HYDRIM G4 Washer-Disinfector
Pre-Installation Instructions
To ensure the optimum performance of SciCan's washer-disinfector models it is imperative that the
correct services are made available and that the positioning of the unit does not compromise the
function of the unit in any way.
Prior to installation it is important that the site be inspected and all the appropriate conditions are met
to ensure the safe and efficient operation of the washer-disinfector.
Practice details and summary results.
Practice/Office location details
Customer Name:
Address:
Tel:
Signature:
Installer/Pre-installation inspector
Name:
Dealer details:
Tel:
Conditions approved/rejected for installation subject to checklist below (!/")
Name:
Signature:
Date:
On behalf of (Dealer):
1
SD-438 EU EN R5
Advertisement
Related Manuals for SciCan HYDRIM G4
Summary of Contents for SciCan HYDRIM G4
- Page 1 HYDRIM G4 Washer-Disinfector Pre-Installation Instructions To ensure the optimum performance of SciCan’s washer-disinfector models it is imperative that the correct services are made available and that the positioning of the unit does not compromise the function of the unit in any way.
