- Page 1 ADP-3355 VGA Convert Module User’s Manual Edition 1.1 2016/11/22...
- Page 2 ADP-3355 User’s Manual Copyright Copyright 2014, all rights reserved. This document is copyrighted and all rights are reserved. The information in this document is subject to change without prior notice to make improvements to the products. This document contains proprietary information and protected by copyright. No part of this document may be reproduced, copied, or translated in any form or any means without prior written permission of the manufacturer.
-
Page 3: Packing List
ADP-3355 User’s Manual Packing List: Please check the package content before you starting using the board. 1 x ADP-3355 VGA Convert Module 1 x CN_DP Cable (OALDP2T-L12 / 10406011) - Page 4 ADP-3355 User’s Manual 1. <Product Specification> Mechanical & Environmental Controller PTN3355 Accessories 1 x OALDP2T-L12 11-pin Cable (connect ADP-3355 to Motherboard) Dimensions (L x W ) 30.8mm x 25.3mm Temperature Operating within 0~60 centigrade Relative Humidity 10%~90%, non-condensing ADP-3355:DisplayPort to VGA Adapter with IO bracket (include cable)
- Page 5 ADP-3355 User’s Manual 3. < Install ADP3355 > 1. Find the CN_DP above HDMI connector CN_DP HDMI 2. Connect ADP3355 to CN_DP CN_BDP CN_DP ADP-3355 VGA Convert Module don’t need diver, and only support COMMELL’s motherboard like LV-67ST…...
- Page 6 Taiwan Commate Computer Inc. 19F., No.94, Sec. 1, Xintai 5th Rd., Xizhi Dist., New Taipei Address City 22102, Taiwan +886-2-26963909 +886-2-26963911 Website http://www.commell.com.tw E-Mail info@commell.com.tw (General Information) tech@commell.com.tw (Technical Support) Commell is a brand name of Taiwan commate computer Inc.
