Technical Specification - SolidRF M5U01 Manual

Cautions & Spec.
Note1
: Some of the 12V DC lighter power sources
will not shut down when the vehicle is turned off.
Please switch off the adapter when you leave the
car, in case the battery of the vehicle is used up.
Note2
: Don't cover the booster body with anythi-
ng, in case the power dissipation make the booster
too high temperature. Booster will shut down wh-
en the temperature is too high itself.
Note3
: Use only the power supply provided by So-
lidRF, any other products non-approved by SolidRF
or self-made power cable may damage the booster.
Frequency
Uplink
(MHz)
Downlink
Gain Uplink
Downlink
Output power 26±2dBm(Uplink)/0±2dBm(Downlink)
Noise figure <5dB
In-band Flatness <8dB
Weight 0.7Kg
VSWR
≦2.0
Gain adjustment 20dB
Impedance 50 ohm
Operating temperature -5°~60°
Current ≦1.5A(6V DC)
Dimension(mm) 155*125*25
RF Exposure: The manufacturer's rated output power of this equipment is for single carrier operation. For si
tuations when multiple carrier signals are present, the rating would have to be reduced by 3.5 dB, especially
where the output is reradiated and can cause interference to adjacent band users. This power reduction is t
o be by means of input power or gain reduction and not by an attenuating at the output of the device.

Technical specification

LTE (band 12) LTE (band 13)
698-716 776-787
728-746 746-757
45±2 45±2
48±2 48±2
www.SolidRFCanada.com
Note4: Troubleshooting
• Properly: The lights on the front panel indicate
the condition of the booster. Every time the bo-
oster is powered on, all of the lights will be light
on in green color for around 2 seconds and then
lights off, this means the booster pass the self
check and in good condition;
• Wrong condition: If any of the lights flashing in
green light, than means the isolation between
the outside antenna and inside antenna is lower
than it should be, and self oscillate occurred.
You must switch off the booster and check the
outside antenna and inside antenna immediately.
Make sure you have followed this installation re-
commended, and check every thing carefully. If
you can't fix the problem please contact the te-
chnician or our distributor.
Cellular ( band5) PCS (band 25/2)
824-849 1850-1910
869-894 1930-1990
45±2 47±2
48±2 50±2
2
AWS (band 4)
1710-1755
2110-2155
47±2
50±2
4
