Freestanding electric cooker
Dear Customer!
Congratulations on your purchase. See for yourself: our
products read reliability.
These ample instructions have been compiled in order to help
you learn how to handle the appliance. They will show you step
by step what your appliance is capable of, so please read them
carefully before you attempt to use your cooker for the first
time.
Contents
Safety precautions ........................................................ 39
Description of the appliance ........................................ 40
Prior first use ................................................................ 41
Alarm timer
Hotplates ....................................................................... 42
Hotplates
Oven............................................................................... 43
Safety precautions
• To avoid any possible hazard, the appliance may be installed by
qualified personnel only.
• Any repairs by unqualified persons may result in electric shock or
short circuit. In order to avoid possible injuries to your body or to the
appliance, do not attempt any repairs by yourself. Such work
should be carried out by qualified service personnel.
• Hot grease is highly inflammable, so pay extra attention when
preparing food with grease or oil. Frying may be carried out only
under constant surveillance.
• Warning! Never let small children in the vicinity of the cooker; they
are not yet aware of danger of burns. Older children may use the
appliance only under your surveillance.
• Surface of hotplates may become very hot during operation. The
inside of the oven, hotplates and steam exits are also places of
potential danger for children.
• Danger of burns! Hotplates, oven and cooking accessories may
become very hot during operation. To avoid burns use kitchen
clothes and gloves when handling hot parts or utensils.
• Mains lead of adjacent appliances may be damaged by hotplates
or if stuck between the oven doors, and produce short circuit,
therefore keep them at safe distance from the appliance.
• Never clean the oven with the high-pressure steam cleaning
device, as it may provoke short circuit.
• Oven door may become very hot during operation. Therefore,
some models are equipped with the third glass to reduce the
surface heat of the glass, as an extra protection against burns.
• Do not keep any flammable material in the drawer under the oven
(paper, wiping cloth, plastic bags, cleaning agents or sprays, etc.),
as they might cause fire. Use the drawer to keep only the oven
utensils (flat baking pan, oil collector, oil filter, etc.).
Safety warnings are listed on page 40.
The first thing to do is to check if your appliance has arrived
undamaged. In case you find any transport damages, please
report it immediately to your local dealer, or to the regional
warehouse which supplied the appliance. You will find their
phone numbers on the invoice or on the delivery note.
We hope your cooker will successfully serve its purpose for
many years.
Cleaning and maintenance ...........................................50
Glass ceramic hob
Oven
Troubleshooting guide ..................................................52
Replacement of parts ....................................................53
Instructions for installation and connection ...............53
Technical information...................................................54
Technical information...................................................55
After sale service ...........................................................55
• If you discover any visible cracks upon the glass ceramic surface,
you may not use the hob anymore, because there is an electric
shock hazard. In such cases switch all the hotplates off and
unscrew the fuse or switch off the main switch to disconnect the
appliance completely from the mains. Call the nearest service
center.
• The appliance must be placed directly on the floor, without any
supports.
• The appliance is manufactured in compliance with the relevant
effective safety standards. Nevertheless, we strongly recommend
that persons with impaired physical, motoric, or mental capacity, or
persons with inadequate experience or knowledge, do not use the
appliance unless attended by a qualified person. The same
recommendation applies when the appliance is used by persons of
less-than-legal age.
electrical and electronic equipment. By ensuring this
product is disposed of correctly, you will help prevent
potential negative consequences for the environment and
human health, which could otherwise be caused by
inappropriate waste handling of thisproduct. For more
detailed information about recycling of this product,
please contact your local city office, your household waste
disposal service or the shop where you purchased the
product.
Instructions for use, installation and connection
The symbol on the product or on its packaging
indicates that this product may not be treated as
household waste. Instead it shall be handed over to
the applicable collection point for the recycling of
GB IE MT
39
