not fail during normal service due to defects in material and workmanship that are not due to apparent abuse, misuse, or accident.

  • Page 18: Hydrim C51W Specifications

    Max. altitude: 2000m / 6561.7ft. Mains supply: + / -10% of nominal * If hot water temperature is less than 50˚C / 122˚F, and if the power line is 240V, allow 30 minutes between cycles. HYDRIM C51w Operator’s Manual Page 17...
