Summary of Contents for Gorenje E 52108 A
- Page 3 Dear customer. Thank you for buying one of our latest series of Gorenje cookers. We wish that our product would do you a good turn. We recommend you to study these instructions and to operate this product according to instructions.
-
Page 4: Cooker Operation
CONTROL ELEMENTS OF THE COOKER Control knob of the left front hotplate Control knob of the left rear hotplate Control knob of the right rear hotplate Control knob of the right front hotplate Oven thermostat knob Oven function knob Thermostat function signal lamp “Power ON”... - Page 5 RAPIDE HOT PLATES First they are used for quick cooking and roasting. OVEN OVEN INSIDE Oven with embossed side walls with three slots for shelf position. There are in the oven top and grilling element at the seling of cavity, bottom heating element is hidden under bottom. OVEN SWITCHING ON AND OFF Select the desired function of the oven by the oven function knob.
- Page 6 Oven illumination being on in setting up all the oven functions Grilling by infrared radiation. The temperature selector is set to the maximum position. Oven is heat by top and bottom heating element. The thermostat can be set to a temperature within 50 °C - 250 °C. Oven is heat only by bottom heating lelment.
- Page 7 NEVER ALLOW YOUNG CHILDREN NEAR THE APPLIANCE WHEN THE GRILL IS IN USE AS THE SURFACES GET EXTREMELY HOT. DO NOT LINE THE GRILL PAN WITH ALUMINIUM FOIL. CLEANING AND MAINTENANCE OF THE COOKER Keep to the following principles while cleaning or maintaining the cooker: Set all knobs in off position.
- Page 8 INSERTING OF GRID IN THE OVEN...
-
Page 9: Electrical Connection
CLAIM If there is any defect on the cooker within the period of warranty, do not repair it by yourself. Make a claim at a shop in which you bought the cooker or at service representatives. METHODS OF UTILISATION AND LIQUIDATION OF PACKAGES Collection of packages at collecting places in your locality guarantees their recycling. -
Page 10: Important Notice
INSTALLATION OF AN ELECTRIC COOKER CONNECTION Using a screwdriver open the connector cover at the rear of the appliance. The cover is released by releasing the two locks located at either side of the connector bottom. Pass the supply cable through the cable clamp and connect to the appropriate terminals shown in the diagram below. Ensure all terminal screws are tight. Tighten the screws on the cable clamp and replace the cover. -
Page 11: Levelling The Cooker
LOCATION OF THE COOKER The appliance is designed for location in the kitchen line. The cooker can be set in the normal areas. The cooker can from the point of view of thermal resistance be positioned on any floor (support plate). The cooker can be fit between cupboards with a thermal resistance of 100 °C or they must be covered with a heat-insulating material. The cooker must not be located on a pedestal. -
Page 12: Installation
INSTALLATION: The stabilizing agent against overturning appliances - console - is as shown attached to the wall using dowels and screws. Subsequently, the appliance is placed against the wall so that the attached bracket inserted into the hole in the rear wall. Installation procedure: ... - Page 13 FICHE, REGULATION (EU) NO 65/2014 AND PRODUCT INFORMATION REGULATION (EU) NO 66/2014 Symbol Unit Value Supplier’s name or trade mark GORENJE Model identification E52108 Energy Efficiency Index per cavity 119,1 cavity Energy efficiency class 0,92 Energy consumption during a cycle in conventional mode...
-
Page 14: Technical Data
TECHNICAL DATA ELECTRIC COOKER E52108AW E52108GW Dimensions Height / Depth / Weight (mm) 900 / 500 / 605 Cooking plate Electric hot plates Left rear Ø 145 mm (kW) Left front Ø 180 mm (kW) Right rear Ø 180 mm (rapid) (kW) Right front Ø...
