Warning
Do not connect these two power supplying sources to the device at the same
time; it may result in device damage!
Log function. Support system resource information and running status real-time
display.
Backlight compensation: screen auto split to realize backlight compensation to
adjust the bright.
Support video watermark function to avoid vicious video modification.
Assistant
Support picture parameter setup such as electronic shutter and gain setup.
Support motion detect function.
Function
Support dual-stream, ACF.
Built-in microphone and speaker (This function is optional. For some series
product only.).
Support PIR human body movement detect.
Support white light alarm function.
1.3 1.3 Specification 1.3 1.3 Specifications s s s Specification Specification

1.3.1 Performance

Please refer to the following sheet for product performance specification.
Parameter
Main Processor
OS
System
Resources
User Interface
System Status
Image Sensor
Pixel
Gain Control
White Balance
BLC
Exposure Mode
Video
Compression
Standard
Video
Rate
Video Bit Rate
！ ！ ！ ！
Model
IPC-KW10
High performance DSP
Embedded LINUX
Support real-time network monitor, local record, and remote operation
at the same time.
Remote operation interface such as WEB, DSS, PSS.
Bit stream statistics, log, and software version.
1/4-inch CMOS
1280(H)*720(V)
Fixed/Auto
Manual/Auto
On/Off
Manual/Auto
PAL: It ranges from 1/3 to 1/10000.
NTSC: It ranges from 1/4 to 1/10000.
H.264/H.264B/MJPEG
PAL:
Main stream(1280*720@25fps)
Frame extra stream(704*576@25fps)
NTSC:
Main stream(1280*720@30fps)
extra stream(704*480@30fps)
H.264: 16Kbps-8192Kbps
MJPEG is adjustable and bit rate is adjustable
Support customized setup.
IPC-KW10W IPC-KW12 IPC-KW12W
