Dimensions - Dahua IPC-KW10 User Manual

SN Port Name
4 IR light
5 Speaker
6 Microphone
7 Micro SD card
8 Network port
9 Power port
Reset/WPS
10
button
2.2 2.2 Dimension 2.2 2.2 Dimension Dimensions s s s Dimension
Please refer to the following figure for dimension information. The unit is mm. See Figure 2-2.
Indicator Connector
/ /
/ /
/ /
Micro
Micro SD
card slot
LAN Ethernet port
DC12V /
Reset/WPS
Figure 2-2 Dimension
Note
For lighting at night
Output audio signal.
(This function is optional. For some
series product only.)
Directly receive audio signal.
SD card storage.
SD
(This function is optional. For some
series product only.).
Connect to standard Ethernet cable.
Input DC 12V power.
When device works normally:
Press the WPS button of the
router and
respectively for at least 2
seconds. Usually the device
can connect to the router.
(Optional function supported by
some series)
Press the button for 10s,
device restores
settings.
the device
default
6
