The lightning flash with an arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of uninsulated
dangerous voltage within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
INFORMATION - This equipment has been tested and found to comply with
limits for a Class A digital device, pursuant to part 15 of the FCC Rules & CE Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
WARNING - Changes or modifications not expressly approved by the manufacturer
could void the user's authority to operate the equipment.
CAUTION : To prevent electric shock and risk of fire hazards:
◆ Do NOT use power sources other than those specified.
This installation should be made by a qualified service person and
should conform to all local codes.
1
Ultra High Resolution Digital Day/Night Vandal Resistant Dome Camera
Advertisement
Table of Contents
Related Manuals for Genie CCTV AVRCD-6351
Summary of Contents for Genie CCTV AVRCD-6351
- Page 1 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
-
Page 2: Table Of Contents
■ Contents Features Menu Flow ■ Setup Page Menu Warnings and Precautions ㆍ LENS ㆍ EXPOSURE Components ㆍ White Balance (White Bal.) ㆍ SSDR (Super Dynamic Range) ㆍ BACKLIGHT Names and Functions of Parts ㆍ DNR3 (Super Noise Reduction) ■ LENS ㆍ... -
Page 3: Features
■ Features Warning ■ Ultra High Resolution SSDR (Super Dynamic Range) The camera requires periodic inspection. By adopting a diagonal 6mm(1/3") 410,000 For images with high contrast between bright Contact an authorised technician to carry out the inspection. (NTSC) pixel, 470,000(PAL) pixel SONY CCD, and dark spots from difficult lighting conditions the camera produces clear picture quality with a such as backlighting, this camera selectively... - Page 4 ■ Precautions Do not drop the camera and protect Never keep the camera pointed Do not install the camera in Do not install or use the camera in an it from physical shocks. directly at strong light. extreme temperature conditions. environment where the humidity is high.
-
Page 5: Components
■ Components Names and Functions of Parts ■ 1. COLOUR DOME CAMERA ① ② 2. SCREWS 3. WRENCH ③ 4. WIRE FOR VBS-EXTRA ④ 5. INSTRUCTION GUIDE Ultra High Resolution Digital Day/Night Vandal Resistant Dome Camera Ultra High Resolution Digital Day/Night Vandal Resistant Dome Camera... -
Page 6: Names And Functions Of Parts
■ Names and Functions of Parts Names and Functions of Parts ■ LENS : Vari-Focal DC Auto Iris Lens ① 3 AXIS BRACKET ③ Please loosen screws and fix tilted and panned position. VBS-EXTRA FOR CONNECTING TO LCD ④ Please use the supplied wire when connecting to a Monitor. VBS-EXTRA OSD PCB ②... -
Page 7: Installation
■ Installation 1. Dome Base Mounting - Open the dome cover by loosening 3 screws using special wrench provided. Surface Mount bracket - Mount the base of camera to a sturdy surface using 4 screws (1.5 inch) and 4 premade holes on the base of the dome. 2. -
Page 8: Setup Page Menu
■ How to Use the Camera ■ Menu ■ Settings Settings can be made using the 5 buttons located in the camera. SETUP menu LENS (selection) ㆍDC ㆍBRIGHTNESS ㆍSHUTTER ㆍAGC EXPOSURE ㆍSENS-UP ㆍRETURN ㆍATW ㆍOUTDOOR ㆍINDOOR WHITE BALANCE ㆍMANUAL ㆍAWC→SET SSDR ㆍOFF ㆍON... - Page 9 ■ How to Use the Camera MAIN MENU ● DC : Select Auto Iris Lens Select the function using Change the status using 1.LENS You can adjust the minimum shutter and maximum value of ESC the UP or DOWN button. the LEFT or RIGHT button.
-
Page 10: ㆍ White Balance (White Bal.)
■ How to Use the Camera Note EXPOSURE SETUP • If you press the SET button in 'AUTO' mode, You can adjust brightness 1.BRIGHTNESS by increasing or decreasing the shutter speed. (X2~X512) 2.SHUTTER MANUAL • Note that the higher the zoom level, the brighter the screen, but the 3.AGC HIGH more likely it is that an after-image will appear. -
Page 11: ㆍ Ssdr (Super Dynamic Range)
■ How to Use the Camera BACKLIGHT Note • White Balance may not work properly under the following conditions. This camera is designed so that it delivers a distinctive subject and In this case select the AWC mode. background at the same time, even when the subject is in backlight, unlike conventional cameras, by adopting a proprietary W-V DSP chip. - Page 12 ■ How to Use the Camera HLC MASKING AREA MAIN MENU 1.LENS 2.EXPOSURE 3.WHITE BAL 4.SSDR 5.BACKLIGHT 6.DNR3 HLC ON HLC OFF 7.DAY/NIGHT AUTO ● OFF : Not being used 2. Select a desired mode using the Left and Right buttons. 3.
-
Page 13: Monitor
■ How to Use the Camera 2. Select a desired mode using the Left and Right buttons according to the 2. Select a desired mode using the Up and Down buttons. picture display you want. ● COLOUR : The picture is always displayed in colour. SPECIAL ●... - Page 14 ■ How to Use the Camera CAMERA TITLE SETUP 4) Use the 4 direction buttons to move Note to a desired letter and select the letter • As the DIS function uses the digital zoom the camera's resolution will by pressing the SET button. Repeat decrease.
-
Page 15: Return
■ How to Use the Camera ● MOTION DET : 1) When the SPECIAL menu screen is displayed, press the Up and Down buttons so that the arrow indicates 'PRIVACY'. This product has a feature that allows you to observe movement of objects in 8 different 2) Set up the mode using the 4 direction buttons. -
Page 16: Troubleshooting
■ How to Use the Camera Troubleshooting ■ If you have trouble operating your camera, refer to the following table. ● LANGUAGE : You can select the menu language according to your If the guidelines do not enable you to solve the problem, contact an requirements. -
Page 17: Specifications
■ Troubleshooting Specifications ■ Problem Solution ITEM NTSC AC24V / DC12V DC12V AC24V / DC12V DC12V The Motion Detection • Check that MOTION DET in the SPECIAL SETUP Power Consumption 170mA(AC24V)/250mA(DC12V) 160mA 170mA(AC24V)/250mA(DC12V) 160mA function does not is not set to 'OFF'. Image Sensor work. - Page 18 ■ MEMO...
-
Page 19: Dome Camera
Model : AVRCD-6351 AVRCD-6351DV Ultra High Resolution Digital Day/Night Vandal Resistant Dome Camera Instruction Guide GENIE CCTV LTD. CCTV House, City Park, Watchmead, Welwyn Garden City, Hertfordshire, AL7 ILT Tel : +44 (0) 1707 330541 Fax : +44 (0) 1707 330543 www.geniecctv.com...
